Image preview - the first page of the document
>> Download Схема PMA-SA1 documenatation <<
Text preview - extract from the document
PMA-SA1
SCHEMATIC DIAGRAMS (1/2)
1 2 3 4 5 6 7 8 9 10 11
A
B
C
D
E
F
G
SCHEMATIC DIAGRAMS (1/2)
1U-3659-1 POWER AMP L UNIT
1U-3659-2 POWER AMP R UNIT
1U-3659-3 MULTIPLYER L UNIT
1U-3659-4 MULTIPLYER R UNIT
1U-3659-5 POWER AMP C UNIT H
SIGNAL LINE
1U-3660-2 BALANCE VOLUME UNIT
1U-3660-6 MAIN VOL UNIT
32
PMA-SA1
SCHEMATIC DIAGRAMS (2/2)
1 2 3 4 5 6 7 8 9 10 11
A
B
C
D
E
F
G
SCHEMATIC DIAGRAMS (2/2)
1U-3658-1 EQ/INPUT UNIT 1U-3659-6 POWER SW UNIT
1U-3658-2 CONT./P.SUPPLY UNIT 1U-3659-7 EQ POWER SW UNIT
1U-3658-3 PHONO INPUT UNIT 1U-3659-8 BALANCE INPUT SW UNIT
1U-3658-4 REC SEL. SW UNIT 1U-3660-1 FUNCTION SW UNIT
1U-3658-5 REC OUT UNIT 1U-3660-3 BALANCED INPUT UNIT H
SIGNAL LINE 1U-3658-6 LED UNIT 1U-3660-4 DIODE UNIT
1U-3660-5 TERMINAL UNIT
