Image preview - the first page of the document
ERF-331 & 361 & 391 & 411


>> Download ERF-331 & 361 & 391 & 411 documenatation <<

Text preview - extract from the document
CONTENTS




    1.       Specifications                     ..............................................................................................                                                                  3
             1.2 Types of the approved safety standards                                                                ....................................................                                     3
    2.       External drawings                             .........................................................................................                                                            4
    3.       Wiring diagrams                           ...........................................................................................                                                              5
    4.       Name of parts                        .............................................................................................                                                                 6
    5.       Air flow diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
    6.       Refrigerant cycle diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
    7.       Machine room view and part list                                                    ..................................................................                                              9
    8.       Components disassembly pictures                                                       ...............................................................                                           10
    9.       Components specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
    10. Explode drawings                                   .......................................................................................                                                           22
    11. Part lists                 ....................................................................................................                                                                      24
    12. PCB control functions                                        .................................................................................                                                       35
    13. Main PCB diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
    14. Trouble Shooting                                 ........................................................................................                                                            43




                                                                                             1
1. SPECIFICATIONS

1. Specifications

        Model name                  ERF-331     ERF-361            ERF-391            ERF-411
        Division                       M       A      M           A        M        A        M
        Refrigerant     R-134a        80gr    90gr   90gr       90gr     90gr     90gr     90gr
        Blowing agent                                       C-PENTANE
        Cooling system                                    Fan cool system
        Defrost system                        Automatic start & Automatic stop system
        Compressor                                          HPL25YG1-5
        Rated voltage (w)                              AC220~240V / 50Hz
        Rated input (W)               135     135     135        135      135      135      135
        Lamp rated input (W)           15      15      15        15       15        15       15
        Gross          Freezer         99      93      93        93       93       114      114
        capacity       Refrigerator   201      223    223        253      253      254      254
        (liter)        Total          300     316     316        346      346      368      368
        External       Height        1706     1780   1780       1911     1911     2000     2000
        dimension      Width          596      600    600        600      600      600      600
        (mm)           Depth          624      618    618        618      618      618      618
        Energy         kwh/24h        1,26    1,29    1,28      1,30     1,29      1,33     1,32
        consumption class               B       B       B         B        B        B         B
        Freezing capacity(kg/24h)      5.0     5.0     5.0       5.0      5.0      5.0      5.0
        Star rating                   * ***   * ***   * ***     * ***    * ***    * ***    * ***
        Climate class                   N       N       N         N        N        N        N
        Net weight (kg)                61      69      69        75        75       79       79

       Note) A : Electronic control type
             M : Manual control type




1.2. Types of the approved safety standards




                                                   3
2. EXTERNAL DRAWINGS

1. ERF-331M




2. ERF-361A(M), 391A(M), 411A(M)




                                   4
3. WIRING DIAGRAMS

1. ERF-331M




2. ERF-361M, 391M, 411M




3. ERF-361A, 391A, 411A




                          5
4. NAME OF PARTS

1. ERF-331M

                                   1.    Shelves (The material of shelf can be changed
                                         by model).
                                         ERF-331, 361 series: 2 shelves.
                                         ERF-391, 411 series: 3 shelves
                                   2.    Cover vegetable case (Tne material of shelf can
                                         be changed by model).
                                   3.    Interior light for refrigerator compartment.
                                   4.    Multi air flow duct.
                                   5.    Refrigerator & freezer temperature control
                                         knob.
                                   6.    Low temperature compartments (only ERF-
                                         411A series).
                                   7.    Vegetable case. 1 box type or 2 boxes type
                                         (For the case of 1 box type, the Part (15) must
                                         be deleted).
                                   8.    Rating plate. It`s attached in the refrigerator
                                         compartment on the left-hand side next to the
                                         vegetable case.
                                   9.    Ice cube tray.
                                   10.   Case for storing & freezing.
                                   11.   Butter pocket.
                                   12.   Egg pocket.
                                   13.   Egg tray.
                                   14.   Bottle pocket.
                                   15.   R door pocket.
                                   16.   Adjustable feet.




 2. ERF-361M, 391M, 411M       3. ERF-361A, 391A, 411A




                           6
5. AIR FLOW DIAGRAM




      Fresh food preserving case
      (Chilled case)
          Used for storing fish or
          meat




                                         Case vegetable
                                            For storing fruits or
                                            vegetables




    Air circulation in the
    freezer compartment
        Cold air flow comes
        out from the front
        hole and comes into
        the lower hole in
        louver




 * Standard Model




                                     7
6. REFRIGERANT CYCLE DIAGRAM




    COMPRESSOR    PIPE CONN. B      HOT PIPE     WI-CON PIPE       DRYER



             SUCTION PIPE CONN.   SUCTION PIPE   EVAPORATOR    CAPILLARY TUBE


                                       8
7. MACHINE ROOM VIEW AND PART LIST




 N
