Image preview - the first page of the document
daewoo_sm_14h3t1


>> Download daewoo_sm_14h3t1 documenatation <<

Text preview - extract from the document
                                                                 S/M No. : TCP082AEFO



Service Manual
TV / VCR Combination
CHASSIS : CP-082
Model : 14H3T1




      SPECIFICATIONS
    ITEMS             MODEL             14H3T1                                                                REMARK



  TV SECTION        STANDARD            PAL-I/II(GB MODEL),PAL-B/G(BLANK MODEL),PAL-B/G,SECAM-L/L(F MODEL)
                                        PAL/SECAM-B/G,DK(K MODEL)
                   SCREEN SIZE          14":A34JLL90X01, A34AGT14X71, A33EKC01X01, A34EAC01X06



                  MAIN VOLTAGE          220~240V AC,50Hz
                      POWER             STAND BY MODE : BELOW 5 Watts
                  CONSUMPTION           OPERATION MODE : 14"=59Watts, 20"=65Watts, 21"=69Watts
                 SOUND OUTPUT           1Wmin(14"), 1.5Wmin(20"), 1.5Wmin(21")
                     SPEAKER            3Watts 8 Ohm
               ANTENNA IMPEDANCE        75 Ohm unbalanced input
                 TUNING SYSTEM          FVS(FREQUENCY SYNTHESIS) TUNING
                      TUNER             VHF-L : E2-S7, VHF-H : S8-S36, UHF : S37-E69 (PAL-I=UHF ONLY)
                NUMBER OF PROGRAM       100 PROGRAM
                  AUX. TERMINAL         SCART JACK(REAR) , RCA JACK(AV2 FRONT), HEADPHONE JACK
                REMOTE CONTROLLER       R-46C with 2 "AAA" type batteries
                 OTHER FEATURE          ON SCREEN DISPLAY, SLEEP TIMER, WAKE UP TIMER, FULL AUTO SEARCH,
                                        MANUAL/FINE TUNING,CHILD LOCK, PANEL LOCK, AUTO REPEAT,
                                        PICTURE TYPE SELECTION (NORMAL 1/2, FAVOURITE), INDEX SEARCH, TV/AV
    VIDEO        SINGLE SYSTEM          PAL/SECAM colour and CCIR mono chrome signals, 625lines/50fields.
   SECTION       RECORDING SYSTEM       2HEAD / 4HEAD
                       INPUT            1Vp-p, 75 ohm, unbalanced
                      OUTPUT            1Vp-p, 75 ohm, unbalanced
                SIGNAL TO NOISE RATIO   45dB with NETTETE IMAGE control at center position
               HORIZONTAL RESOLUTION    240lines with NETTETE IMAGE control at center position
    AUDIO      RECORDING SYSTEM         LONGITUDINAL TRACK
                       INPUT            -3.8dBm(500m Vrms), more than 47 Kohms, unbalanced
                      OUTPUT            -3.8dBm(500m Vrms), less than 1 Kohms, unbalanced
               FREQUENCY RANGE          100Hz to 8KHz
                SIGNAL TO NOISE RATIO   40dB(more than)
   GENERA          TEMPERATRE           5oC to 35oC(operating), -20oC to 60oC (storage temperature)
                      FORMAT            standard
                    TAPE WIDTH          12.65mm
                   TAPE SPEED           SP : 23.39mm/sec, LP : 11.70mm/sec
                  WITH FULLSIZE         SP : 240 min, win E-240 video cassette
                    CASSETTE            LP : 480min, win E-240 video cassette




DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr                                                                   April.2001
SPECIFICATION
CAUTION

                          MODEL      14H3T1                                                               REMARK
  ITEMS


TV        STANDARD                   PAL-I/II(GB MODEL),PAL-B/G(BLANK MODEL),PAL-B/G,SECAM-L/L(F MODEL)
SECTION                              PAL/SECAM-B/G,DK(K MODEL)
          SCREEN SIZE                14":A34JLL90X01, A34AGT 14X71, A33EKC01X01, A34EAC01X06



          MAIN VOLTAGE               220~240V AC,50Hz
          POWER                      STAND BY MODE : BELOW 5 Watts
          CONSUMPTION                OPERATION MODE : 14"=59Watts, 20"=65Watts, 21"=69Watts
          SOUND OUTPUT               1Wmin(14"), 1.5Wmin(20"), 1.5Wmin(21")
          SPEAKER                    3Watts 8 Ohm
          ANTENNA IMPEDANCE          75 Ohm unbalanced input
          TUNING SYSTEM              FVS(FREQUENCY SYNTHESIS) TUNING
          TUNER                      VHF-L : E2-S7,
                                     VHF-H : S8-S36,
                                     UHF : S37-E69 (PAL-1=UHF ONLY)
          NUMBER OF PROGRAM          100 PROGRAM
          AUX, TERMINAL              SCART JACK(REAR) , RCA JACK(AV2 FRONT), HEADPHONE JACK
          REMOTE CONTROLLER          R-46C with "AAA" type batteries
          OTHER FEATURE              ON SCREEN DISPLAY, SLEEP TIMER, WAKE UP TIMER
                                     FULL AUTO SEARCH, MANUAL/FINE TUNING
                                     CHILD LOCK, PANEL LOCK, AUTO REPEAT,
                                     PICTURE TYPE SELECTION (NORMAL 1/2, FAVOURITE),
                                     INDEX SEARCH, TV/AV
VIDEO     SINGLE SYSTEM              PAL/SECAM colour and CCIR mono chrome signals, 625lines/50fidlds.
SECTION RECORDING SYSTEM             2 HEAD / 4 HEAD
          INPUT                      1Vp-p, 75 ohm, unbalanced
          OUTPUT                     1Vp-p, 75 ohm, unbalanced
          SIGNAL TO NOISE RATIO      45dB with NETTETE IMAGE control at center position
          HORIZONTAL RESOLUTION 240lines with NETTETE IMAGE control at center position
AUDIO     RECORDING SYSTEM           LONGITUDINAL TRACK
          INPUT                      -3.8dBm(500m Vrms), more than 47 Kohms, unbalanced
          OUTPUT                     -3.8dBm(500m Vrms). less than 1 Kohms, unbalanced
          FREQUENCY RANGE            100Hz to 8KHz
          SIGNAL TO NOISE RATIO      40dB(more than)
GENERA TEMPERATRE                    5oC to 35oC(operating)
                                     -20oC to 60oC (storage temperature)
          FORMAT                     standard
          TAPE WIDTH                 12.65mm
          TAPE SPEED                 SP : 23.39mm/sec, LP : 11.70mm/sec
          WITH FULLSIZE              SP : 240 min, win E-240 video cassette
          CASSETTE                   LP : 480min, win E-240 video cassette




                                                                 2
CIRCUIT BLOCK DIAGRAM




                 3
SCHEMATIC DIAGRAM




                    -4-
SCHEMATIC DIAGRAM




                    -5-
 EXPLODED VIEW

1. 14H3




                 6
SERVICE PARTS LIST

 CAUTION
         "       " is safety component, so it must be used the same component.
         "   R   " is recomendable part for stock.




