DE'LONGHI INT/A/RU/SKA EC710 EX:C 0132154014
Pos. Spare part code Description
001 7332174100 COVER
003 5332153100 TUBE RETAINER
005 533544 WIRE CLAMP
006 7132102200 BODY
007 534629 STOPPER
008 534628 BALL
009 5532126000 TANK
010 532233 RUBBER PAD
011 5532126400 BOTTOM
013 5313210661 TRAY
014 536196 SUPPORT
015 6032105600 CUP PLATE
016 5332153900 COVER DX
017 5332154000 COVER SX
018 534801 PRESSING DEVICE
020 5332159900 COVER
022 5332107900 MEASURING SPOON
024 6032107300 FILTER
025 7332173700 Small one-cup or pod filter
026 534714 LEVER
027 7313279579 SUMP
028 5332123100 RING NUT
029 6032107200 FILTER
030 7332173800 Large two-cup filter
031 552413 TAP
032 602650 RING
