Image preview - the first page of the document
>> Download AXW-118 & 128 & AMI-926LW v2 documenatation <<
Text preview - extract from the document
Exploded View and Mechanical Parts List
Model : AXW-118
6
Exploded View and Mechanical Parts List
Model : AXW-118
7
Exploded View and Mechanical Parts List
Model : AXW-128
AXL-122L/124L/125R/123DP/125DP/128L
8
Exploded View and Mechanical Parts List
Model : AXW-128
No. Part Name Part Code Description Q'ty Remark No. Part Name Part Code Description Q'ty Remark
1 WINDOW DOOR A 9CD16177A0 MIPS 1 35 COVER SIDE R 9CD04115R0 MIPS 1
2 WINDOW DOOR B 9CD16177B0 MIPS 1 36-1 CHASSIS BOTTOM 9CD0607500 ABS 1 122L/
3 DOOR COVER A 9CD18123A0 MIPS 1 36-2 CHASSIS BOTTOM 9CD0607100 SECC 1.0T 1 124L/125L/125DP
4 DOOR COVER B 9CD18123B0 MIPS 1 37 COVER BACK 9CD0409800 MIPS 1 OPTION
5 SRING DOOR EJECT R 9CD30080R0 STS 0.9 1 38 HOLDER AC CORD 9CD2303300 ABS 1 124L/125L/127L/125DP
6 SRING DOOR EJECT L 9CD30080L0 STS 0.9 1 39 COVER ANT 9CD0410400 ABS 1
7 DOOR FRAME A 9CD18113A0 MIPS 1 40 HOLDER PCB 9CD2304000 MIPS 1 127DP/127L
8 DOOR FRAME B 9CD18113B0 MIPS 1 41-1 HEAT SINK 10 9CD4404500 AL 1 122L
9 CUSHION FOOT 9CD4207700 URETHAN 2 41-2 HEAT SINK N30 9CD4406200 AL 1 124L
10-A DAMPER GEAR B 9CD2603200 ACETAL 2 41-3 HEAT SINK N50 9CD4405900 AL 1 125L
10-B DAMPER BASE B 9CD2603300 ABS 2 41-4 HEAT SINK DP1 9CD4405200 AL 1 125DP
11-A LOCKER BASE 9CDOB01900 ABS 2 41-5 HEAT SINK 70 9CD4404300 AL 1
11-B LOCKER CAM 9CDOB02000 ABS 2 41-6 HEAT SINK DP2 9CD4405600 AL 1 127DP
11-C LOCKER SPRING 9CDOB01600 STS 2 41-7 HEAT SINK N100 9CD4406000 AL 1 127L
12 BRKT SIDE 9CD2412900 ABS 2 42 BRACKET HEAT TR 9CD2414400 SUS 0.3T 1
13 KNOB CD A 9CD1342200 ABS 1 43 BRACKET HEAT TR 9CD2414600 SECC 1.0T 1
14 KNOB CD B 9CD1342300 ABS 1 44 BRACKET HEAT TR 9CD2413900 SUS 0.5T 1
15 DECO EQ L 9CD10034L0 ACRYL 1 45 FRAME BOTTOM 9CD0607800 SECC 1.0T 1 127L
16 DECO EQ R 9CD10034R0 ACRYL 1 46 BRKT PCB C 9CD2414500 SECC 1.0T 1 127L
17 KNOB FUNCTION 9CD1342400 ACRYL 4 47 BRKT PCB A 9CD2413100 SECC 1.0T 1 127DP
18 PLATE FUNCTION 9CD0911900 PC 4 48 HEAT SINK PW 9CD4404200 AL 1 127L
19 KNOB POWER 9CD1342600 ABS 1 49 HEAT SINK 9CD4402800 BSP 0.5T 1
20 KNOB DISC 9CD1342500 ABS 1 S1 SCREW TAPTTITE 7173261011 TT2 BIN 2.6 X 10 MFZN 13
21-A CASSETTE DECK LOGIC 9CD6007800 ADR-243AMW 1 124L/125L/127L/125DP S2 SCREW TAPTTITE 7173301011 TT2 BIN 3.0X10 MFZN 18