* Model : 14H3T1
 LOC         PART CODE          PART NAME             DESCRIPTION           REMARK LOC      PART CODE         PART NAME          DESCRIPTION         REMARK
 ZZ100       48B4446C16   TRANSMITTER REMOCON   R-46C16 (AAA)                R       DQ02   DLH2PR----   LED BLOCK         LH-2P-R
 ZZ110       PTACPWA668   ACCESSORY AS          DVT-14H3LA                           I151   1TDA9802--   IC RF             TDA9802                   R

 10          4850Q00910   BATTERY               R03/NN                               I501   1TDA8842N2   IC VIDEO          TDA8842/N2                R

 20          4850A03310   ANT ROD               PH-RM-008A                           I502   1KA7808---   IC REGULATOR      KA7808                    R

 ZZ120       PTBCSHA668 COVER BACK AS           DVT-14H3LA                  R        I601   PTJ1SW8902   HEAT SINK ASS`Y   1TDA8943SF + 7174300811
 M211        4852158501   COVER BACK            HIPS GY                              1      1TDA8943SF   IC AUDIO AMP      TDA8943SF                 R

 M781        4857817610   CLOTH BLACK           FELT 300X20X0.7                      0000A 4857018902    HEAT SINK         A1050P-H24
 ZZ130       PTPKCPA668   PACKING AS            DVT-14H3LA                           0000B 7174300811    SCREW TAPPTITE    TT2 RND 3X8 MFZN
 M801        4858035800   BOX CARTON            "SW-3 DVT-1488,1484"                 I701   1SDA555XFL   IC MICOM OTP      SDA555XFL                 R

 M801A 6520010100         STAPLE PIN            18M/M J D O                          I702   1AT24C16PC   IC                AT24C16-10PC              R

 M811        4858195900   PAD                   EPS 14H3                             IA01   1TC4053BP-   IC                TC4053BP                  R

 M821        4858213800   BAG INSTRUCTION       L.D.P.E T0.05X250X400                IA03   1TC4066BP-   IC                TC 4066BP                 R

 M822        4858215700   BAG PE                PE FOAM t0.5x1050X950                IA60   1TC4053BP-   IC                TC4053BP                  R

 ZZ131       48519A4710   CRT GROUND NET        1401S-1015-1P                        IL01   1STV8225--   IC SIF            STV8225                   R

 ZZ132       58G0000084   COIL DEGAUSSING       DC-1450                              IL20   1TA1238N--   IC SECAM.L        TA1238N                   R

 ZZ140       PTCACAA668   CABINET AS            DVT-14H3LA                   R       IL50   1STV8225--   IC SIF            STV8225                   R

 M191        4851944400   BUTTON CTRL           4948301+5543100              R       IN02   1K1A6801K-   IC MOTOR DRIVER   KIA6801K                  R

 M191A 7178301011         SCREW TAPPTITE        TT2 WAS 3X10 MFZN                    IQ01   1KRT30----   IC PREAMP         KRT30                     R

 M201A 4856013300         SCREW CRT FIXING      30X80 BK                             JA01   4859109950   JACK PIN BOARD    PH-JB-9710A
 M201B 4856013301         SCREW CRT FIXING      30X140 YL                            JS01   4859200401   SOCKET RGB        YRS21-R1
 M201C 4856215402         WASHER RUBBER         CR T2.0                              L155   58B0000S88   COIL PIF          TRF-7780A (STICK)
 M211A 7172401612         SCREW TAPPTITE        TT2 TRS 4X16 MFZN BK                 M041   97P0475800   CASE SHI PREAMP   ET T0.4
 M281        4852817761   DOOR F/L              ABS GY                               M191   4851931000   DECK AS           DRS-9400N                 R

 M281A 4856723400         SPRING                SWPB 0.4                             M191A 7172401612    SCREW TAPPTITE    TT2 TRS 4X16 MFZN BK
 M461        97P4602700   CLAMP CORD            NYLON 66 BLK 5280N                   M191B 7178301212    SCREW TAPPTITE    TT2 WAS 3X12 MFZN BK
 M481        4854858901   BUTTON POWER          ABS GY                       R       M191C 97P0919100    PLATE EARTH AB    SUS 304 CSP T=0.2
 M481A 4856716000         SPRING                SWPA PIE0.5                          M191D 7278300611    SCREW TAPPTITE    TT3 WAS 3X6 MFZN
 M541        4855415800   SPEC PLATE            150ART P/E FILM (C/TV)               M381   4853818100   FRAME MAIN PCB    FR HIPS BK
 M561        48556136SS   MARK BRAND            SILVER ETCHING DIA-CUTTIN            M381A 7178301011    SCREW TAPPTITE    TT2 WAS 3X10 MFZN
 SP01A 4856013600         SCREW SPKR FIX        SWRM+SECC                            M391   4853948400   BRKT EARTH        C5212P-1/2M T0.15
 V901        4859609841   CRT                   A34AGT14X71 P38                      M392   4853953200   BRKT PCB          FR HIPS BK
 ZZ200       PTFMSJA668   MASK FRONT AS         DVT-14H3LA                   R       M392A 7172401612    SCREW TAPPTITE    TT2 TRS 4X16 MFZN BK
 M201        4852076601   MASK FRONT            HIPS GY                              M392B 7178301011    SCREW TAPPTITE    TT2 WAS 3X10 MFZN
 M331        4853312501   RETA BACK             HIPS NC                              M721   4857248300   SHIELD TOP        SECC T0.8
 ZZ202       PTSPPWA668 SPEAKER AS              DVT-14H3LA                   R       M721A 7172401612    SCREW TAPPTITE    TT2 TRS 4X16 MFZN BK
 PA601       4850703S50   CONNECTOR             YH025-03+35098+ULW=200               M721D 7178301011    SCREW TAPPTITE    TT2 WAS 3X10 MFZN
 SP01        48A8306000   SPEAKER SYSTEM        SS-5070A01 3W 8 OHM         R        M722   4857243000   SHIELD BOTTOM     SECC-O T0.5
 ZZ290       PTMPMSA668 PCB MAIN MANUAL AS      DVT-14H3LA                  R        M722A 7178301011    SCREW TAPPTITE    TT2 WAS 3X10 MFZN
 DN03        DS15312H--   LED IR                SI5312-H                             M722B 7178301011    SCREW TAPPTITE    TT2 WAS 3X10 MFZN
 DN03A 97P2339600         HOLDER IR             ABS                                  M791   4857913304   RUBBER CUSHION    FR RUBBER SPONGE
 DQ01        DLH2PR----   LED BLOCK             LH-2P-R                              P101   485923162S   CONN WAFER        YW025-03 (STICK)




                                                                                 9
                                                                                                                    SERVICE PARTS LIST



