Service Bulletin OST-C1262


>> Download Service Bulletin OST-C1262 documenatation <<

Text preview - extract from the document
                                  100 Corporate Drive Mahwah, NJ 07430



                                                                                       Service Bulletin
                                         No. : OST-C1262
                                         Date: March 11, 2008
_____________________________________________________________

Model:               AVR-1508, AVR-588, AVR-488, AVR-1708, AVR-688, AVR-1908,
and AVR-788

Subject:             Countermeasure for improving a malfunction.


Symptom: SUB TRANS (SUB501) was not properly fixed during the
manufacturing process. This may result in cracks in the PCB.


Solution: Add bond (SONY Bond SC608Z2) to the SUB TRANS (SUB501) to
secure it to the PCB.




______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
Parts:
SONY Bond SC608Z2.

http://www.sonycid.jp/en/products/mc4/sc608.html

Serial Number Range:
The above modification has been applied to production models beginning from
the following serial numbers.  (Last 5-digits)

AVR-1508             20519 ~
AVR-588              24408 ~
AVR-488              08711 ~
AVR-1708             17840 ~
AVR-688              11908 ~
AVR-1908             18038 ~
AVR-788              12906 ~
