Image preview - the first page of the document
>> Download DWF-1089 & 9289 & 8089 & 7589 documenatation <<
Text preview - extract from the document
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO
WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO
WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO
WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO
WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER
Contents
1. SPECIFICATIONS 2
WASHING MACHINE
2. STRUCTURE OF THE WASHING MACHINE 3
3. FUNCTIONS OF THE CONTROL PANEL 4
4. DIRECTIONS FOR INSTALLATION AND USE
INSTALLATION OF THE UNDER BASE COVER 5
HOW TO INSTALL ON AN INCLINED PLACE 5
HOW TO CONNECT THE INLET HOSE 6
5. WASHING PROCEDURE AND COURSE SELECTION
FULL AUTOMATIC COURSE 7
PARTIAL SELECTIONS AMONG WASH, RINSE OR SPIN 8
DRY, SILK WAHING 9, 10
ENCHANCED CONVENIENCE IN USE 11
6. FEATURE AND TECHNICAL EXPLANATION
FEATURE OF THE WASHING MACHINE 12
WATER CURRENT TO ADJUST THE UNBALANCED LOAD 12
FUNCTION FOR SOAK WASH 12
AUTOMATIC WATER SUPPLY SYSTEM FOR BLANKET WASH 12
PULSATOR SYSTEM 13
AUTOMATIC DRAINING TIME ADJUSTMENT 13
SOFTENER DISPENSER 14
AUTOMATIC UNBALANCE ADJUSTMENT 15
CIRCULATING-WATER COURSE AND LINT FILTER 15
LINT FILTER 16
RESIDUAL TIME DISPLAY 16
DRAIN MOTOR 16
GEAR MECHANISM ASS'Y 17
PRINCIPLE OF BUBBLE GENERATOR 17
FUNCTIONAL PRINCIPLE OF BUBBLE WASHING MACHINE 18
7. DIRECTIONS FOR DISASSEMBLY AND ADJUSTMENT
GEAR MECHANISM ASS'Y REPLACEMENT 19
DRAIN MOTOR AND VALVE 20
BRAKE ADJUSTMENT 20
8. TROUBLE SHOOTING GUIDE
CONCERNING WATER SUPPLY 21
CONCERNING WASHING 22
CONCERNING DRAINING 23
CONCERNING SPINNING 24
CONCERNING OPERATION 25
9. PRESENTATION OF THE P.C.B ASS'Y 26
APPENDIX
WIRING DIAGRAM 27
PARTS DIAGRAM 31
PARTS LIST 34
CIRCUIT DIAGRAM 42
1. SPECIFICATIONS
NO. ITEM DWF-1089 DWF-9289 DWF-8089 DWF-7589
1 POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE AND CYCLE
50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz
2 POWER CONSUMPTION
430W 480W 430W 480W 400W 460W 400W 460W
MACHINE NON-PUMP 55Kg (GROSS : 64Kg) 54Kg (GROSS : 63Kg) 50Kg (GROSS : 60Kg) 49Kg (GROSS : 59Kg)
3
WEIGHT PUMP 56Kg (GROSS : 65Kg) 55Kg (GROSS : 64Kg) 51Kg (GROSS : 61Kg) 50Kg (GROSS : 60Kg)
4 DIMENSION (WXHXD) 628 X 1005 X 673mm 610 X 962 X 655mm
FULL AUTOMATIC 8 COURSE
5 WASHING COURSE
(FUZZY, MEMORY, DRY, SILK, ECONOMICAL, STRONG, NIGHT, BLANKET)
6 WATER CONSUMPTION NORMAL 315L NORMAL 304L NORMAL 265L NORMAL 259L
HIGH(96L), MID(81L) HIGH(93L), MID(78L) HIGH(82L), MID(70L) HIGH(80L), MID(68L)
7 WATER LEVEL SELECTOR LOW(65L), SMALL(49L) LOW(61L), SMALL(48L) LOW(57L), SMALL(43L) LOW(55L), SMALL(42L)
E.SMALL(36L) E.SMALL(33L) E.SMALL(31.5L) E.SMALL(30.5L)
8 OPERATING WATER PRESSURE 0.3kgf/cm2~8kgf/cm2 (2.94 N/cm2~78.4N/cm2)
60Hz WASH : 145~160, SPIN : 750~800
REVOLUTION
9 50Hz WASH : 130~145, SPIN : 700~750
PER MINUTE
SILK, DRY
COURSE WASH : 70 (60Hz), 60 (50Hz)
10 PULSATOR 6 WINGS (◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