LOC     PART CODE        PART NAME               DESCRIPTION           REMARK    LOC   PART CODE       PART NAME        DECSCRIPTION        REMARK
P601    485923162S   CONN WAFER            YW025-03 (STICK)                      CC169 HCBK472KCA   C CHIP CERA    50V X7R 4700PF K 2012
PA801   4850712V11   CONNECTOR             YH025-12+YST025+ULW=200               CC170 HCBK102KCA   C CHIP CERA    50V X7R 1000PF K 2012
PA802   4850709S01   CONNECTOR             YH025-09+YST025+ULW=200               CC175 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
PA803   4850707S01   CONNECTOR             YH025-07+YST025+ULW=200               CC501 HCQK221JCA   C CHIP CERA    50V CH 220PF J 2012
PA901   4850705S04   CONNECTOR             YH025-05+YST025+ULW=400               CC502 HCQK151JCA   C CHIP CERA    50V CH 150PF J 2012
PAY01   4850706V10   CONNECTOR             60-8283-3068-45+UAW=150               CC504 HCQK560JCA   C CHIP CERA    50V CH 56PF J 2012
PAY04   4850702V07   CONNECTOR             BIC-02H-20T+USW=100                   CC506 HCQK100JCA   C CHIP CERA    50V CH 10PF J 2012
PN02    4859292320   CONN WAFER            GF120-07S-TS                          CC512 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
PN02A 4859200270     CONN FFC              K-7X140-0.25                          CC514 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
PN03    4859278220   CONN WAFER            TKC-G10P-A1                           CC517 HCQK181JCA   C CHIP CERA    50V CH 180PF J 2012
PNA01 4850707V03     CONNECTOR             60-8283-3078-45+ULW=100               CC526 HCQK150JCA   C CHIP CERA    50V CH 15PF J 2012
PY02    4859292320   CONN WAFER            GF120-07S-TS                          CC527 HCQK150JCA   C CHIP CERA    50V CH 15PF J 2012
PY03    485923202S   CONN WAFER            YW025-07 (STICK)                      CC528 HCFK474ZCA   C CHIP CERA    Y5V 50V 0.47MF Z 2012
RN30    RS02Y399JS   R M-OXIDE FILM        2W 3.9 OHM J SMALL                    CC529 HCBK472KCA   C CHIP CERA    50V X7R 4700PF K 2012
SF150   5PJ1952M--   FILTER SAW            J1952M                                CC530 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
SF501   5PJ1952M--   FILTER SAW            J1952M                                CC533 HCQK181JCA   C CHIP CERA    50V CH 180PF J 2012
SFL01   5PL9653M--   FILTER SAW            L9653M                                CC535 HCBK332KCA   C CHIP CERA    50V X7R 3300PF K 2012
SFL50   5PL9653M--   FILTER SAW            L9653M                                CC536 HCBK472KCA   C CHIP CERA    50V X7R 4700PF K 2012
SN01    TST5811---   TR PHOTO              ST-5811                               CC538 HCQK181JCA   C CHIP CERA    50V CH 180PF J 2012
SN01A 97P2343500     HOLDER TR             ABS FR                                CC539 HCQK181JCA   C CHIP CERA    50V CH 180PF J 2012
SN02    TST5811---   TR PHOTO              ST-5811                               CC540 HCBK102KCA   C CHIP CERA    50V X7R 1000PF K 2012
SN02A 97P2343500     HOLDER TR             ABS FR                                CC543 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
SN03    4850S00001   SENSOR REEL           SG-258S                               CC545 HCBK392KCA   C CHIP CERA    50V X7R 3900PF K 2012
SN04    4850S00001   SENSOR REEL           SG-258S                               CC546 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
SWN01 5SN0101Z20     SW DETECT             JDS1105-6XD                           CC548 HCBK102KCA   C CHIP CERA    50V X7R 1000PF K 2012
TU01    5800000032   COIL OSC              DE0-006                               CC550 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
U101    4859721030   TUNER VARACTOR        TAEL-G772D                  R         CC552 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
U150    4859719730   TUNER VARACTOR        DT5-BF15P                   R         CC554 HCQK151JCA   C CHIP CERA    50V CH 150PF J 2012
U150A   4859004650   PLUG PHONE AS         PLUG+CABLE1365 AWG26=250B             CC576 HCBK472KCA   C CHIP CERA    50V X7R 4700PF K 2012
X701    5XE6R0000C   CRYSTAL QUARTZ        HC-49/U 6.000MHZ 20PPM                CC602 HCBK822KCA   C CHIP CERA    50V X7R 8200PF K 2012
X702    5XYR03276C   CRYSTAL QUARTZ        C-001R 32.768000KHZ 20PPM             CC619 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
XL20    5XJX4R286C   CRYSTAL QUARTZ        HC-49S 4.286000M 20PPM TP             CC620 HCBK102KCA   C CHIP CERA    50V X7R 1000PF K 2012
XN01    5XJ16R000E   CRYSTAL QUARTZ        HC-49S 16.000000MHZ 30PPM             CC621 HCBK102KCA   C CHIP CERA    50V X7R 1000PF K 2012
XY01    5XJX4R433B   CRYSTAL QUARTZ        HC-49S 4.433619M 15PPM TP             CC703 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
Z154    5PYXT5R5MB FILTER CERA             XT 5.5MB                              CC705 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
Z503    5PYXT5R5MB FILTER CERA             XT 5.5MB                              CC708 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
ZZ200   PTMPJ2A668   PCB CHIP MOUNT B AS   DVT-14H3LA                            CC710 HCBK472KCA   C CHIP CERA    50V X7R 4700PF K 2012
CC150   HCBK103KCA C CHIP CERA             50V X7R 0.01MF K 2012                 CC712 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC156   HCBK102KCA C CHIP CERA             50V X7R 1000PF K 2012                 CC713 HCQK221JCA   C CHIP CERA    50V CH 220PF J 2012
CC157   HCFK104ZCA   C CHIP CERA           50V Y5V 0.1MF Z 2012                  CC715 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC159   HCFK104ZCA   C CHIP CERA           50V Y5V 0.1MF Z 2012                  CC716 HCFK104ZCA   C CHIP CERA    50V Y5V 0.1MF Z 2012
CC160   HCQK820JCA C CHIP CERA             50V CH 82PF J 2012                    CC717 HCBK223KCA   C CHIP CERA    50V X7R 0.022MF K 2012
CC161   HCBK333KCA C CHIP CERA             50V X7R 0.033MF K 2012                CC719 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC162   HCBK333KCA C CHIP CERA             50V X7R 0.033MF K 2012                CC720 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC163   HCBK223KCA C CHIP CERA             50V X7R 0.022MF K 2012                CC721 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC165   HCFK104ZCA   C CHIP CERA           50V Y5V 0.1MF Z 2012                  CC722 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012
CC167   HCQK560JCA C CHIP CERA             50V CH 56PF J 2012                    CC724 HCBK103KCA   C CHIP CERA    50V X7R 0.01MF K 2012




                                                                                10
SERVICE PARTS LIST


LOC     PART CODE        PART NAME         DESCRIPTION        REMARK    LOC    PART CODE         PART NAME        DECSCRIPTION        REMARK
CC726   HCQK330JCA C CHIP CERA       50V CH 33PF J 2012                CCN32 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CC727   HCQK330JCA C CHIP CERA       50V CH 33PF J 2012                CCP01 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CC728   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCP03 HCBK473KCA C CHIP CERA          50V X7R 0.047MF K 2012
CC730   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCP05 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CC732   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCQ01 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CC734   HCQK221JCA C CHIP CERA       50V CH 220PF J 2012               CCU06 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CC735   HCQK151JCA C CHIP CERA       50V CH 150PF J 2012               CCU09 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CC736   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCU11 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCA01 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCU20 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCA02 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCU27 HCBK222KCA C CHIP CERA          50V X7R 2200PF K 2012
CCA03 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCY04 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCA04 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCY08 HCQK509DCA C CHIP CERA          50V CH 5PF D 2012
CCA05 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCY09 HCQK391JCA C CHIP CERA          50V CH 390PF J 2012
CCA07 HCBK102KCA C CHIP CERA         50V X7R 1000PF K 2012             CCY11 HCQK201JCA C CHIP CERA          50V CH 200PF J 2012
CCA18 HCQK101JCA C CHIP CERA         50V CH 100PF J 2012               CCY15 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCA64 HCBK472KCA C CHIP CERA         50V X7R 4700PF K 2012             CCY25 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCL01   HCQK220JCA C CHIP CERA       50V CH 22PF J 2012                CCY27 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCL02   HCQK820JCA C CHIP CERA       50V CH 82PF J 2012                CCY31 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCL03   HCQK220JCA C CHIP CERA       50V CH 22PF J 2012                CCY32 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCL08   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             CCY35 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCL09   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             CCY46 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCL11   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCY47 HCBK473KCA C CHIP CERA          50V X7R 0.047MF K 2012
CCL20   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             CCY48 HCBK103KCA C CHIP CERA          50V X7R 0.01MF K 2012
CCL21   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCY50 HCQK510JCA C CHIP CERA          50V CH 51PF J 2012
CCL22   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              CCY51 HCQK300JCA C CHIP CERA          50V CH 30PF J 2012
CCL23   HCQK150JCA C CHIP CERA       50V CH 15PF J 2012                CCY52 HCQK300JCA C CHIP CERA          50V CH 30PF J 2012
CCL24   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             CCY54 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCL26   HCQK101JCA C CHIP CERA       50V CH 100PF J 2012               CCY55 HCQK300JCA C CHIP CERA          50V CH 30PF J 2012
CCL27   HCQK101JCA C CHIP CERA       50V CH 100PF J 2012               CCY56 HCQK300JCA C CHIP CERA          50V CH 30PF J 2012
CCL28   HCBK333KCA C CHIP CERA       50V X7R 0.033MF K 2012            CCY57 HCQK510JCA C CHIP CERA          50V CH 51PF J 2012
CCL30   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             CCY60 HCFK104ZCA     C CHIP CERA      50V Y5V 0.1MF Z 2012
CCL31   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             DC154   DBB639C--B   DIODE CHIP       BB639C
CCL32   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             ICN01   1DW777FE1Q IC MICOM           DW37777MAH-FE1(408GP)
CCL33   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             ICP01   1LC74793--   IC VPS           LC74793JM
CCL36   HCBK473KCA C CHIP CERA       50V X7R 0.047MF K 2012            ICY01   1LA71598MQ   IC CHIP Y/C      LA71598SM
CCL39   HCBK473KCA C CHIP CERA       50V X7R 0.047MF K 2012            QC150 T2SA812T2B     TR CHIP          2SA812-T2B
CCL40   HCBK103KCA C CHIP CERA       50V X7R 0.01MF K 2012             QC151 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCL41   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              QC152 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCL50   HCQK220JCA C CHIP CERA       50V CH 22PF J 2012                QC153 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCL51   HCQK820JCA C CHIP CERA       50V CH 82PF J 2012                QC501 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCL52   HCQK220JCA C CHIP CERA       50V CH 22PF J 2012                QC502 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCL53   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              QC503 T2SA812T2B     TR CHIP          2SA812-T2B
CCL56   HCFK104ZCA   C CHIP CERA     50V Y5V 0.1MF Z 2012              QC504 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCN07 HCFK104ZCA     C CHIP CERA     50V Y5V 0.1MF Z 2012              QC505 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCN14 HCBK103KCA C CHIP CERA         50V X7R 0.01MF K 2012             QC506 T2SA812T2B     TR CHIP          2SA812-T2B
CCN29 HCBK332KCA C CHIP CERA         50V X7R 3300PF K 2012             QC507 T2SC1623T2     TR CHIP          2SC1623-L6/T2B
CCN30 HCBK182KCA C CHIP CERA         50V X7R 1800PF K 2012             QC508 T2SC1623T2     TR CHIP          2SC1623-L6/T2B




