Image preview - the first page of the document
>> Download CM-530A documenatation <<
Text preview - extract from the document
REPLACEMENT PARTS LIST
Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
ZZ100 48B3018C26 T/ REMOCON R-18C26
IC01 1M50560388 IC REMOCON M50560-388GP
ZZ131 58G0000110 COIL DEGAUSSING DC-2080 20"
ZZ131 58G0000084 COIL DEGAUSSING DC-1450 14"
ZZ132 48519A5110 CRT GROUND AS 2001S-1015-1P 20"
ZZ132 48519A4710 CRT GROUND AS 1401S-1015-1P 14"
A001 4859805110 PCB LED T1.6X33X29(203X141/6X4)
DL01 DD1LARN--- LED DS2 (DL-1LARN) RED
DL02 DDL1LGN--- LED DL-1LGN
DL03 DD1LARN--- LED DS2 (DL-1LARN) RED
I704 1SR5HP---- IC PREAMP SR-5HP
JL01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
M352 4853527501 HOLDER LED HIPS BK
M371 4853734900 RETA P-AMP FR ABS BK
PA701 4850706S01 CONN AS YH025-06+YST025+ULW=200
CRT1 4859604263 CRT A48JLL91X02 M16
M211B 7122401412 SCREW TAPPING T2S TRS 4X14 MFZN BK
M211C 7122401412 SCREW TAPPING T2S TRS 4X14 MFZN BK
M221A 7122401412 SCREW TAPPING T2S TRS 4X14 MFZN BK
M251 4852525800 GRILL SPKR SECC T0.5 20"
M251 4852525700 GRILL SPKR SECC T0.5 14"
M281 4852815601 DOOR ABS BK 20"
M281 4852815501 DOOR ABS BK 14"
M361 4853622600 TERMINAL ANT FR HIPS BK CORE A
M481 4854837604 BUTTON POWER ABS BK 20"
M481 4854837504 BUTTON ABS BK 14"
M481A 4856716000 SPRING SWPA PIE0.5
M491 4854916602 BUTTON HG ABS BK
M491A 7121301011 SCREW TAPPING T2S PAN 3X10 MFZN
M492 4854917401 BUTTON ABS BK
M492A 7121301011 SCREW TAPPING T2S PAN 3X10 MFZN
M501 4855050527 DECO CTRL PVC T0.2 20"
M501 4855050527 DECO CTRL PVC T0.2 14"
M551 4855519300 DECO SENSOR P.C SMOG 20"
M551 4855519204 DECO SENSOR PC 14"
M561 4855615900 MARK BRAND A1050P-H24 T0.4 20"
M561 4855613600 MARK BRAND COPPER T0.4 14"
M621 4856013300 SCREW CRT FIXING AS 30X70 BK
M622 4856215402 WASHER RUBBER CR
M623 4856013301 SCREW CRT FIXING AS 30X140 YL
M681 4856816300 CLAMP WIRE NYLON 6 (V0)
M791 4857923300 DOOR LOCK LA701(KIFCO)
SP01A 7128301011 SCREW TAPPING T2S WAS 3X10 MFZN
M201 4852047401 MASK FRONT HIPS BK 20"
M201 4852047301 MASK FRONT HIPS BK 14"
M331 4853311601 RETAINER BACK HIPS NC
P004A 4850703028 CONN AS YH025-03+YST025+USW=200
SP01 4858305220 SPEAKER 3W 8 OHM MSF-2D30SB02U
ASB1 4850A18140 ANT SHIELD BOX S-701F=200
C403 CMXM2A474J C MYLAR 100V 0.47MF J
C410 CMYB2D334J C MYLARP 200V EU 0.33MF J 14"
C410 CMYB2D394J C MYLAR 200V EU 0.39MF J 20"
C414 CMYH3C622J C MYLAR P 1.6KV BUP 6200PF J 14"
C414 CMYH3C752J C MYLAR 1.6KV BUP 7500PF J 20"
C527 CMXM2A224J C MYLAR 100V 0.22MF J
C801 CLYL2E104M C LINE ACROSS 250V 0.1MF M S,D,V
C803 CCYB3A472K C CERA 1KV B 4700PF K
C804 CCYB3A472K C CERA 1KV B 4700PF K
C805 CCYB3A472K C CERA 1KV B 4700PF K
C806 CCYB3A472K C CERA 1KV B 4700PF K
C807 CEYN2W151P C ELECTRO 450V LHS 150MF (25X40)
C811 CMYE2J333J C MYLAR 630V PU 0.033MF J
22
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
C814 CH1BEE472M C CERA AC U/C/V 2.5KV SDE2G472M20BS
C816 CH1BEE472M C CERA AC U/C/V 2.5KV SDE2G472M20BS
C818 DSVC471D14 VARISTOR SVC471D14A
C822 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
C826 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
D701 DS1VB20--- DIODE BRIDGE S1VB20
D801 DBYW95C--- DIODE BYW95C (TAPPING)
D810 DPBS408GU- DIODE PBS408GU-CA
DL01 58Q3580047 COIL DELAY LINE B040358T 3.58MHZ
F801 5FSGB3122L FUSE GLASS TUBE SEMKO MF51 3.15A 250V TL
I101 1LA7522--- IC LA7522
I133 1UPC574J-- IC UPC574J
