Image preview - the first page of the document
Схема 2 AVR-1908


>> Download Схема 2 AVR-1908 documenatation <<

Text preview - extract from the document
AVR-1908 BKE3, AVR-1908 BKE2 and SRE2, AVR-1908 SPE2A,
AVR-1908 SPE1C, AVR-1908 SPEUT,
AVR-788 BKE3

HDMI P.W.B. UNIT / FOIL SIDE




      2) Delete the
      Capacitor"C1367 (330pF)".




                                                    3) Replace the Transistor
                                                    "KTC2875B" with
                                                    "2SD2114K" for Q1037.



      1) Replace the Resistor "100
      k ohms" with "10k ohms" for
      "R1343"