                                                                  11
                                                                                                         SERVICE PARTS LIST



LOC     PART CODE       PART NAME        DESCRIPTION       REMARK    LOC    PART CODE        PART NAME        DECSCRIPTION      REMARK
QC509   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC167   HRFT223JCA   R CHIP          1/10 22K OHM J 2012
QC601   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC168   HRFT104JCA   R CHIP          1/10 100K OHM J 2012
QC603   T2SA812T2B   TR CHIP        2SA812-T2B                      RC169   HRFT104JCA   R CHIP          1/10 100K OHM J 2012
QC604   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC174   HRFT154JCA   R CHIP          1/10 150K OHM J 2012
QC605   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC175   HRFT753JCA   R CHIP          1/10 75K OHM J 2012
QC701   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC176   HRFT152JCA   R CHIP          1/10 1.5K OHM J 2012
QC702   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC178   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
QC703   T2SA812T2B   TR CHIP        2SA812-T2B                      RC179   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
QC704   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC501   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012
QC706   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC502   HRFT561JCA   R CHIP          1/10 560 OHM J 2012
QC707   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC503   HRFT101JCA   R CHIP          1/10 100 OHM J 2012
QC708   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC504   HRFT562JCA   R CHIP          1/10 5.6K OHM J 2012
QC711   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC505   HRFT270JCA   R CHIP          1/10 27 OHM J 2012
QCA01   T2SA812T2B   TR CHIP        2SA812-T2B                      RC506   HRFT681JCA   R CHIP          1/10 680 OHM J 2012
QCA02   T2SA812T2B   TR CHIP        2SA812-T2B                      RC507   HRFT182JCA   R CHIP          1/10 1.8K OHM J 2012
QCA03   T2SA812T2B   TR CHIP        2SA812-T2B                      RC508   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
QCA04   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC509   HRFT391JCA   R CHIP          1/10 390 OHM J 2012
QCA05   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC512   HRFT331JCA   R CHIP          1/10 330 OHM J 2012
QCA09   T2SA812T2B   TR CHIP        2SA812-T2B                      RC514   HRFT241JCA   R CHIP          1/10 240 OHM J 2012
QCA10   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC515   HRFT151JCA   R CHIP          1/10 150 OHM J 2012
QCA11   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC516   HRFT750JCA   R CHIP          1/10 75 OHM J 2012
QCA14   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC517   HRFT750JCA   R CHIP          1/10 75 OHM J 2012
QCL01   TKTC3881-B   TR CHIP        KTC3881                         RC518   HRFT750JCA   R CHIP          1/10 75 OHM J 2012
QCL02   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC523   HRFT753JCA   R CHIP          1/10 75K OHM J 2012
QCL20   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC524   HRFT182JCA   R CHIP          1/10 1.8K OHM J 2012
QCL21   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC526   HRFT104JCA   R CHIP          1/10 100K OHM J 2012
QCL22   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC528   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
QCL23   T2SA812T2B   TR CHIP        2SA812-T2B                      RC529   HRFT153JCA   R CHIP          1/10 15K OHM J 2012
QCL50   TKTC3881-B   TR CHIP        KTC3881                         RC530   HRFT393JCA   R CHIP          1/10 39K OHM J 2012
QCL52   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC532   HRFT103JCA   R CHIP          1/10 10K OHM J 2012
QCN01   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC534   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
QCP01   T2SA812T2B   TR CHIP        2SA812-T2B                      RC536   HRFT470JCA   R CHIP          1/10 47 OHM J 2012
QCY01   TKTC3121-B   TR CHIP        KTC3121-B                       RC537   HRFT103JCA   R CHIP          1/10 10K OHM J 2012
QCY02   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC540   HRFT303JCA   R CHIP          1/10 30K OHM J 2012
QCY03   T2SA812T2B   TR CHIP        2SA812-T2B                      RC541   HRFT103JCA   R CHIP          1/10 10K OHM J 2012
QCY04   T2SA812T2B   TR CHIP        2SA812-T2B                      RC542   HRFT273JCA   R CHIP          1/10 27K OHM J 2012
QCY05   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC544   HRFT271JCA   R CHIP          1/10 270 OHM J 2012
QCY06   T2SC1623T2   TR CHIP        2SC1623-L6/T2B                  RC548   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012
RC105   HRFT183JCA   R CHIP         1/10 18K OHM J 2012             RC549   HRFT272JCA   R CHIP          1/10 2.7K OHM J 2012
RC150   HRFT101JCA   R CHIP         1/10 100 OHM J 2012             RC550   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
RC154   HRFT392JCA   R CHIP         1/10 3.9K OHM J 2012            RC551   HRFT112JCA   R CHIP          1/10 1.1K OHM J 2012
RC156   HRFT822JCA   R CHIP         1/10 8.2K OHM J 2012            RC553   HRFT561JCA   R CHIP          1/10 560 OHM J 2012
RC160   HRFT242JCA   R CHIP         1/10 2.4K OHM J 2012            RC554   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
RC161   HRFT182JCA   R CHIP         1/10 1.8K OHM J 2012            RC555   HRFT331JCA   R CHIP          1/10 330 OHM J 2012
RC162   HRFT302JCA   R CHIP         1/10 3K OHM J 2012              RC556   HRFT102JCA   R CHIP          1/10 1K OHM J 2012
RC164   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RC557   HRFT103JCA   R CHIP          1/10 10K OHM J 2012
RC165   HRFT561JCA   R CHIP         1/10 560 OHM J 2012             RC558   HRFT821JCA   R CHIP          1/10 820 OHM J 2012




                                                                12
SERVICE PARTS LIST



LOC     PART CODE       PART NAME        DESCRIPTION       REMARK   LOC   PART CODE        PART NAME         DECSCRIPTION     REMARK
RC559   HRFT242JCA   R CHIP         1/10 2.4K OHM J 2012            RCA38 HRFT391JCA   R CHIP          1/10 390 OHM J 2012

RC603   HRFT362JCA   R CHIP         1/10 3.6K OHM J 2012            RCA40 HRFT683JCA   R CHIP          1/10 68K OHM J 2012

RC604   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA41 HRFT683JCA   R CHIP          1/10 68K OHM J 2012

RC605   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA42 HRFT152JCA   R CHIP          1/10 1.5K OHM J 2012

