Image preview - the first page of the document
>> Download KOG-6C675S documenatation <<
Text preview - extract from the document
S/M No. : G6C675S001
Service Manual
Microwave Oven
Model: KOG-6C675S
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr Jan. 2004
PRECAUTIONS TO BE OBSERVED BEFORE AND
DURING SERVICING TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other micro-
wave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and
sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5)
Evidence of dropping or abuse.
(c) Before turning on power to the microwave oven for any service test or inspection within the microwave gen-
erating compartments, check the magnetron, wave guide or transmission line, and cavity for proper align-
ment, integrity, and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door seal, and microwave generation
and transmission systems shall be repaired, replaced, or adjusted by procedures described in this manual
before the oven is released to the owner.
(e) A microwave leakage check to verify compliance with the Federal performance standard should be per-
formed on each oven prior to release to the owner.
TABLE OF CONTENTS
SAFETY AND PRECAUTIONS ...........................................................................................................................................2
1. FOR SAFE OPERATION ..................................................................................................................................2
2. FOR SAFE SERVICE PROCEDURES .............................................................................................................2
SPECIFICATIONS ...............................................................................................................................................................3
EXTERNAL VIEW ................................................................................................................................................................4
1. OUTER DIMENSION ....................................................................................................................................... 4
2. FEATURE DIAGRAM ........................................................................................................................................5
INSTALLATION ...................................................................................................................................................................6
OPERATIONS AND FUNCTIONS .......................................................................................................................................7
DISASSEMBLY AND ASSEMBLY......................................................................................................................................8
INTERLOCK MECHANISM AND ADJUSTMENT .............................................................................................................17
TROUBLESHOOTING GUIDE .........................................................................................................................................18
MEASUREMENT AND TEST ............................................................................................................................................20
1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT ........................................................................20
2. MICROWAVE RADIATION TEST ...................................................................................................................21
3. COMPONENT TEST PROCEDURE ...............................................................................................................22
WIRING DIAGRAM ............................................................................................................................................................23
EXPLODED VIEW AND PARTS LIST...............................................................................................................................24
1. DOOR ASSEMBLY .........................................................................................................................................25
2. CONTROL PANEL ASSEMBLY ......................................................................................................................25
3. TOTAL ASSEMBLY.........................................................................................................................................25
1
SAFETY AND PRECAUTIONS
1. FOR SAFE OPERATION
Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may
cause serious bodily injury to the operator.
IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE.
(Only a trained service personnel should make repairs.)
(1) A broken door hinge.
(2) A broken door viewing screen.
(3) A broken front panel, oven cavity.
(4) A loosened door lock.
(5) A broken door lock.
The door gasket plate and oven cavity surface should be kept clean.
No grease, soil or spatter should be allowed to build up on these surfaces or inside the oven.
DO NOT ATTEMPT TO OPERATE THIS APPLIANCE WITH THE DOOR OPEN.
The microwave oven has concealed switches to make sure the power is turned off when the door is opened.
Do not attempt to defeat them.
DO NOT ATTEMPT TO SERVICE THIS APPLIANCE UNTIL YOU HAVE READ THIS SERVICE MANUAL.
2. FOR SAFE SERVICE PROCEDURES
1. If the oven is operative prior to servicing, a microwave emission check should be performed prior to servicing the
oven.
2. If any certified oven unit is found to servicing, a microwave emission check should be performed prior to servicing the
oven.
(a) inform the manufacturer, importer or assembler,
(b) repair the unit at no cost to the owner,
(c) attempt to ascertain the cause of the excessive leakage,
(d) tell the owner of the unit not to use the unit until the oven has been brought into compliance.
3. If the oven operates with the door open, the service person should tell the user not to operate the oven and contact
the manufacturer and the dealer immediately.
IMPORTANT
The wire in this mains lead coloured in accordance with the following code.
Green-and-yellow : Each
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows.
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with
the letter E , earth symbol or coloured green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured
black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or
coloured red.
NOTE
This oven is designed for counter-top use only.
2
SPECIFICATIONS
POWER SUPPLY 230V/50Hz, SINGLE PHASE WITH EARTHING
MICROWAVE 1200 W
POWER
GRILL 1050 W
CONSUMPTION
COMBINATION 2200 W
MICROWAVE ENERGY OUTPUT 800W
MICROWAVE FREQUENCY 2450MHz
OUTSIDE DIMENSIONS (WXHXD) 465 x 279 x 384mm
CAVITY DIMENSIONS (WXHXD) 290 x 220 x 306mm
NET WEIGHT APPROX. 13.4Kg
TIMER 35 min. DUAL SPEED
POWER SELECTIONS 7 LEVELS
CAVITY VOLUME 0.7 Cu.Ft.
* Specifications are subject to change without notice.
3
EXTERNAL VIEW
1. OUTER DIMENSION
465 384
4
2. FEATURE DIAGRAM
1 2 3 4 5
6
7
8
e wq 0 9
1 Door seal - Door seal maintains the microwave energy within the oven cavity and prevents microwave leakage.
2 Reflector (Insulator Heater)
3 Heating Element
4 Oven cavity
5 Safety interlock system
6 Knob V.P.C - Used to select a microwave power level.
7 Knob timer - Used in setting cooking time for all functions.
8 Metal Rack
9 Coupler - This fits over the shaft in the center of the ovens cavity floor. This is to remain in the oven for all cooking.
0 Roller guide - This must always be used for cooking together with the glass cooking tray.
q Glass cooking tray - Made of special heat resistant glass. Food in a proper receptacle is placed on this tray for cooking.
w Door viewing screen - Allows viewing of food.
The screen is designed so that light can pass through, but not the microwave.
e Door hook - When the door is closed, it will automatically shut off.
If the door is opened while the oven is operating, the magnetron will immediately stop operating.
5
INSTALLATION
1. Steady, flat location.
This microwave oven should be set on a steady, flat surface.
2. Leave space behind and side.
All air vents should be kept a clearance. If all vents are covered during operation, the oven may be overheated
and, eventually, cause oven failure.
3. Away from radio, and TV sets
Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna, or
feeder and so on.
4. Away from heating appliances and water taps
Keep the oven away from hot air, steam or splash when choosing a place to position it, or the insulation might be
adversely affected and breakdowns occur.
5. Power supply
Check your local power source.
This microwave oven requires a current of approximately 12 amperes, 230 Volts, 50 Hz.
Power supply cord is about 0.8 meters long.
The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other
accident causing oven damage. Using low voltage will cause slow cooking. We are not responsible for damage
resulting from use of this oven with a voltage of ampere fuse other than those specified.
This appliance is supplied with cable of special type, which, if damaged, must be repaired with cable of same
type.
Such a cable can be purchased from DAEWOO and must be installed by a qualified person.
6. Examine the oven after unpacking for any damage such as:
A misaligned door, broken door or a dent in cavity.
If any of the above are visible, DO NOT INSTALL, and notify dealer immediately.
7. Do not operate the oven if it is colder than room temperature
(This may occur during delivery in cold weather.) Allow the oven to become room temperature before operating.
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of the electric
shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earth-
ing plug. The plug must be plugged into an outlet that is properly installed and earthed.
WARNING
Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified electrician or service-
man if the earthing instructions are not completely understood, or if doubt exists as to whether the appliance is
properly earthed, and either : If it is necessary to use an extension cord, use only a 3-wire extension cord that
has a 3-blade earthing plut, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating
of the extension cord should be equal to or greater than the electrical rating of the appliance, or Do not use an
extension cord.
6
OPERATIONS AND FUNCTIONS
