Image preview - the first page of the document
Disney_DVD_Player_and_VCR_DVD2100-C_Parts_and_Service_Manual


>> Download Disney_DVD_Player_and_VCR_DVD2100-C_Parts_and_Service_Manual documenatation <<

Text preview - extract from the document
                                                                              CLASS 1
                                                                              LASER PRODUCT




DVD2100-C
SERVICE MANUAL
DVD VIDEO PLAYER & VHS VIDEO CASSETTE RECORDER




                            ORIGINAL
                          MFR'S VERSION A




            Design and specifications are subject to change without notice.
                                 IMPORTANT WARNING
CAUTION:
DVD PLAYER IS A CLASS 1 LASER PRODUCT. HOWEVER THIS PLAYER USES A VISIBLE LASER
BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO
OPERATE THE PLAYER CORRECTLY AS INSTRUCTED.

THE FOLLOWING CAUTION LABEL IS LOCATED ON THE REAR PANEL OF THE PLAYER.




                                                         CLASS 1
                                                         LASER PRODUCT


                                                (Printed on the Rear Panel)


WHEN THIS PLAYER IS PLUGGED TO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE
TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF
THIS PLAYER.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.



                     SERVICING NOTICES ON CHECKING
1. KEEP THE NOTICES                                       3. PUT PARTS AND WIRES IN THE
  As for the places which need special attentions,           ORIGINAL POSITION AFTER
  they are indicated with the labels or seals on the         ASSEMBLING OR WIRING
  cabinet, chassis and parts. Make sure to keep the            There are parts which use the insulation
  indications and notices in the operation manual.             material such as a tube or tape for safety, or
                                                               which are assembled in the condition that
2. USE THE DESIGNATED PARTS                                    these do not contact with the printed board.
  The parts in this equipment have the specific                The inside wiring is designed not to get closer
  characters of incombustibility and withstand                 to the pyrogenic parts and high voltage parts.
  voltage for safety. Therefore, the part which is             Therefore, put these parts in the original
  replaced should be used the part which has                   positions.
  the same character.
                                                          4. PERFORM A SAFETY CHECK AFTER
  Especially as to the important parts for safety
  which is indicated in the circuit diagram or the           SERVICING
  table of parts as a     mark, the designated                 Confirm that the screws, parts and wiring which
  parts must be used.                                          were removed in order to service are put in the
                                                               original positions, or whether there are the
                                                               portions which are deteriorated around the
                                                               serviced places serviced or not. Check the
                                                               insulation between the antenna terminal or
                                                               external metal and the AC cord plug blades.
                                                               And be sure the safety of that.



                               HOW TO ORDER PARTS
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER.
   The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
    found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
   You can find it in your SERVICE MANUAL.



                                                       A1-1
                          WHEN REPLACING DVD DECK
[ When the removal of the DVD Deck ]
 Before removing Pick Up PCB and DVD PCB connector, make the short circuit on the position as
 shown Fig. 1 using a soldering. If you remove the DVD Deck with no soldering, the Laser may be
 damaged.

[ When the installation of the DVD Deck ]
 Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD
 PCB connector.
                                                                               Pick Up PCB




                                                     Make the sort circuit
                                                     using a soldering.

                                            Fig. 1




                      PREPARATION OF SERVICING
The laser diode used for a pickup head may be destroyed with external static electricity.
Moreover, even if it is operating normally after repair, when static electricity discharge is
received at the time of repair, a life of product may become short.
Please perform the following measure against static electricity, be careful of destruction of a
laser diode enough at the time of repair, and work.