RC606   HRFT332JCA   R CHIP         1/10 3.3K OHM J 2012            RCA44 HRFT471JCA   R CHIP          1/10 470 OHM J 2012

RC607   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCA45 HRFT221JCA   R CHIP          1/10 220 OHM J 2012

RC608   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCA46 HRFT221JCA   R CHIP          1/10 220 OHM J 2012

RC609   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA48 HRFT471JCA   R CHIP          1/10 470 OHM J 2012

RC702   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA49 HRFT221JCA   R CHIP          1/10 220 OHM J 2012

RC703   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA50 HRFT471JCA   R CHIP          1/10 470 OHM J 2012

RC704   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA51 HRFT750JCA   R CHIP          1/10 75 OHM J 2012

RC705   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA52 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RC706   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA53 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RC707   HRFT182JCA   R CHIP         1/10 1.8K OHM J 2012            RCA54 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RC708   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCA55 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RC713   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL01 HRFT470JCA   R CHIP          1/10 47 OHM J 2012

RC718   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCL02 HRFT222JCA   R CHIP          1/10 2.2K OHM J 2012

RC719   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCL03 HRFT101JCA   R CHIP          1/10 100 OHM J 2012

RC721   HRFT473JCA   R CHIP         1/10 47K OHM J 2012             RCL04 HRFT153JCA   R CHIP          1/10 15K OHM J 2012

RC722   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL05 HRFT751JCA   R CHIP          1/10 750 OHM J 2012

RC723   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL06 HRFT103JCA   R CHIP          1/10 10K OHM J 2012

RC725   HRFT243JCA   R CHIP         1/10 24K OHM J 2012             RCL07 HRFT682JCA   R CHIP          1/10 6.8K OHM J 2012

RC726   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL08 HRFT333JCA   R CHIP          1/10 33K OHM J 2012

RC727   HRFT680JCA   R CHIP         1/10 68 OHM J 2012              RCL24 HRFT102JCA   R CHIP          1/10 1K OHM J 2012

RC728   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCL25 HRFT333JCA   R CHIP          1/10 33K OHM J 2012

RC732   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCL26 HRFT123JCA   R CHIP          1/10 12K OHM J 2012

RC742   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL27 HRFT102JCA   R CHIP          1/10 1K OHM J 2012

RC744   HRFT103JCA   R CHIP         1/10 10K OHM J 2012             RCL28 HRFT202JCA   R CHIP          1/10 2K OHM J 2012

RC751   HRFT472JCA   R CHIP         1/10 4.7K OHM J 2012            RCL29 HRFT471JCA   R CHIP          1/10 470 OHM J 2012

RC752   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCL30 HRFT103JCA   R CHIP          1/10 10K OHM J 2012

RC753   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCL31 HRFT222JCA   R CHIP          1/10 2.2K OHM J 2012

RCA02   HRFT393JCA   R CHIP         1/10 39K OHM J 2012             RCL32 HRFT332JCA   R CHIP          1/10 3.3K OHM J 2012

RCA03   HRFT753JCA   R CHIP         1/10 75K OHM J 2012             RCL33 HRFT103JCA   R CHIP          1/10 10K OHM J 2012

RCA04   HRFT824JCA   R CHIP         1/10 820K OHM J 2012            RCL50 HRFT470JCA   R CHIP          1/10 47 OHM J 2012

RCA05   HRFT753JCA   R CHIP         1/10 75K OHM J 2012             RCL51 HRFT153JCA   R CHIP          1/10 15K OHM J 2012

RCA15   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCL52 HRFT222JCA   R CHIP          1/10 2.2K OHM J 2012

RCA19   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCL53 HRFT751JCA   R CHIP          1/10 750 OHM J 2012

RCA20   HRFT821JCA   R CHIP         1/10 820 OHM J 2012             RCL54 HRFT101JCA   R CHIP          1/10 100 OHM J 2012

RCA22   HRFT124JCA   R CHIP         1/10 120K OHM J 2012            RCL55 HRFT103JCA   R CHIP          1/10 10K OHM J 2012

RCA23   HRFT124JCA   R CHIP         1/10 120K OHM J 2012            RCL56 HRFT682JCA   R CHIP          1/10 6.8K OHM J 2012

RCA24   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCL60 HRFT223JCA   R CHIP          1/10 22K OHM J 2012

RCA25   HRFT124JCA   R CHIP         1/10 120K OHM J 2012            RCL61 HRFT333JCA   R CHIP          1/10 33K OHM J 2012

RCA26   HRFT124JCA   R CHIP         1/10 120K OHM J 2012            RCL62 HRFT333JCA   R CHIP          1/10 33K OHM J 2012

RCA27   HRFT102JCA   R CHIP         1/10 1K OHM J 2012              RCN01 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RCA35   HRFT223JCA   R CHIP         1/10 22K OHM J 2012             RCN02 HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012

RCA36   HRFT333JCA   R CHIP         1/10 33K OHM J 2012             RCN11 HRFT103JCA   R CHIP          1/10 10K OHM J 2012

RCA37   HRFT153JCA   R CHIP         1/10 15K OHM J 2012             RCN12 HRFT103JCA   R CHIP          1/10 10K OHM J 2012




                                                                13
                                                                                                               SERVICE PARTS LIST



