Image preview - the first page of the document
>> Download FR-860NA documenatation <<
Text preview - extract from the document
S/M No. : FR860NA010
Refrigerator
Model : FR-860NA
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr Nov. 1999
SAFETY AND PRECAUTIONS
1) For starters, be sure to check any chances of the leakage of electricity.
2) You could handle a part in the vicinity of electricity after unplugging.
3) You should put on rubber glovers to prevent an electric shock on operation test.
4) Make sure the rated current, voltage, capacity before using an instrument.
5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten.
6) Be careful not to let water to permeate the electric part in the machine room.
7) With the door open during your working, you might be damaged by that door.
8) You should give a title to the refrigerator for your safe after removing the breakable goods inside the refrigerator.
9) You'd better use cotton gloves if you fix it up around the evaporator.
TABLE OF CONTENTS
EXTERNAL VIEWS ............................................................................................................................. 2
1. EXTERNAL SIZE........................................................................................................................... 2
2. NAME OF PARTS ......................................................................................................................... 2
SPECIFICATIONS ............................................................................................................................... 3
1. OUTLINE ....................................................................................................................................... 3
2. ELECTRIC PARTS........................................................................................................................ 3
3. POWER CORD ............................................................................................................................. 8
4. DOOR COLOR.............................................................................................................................. 9
OPERATION AND FUCTIOLNS.......................................................................................................... 10
DIAGRAM ............................................................................................................................................ 17
1. CIRCUIT DIAGRAM ...................................................................................................................... 17
2. AIR FLOW DIAGRAM ................................................................................................................... 18
3. REFRIGRANT CYCLE DIAGRAM ................................................................................................ 19
EXCHANGE OF MAJOR PARTS........................................................................................................ 21
EXPLODED VIEW AND PARTS LIST................................................................................................. 38
1. EXPLODED VIEW......................................................................................................................... 38
2. TOTAL PARTS LIST ..................................................................................................................... 39
3. MACHINE ROOM ECPLODED VIEW AND PARTS LIST............................................................. 43
1
EXTERNAL VIEWS
1. EXTERNAL SIZE
2. NAME OF PARTS
1 Freezer Compartment Lamp
2 Shelf Ffreezer
3 Case Iec Maker
4 Cover Iec Maker
5 Ice Maker
6 Ice Box
7 Deodorant
8 Door Water Supply
9 Case Water Supply
10 Door Chilled Case
11 Case Chilled
12 Freshfood Compartment Lamp
13 Shelf Refrigerator
14 Cover Vegetable
15 Case Vegetable
