0128741601
DE'LONGHI "INT/RU/TR" VVX1420
1
3
2
4 5
6
7
8
23
22
21
9
10 24
25
19
26
11
12 14
13 12 18
17
32
33
35
15
16
DE'LONGHI INT/RU/TR VVX1420 0128741601
Pos. Spare part code Description
01 5512810411 STOPPER
02 5312811051 O-RING
03 5312811011 RUBBER PAD
04 5312811021 RUBBER PAD
05 5312811031 STOP
06 7012810011 SUPPORT
07 5912811041 BODY UPPER
08 5312811191 GASKET
09 5312811111 SUPPORT
10 6812810221 BOILER
11 5212810261 THERMOSTAT 165◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