 LOC    PART CODE        PART NAME         DESCRIPTION      REMARK    LOC    PART CODE       PART NAME             DECSCRIPTION            REMARK
RCN15   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCU23   HRFT470JCA   R CHIP               1/10 47 OHM J 2012
RCN16   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCU24   HRFT223JCA   R CHIP               1/10 22K OHM J 2012
RCN17   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCU25   HRFT103JCA   R CHIP               1/10 10K OHM J 2012
RCN18   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCU26   HRFT103JCA   R CHIP               1/10 10K OHM J 2012
RCN19   HRFT182JCA   R CHIP          1/10 1.8K OHM J 2012            RCU27   HRFT103JCA   R CHIP               1/10 10K OHM J 2012
RCN21   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCU31   HRFT684JCA   R CHIP               1/10 680K OHM J 2012
RCN22   HRFT105JCA   R CHIP          1/10 1M OHM J 2012              RCU34   HRFT153JCA   R CHIP               1/10 15K OHM J 2012
RCN23   HRFT511JCA   R CHIP          1/10 510 OHM J 2012             RCU37   HRFT103JCA   R CHIP               1/10 10K OHM J 2012
RCN24   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY01   HRFT223JCA   R CHIP               1/10 22K OHM J 2012
RCN25   HRFT106JCA   R CHIP          1/10 10M OHM J 2012             RCY06   HRFT122JCA   R CHIP               1/10 1.2K OHM J 2012
RCN26   HRFT104JCA   R CHIP          1/10 100K OHM J 2012            RCY08   HRFT331JCA   R CHIP               1/10 330 OHM J 2012
RCN34   HRFT221JCA   R CHIP          1/10 220 OHM J 2012             RCY09   HRFT272JCA   R CHIP               1/10 2.7K OHM J 2012
RCN35   HRFT273JCA   R CHIP          1/10 27K OHM J 2012             RCY10   HRFT201JCA   R CHIP               1/10 200 OHM J 2012
RCN36   HRFT221JCA   R CHIP          1/10 220 OHM J 2012             RCY11   HRFT561JCA   R CHIP               1/10 560 OHM J 2012
RCN37   HRFT273JCA   R CHIP          1/10 27K OHM J 2012             RCY12   HRFT561JCA   R CHIP               1/10 560 OHM J 2012
RCN41   HRFT332JCA   R CHIP          1/10 3.3K OHM J 2012            RCY13   HRFT152JCA   R CHIP               1/10 1.5K OHM J 2012
RCN44   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY14   HRFT472JCA   R CHIP               1/10 4.7K OHM J 2012
RCN45   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY18   HRFT563JCA   R CHIP               1/10 56K OHM J 2012
RCN46   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCY26   HRFT182JCA   R CHIP               1/10 1.8K OHM J 2012
RCN47   HRFT101JCA   R CHIP          1/10 100 OHM J 2012             RCY27   HRFT822JCA   R CHIP               1/10 8.2K OHM J 2012
RCN48   HRFT101JCA   R CHIP          1/10 100 OHM J 2012             RCY50   HRFT511JCA   R CHIP               1/10 510 OHM J 2012
RCN49   HRFT472JCA   R CHIP          1/10 4.7K OHM J 2012            RCY51   HRFT511JCA   R CHIP               1/10 510 OHM J 2012
RCN52   HRFT474JCA   R CHIP          1/10 470K OHM J 2012            RCY52   HRFT103JCA   R CHIP               1/10 10K OHM J 2012
RCN53   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY53   HRFT363JCA   R CHIP               1/10 36K OHM J 2012
RCP01   HRFT391JCA   R CHIP          1/10 390 OHM J 2012             RCY54   HRFT473JCA   R CHIP               1/10 47K OHM J 2012
RCP04   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY55   HRFT393JCA   R CHIP               1/10 39K OHM J 2012
RCP05   HRFT182JCA   R CHIP          1/10 1.8K OHM J 2012            RCY56   HRFT302JCA   R CHIP               1/10 3K OHM J 2012
RCP06   HRFT562JCA   R CHIP          1/10 5.6K OHM J 2012            RCY57   HRFT473JCA   R CHIP               1/10 47K OHM J 2012
RCP07   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             RCY58   HRFT473JCA   R CHIP               1/10 47K OHM J 2012
RCQ02   HRFT222JCA   R CHIP          1/10 2.2K OHM J 2012            RCY59   HRFT472JCA   R CHIP               1/10 4.7K OHM J 2012
RCQ03   HRFT222JCA   R CHIP          1/10 2.2K OHM J 2012            ZZ200   PTMPJRA668   PCB MAIN RADIAL AS   DVT-14H3LA
RCU01   HRFT124JCA   R CHIP          1/10 120K OHM J 2012            C102    CEXF1H100V   C ELECTRO            50V RSS 10MF (5X11) TP
RCU02   HRFT124JCA   R CHIP          1/10 120K OHM J 2012            C105    CEXF1H101V   C ELECTRO            50V RSS 100MF (8X11.5) TP
RCU03   HRFT152JCA   R CHIP          1/10 1.5K OHM J 2012            C107    CEXF1C331V   C ELECTRO            16V RSS 330MF (8X11.5) TP
RCU04   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             C151    CEXF1E221V   C ELECTRO            25V RSS 220MF (8X11.5) TP
RCU06   HRFT152JCA   R CHIP          1/10 1.5K OHM J 2012            C156    CEXF1H100V   C ELECTRO            50V RSS 10MF (5X11) TP
RCU07   HRFT101JCA   R CHIP          1/10 100 OHM J 2012             C157    CEXF1H101V   C ELECTRO            50V RSS 100MF (8X11.5) TP
RCU08   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             C164    CEXF1H220V   C ELECTRO            50V RSS 22MF (5X11) TP
RCU09   HRFT562JCA   R CHIP          1/10 5.6K OHM J 2012            C166    CEXF1E470V   C ELECTRO            25V RSS 47MF (5X11) TP
RCU12   HRFT123JCA   R CHIP          1/10 12K OHM J 2012             C173    CEXF1H229V   C ELECTRO            50V RSS 2.2MF (5X11) TP
RCU13   HRFT223JCA   R CHIP          1/10 22K OHM J 2012             C174    CEXF1E101V   C ELECTRO            25V RSS 100MF (6.3X11) TP
RCU14   HRFT822JCA   R CHIP          1/10 8.2K OHM J 2012            C176    CEXF1H100V   C ELECTRO            50V RSS 10MF (5X11) TP
RCU15   HRFT103JCA   R CHIP          1/10 10K OHM J 2012             C177    CEXF1E470V   C ELECTRO            25V RSS 47MF (5X11) TP
RCU16   HRFT334JCA   R CHIP          1/10 330K OHM J 2012            C500    CEXF1H100V   C ELECTRO            50V RSS 10MF (5X11) TP
RCU17   HRFT151JCA   R CHIP          1/10 150 OHM J 2012             C503    CEXD1H229F   C ELECTRO            50V RND 2.2MF (5X11) TP
RCU18   HRFT273JCA   R CHIP          1/10 27K OHM J 2012             C507    CMXM2A473J C MYLAR                100V 0.047MF J (TP)
RCU22   HRFT152JCA   R CHIP          1/10 1.5K OHM J 2012            C509    CEXF1H229V   C ELECTRO            50V RSS 2.2MF (5X11) TP




                                                                 14
SERVICE PARTS LIST



LOC    PART CODE       PART NAME        DESCRIPTION            REMARK   LOC    PART CODE        PART NAME         DECSCRIPTION          REMARK
C510   CEXF1H478V   C ELECTRO      50V RSS 0.47MF (5X11) TP             CA20   CEXF1H100A   C ELECTRO       50V RSM 10MF (5X7) TP

C511   CEXF1E101V   C ELECTRO      25V RSS 100MF (6.3X11) TP            CA21   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C513   CEXF1E101V   C ELECTRO      25V RSS 100MF (6.3X11) TP            CA22   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C515   CEXF1H478V   C ELECTRO      50V RSS 0.47MF (5X11) TP             CA23   CEXF1C470A   C ELECTRO       16V RSM 47MF (5X7) TP

C516   CEXF1H229V   C ELECTRO      50V RSS 2.2MF (5X11) TP              CA24   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C518   CMXM2A104J C MYLAR          100V 0.1MF J (TP)                    CA25   CEXF1H100A   C ELECTRO       50V RSM 10MF (5X7) TP

C519   CEXF1H478V   C ELECTRO      50V RSS 0.47MF (5X11) TP             CA26   CEXF1H100A   C ELECTRO       50V RSM 10MF (5X7) TP

C523   CEXF1H220V   C ELECTRO      50V RSS 22MF (5X11) TP               CA60   CEXF1E101V   C ELECTRO       25V RSS 100MF (6.3X11) TP

C531   CEXF1E101V   C ELECTRO      25V RSS 100MF (6.3X11) TP            CA62   CEXF1H100V   C ELECTRO       50V RSS 10MF (5X11) TP

C532   CEXF1H109V   C ELECTRO      50V RSS 1MF (5X11) TP                CA63   CEXF1H100V   C ELECTRO       50V RSS 10MF (5X11) TP

C534   CEXF1H478V   C ELECTRO      50V RSS 0.47MF (5X11) TP             CA65   CEXF1E470V   C ELECTRO       25V RSS 47MF (5X11) TP

C537   CEXF1H109V   C ELECTRO      50V RSS 1MF (5X11) TP                CA66   CEXF1E470V   C ELECTRO       25V RSS 47MF (5X11) TP

C541   CMXM2A104J C MYLAR          100V 0.1MF J (TP)                    CA67   CEXF1C331V   C ELECTRO       16V RSS 330MF (8X11.5) TP

C542   CEXD1H109F   C ELECTRO      50V RND 1MF (5X11) TP                CL05   CEXF1H479V   C ELECTRO       50V RSS 4.7MF (5X11) TP

C544   CEXF1H229V   C ELECTRO      50V RSS 2.2MF (5X11) TP              CL06   CEXD1H229F   C ELECTRO       50V RND 2.2MF (5X11) TP

C545   CEXF1H100V   C ELECTRO      50V RSS 10MF (5X11) TP               CL10   CEXF1E101V   C ELECTRO       25V RSS 100MF (6.3X11) TP

C547   CEXF1C221V   C ELECTRO      16V RSS 220MF (8X11.5) TP            CL12   CEXF1H479V   C ELECTRO       50V RSS 4.7MF (5X11) TP

C549   CEXF1C331V   C ELECTRO      16V RSS 330MF (8X11.5) TP            CL25   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C551   CEXF1C331V   C ELECTRO      16V RSS 330MF (8X11.5) TP            CL29   CEXF1H229A   C ELECTRO       50V RSM 2.2MF (4X7) TP

