Image preview - the first page of the document
>> Download Схема D-A03 documenatation <<
Text preview - extract from the document
For Hong Kong,
U.S.A. and Canada model
Hi-Fi Personal Audio System
SERVICE MANUAL
MODEL D-A03
PERSONAL AUDIO SYSTEM
VERTICAL LOADING SYSTEM VERTICAL LOADING SYSTEM
COMPACT DISC PLAYER COMPACT DISC PLAYER
POWER POWER
CD CD
PERSONAL AUDIO SYSTEM/CD-MD RECEIVER FM/AM SDB
D-A03
MD
AUX FM/AM AUX EQ
MENU TUNING
VOLUME VOLUME
TUNING/ TUNING/
PRESET PRESET
SLEEP TIMER OFF TOTAL
RANDOM INTOR SCAN ROCK POP JAZZ DANCE FLATT
N.SPEED HI.SPEED SDB
REC REC MODE EQ
TOC/NAME
ENTER CLEAR
DISPLAY
power loading mechanism
PERSONAL AUDIO SYSTEM / CD STEREO RECEIVER
TIMER/DELETE
40-STATION PRESET MEMORY
PLAY MODE 6-MODE PRESET EQUALIZER
PHONES PHONES
PROG.
REMOTE REMOTE
SENSOR SENSOR
REMOTE CONTROL UNIT REMOTE CONTROL UNIT
Hong Kong model U.S.A. and Canada model
G Some illustrations using in this service manual are slightly different from the actual set.
14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011 JAPAN
Telephone: 03 (3584) 8111
X0130 337 NC 0112
D-A03
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
SPECIFICATIONS (There is no MD Section in the U.S.A. and Canada model)
Amplifier Section
Practical maximum output: Front speaker 11W (5.5W + 5.5W EIAJ)
Audio input/output jacks: MONO output terminal, AUX input terminal, 3.5mm headphone jack
Tuner Section
Receive frequency bands: FM: 87.50MHz to 108.00MHz
AM: 520kHz to 1710kHz (U.S.A. and Canada model)
522kHz to 1611kHz (Hong Kong model)
Receive sensitivity: FM: 1.5◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