16 Adjustable Foot
17 Freezer Pocket Top
18 Freezer Pocket Under
19 Egg Pocket
20 Egg Tray
21 Bottle Pocket
22 Multi Pocket
23 Multi Pocket
2
SPECIFICATIONS
1. OUTLINE
DIVISION CONTENTS
MODEL NAME FR-860NA
USABLE CAPACITY FREEZER 189 l
REFRIGERATOR 457 l
TOTAL 646 l
EXTERNAL DIMENSION( mm) WIDTH 884 mm
DEPTH 831 mm
HEIGHT 1831 mm
REFRIGENT R12 190 g
R134a 150 g
COOLING &CONTROL SYSTEM COOLING SYSTEM Fan Cooling System
DEFROST SYSTEM Fin Evaporator Forced
DEFORST CONTROL Automatic Start & Stop
NET WEIGHT (kg) 107 kg
2. ELECTRIC PARTS
1) COMPRESSOR
REFRIGERANT R12
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 50 240 / 50
COMP MODEL X X X BL25YG-2 SL30YG-5 PL25YH-4 SL30YG-5 SL30YG-5
PART CODE 3952125R20 3954130R51 3956125P40 3954130R51 3954130R51
STARTING TYPE RSIR RSCR RSIR RSIR
MAIN COIL RESISTANCE
AUX. COIL RESISTANCE
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 50 240 / 50
COMP MODEL X HBL25YG-3 X X HPL26YH-5 X HPL26YH-5 HPL26YH-5
PART CODE 3952125R30 3956126S50 3956126S50 3956126S50
STARTING TYPE CSR RSCR RSCR RSCR
MAIN COIL RESISTANCE
AUX. COIL RESISTANCE
3
SPECIFICATIONS
2) RELAY
REFRIGERANT R12
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
ASSY TYPE NAME X X X 414THBYY-52 276THBYY-52 197SHBYY-52 276THBYY-52 276THBYY-52
PART CODE 3018119460 3018119350 3018118100 3018119350 3018119350
C-RELAY RESIS-TANCE
PART CODE
PTC RESIS-TANCE S220 S220 S330 S220 S220
PART CODE
OVER LOAD PART CODE 414THB 276THB 197SHB 276THB 276THB
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
ASSY TYPE NAME X 783NHBZZ-52 X X 197NHBYY-52 X 197NHBYY-52 197NHBYY-52
PART CODE 3018119390 3018119920 3018119920 3018119920
C-RELAY RESIS-TANCE
PART CODE
PTC RESIS-TANCE S220 S330 S330 S330
PART CODE
OVER LOAD PART CODE 783NHB 197NHB 197NHB 197NHB
3) STARTING CAPACITOR
REFRIGERANT R12
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
PART CODE X X X 3016400100 X X X X X
RATED VOLTAGE 200V
RATED CAPACITANCE 100
REFRIGERANT R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
PL KL
PART CODE X 3016400100 X X X X X X X
RATED VOLTAGE 200V
RATED CAPACITANCE 100
4
SPECIFICATIONS
4) RUNNING CAPACITOR
REFRIGERANT R12
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
PART CODE X X X 3816800400 X X 400EL15110 X X
RATED VOLTAGE 300V 350V
RATED CAPACITANCE 7 5
REFRIGERANT R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
PL KL
PART CODE X 3816800400 X X 3016401900 X X 3016401900 3016401900
RATED VOLTAGE 300V 400V 400V 400V
RATED CAPACITANCE 7 4 4 4
5) F-FAN MOTOR
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
TYPE NAME DL-2213DWFA DL-2213DWFA DL-2213DWFA DL-2213DWFA DL-2213DWFA DL-2213DWFA DL-2213DWFA DL-2213DWFA
PART CODE 3015905310 3015905310 3015905310 3015905310 3015905310 3015905310 3015905310 3015905310
REVOLUTION 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM
6) R-FAN MOTOR
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
TYPE NAME DL-2213DWRA DL-2213DWRA DL-2213DWRA DL-2213DWRA DL-2213DWRA DL-2213DWRA DL-2213DWRA DL-2213DWRA
PART CODE 3015906910 3015906910 3015906910 3015906910 3015906910 3015906910 3015906910 3015906910
REVOLUTION 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM
7) C- FAN MOTOR
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
TYPE NAME DL-2213DWCA DL-2213DWCA DL-2213DWCA DL-2213DWCA DL-2213DWCA DL-2213DWCA DL-2213DWCA DL-2213DWCA
PART CODE 3015906800 3015906800 3015906800 3015906800 3015906800 3015906800 3015906800 3015906800
REVOLUTION 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM 2200RPM
5
SPECIFICATIONS
8) DEFROST HEATER
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
SPEC (W) 250W 250W 250W 250W 250W 250W 250W
PART CODE 3012800301 3012800301 3012800301 3012800310 3012800310 3012800310 3012800310
10) LAMP ASSEMBLY
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
