DE'LONGHI "INT" VVX320 (G)
BIANCO - WHITE
13
14
12
11
08 09
10
58
07
06 56
05 54
03 15
04 55
57
02
30
26
24
52
51
27
01
50
41
32 48
33 47
40 46
45
19 12
44
49
42
39
DE'LONGHI INT VVX320 0128711504
Pos. Spare part code Description
01 7328148700 IRON
02 5328132700 CONNECTION L
03 5928126600 BODY
04 5328503500 TUBE
05 5328132600 CONNECTION
06 5328134200 SUPPORT
07 5328133200 STOP
08 5528108200 KNOB
09 5128105900 MICROSWITCH
10 5328134000 LEVER
11 5328148500 COVER
12 5528104000 CABLE
13 5328133700 CABLE GROMMET
14 5928126300 COVER
15 5928130100 COVER
19 5312810001 CONNECTION
24 5328141800 TEMPLATE
26 5128105400 LAMP
27 5328141900 PUSH BUTTON
30 5128106800 SWITCH
32 9811861646 SCREW
33 9816100626 NUT
39 5028101900 POWER SUPPLY CORD
40 5228105200 SOLENOID VALVE
41 5328163000 GASKET
42 5328128900 BODY LOWER
44 5328500600 TUBE
45 6828100400 BOILER LOWER
- Pag. 1/2 -
DE'LONGHI INT VVX320 0128711504
Pos. Spare part code Description
46 5228105100 THERMOSTAT 180◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