21-B CASSETTE DECK LOGIC 9CD6007700 ADR-243DSW 1 122L S3 SCREW TAPTTITE 7173301212 TT2 BIN 3.0X12 BK 18
22 BADGE DAEWOO 9CD1500900 ABS 1 S4 SCREW TAPTTITE 7173301612 TT2 BIN 3.0X16 BK 2
23 PANEL FRONT 9CD0308600 MIPS 1 S5 SCREW TAPTTITE 7173300611 TT2 BIN 3.0X6 MFZN 7
24 DECO VOL 9CD1003300 ABS 1 S6 SCREW TAPTTITE 7173301411 TT2 BIN 3.0X14 MFZN 2 AMI-127R Ref.
25 KNOB VOL 9CD1342700 ABS 1 S7 SCREW TAPTTITE 7173400611 TT2 BIN 4.0X6 MFZN 4
26 WINDOW FLT 9CD1617800 ACRYL 1 S8 SCREW TAPTTITE 7173401011 TT2 BIN 4.0X10 MFZN 4
27 CD DECK MECHA 9CD6006900 1 S9 WASHER SCREW 9CD3102401 TT2 BIN 3.0X8 + D12 4
28 DOOR CD 9CD1812400 MIPS 1 S9 WASHER SCREW 9CD3102400 TT2 BIN 3.0X10 + D14 3
29 WIN DOOR CD 9CD1617600 ACRYL 1 W1 WASHER PLAIN 1
30 PLATE LED 9CD0911700 PVC T=0.5 1 OPTION No. Part Name Q'ty Remark
31-A GUIDE FLT 9CD2506500 ABS 1 122L/124L/125L/125DP P1 FRONT PCB 1
31-B GUIDE FLT 9CD2506300 ABS 1 125S/127L/127DP P2 MAIN PCB 1
31-C GUIDE FLT 9CD2506700 ABS 1 128 P3 POWER PCB 1
32 PLATE FLT 9CD0909800 PVC T=1.0 2 P4 DECK PCB 1 127L/127DP
33 COVER TOP 9CD0411400 MIPS P5 PCB CD 1
34 COVER SIDE L 9CD04115L0 MIPS 1 P5 PCB JACK 1 OPTION
9
Exploded View and Mechanical Parts List
Model : AMI-926LW/RW
10
Exploded View and Mechanical Parts List
Model : AMI-926LW/RW
11
Wiring Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
12
Block Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
13
Schematic Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : MAIN
14
Schematic Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : TUNER
IFOUT
GND
GND
OSC
OUT
ANT
ANT
VT
B+
1 5 8 3 4 6 2 7
24 23 22 21 20 19 18 17 16 15 14 13
AM AM SD
OSC MIX
AM AGC
DET 1/2
V REG FM
2 10 DET
1 1/2
FM
1 4 7 10 12 IF SW
13
2 5 8 13 PD
14 LED DECORDER
3 6 9 11 14 SD COMP
VCC DET GND DRIVER VCO
3
6 5 4 9 8 7 11 12
1 2 3 4 5 6 7 8 9 10 11 12
21 20 19 12 2 17
VSS VT VT-IN FM/AM IF N.C VDD
AM/FM 7
IF REQ 8
14 N.C
DO 6
15 AM OSC 1/2 CL 5
CB
11 MUTE I/F DI 4
CE 3
13
16 FM OSC
FM 10
9 ST/MO X-IN 1
18 PD
X-OUT 22
15
Schematic Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : TAPE
16
Schematic Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : CD
17
Schematic Diagram
Model : AXW-118 / 128
Ass'y Name : FRONT
18
Schematic Diagram
Model : AMI-926LW/RW
Ass'y Name : FRONT
19
Schematic Diagram
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : POWER
20
P.C.B Pattern Layout
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : MAIN PCB
21
P.C.B Pattern Layout
Model : AXW-118 / 128 / AMI-926LW/RW Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : POWER PCB Ass'y Name : TAPE PCB
22
P.C.B Pattern Layout
Model : AXW-118 / 128 / AMI-926LW/RW
Ass'y Name : CD PCB
23
P.C.B Pattern Layout
Model : AXW-118
Ass'y Name : FRONT PCB
24
P.C.B Pattern Layout
Model : AXW-128
Ass'y Name : FRONT PCB
25
P.C.B Pattern Layout
Model : AMI-926LW/RW
Ass'y Name : FRONT PCB
26