SPEC (W) 15W 15W 15W 15W 15W 15W 15W 15W
PART CODE 3013600010 3013600010 3013600010 3013600010 3013600080 3013600080 3013600080 3016800080
COLOR
12) PCB TRANSFORMER(FR-860NA)
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
TYPE NAME FRB-6575NA FRB-6575NA FRB-6575NA FRB-6575NA FRB-6575NA FRB-6575NA FRB-6575NA
PART CODE 5EPK057009 X 5EPK057008 5EPK057007 5EPK057007 5EPK057007 5EPK057007
13) MAIN PCB ASSEMBLY(FR-860NA)
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 60 240 / 50
SL KL
TYPE NAME N105 N105 N105 N105 N105 N105 N105 N105
PART CODE 3014391100 3014391100 3014391100 301439100 301439100 3014391020 3014391010
14) DRYER
REFRIGERANT R12 R134a
SPEC (g) 10g 15g
PART CODE 3016805400 3016801030
6
SPECIFICATIONS
15) FUSE (PCB)
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
RATED CURRENT 250V/1.6A 250V/1.6A 250V/1.6A 250V/1.6A 250V/1.6A 250V/1.6A 250V/1.6A
PART CODE 5F3GB1682R 5F3GB1682R 5F3GB1682R 5F3GB1682R 5F3GB1682R 5F3GB1682R 5F3GB1682R
16) THERMO FUSE
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
OPERATING TEMPERATURE 77 77 77 77 77 77 77 77
PART CODE 3017200500 3017200500 3017200500 3017200500 3017200500 3017200500 3017200500 3017200500
17) DOOR S/W
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
TYPE NAME
PART CODE 3018100010 3018100010 3018100010 3018100010 3018100010 3018100010 3018100010
18) F-SENSER
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
TYPE NAME
PART CODE 3014801501 3014801501 3014801501 3014801501 3014801501 3014801501 3014801501 3014801501
19) R-SENSER
REFRIGERANT R12,R134a
VOLTAGE ( V/HZ) 220/50
100 /50,60 110 / 60 115,120/60 127/60 220 / 60 230 / 60 240 / 50
SL KL
TYPE NAME
PART CODE 3014801601 3014801601 3014801601 3014801601 3014801601 3014801601 3014801601 3014801601
7
SPECIFICATIONS
3. POWER CORD
NO SHAPE OF POWER CORD PART CODE DESCRIPTION REMARK
1 3011315000 CP-2PIN For european country
2 401RA17200 CP-2PIN For other country
3 4006D17101 KP-30 For America & El Salvador
4 401PD17101 KP-211 For Japan & Taiwan
5 3011300801 BP-3PIN
6 3011303010 # 267 For Chile
7 3011315310 For Israel
8 3011303050 BS-1363A For U.K, Middle Asia Singapore & Malaysia
9 3011301200 KP-551/550 For China & Australia
8
SPECIFICATIONS
4. DOOR COLOR
1) ASSEMBLY URETHAN FREEZER DOOR
NON-KEY TYPE
Refrigerant R12 R134a
High-glossy High-glossy High-glossy High-glossy
COLOR TYPE Dull lamiasheet Normal PCM Dull lamiasheet Normal PCM
Laminasheet Bright PCM Laminasheet Bright PCM
PART CODE 3010074040 3010074050
KEY TYPE
Refrigerant R12 R134a
High-glossy High-glossy High-glossy High-glossy
COLORTYPE Dull laminasheet Normal PCM Dull laminasheet Normal PCM
Laminasheet Bright PCM Laminasheet Bright PCM
PARTCODE X X
2) ASSEMBLY URETHAN REFRIGERATOR DOOR
NON-KEY TYPE
Refrigerant R12 R134a
COLORTYPE Dull laminasheet High-glossy Normal PCM High-glossy Dull laminasheet High-glossy Normal PCM High-glossy
Laminasheet Bright PCM Laminasheet Bright PCM
PARTCODE 3010072510 3010072520
KEY TYPE
Refrigerant R12 R134a
High-glossy High-glossy High-glossy High-glossy
COLORTYPE Dull laminasheet Normal PCM Dull laminasheet Normal PCM
Laminasheet Bright PCM Laminasheet Bright PCM
PARTCODE X X
9
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
1 DISPLAY CUSTOM LED
1. Normal State
1) SILENT Icon(AMBER) and Fuzzy Icon are lit.
2) SURROUND Icon are lit in two colors(AMBER,GREEN).
3) SURROUND, FRZ. ,REF. LEDs are lit.
4) Initial Mode ; " and " of Freezer Icons and Refrigerator
1" 2"
Icons are lit.
2. FRZ.SET Button
1) Temperature regulation of Freezer (compartment)
2) Temperature indicators change by pressing the button.
ECONO 1 2 3 Q.F
3) When Q.F is chosen, Freezer Icons (middle left) are On and
Off 3 times, then only Q.F Icon is lit.
3. REF.SET Button
1) Temperature regulation of Refrigerator(Freshfood Compartment)
2) Temperature indicators change by pressing the button.
