Image preview - the first page of the document
Service Bulletin OST-C1102


>> Download Service Bulletin OST-C1102 documenatation <<

Text preview - extract from the document
                                  100 Corporate Drive Mahwah, NJ 07430



                                                                                       Service Bulletin
                                         No. : OST-C1102
                                         Date: March 14, 2007
_____________________________________________________________

Model:               AVR-2307CI, AVR-2307, AVR-887


Subject:             Countermeasure for the AUTO SETUP Phase symptom.


Symptom: Upon execution of the AUTO SETUP the unit indicates the Phase
Error message "-Caution- phase" (all channels) even though the speakers have
been connected properly.


Solution: If the above complaint was reported from your customer, please
explain to your customer the "Cause" and "Measure" of Instruction manual
page13. Check the polarity of the pertinent speakers. For some speakers, this
screen may be displayed even though the speakers are properly connected. If
so, please select "Skip < " on the OSD screen from which the error message has
been indicated and proceed to the next step." Instruction manual page13:




______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
