Image preview - the first page of the document



>> Download Схема AVR-3801 documenatation <<

Text preview - extract from the document

                                                                             Hi-Fi Component




                     SERVICE MANUAL
     MODEL                      AVR-3801
                     AV SURROUND RECEIVER




Some illustrations using in this service manual are slightly different from the actual set.
AVR-3801




       SAFETY PRECAUTIONS
       The following check should be performed for the continued protection of the customer and service technician.

       LEAKAGE CURRENT CHECK
       Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
       resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
       power cord is less than 460 kohms, the unit is defective.

    SPECIFICATIONS
    ! AUDIO SECTION
      " Power Amplifier
         Rated output:                                 Front:           105W + 105W (8/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
                                                                        150W + 150W (6/ohms, 1kHz with 0.7% T.H.D.)
                                                                        180W + 180W (6/ohms, EIAJ)
                                                       Center:          105W (8/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
                                                                        150W (6/ohms, 1kHz with 0.7% T.H.D.)
                                                                        180W + 180W (6/ohms, EIAJ)
                                                       Surround:        105W + 105W (8/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
                                                                        150W + 150W (6/ohms, 1kHz with 0.7% T.H.D.)
                                                                        180W + 180W (6/ohms, EIAJ)
                                                       Surround Back: 105W + 105W (8/ohms, 20 Hz ~ 20kHz with 0.05% T.H.D.)
                                                                        150W + 150W (6/ohms, 1kHz with 0.7% T.H.D.)
                                                                        180W + 180W (6/ohms, EIAJ)
         Dynamic power:                                140W
