AVR-5308CI BKEU


1U-3833 DIGITAL P.W.B. UNIT/ COMPONENT SIDE
                       1) Replace the Resistor "220
                       ohms" with "0 ohms" for
                       "RE494"


                       3) Delete the Capacitor
                       "C451 (330pF)".




                       2) Replace the Resistor "100
                       k ohms" with "10k ohms" for
                       "R451"