ECONO 1 2 3 Q.R
3) When Q.R is chosen, Refrigerator Icons (middle right) are On
and Off 3 times, then only Q.R Icon is lit.
4. Fuzzy Button
1) Fuzzy Led is lit.
2) Freezer and Refrigerator Icons are On and Off 3 times, then it
starts middle mode. (1 and 2 are On.)
3) Fuzzy Mode is finished by pressing the button once again.
5. SILENT Control
1) SILENT LED is lit and SILENT Icon turns into green.
2) The other LEDs are all Off.
3) When the button is pressed once again, SILENT LED is Off
and SILENT Icon turns into amber.
The other LEDS return to normal [previous[ state.
4) SILENT Mode continues for 130 minutes.
10
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
2 Temperature Regulation 1. COM 1. Temperature Indicators are lit one by one from ECONO to Q.F.
of Freezer Compartment 2. F-Fan
ECONO 1 2 3 Q.F
2. COMP and F-Fan are controlled by On/Off point of each mode. DIFF. of On/Off and
"3"/"1" is fixed by
3. Freezer On/Off DIFF. : 5 Micom.
(Freezer Middle("2") Off-point : -23.5 )
4. Freezer "3"/"1" DIFF. : 1 (2/3 DIFF. : 2 )
5.
-16.5
-17.5
-18.5
-20.5
-21.5
-22.5
-23.5
-25.5
6. If temperature regulation is done during Fuzzy Mode, the mode
is finished and temperature regulation is executed.
7. During Q.F Mode, COMP and F-Fan are On for 150 minutes
regardless of F-Sensor.
3 Temperature Regulation 1. Temperature indicators are lit one by one from ECONO to Q.R.
of Refrigerator
(Freshfood Compartmnet) ECONO 1 2 3 Q.F
2. R-Fan is controlled by On/Off-point of each mode.
3. Refrigerator On/Off DIFF. : 0.35 On/Off DIFF. and
(Refrigerator Middle(2) Off-point : -1.0 ) "3"/"1" DIFF. are fixed
by MICOM.
4. Refrigerator "3"/"1" DIFF. : 1 ("2"/"1" DIFF. : 2 ) R-Fan turns Off if D-S
-3 and COMP Off.
5.
6. Weak Refrigeration Weak-refrigerationPoint :
1) When Weak-refrigeration is sensed, COMP is On regardless R-S Off-point + 7
of F-Sensor.
2) When R-Sensor reaches to R-Fan Off-point, COMP is
controlled by F-Sensor and R-Fan becomes Off.
3) Weak-refrigeration point : R-S Off-point + 7 End of Weak-refriger-
ation : same as R-
7. If temperature regulation is done during Fuzzy Mode, the mode Fan Off-point
is finished and temperature regulation is executed.
8. Q.R Mode continues for 40minutes.
11
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
9. When Q.R starts during 1 mode of refrigerator;
1) R-Fan and COMP are On until R-Sensor reaches to
Over-refrigeration Off-point.
2) "3" continues until Q.R ends after Over-refrigeration Off-point.
3) It returns to normal state after Q.R(40minutes).
4 Fuzzy Mode 1. COMP On/Off Temperature 1. Fuzzy Mode starts by pressing the button. It runs in "2"mode if
2. R-Fan On/Off Temperature RT 14 .
3. COMP 2. The mode is finished by pressing the button once again and it
4. R-Fan returns to previous mode.
5. F-Fan
3. Application of Predictive refrigeration to Freezer and Refrigerator
1) Checking total time of door-opening by 2hours interval It runs in only "2", "3"
Door-opening is checked as the followings. mode during Fuzzy
Over 30seconds : much opening ( 1 ) Mode.
Under 30seconds : little opening ( 0 )
Collecting data for 8 days
2) Checking 8 days data "2"/"3" DIFF.
If door-openings over 30 seconds are more than 6 times, it of Refrigerator in
runs in 3 mode during that time. Fuzzy Mode : 1
If door-openings under 30 seconds are less than 5 times,
it runs in 2 mode during that time.
