Image preview - the first page of the document



>> Download Service Bulletin DZ09-250 documenatation <<

Text preview - extract from the document

                                  100 Corporate Drive Mahwah, NJ 07430



                                                                                       Service Bulletin
                                         No. : DZ09-250
                                         Date: December 14, 2009
_____________________________________________________________

Model:               AVR-3310CI, AVR-990, AVR-4310CI, AVR-4810CI


Subject:   Exchange of the AC inlet.
Countermeasure is applicable only upon claim from the customer.

Symptom: No power. (D.O.A.)
Reason: The Parts Vendor Company mixed a few unstable AC Inlets into
production.

Solution: Replace the AC Inlet when the above symptom occurs and is
claimed by the customer.
MODIFICATION: If you receive a claim from the customer, please replace the
AC Inlet with new one.




Parts:

    Ref#                        Description                                  Part Number
   JK802                          AC inlet                                  00D2033958004

______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
Serial Number Range:
Please apply the above modification to the production models in the following
serial numbers.

AVR-4810CI                      9**1500022 ~ 9**1500717
AVR-4310CI                      9**1503679 ~ 9**1505489
AVR-3310CI                      No Need to Modify
AVR-990                         No Need to Modify




______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
The information contained in this document is intended for the exclusive use by DENON Authorized Service Centers and their
employees. This document may contain information that is privileged, confidential and may be protected from disclosure under
applicable laws and terms of the DENON Service Agreement. Any distribution, disclosure, dissemination or copying of this
document and the information it contains is prohibited. No responsibility will be accepted by DENON for any damage, injury or loss
resulting from the misuse of the information contained in this document.
