DE'LONGHI INT/A EO3835.A 0118484506
Pos. Spare part code Description
5118109000 LAMP PHP T22(E14)240-250V 15W EO12
01 7018127400 FRAME
02 5318142400 HANDLE
03 7018108500 BRACKET
04 5318119800 RUBBER PAD
05 5918144400 THERMOSTAT KNOB
06 5318140300 GLASS
07 6118101100 ROD
08 7118106800 SUPPORT
09 5918144500 TIMER KNOB
10 5918145400 Change Over Switch KNOB
11 611900 SPRING
14 5918145600 CONTROL PANEL
15 6118102700 ROD
16 5518115800 BRACKET
17 5118116200 Heating Element Low
18 5118115000 GEARMOTOR
19 6118101800 SUPPORT
20 7018123000 DRIP PAN
21 6118102900 GRID
22 7018122900 PLATE
25 532233 RUBBER PAD
26 5318143200 FOOT
30 5318132700 LAMP HOLDER
31 5118115600 Heating Element Up
32 5218106600 Change Over Switch
33 5211810081 TIMER
34 5118110300 WIRING LAMP
- Pag. 1/2 -
DE'LONGHI INT/A EO3835.A 0118484506
Pos. Spare part code Description
35 5318139700 RED LENS
37 5318123800 EXTENSION
38 5318141900 GEAR
39 521073 THERMOSTAT
40 5318127400 BLOCK
41 7018108400 LEVER
42 6118103000 SPRING
43 7018109400 HOUSING
44 5218104800 FUSE
Spare parts list extract from the site on 16-08-2010
- Pag. 2/2 -