5 Defrosting Period 1. Defrosting Mode 1. What to be considered in determining defrosting period
1) Total COMP run-time
2) COMP running-rate
3) Total door opened-time
4) Total Time (COMP On + COMP Off)
5) Each Error
D-Sensor Error F-Sensor Error
RT-Sensor Error Door S/W Error
2. Terms to start Defrosting Period
START 2 4 6 8 10
(Total COMP run-time)
1) Defrosting mode starts at 6, 8, 10 hours.
2) The mode starts when COMP running-rate is over 80% at
2hours interval.
3) The mode starts when total door opened time is more than
10 minutes.
4) The mode starts when total run-time is more than 60 hours.
5) The mode starts when each Error occurs in case total COMP
run-time is more than 6 hours.
6) The mode starts unconditionally when COMP run-time is more
than 10 hours.
12
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
6 Defrosting Mode 1. COMP 1. Defrosting Mode
2. F-Fan 1) Time = 50 minutes
3. R-Fan Pre-cool 2) COMP and F-Fan ; ON
4. Heater 3) If F-Sensor - 27 , Pre-cool
becomes Off, though time does
not pass 50 minutes.
1) Heater turns Off when D-Sensor 10 .
Heater Defrostiong 2) Limit time = 80minutes
3) Heater continues to be On for 40
minutes in case of D-Sensor Error.
1) Time = 4minutes
Pause 2) COMP, F-Fan, R-Fan ; Off
1) Time = 5minutes
Fan-delay
2) Only COMP is On.
2. Output Control and Limit Time of each Mode C-Fan and COMP are
co-working.
Pre-cool HTR Defrosting Pause Fan-delay
COMP ON OFF OFF ON
F-Fan ON OFF OFF OFF
R-Fan Control OFF OFF OFF
Heater OFF ON OFF OFF
Limit 80 min.
Time 50 min. 40 min. 4 min. 5 min.
( D-Sensor error)
7 Error Display 1. Press SILENT Button 3 times while pressing FRZ.SET Button and Limit time = 8min.
(Displayed at C-LED on REF.SET Button at the same time.
F-PCB)
2. All LED of C-LED turn Off if there is no error.
3. If Error occurs, letters of LED are lit. Checking Error with-
out using JIG
4. Press SILENT Button 3 times again while pressing FRZ.SET
Button and REF.SET Button at the same time, then the mode is
finished.
13
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
ERROR CODE C-LED CONTENTS OPERATION STATE
F-S Short-circuit/ COMP and F-Fan are On
F1 Freezer Disconnection for 40min., Off for 20min.
(Period : 60min.)
Ref. R-S Short-circuit/ It runs at 20minutes' interval
r1 Disconnection according to RT
D-S Short-circuit R-Fan On/Off control possible
/Disconnection only when COMP is On.
d1 Q.F of
Freezer D-S 3.5 Heater is On for 40min. in
When COMP is case of Defrosting.
Off.
ECONO of RT-S Short-circuit Deletion of function by
rt Ref. /Disconnection RT-Sensor
Door S/W is Deletion of Fan-control by
defective.(In case Door S/W
d0 "1" of Ref. door-opening is
sensed as `over Defrosting Period : 6hours of
1hour') total COMP run-time.
Abnormal Cycle
(Continuous
C1 "2" of Ref. Normal Running
COMP running for
over 3hours at
D-S 5 . )
When it returns to
Time(80min.),
F3 "3" of Ref. not to D-Sensor in Normal Running
HTR Defrosting of
Defrosting Mode
Automatic Icemaker Error Code ; refer to 19)
If R-Sensor is defective, R-Fan runs at 20 minutes interval by RT;
- RT 14 : On for 3 min., Off for 17min.
- 14 < RT 26 : On for 6min., Off for 14min.
- 26 < RT : On for 9min., Off for 11min.
All the Error Code is reset by itself when it returns to normal state.
8 Run-time, Sensor 1. Function of A/S JIG Run-time (from initial
Temperature, Error Code 1) Run-time, Sensor Temperature and Error Code are displayed power supply till now)
Display(JIG Display) on 88 LED of JIG. is displayed by the
2) How to use JIG minute.
