AVR-3808CI BKEU and EC, AVR-3808 BKE2, SRE2, SPE2A and SPEUT,
AVC-3808 E1C
AVR-4308CI BKEU and BKEC, AVR-4308 BKE2 and SRE2, AVR-4308 SPE2A


1U-3799 DIGITAL P.W.B. UNIT/ COMPONENT SIDE




      2) Delete the Capacitor
      "CC969 (330pF)".




          1) Replace the Resistor "100
          k ohms" with "10k ohms" for
          "RR956"