C552   CEXD1H229F   C ELECTRO      50V RND 2.2MF (5X11) TP              CL34   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C556   CEXF1H479V   C ELECTRO      50V RSS 4.7MF (5X11) TP              CL35   CEXF1H109A   C ELECTRO       50V RSM 1MF (4X7) TP

C609   CEXF1C220A   C ELECTRO      16V RSM 22MF (5X7)                   CL38   CEXF1H109A   C ELECTRO       50V RSM 1MF (4X7) TP

C611   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CL54   CEXF1H479V   C ELECTRO       50V RSS 4.7MF (5X11) TP

C613   CMXM2A104J C MYLAR          100V 0.1MF J (TP)                    CL55   CEXF1E101V   C ELECTRO       25V RSS 100MF (6.3X11) TP

C614   CEXF1H100V   C ELECTRO      50V RSS 10MF (5X11) TP               CL57   CEXF1H479V   C ELECTRO       50V RSS 4.7MF (5X11) TP

C615   CEXF1C220A   C ELECTRO      16V RSM 22MF (5X7)                   CN08   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C616   CEXF1C331V   C ELECTRO      16V RSS 330MF (8X11.5) TP            CN11   CDXF0H104K   C SUPER         5.5V 0.1F F (TAPPING)

C617   CEXF1H100V   C ELECTRO      50V RSS 10MF (5X11) TP               CN15   CEXF1H109A   C ELECTRO       50V RSM 1MF (4X7) TP

C618   CMXM2A104J C MYLAR          100V 0.1MF J (TP)                    CN18   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C620   CEXF1C331V   C ELECTRO      16V RSS 330MF (8X11.5) TP            CN26   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C702   CEXF1E101V   C ELECTRO      25V RSS 100MF (6.3X11) TP            CN27   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C704   CEXF1C101A   C ELECTRO      16V RSM 100MF (6.3X7) TP             CN28   CEXF1A471V   C ELECTRO       10V RSS 470MF (8X11.5) TP

C706   CEXF1C101A   C ELECTRO      16V RSM 100MF (6.3X7) TP             CN29   CEXF1C470A   C ELECTRO       16V RSM 47MF (5X7) TP

C709   CEXF1C101A   C ELECTRO      16V RSM 100MF (6.3X7) TP             CN31   CEXF1C470A   C ELECTRO       16V RSM 47MF (5X7) TP

C718   CEXF1H100A   C ELECTRO      50V RSM 10MF (5X7) TP                CN33   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

C723   CEXF1C101A   C ELECTRO      16V RSM 100MF (6.3X7) TP             CP04   CEXF1H479A   C ELECTRO       50V RSM 4.7MF 4X7

C729   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CP07   CEXF1H109A   C ELECTRO       50V RSM 1MF (4X7) TP

C731   CEXF1C101A   C ELECTRO      16V RSM 100MF (6.3X7) TP             CP09   CEXF1C101A   C ELECTRO       16V RSM 100MF (6.3X7) TP

CA08   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CP10   CEXF1H109V   C ELECTRO       50V RSS 1MF (5X11) TP

CA09   CEXF1H100A   C ELECTRO      50V RSM 10MF (5X7) TP                CQ03   CEXF1C470A   C ELECTRO       16V RSM 47MF (5X7) TP

CA10   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CU01   CEXF1H100A   C ELECTRO       50V RSM 10MF (5X7) TP

CA11   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CU02   CMXM2A153J C MYLAR           100V 0.015MF J (TP)

CA12   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CU03   CMXM2A333J C MYLAR           100V 0.033MF J (TP)

CA13   CEXF1C470A   C ELECTRO      16V RSM 47MF (5X7) TP                CU04   CMXM2A104J C MYLAR           100V 0.1MF J (TP)

CA14   CEXF1H100A   C ELECTRO      50V RSM 10MF (5X7) TP                CU05   CEXF1H479A   C ELECTRO       50V RSM 4.7MF 4X7

CA15   CEXF1H100A   C ELECTRO      50V RSM 10MF (5X7) TP                CU08   CMXM2A122J C MYLAR           100V 1200PF J (TP)

CA16   CEXF1H100A   C ELECTRO      50V RSM 10MF (5X7) TP                CU10   CEXF1C470A   C ELECTRO       16V RSM 47MF (5X7) TP




                                                                   15
                                                                                                                SERVICE PARTS LIST



 LOC   PART CODE          PART NAME          DESCRIPTION          REMARK LOC   PART CODE         PART NAME           DECSCRIPTION          REMARK
CU12   CEXF1C220A   C ELECTRO         16V RSM 22MF (5X7)                QQ02   TKSR1001--   TR                  KSR1001

CU13   CEXF1H479A   C ELECTRO         50V RSM 4.7MF 4X7                 QU01   TKTC3198Y-   TR                  KTC3198Y

CU14   CMXM2A222J C MYLAR             100V 2200PF J (TP)                QU02   TKSR1001--   TR                  KSR1001

CU15   CMXM2A102J C MYLAR             100V 1000PF J (TP)                QU03   TKTA1266Y-   TR                  KTA1266Y (TP)

CU16   CMXM2A103J C MYLAR             100V 0.01MF J (TP)                QU04   TKTC3202Y-   TR                  KTC3202Y (TP)

CU17   CMXM2A333J C MYLAR             100V 0.033MF J (TP)               QU05   TKTA1266Y-   TR                  KTA1266Y (TP)

CU18   CEXF1C470A   C ELECTRO         16V RSM 47MF (5X7) TP             QU06   TKTC3198Y-   TR                  KTC3198Y

CU19   CMXM2A223J C MYLAR             100V 0.022MF J TP                 QU07   TKTC3198Y-   TR                  KTC3198Y

CU21   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          QY50   TKTC3198Y-   TR                  KTC3198Y

CU23   CEXF1H229A   C ELECTRO         50V RSM 2.2MF (4X7) TP            R106   RN02B560JS   R METAL FILM        2W 56 OHM J SMALL

CU24   CEXF1C470A   C ELECTRO         16V RSM 47MF (5X7) TP             R107   RN02B560JS   R METAL FILM        2W 56 OHM J SMALL

CY01   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              R157   RV4121103P   R SEMI FIXED        NVZ6THT 10K OHM

CY02   CMXM2A473J C MYLAR             100V 0.047MF J (TP)               R171   RV5426103P   R SEMI FIXED        ENV-DJAA03B14 10K OHM B

CY03   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              R180   RN02B560JS   R METAL FILM        2W 56 OHM J SMALL

CY05   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          R181   RN02B560JS   R METAL FILM        2W 56 OHM J SMALL

CY10   CEXF1H479A   C ELECTRO         50V RSM 4.7MF 4X7                 R547   RN02B829JS   R METAL FILM        2W 8.2 OHM J SMALL

CY16   CEXF1A471V   C ELECTRO         10V RSS 470MF (8X11.5) TP         SW02   5S50101Z90   SW TACT             THVV502GDA

CY17   CEXF1H100A   C ELECTRO         50V RSM 10MF (5X7) TP             SW03   5S50101Z90   SW TACT             THVV502GDA

CY18   CEXF1C220A   C ELECTRO         16V RSM 22MF (5X7)                SW04   5S50101Z90   SW TACT             THVV502GDA

CY21   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              SW06   5S50101Z90   SW TACT             THVV502GDA

CY24   CEXF1C470A   C ELECTRO         16V RSM 47MF (5X7) TP             SW07   5S50101Z90   SW TACT             THVV502GDA

CY26   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          SW08   5S50101Z90   SW TACT             THVV502GDA

CY28   CEXF1C100A   C ELECTRO         16V RSM 10MF 5X7                  SW10   5S50101Z90   SW TACT             THVV502GDA

CY29   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              SW11   5S50101Z90   SW TACT             THVV502GDA

CY30   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              SW12   5S50101Z90   SW TACT             THVV502GDA

CY36   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          SW13   5S50101Z90   SW TACT             THVV502GDA

CY38   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          X501   5XEX3R579C   CRYSTAL QUARTZ      HC-49U 3.579545M (TP)