I201 1MC7812--- IC REGULATOR MC7812 12V 1A (KA7812)
I201A 4857025200 HEAT SINK SPCC T1.0 DG
I201B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I201D 4856215200 WASHER SPCC
I202 1KA7809--- IC REGULATOR KA7809
I202A 4857013300 HEAT SINK C SPCC T1.0 SN-3
I202B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I202D 4856215200 WASHER SPCC
I301 1LA7837--- IC LA7837
I301A 4857024602 HEAT SINK AL EX (2160AS)
I301B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I501 1TA8867AN- IC TA8867AN
I503 1TC4052BP- IC TC4052BP
I504 1DBL2052-- IC SWITCH DBL2052
I701 1Z86221480 IC MICOM Z86227-1480
I702 1AT93C46PC IC EEPROM AT93C46-10PC
I801 1STR59041- IC STR59041
I801A 4857026500 HEAT SINK AL EX
I801B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
JV01 4859103450 JACK PIN BOARD YSC02P-2400-13A (12.5MM)
L106 58B4500047 COIL PIF TRF-4547
L107 58C5580019 COIL CHOKE TRF-9225 (0.55UH)
L401 58H0000018 COIL H-LINEARITY P L-125 (125UH) 14"
L401 58H0000020 COIL H-LINEARITY L-76(76.5UH) 20"
L507 58Q3570048 COIL DELAY LINE SD-11P1CM-A
L508 58Q3R58051 COIL DELAY LINE SD-11 P1CN-A
L801 5PTLF106-- FILTER LINE TLF-106
L841 58C0000107 COIL CHOKE L-680
M351 4853514400 STOPPER CORD FR P.P BLACK
M791 4857913304 RUBBER CUSHION FR RUBBER SPONGE
M792 4857913304 RUBBER CUSHION FR RUBBER SPONGE
P401 4859240020 CONN WAFER YFW500-05
P801 4859242220 CONN WAFER YFW800-02
P803 4859242220 CONN WAFER YFW800-02
PA702 4850705N07 CONN AS BIC-05T-25T+ULW=200
PA703 4850706N03 CONN AS BIC-06T-25T+ULW=200
PA802 4850702S09 CONN AS BL102NG+MXH40058-02=300
PA950 4850705036 CONN AS GIL-J-5P+GIL10000+ULW=500
PA980 4850703239 CONN AS YBH025-03+YBIT025+ULW=350
PWC1 4859904210 CORD POWER AS WSP-93 250V 7.5A L=2600
A0000 4859905011 CORD POWER WSP-93 7.5A 250V 2.6M
Q402 TKSD5071Y- TR P KSD5071Y 14"
Q402 TKSD5072TU TR KSD5072-TU 20"
Q402A 4857024500 HEAT SINK AL EX B/K
Q402B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
Q402D 4856215201 WASHER SPCC
Q602 TKTA940--- TR KTA940
Q602A 4857025200 HEAT SINK SPCC T1.0 DG
Q602B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q602D 4856215200 WASHER SPCC
23
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
Q603 TKTC2073-- TR KTC2073
Q603A 4857025200 HEAT SINK SPCC T1.0 DG
Q603B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q603D 4856215200 WASHER SPCC
Q701 1KA7805--- IC REGULATOR KA7805
Q702 TKTD2058Y- TR KTD 2058-Y
Q702A 4857013300 HEAT SINK C SPCC T1.0 SN-3
Q702B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q702D 4856215200 WASHER SPCC
Q950 TKTC3229-- TR KTC 3229
Q951 TKTC3229-- TR KTC 3229
Q952 TKTC3229-- TR KTC 3229
R801 RX10B479JK R CEMENT 10W 4.7 OHM J (PCB 25MM)
R807 RX07B300JN R CEMENT 7W 30 OHM J BENCH 4P
R830 DJ140M290L POSISTOR J503P53D140M290L
R941 RV5221103- R SEMI FIXED V10K-5X2.5-6Y-PC-RP
R942 RV5221201- R SEMI FIXED EVN D2A A03 200 OHM B
R943 RV5221103- R SEMI FIXED V10K-5X2.5-6Y-PC-RP
R944 RV5221201- R SEMI FIXED EVN D2A A03 200 OHM B
R945 RV5221103- R SEMI FIXED V10K-5X2.5-6Y-PC-RP
RLY1 5SC0101328 SW RELAY SDT-SS-112DM
SCT1 4859302530 SOCKET CRT ISM-03S
SW301 5S40403035 SW LEVER JRS-1301
SW701 5S50101008 SW TACT KPT-1105V 1C-1P
SW702 5S50202002 SW TACT JTM-1108B 2C-2P
SW703 5S50202002 SW TACT JTM-1108B 2C-2P
SW704 5S50101008 SW TACT KPT-1105V 1C-1P
SW705 5S50202002 SW TACT JTM-1108B 2C-2P
SW706 5S50202002 SW TACT JTM-1108B 2C-2P
SW801 5S40102073 SW PUSH ME-7 1C 2P (70062-220)