JIG Display Mode starts about 3 seconds after JIG connection. (00:00 ~ 23:59)
88 LED of JIG displays running time.
The following is displayed as pressing JIG Switch ;
unning- R- D- F- Error Code
ime Sensor Sensor Sensor (When it occurs)
3) JIG Display Mode stops by disconnecting it and returns to When it returns to Jig
normal[previous] state. Display Mode, not to
4) Prevention of COMP-restart (6min.) and Fan-delay of 1min. Normal State, 3
are omitted during JIG connection. seconds are skipped.
14
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
9 Forced Defrosting Defrosting Mode A/S Forced Defrosting
1. How to start ; press both buttons 5 times.
2. How to proceed ;
1) Let Heater On for 30 seconds.
2) Delete Pre-cool of Normal Defrosting Mode.
HTR Defrosting Pause Fan Delay Normal Running
3) Heater turns Off when D-Sensor temperature(30 seconds
after Heater-On) is more than 10
4) Heater turns Off when Heater time passes 80 minutes.
(F3 ERROR)
5) SILENT Icon lights On and Off when it starts A / S Forced
Defrosting.
10 Time Delay of Electric 1. COMP 1. F-Fan Time Delay in COMP On/Off Available from
Devices 2. F-Fan MICOM CODE
3. R-Fan ON 13GSNA04-1
OFF COMP
ON
OFF F-FAN
1min. 1min.
2. F-Fan, R-Fan Time Delay by Door Switch Input
OPEN
CLOSE DOOR S/W
OFF
ON F-FAN
OFF
ON R-FAN
20sec. 0.5sec.
11 Initial Defrosting 1. Defrosting Mode 1. Defrosting Mode starts when D-Sensor 3.5 at initial COMP Delay for
power supply. (It starts from Pre-cool Mode.) 6minutes at initial
Defrosting
12 Explanation after 1. Electric Devices 1. It starts by pressing FRZ.SET and REF.SET buttons for
Delivery 3 seconds right after initial power supply.
2. Electric devices turn Off for 3 hours.
3. Display works in normal way.
13 Prevention of COMP 1. COMP 1. COMP does not restart within 6 minutes after COMP Off, 6 minute delay
Restart though F-Sensor turns On.
14 Buzzer 1. Buzzer 1. Buzzer rings when any F-PCB button is pressed.
2. Buzzer rings within 3 seconds at initial power supply.
3. Fuzzy Button and Buzzer do not work during temperature
regulation.
4. Buzzer rings at 1 minutes interval when either door is
opened. (It works for 5 minutes.)
5. Buzzer rings on by pressing JIG Switch.
15
OPERATION AND FUCTIOLNS
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
1. Demonstration Mode starts by pressing REF.SET Button Display works in
5 times while pressing SILENT Button. normal way.
All the electric devices turn Off except for F-Fan and R-Fan.
2. Fan Control
Door Open Door Close
F-FAN ON OFF
R-FAN ON OFF
Fuzzy and Normal are
displayed one by one
3. The mode is finished by doing 1. Again.
at 15 seconds interval.
16 Silent Mode 1. COMP 1. SILENT Mode starts by pressing the button.
2. F-Fan
3. R-Fan 2. Terms to start SILENT Mode
4. C-LED 1) F-Sensor temperature -15
2) Not restart within 40 minutes after the mode
3) Not F-Sensor Error
4) Not Door Switch Error
5) Not in the Defrosting Mode
(Heater Defrosting, Pause, Fan Delay)
When the above terms are satisfied, SILENT Mode starts.
3. When the mode starts, all the devices(COMP, F-Fan, R-Fan) turn
Off and only SILENT LED/Icon are lit.
4. Terms to finish SILENT Mode
1) F-Sensor Temperature - 9
2) When it passes Limit Time of 130min.
3) Pressing the SILENT Button again during the mode
4) Total time of door-opening is more than 30 seconds during the mode.
In case SILENT Mode is finished by 1) or 2), F/R-Fan Delay
time(5 minutes) and Restart prevention time (40 minutes) are set.
5. When it is finished, all the devices and C-LED return to
normal[previous] state.
6. When SILENT Mode starts during the Pre-cool Mode, the
Pre-cool mode restarts after the SILENT Mode.
7. When SILENT Mode starts during Fuzzy, Q.F and Q.R, those
modes restart and continue for the rest time after SILENT Mode.
