Image preview - the first page of the document
>> Download Описание D-G1 documenatation <<
Text preview - extract from the document
NEW MODEL INFORMATION
D-G1
Micro Component System
Transparent Elegance
An air of elegance surrounds the D-G1 mini Hi-Fi system and quietly pervades the room. A new concept in personal Hi-Fi
design has come into the world, bringing delight to music lovers everywhere. Even though the D-G1 contains all the functions of
the receiver, the CD player, and the cassette deck within a single unit, it is only 180 mm wide, 259 mm high, and 287 mm deep.
You can set up the D-G1 just about anywhere you like. There is a remarkable sense of transparency about the D-G1 that lets it
blend in well with virtually any interior, and it is small enough to fit onto a bookshelf, bay windowsill, or other inconspicuous spot.
Another remarkable aspect of the D-G1 is the rich sound that fills your room from such a modest-looking unit. Then there is the
D-G1's remarkable ease of use. The D-G1 just gives you the functions you really need. With beautiful sound, elegant design, and
simple operation, the D-G1 is the perfect companion for a lifestyle that persistently beckons you to enjoy a few moments of peace.
s DENON's Famous High-Quality Sound s Large, Easy-to-Read Display
Despite the D-G1's unassuming appearance, it boasts high The characters on the D-G1's large display are clear and
output power of 20 W + 20 W, capable of reproducing all gen- easy to read. The function buttons on the front panel, too, are
res of music with a rich sound that effortlessly fills your listen- large and glow in the dark for quick, easy operation at any
ing space. time.
s 4-mode Graphic Equalizer for Custom Sound s Auto Power Off
Refinement In a function mode other than the tuner, if there has been
You can choose any of four sound spaces-Rock, Pops, no operation for approximately 30 minutes, the system will
Classical, and Flat-to enjoy the type of music you want to automatically turn itself off to reduce power consumption.
hear.
s Convenient CD Editing Functions
s Versatile Timers Playback functions include Random Play, 20-track
The D-G1 provides a REC timer that activates the recording Programmed Play.
function when the power switch is turned on, and a Sleep timer
that turns the unit off every night (or any other time) in 10- s CD-Synchro Recording System
minute increments from 10 to 60 minutes after you turn it on.
s Full Logic Auto Reverse Mechanism, for Automatic
s Bass Control, for a Powerful Bass Foundation Playback of the Reverse Side of a Tape
The D-G1 includes a Bass Control function that enriches
the deep bass sound, further defying the modest size of the s Dolby Noise Reduction, for Improved Sound Quality
speakers. You can enjoy this reinforced bass foundation even during Recording and Playback
at relatively low volume levels. The D-G1 is equipped with a Dolby B noise reduction cir-
cuit to reduce tape noise and enhance the realism of the
sound over the full spectrum from large to small signals.
Speaker Section
s Pearl Mica Woofer Cones, for Superior Response
Characteristics
The D-G1's speakers feature soft dome tweeters and
woofers with pearl mica cones that are highly responsive to
sound vibrations. The combination of the two produces a
clear, lively sound, rich with musical details.
s High Quality Sound, Tuned by UK
s Anti-magnetic Design
Specifications
s Power Amplifier Section
Rated output power ................. 20 W + 20 W (6 ohms)
Analog Input Terminal.............. 1
Digital Output Terminal ............ 1
s FM Section
Frequency range...................... 87.50 - 108.00 MHz
s AM Section
Frequency range...................... 530 - 1720 MHz
s CD Player Section
Type......................................... Single CD Player
Programming ........................... 20 tracks
s Cassette Deck Section
Type......................................... 4-track, 2-channel
Head
Record and Playback .......... Record x 1, Playback x 1
Erase ................................... Erase x 1
Dolby NR ................................. B
s General
Power source........................... 120 V, 60 Hz, 70 W
Dimensions, Weight................. 180 (W) x 259 (H) x 287 (D) mm, 6.3 kg
7.1" (W) x 10.2" (H) x 11.3" (D), 13.9 lbs
s Speaker Section
Type......................................... 2-way
Speaker
Woofer ................................. 14 cm
Tweeter................................ 2 cm
Maximum input power.............. 50 W
Anti-magnetic design ............... provided
Dimensions, Weight (each)...... 150 (W) x 259 (H) x 212 (D) mm, 2.3 kg
5.9" (W) x 10.2" (H) x 8.3" (D), 5.1 lbs
*Design and specifications are subject to change without notice.
DENON ELECTRONICS. NIPPON COLUMBIA CO., LTD.
DIVISION OF DENON CORPORATION (USA) 14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011, JAPAN
222 NEW ROAD, PARSIPPANY, NEW JERSEY 07054, USA Denon Home Page Address: http://www.denon.co.jp
TEL: 973-396-0810 www.del.denon.com
DENON CANADA INC.
17 DENISON STREET, MARKHAM ONTARIO, CANADA L3R 1B5
TEL: 905-475-4085
11770699 A Printed in Japan
