Image preview - the first page of the document



>> Download Схема DVM-4800 documenatation <<

Text preview - extract from the document

                                                                 For U.S.A. & Canada model


                                                                                  Digital Player




                     SERVICE MANUAL
     MODEL                      DVM-4800
                  DVD VIDEO AUTO CHANGER




Some illustrations using in this service manual are slightly different from the actual set.




                14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011 JAPAN
                                  Telephone: 03 (3584) 8111

                                                                                      X0124 205 NC 0110
                                                                                                                DVM-4800



SPECIFICATIONS
   Signal system:             NTSC
   Applicable discs:          (1) DVD-video/audio discs
                                  1-layer 12 cm single-sided discs, 2-layer 12 cm single-sided discs,
                                  2-layer 12 cm double-sided discs (1 layer per side)
                                  1-layer 8 cm single-sided discs, 2-layer 8 cm single-sided discs,
                                  2-layer 8 cm double-sided discs (1 layer per side)
                              (2) Compact discs (CD-DA, Video CD)
                                  12 cm discs, 8 cm discs
   S-Video output:            Y output level:    1 Vp-p (75 /ohms)              C output level: 0.286 Vp-p
                              Output connectors: S connectors, two sets
   Video output:              Output level:       1 Vp-p (75 W/ohms)            Output connector: Pin-plug jacks, two sets
   Component output:          Y output level:     1 Vp-p (75 /ohms)
                              CB/CR output level: 0.650 Vp-p (75 /ohms)         PB/PR output level: 0.700 Vp-p (75 /ohms)
                              Output connector: Pin jack, 1 set
   Audio output:              Fixed output level: 2 Vrms (1 kHz, 0 dB)
   Number of connectors:      1 set (2 ch mixed output)
                              1 set (6 ch discrete output)
   Audio output properties:   (1) Frequency response