1. In case of Weak-refrigeration (though R-Fan and COMP work on and on) ;
2. Resistance R32 : Resistance of R-Sensor middle("2") Off-point
(- 1.0 , 31.4 )
3. Resistance R50 : Reduce the point by 1.5 in case of Weak-refrigeration.
(-2.5 , 2.15 )
4. SW1 : Let SW1 OPEN, then the point is reduced by 1.5 .
5. Switch and R-Sensor middle("2" Off-point)
Switch Status R-Sensor Middle Off-point
Normal / Using Jig -1.0
In Weak-refrigeration -2.5
16
DIAGRAM
1. CIRCUIT DIAGRAM
17
DIAGRAM
2. AIR FLOW DIAGRAM
Freezer
Pleas don't put bottles such as
Freezer pocket
beer, beverage etc.
Please don t put long term storing
' It might be broken because of
items such as ice cream etc.
freezing.
It might be melted because of
opening the door freguently.
Inlet fo cooling air
it should not be blocied with
food etc. as it is he inlet where
cooling air returns.
Multiple outlet of cooling air
Refrigerator pocket Please don't put in begetable etc,
It is good for the storage of beer which contain moisture. It might be
and beverage etc. frozen because of low tempeature.
Refrigerator pocket
It is good for the storage of beer
and beverage etc.
Crisper
It is suitable to store vegeta-
ble and fruit. The moisture panel
which is attached to the cover
maintains the humidity properly.
Vegetable and fruit would be better
to be packed with clean wrap foils.
18
DIAGRAM
3. REFRIGRANT CYCLE DIAGRAM
C
C A A
E P
O P C
H V S I
M I C
O A U P
P W D L U
T P C E
R I R L M
O
E - P Y A U P
R C
S C I E R L I
A O
S O P R Y A P
T N
O N E T E
T O
R O
U R S
R
B
E
19
EXCHANGE OF MAJOR PARTS
1. FREEZER & REFRIGERATOR DOORS
1) Insert flat type (-) screw driver between Hinge Cover
and Cabinet surface to remove the Cover.
(Be careful not to break the hooks of Cover and not to
damage the Cabinet surface.)
2) Remove 4 bolts with 10mm wrench.
3) Disconnect Connector Housing.
4) Lift F-Door a little to remove it.
5) Unfasten Hinge Pin with 6mm wrench.
6) Lift R-Door up a little to remove it.
20
EXCHANGE OF MAJOR PARTS
2. DOOR HANDLES
1) Insert tiny screw driver into the gap between handle
and decorator to remove the decorator.
Freezer Handle : bottom gap
Refrigerator Handle : top gap
2) Pull out Handle Decorator from up to down.
Be careful not to damage the surface of Handle.
Once it is peeled or damaged, corrosion may occur
from metal parts beneath the handle.
3) Remove the 2 Handle screws.
4) See to it that the screws are fastened well when
reassembling the handle.
3. F LIGHT BULB
1) Remove cover by pushing the hook.
21
EXCHANGE OF MAJOR PARTS
2) Remove the light bulb by turning it counterclockwise.
(Lamp : 15W)
3) Pull Light-bulb Base down forward with snap, if necessary
In assembling, push it upward with snap.
Be careful not to damage the Liner surface.
4. F LOUVER
1) Remove F-lamp cover.
2) Insert both fingers into the rectangular holes and pull
out louver forward smoothly.
3) In reassembling the louver, insert the bottom of louver
first and press smppthly the triangle-marked parts until
they are clicked well.
22
EXCHANGE OF MAJOR PARTS
5. F LOUVER INSULATOR
1) Remove F-louver.
2) Peel out the aluminum tape on the sensor plate to
remove it.
3) Pull the louver insulator forward smoothly .
Be careful not to damage the sealing sponges on the
insulator, for they affect cold-air circulation.
6. F SENSOR EXCHANGE
F-Louver Instilator
1) Cut down sensor wires and insert 2 pieces of heat F-Sensor
Soldering
shrinkage tube to each wire.
2) Connect new sensor wires and old ones, and put sol
dering on the connecting part.
3) Move shrinkage tubes to hide the connecting part
and give mild heat around them to shrink.
Wire
7. Fan Motor
1) Remove louver and louver insulator.
2) Remove the mo◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