CY40   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              X502   5XEX4R436C   CRYSTAL QUARTZ      HC-49U 4.433619M 20PP TA

CY42   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              Z151   5PXLT5R5MH   FILTER CERA         LT 5.5MH

CY43   CMXM2A223J C MYLAR             100V 0.022MF J TP                 Z501   5PXLT5R5MH   FILTER CERA         LT 5.5MH

CY44   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              ZZ200 PTMPJAA668    PCB MAIN AXIAL AS   DVT-14H3LA

CY45   CMXM2A223J C MYLAR             100V 0.022MF J TP                 10     2TM14006LB   TAPE MASKING        3M #232 6.0X2000M

CY53   CEXF1C101A   C ELECTRO         16V RSM 100MF (6.3X7) TP          20     2TM10006LB   TAPE MASKING        3M #232-MAP-C 6.2X2000M

CY58   CEXF1H100A   C ELECTRO         50V RSM 10MF (5X7) TP             A001   4859803893   PCB MAIN            330X246

CY59   CEXF1H109A   C ELECTRO         50V RSM 1MF (4X7) TP              C101   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

I101   1UPC574J--   IC                UPC574J                     R     C168   CZCH1H220J   C CERA              50V CH 22PF J (AXIAL)

I150   1UPC574J--   IC                UPC574J                     R     C171   CCZB1H102K   C CERA              50V B 1000PF K (AXIAL)

IN03   1K1A7033AP   IC RESET          KIA7033AP                         C505   CZCH1H220J   C CERA              50V CH 22PF J (AXIAL)

IN04   1K1A7042AP   IC REGULATOR      KIA7042AP                         C508   CCZF1H223Z   C CERA              50V F 0.022MF Z

LU01   5CPX103J--   COIL PEAKING      10MH 5MM J RADIAL                 C520   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

Q705   TKTC3198Y-   TR                KTC3198Y                          C521   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

Q710   TKTA1266Y-   TR                KTA1266Y (TP)                     C522   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

Q712   TH2N7000--   FET               H2N7000                           C707   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

Q713   TH2N7000--   FET               H2N7000                           CA17   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

QA12   TKTC3198Y-   TR                KTC3198Y                          CA68   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

QA13   TKTC3198Y-   TR                KTC3198Y                          CA69   CBZF1H104Z   C CERA SEMI         50V F 0.1MF Z

QQ01   TKSR1001--   TR                KSR1001                           CL37   CCZF1H103Z   C CERA              50V F 0.01MF Z




                                                                      16
SERVICE PARTS LIST



 LOC   PART CODE        PART NAME         DESCRIPTION        REMARK LOC      PART CODE       PART NAME       DECSCRIPTION           REMARK
CN01   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D504   D1N4148---   DIODE          1N4148 (TAPPING)

CN02   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D505   D1N4148---   DIODE          1N4148 (TAPPING)

CN03   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D506   D1N4148---   DIODE          1N4148 (TAPPING)

CN04   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D601   D1N4148---   DIODE          1N4148 (TAPPING)

CN09   CZCH1H220J   C CERA          50V CH 22PF J (AXIAL)             D602   D1N4148---   DIODE          1N4148 (TAPPING)

CN10   CZCH1H220J   C CERA          50V CH 22PF J (AXIAL)             D701   D1N4148---   DIODE          1N4148 (TAPPING)

CN12   CZCH1H180J   C CERA          50V CH 18PF J (AXIAL)             D703   D1N4148---   DIODE          1N4148 (TAPPING)

CN13   CZCH1H180J   C CERA          50V CH 18PF J (AXIAL)             D704   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CN16   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D705   D1N4148---   DIODE          1N4148 (TAPPING)

CN17   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     D706   D1N4148---   DIODE          1N4148 (TAPPING)

CN19   CCZF1H103Z   C CERA          50V F 0.01MF Z                    D707   D1N4148---   DIODE          1N4148 (TAPPING)

CN20   CCZB1H101K   C CERA          50V B 100PF K (AXIAL)             D708   D1N4148---   DIODE          1N4148 (TAPPING)

CN21   CCZB1H101K   C CERA          50V B 100PF K (AXIAL)             D709   D1N4004S--   DIODE          1N4004S

CN22   CCZB1H101K   C CERA          50V B 100PF K (AXIAL)             D710   D1N4148---   DIODE          1N4148 (TAPPING)

CN23   CCZB1H102K   C CERA          50V B 1000PF K (AXIAL)            D711   DUZ2R4B---   DIODE ZENER    UZ-2.4B

CN24   CCZB1H102K   C CERA          50V B 1000PF K (AXIAL)            DA01   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CN25   CCZB1H102K   C CERA          50V B 1000PF K (AXIAL)            DA02   D1N4148---   DIODE          1N4148 (TAPPING)

CN34   CCZF1H223Z   C CERA          50V F 0.022MF Z                   DA03   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CN35   CCZF1H223Z   C CERA          50V F 0.022MF Z                   DA04   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CN37   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DA05   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CP02   CZCH1H220J   C CERA          50V CH 22PF J (AXIAL)             DA06   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CU22   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DA07   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CU25   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DA12   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CU26   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DA13   D1N4148---   DIODE          1N4148 (TAPPING)

CY06   CZSL1H270J   C CERA          50V SL 27PF J (AXIAL)             DA14   DUZ12BM---   DIODE ZENER    UZ-12BM (UNIZON)

CY07   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DA15   D1N4148---   DIODE          1N4148 (TAPPING)

CY19   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DL01   D1SS85TA--   DIODE          1SS85TA

CY20   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DL50   D1SS85TA--   DIODE          1SS85TA

CY22   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DN01   D1N4004S--   DIODE          1N4004S

CY23   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DN02   D1N4004S--   DIODE          1N4004S

CY33   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DN04   D1N4148---   DIODE          1N4148 (TAPPING)

CY34   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DN05   DUZ6R2BM--   DIODE ZENER    UZ-6.2BM

CY37   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DN06   D1N4004S--   DIODE          1N4004S

CY39   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DN07   D1N4004S--   DIODE          1N4004S

CY41   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DQ07   D1N4148---   DIODE          1N4148 (TAPPING)

CY49   CCZF1H103Z   C CERA          50V F 0.01MF Z                    DU01   D1N4148---   DIODE          1N4148 (TAPPING)

CY65   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DY01   D1N4148---   DIODE          1N4148 (TAPPING)

CY66   CBZF1H104Z   C CERA SEMI     50V F 0.1MF Z                     DY02   D1N4148---   DIODE          1N4148 (TAPPING)

D101   DUZ5R1B---   DIODE ZENER     UZ-5.1B                           DY03   D1N4004S--   DIODE          1N4004S

D102   D1N4148---   DIODE           1N4148 (TAPPING)                  J001   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D150   DUZ5R1B---   DIODE ZENER     UZ-5.1B                           J002   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D151   D1N4148---   DIODE           1N4148 (TAPPING)                  J003   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D152   DUZ5R1B---   DIODE ZENER     UZ-5.1B                           J004   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D153   DUZ5R1B---   DIODE ZENER     UZ-5.1B                           J005   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D501   DUZ6R2BM--   DIODE ZENER     UZ-6.2BM                          J006   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D502   D1N4148---   DIODE           1N4148 (TAPPING)                  J007   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING

D503   D1N4148---   DIODE           1N4148 (TAPPING)                  J008   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING




                                                                 17
                                                                                                           SERVICE PARTS LIST



 LOC   PART CODE        PART NAME         DESCRIPTION          REMARK    LOC   PART CODE       PART NAME       DECSCRIPTION           REMARK

J009   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J058   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J010   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J059   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J011   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J060   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J012   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J061   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J013   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J062   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J014   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J063   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J015   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J064   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J016   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J065   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J017   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J066   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J018   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J067   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J019   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J068   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J020   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J069   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J021   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J070   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J022   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J071   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J023   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J072   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J024   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING            J073   85801065GY   WIRE COPPER    AWG22 1/0.65 TIN COATING
J025   85801065GY   WIRE COPPER     AWG22 1/0.65 TIN COATING



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
