SPECIFICATIONS
MODEL NUMBER TR-951AUB
CD27USB
DATE 2007/12/28
TEST CONDITION:
1.POWER SUPPLY VOLTAGE:AC220 V, 50 HZ
2.STANDARD MODULATION:1000HZ,30%MOD
3.REFERENCE OUTPUT:50mw
4.RESISTIVE LOAD:4 OHM
AM FM MAX OUTPUT POWER
NO. TEST ITEMS FREQ/TAPE UNIT NORMAL LIMIT DATA
KHZ 520
FRERQUENCY RANGE
KHZ 1630
INTERMEDIATE FREQUENCY KHZ
600KHZ KHZ / /
DIAL DEVIATION 1000KHZ KHZ / /
1400KHZ KHZ / /
600KHZ dB/M
MAX SENSITIVITY 1000KHZ dB/M
1400KHZ dB/M
600KHZ dB/M
5 USEADLE SENSITIVITY 20dB S/N 1000KHZ dB/M 68
1400KHZ dB/M 68
6 S/N RATIO @5mV 1000KHZ dB
8 ACA 10KHZ 1000KHZ dB 10
600KHZ dB
IF REJECTION 1000KHZ dB
1400KHZ dB
IMAGE REJECTION 1400KHZ dB
A .G .C figur of merit @ 100mV 1000KHZ dB 38 30
OVERLOAD DISTORTION@100mV 80% MOD 1000KHZ % 4 8
DISTORTION 30% MOD 74dB INPUT 1000KHZ %
HUM/NOISE OUTPUT @VOL.MIN 1000KHZ mV 4 8
FEDELITY-6dB @5AMV HZ 80-3000 150-2200
WHISTLE(5mV/M) @2ND KHZ % / /
@3RD KHZ % / /
VR.MAX.DISTORTION % 25
POWER OUTPUT@10% T.H.D 1000KHZ W
MAX OUTPUT POWER 1000KHZ W
1
SPECIFICATIONS
MODEL NUMBER TR-951AUB
CD27USB
DATE 2007/12/28
TEST CONDITION:
1.POWER SUPPLY VOLTAGE:AC220 V, 50 HZ
2.STANDARD MODULATION:1000HZ,22.5KHZ Deviation(MPX75KHZ DEV)
3.REFERENCE OUTPUT:50mw
4.RESISTIVE LOAD:4 OHM
5.L+R=45%, L-R=45%, PILOT=10%
FM
NO. TEST ITEMS FREQ UNIT NORMAL LIMIT DATA
TUNING RANGE MHZ 87.5
MHZ 108.5
INTERMEDIATE FREQUENCY MHZ
DIAL CALIBRATION 88MHZ KHZ
100MHZ KHZ
106MHZ KHZ /
MAX SENSITIVITY 90MHZ dB 15 24
98MHZ dB 15 24
106MHZ dB 15 24
USEADLE SENSITIVITY 30dB S/N 90MHZ dB
98MHZ dB 26
106MHZ dB 26
6 S/N RATIO @1mV 98MHZ dB
7 HUM MODULATION 100dB INPUT 98MHZ dB / /
8 (-3dB)LIMITING SENSITIVITV 98MHZ dB 30
AFC HOLDING RANGE -3dB 98MHZ KHZ / /
IF REJECTION 90MHZ dB
IMAGE REJECTION 106MHZ dB
AM SUPPRESSION AT 60dB INPIT 98MHZ dB
OVERLOAD CAPACITY 75KHZ DEV 98MHZ dB /
T.H.D.22.5KHZ AT 60dB INPUT 98MHZ % 1 3
HUM/NOISE OUTPUT @VOL.MIN. mV
FREQ.RESPONSE -6dB 50us PRE-AMP HZ 80-5.5K 150-3K
SEPARATION 100HZ dB / /
1KHZ dB
10KHZ dB / /
POW OUTPUT @ 10% T.H.D 98MHZ W
MAX OUTPUT POWER 98MHZ W
STEREO INDICATOR SENSTIVITY dB
2
SPECIFICATIONS
MODEL NUMBER TR-951AUB
CD27USB
DATE 2007/12/28
TEST CONDITION:
1.POWER SUPPLY VOLTAGE:AC 220 V, 50 HZ
2.STANDARD MODULATION:
3.REFERENCE OUTPUT:50mw
4.RESISTIVE LOAD:4 OHM
CD/MP3
NO. TEST ITEMS TAPE UNIT NORMAL LIMIT DATA
S/N RATIO(WITH JIS-A) TCD-784 1KHZ dB
CHANNEL SEPARATION TCD-784 1KHZ dB
CHANNEL BALANCE TCD-784 1KHZ dB /-1 /-3
DISTORTION TCD-784 1KHZ % 1
VR.MAX.DISTORTION(2 ) TCD-784 % 20 25
10% THD OUTPUT POWER TCD-784 W 2.5
MAXIMUM OUTPUT POWER TCD-784 W
DYNAMIC RANGE 1KHZ dB / /
1KHZ dB
20HZ dB / /
9 CD IN FREQUENCY RESPONSE 1K=0dB 100HZ dB /-6
10K dB /-6
20K dB / /
10 FF/FB MUTE LEVEL 1KHZ dB 10
HUN & NOISE VOL.MIN mV
VOL.MAX mV
INTERRUPTION WITHOUT NOISE SBC-444A um 700
BLACK DOT WITHOUT NOISE SBC-444A um 600
FINGERPRINT WITHOUT NOISE SBC-444A um 65
ECCENTERICITY WITHOUT NOISE TCD-712 um 140 ( /-15)
PHILIPS NR5A SEC
ACCESSS OPERATION TIME
PHILIPS NR5A SEC
AUDIO BALANCE FM 60dB/M INPUT 75KHZ DEV dB /-5
AM 74dB/M INPUT 80% MOD dB /-5
TAPE PLAY(MTT-112BN 0dB) dB
CD.PLAY(TCD 784 1KHZ 0dB) dB /-5
RECOR/PLAY BACK(FM 1KHZ I/P) 75KHZ DEV dB /-5
BASS BOOST EFFECT 100Hz dB
4
TR-951AUB
5
6
7
8
5673-9259.sch-1 - Fri Feb 20 14:53:09 2009
9
10
11
1
12
Item No Part Description specification unit QTY
TR-951AUB CD PCB part
TR-951AUB output pc
TR-951AUB M5673 main pcb
13
Oscillator
/Oscillator
14
TR-951AUB USB/SPK/PHONES PCB
TR-951AUB M5673 SD CD pcb parts
Oscillator
/Oscillator
15
TR-951AUB M5673 SD CD pcb parts
P10-100GCP/25L1005MC (M5673 27USB/SD Firmware)
TR-951AUB M5673 USB pcb parts
TR-951AUB/USB M5673 accessory parts
dia. 3MM RED 3V L=30MM
16
TR-951AUB ASSEMBLEING parts
CD-27 ASSEMBLEING
plastic parts . M01-203-MP327/USB
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
475 grey
17
475 grey
475 grey
475 grey
475 grey
black
black
black
black
black
black
black
black
black
black
black
ABS-757 raw material
475 grey
475 grey
black
black
18
475 grey
475 black
475 grey
black
475 grey
P07-089-0001
black
METAL PARTS
L=40MM
sanyo brand
black HF-01-D 180*280MM
EI-48*23.5(horizontal)input:110/220VAC
output:1200MA/10.5VAC
110V/220V
3.5 inch/4 OHM/5W/ dia45
1.5 inch/8 Ohm/5W/dia 32
TR-951AUB/USB packing parts
19
M01-100-S5L8020-(USB+SD)