T401 50D0000022 TRANS DRIVE HD-15D
T401A 4857234100 SHIELD PLATE SPTH-C T0.3
T402 50H0000129 FBT DCF-2077Z
T601 5T0U000005 TRANS SOUND OUTPUT TSP-1036
T701 50P0000191 TRANS POWER TPW-2010
T801 50M0000053 TRANS SMPS TSM-4003
U001 4859712730 TUNER VARACTOR VTSH7USZFD1
X401 4850L02310 RESONATOR CERA CSB503F30
X502 5XE3R5756C CRYSTAL QUARTZ HC-49/U 3.575611MHZ 20PPM
Z104 5PDSW1003S FILTER SAW DSW 1003S
C134 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C201 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C203 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C302 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C303 CTXD1V109K C TANTAL 35V 1MF K (TAPPING)
C305 CMXL1H105J C MYLAR 50V MEU 1MF J
C308 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20) TP
C415 CCXB3D271K C CERA 2KV B 270PF K (T)
C517 CMXL1H105J C MYLAR 50V MEU 1MF J
C610 CEXF2C479V C ELECTRO 160V RSS 4.7MF (8X16) TP
C612 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C701 CEXF1H471V C ELECTRO 50V RSS 470MF (13X20) TP
C702 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C710 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C808 CEXF2A470C C ELECTRO 100V RUS 47MF (10X16) TP
C812 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C815 CEXF2C330V C ELECTRO 160V RSS 33MF (13X20) TP
C819 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C841 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP
C842 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
C843 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C845 CEXF2C330C C ELECTRO 160V RUS 33MF (13X20) TP
24
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
C847 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20) TP
C849 CCXB3A331K C CERA 1KV B 330PF K (TAPPING)
C951 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
Q801 T2SD1207T- TR 2SD1207-T (TAPPING)
Q802 T2SD1207T- TR 2SD1207-T (TAPPING)
Q803 TKSA1013Y- TR KSA1013Y (TP)
Z101 5PXPS45MB- FILTER CERA TPS-4.5MB TRAP (TAPPING)
Z102 5PXFSH4R5M FILTER CERA SFSH4.5MCB-TF21 TAPING
Z103 5PXDA45MC- FILTER CERA CDA 4.5MC 10 (TAPPING)
L103 58B25R2S60 COIL PIF TRF-0082(STICK)
L104 58S4100S17 COIL SIF TRF-4182(41.25MHZ)STICK
L105 58E45R7S17 COIL AFT TRF-4568(45.75MHZ)STICK
L402 58C0000026 COIL BEAD HC-4035
L805 58C0000026 COIL BEAD HC-4035
L806 58C0000026 COIL BEAD HC-4035
P101 485923162S CONN WAFER YW025-03 (STICK)
P601 485923162S CONN WAFER YW025-03 (STICK)
P701 485923192S CONN WAFER YW025-06 (STICK)
P804 485923162S CONN WAFER YW025-03 (STICK)
R130 RS02Z151J- R M-OXIDE FILM 2W 150 OHM J (TAPPING)
R132 RS02Z183J- R M-OXIDE FILM 2W 18K OHM J (TAPPING)
R201 RF02Z229J- R FUSIBLE 2W 2.2 OHM J (TAPPING)
R203 RS01Z560J- R M-OXIDE FILM 1W 56 OHM J (TAPPING)
R204 RS02Z680J- R M-OXIDE FILM 2W 68 OHM J (TAPPING)
R205 RS01Z560J- R M-OXIDE FILM 1W 56 OHM J (TAPPING)
R307 RS01Z331J- R M-OXIDE FILM 1W 330 OHM J (TAPPING)
R309 RS01Z229J- R M-OXIDE FILM 1W 2.2 OHM J (TAPPING)
R315 RF01Z309J- R FUSIBLE 1W 3 OHM J (TAPPING)
R404 RS01Z331J- R M-OXIDE FILM 1W 330 OHM J (TAPPING)
R405 RS02Z153J- R M-OXIDE FILM 2W 15K OHM J (TAPPING)
R406 RS02Z153J- R M-OXIDE FILM 2W 15K OHM J (TAPPING)
R410 RS01Z182J- R M-OXIDE FILM 1W 1.8K OHM J (TAPPING)
R419 RS02Z153J- R M-OXIDE FILM 2W 15K OHM J (TAPPING)
R611 RS01Z121J- R M-OXIDE FILM 1W 120 OHM J (TAPPING)
R702 RS01Z101J- R M-OXIDE FILM 1W 100 OHM J (TAPPING)
R703 RS01Z229J- R M-OXIDE FILM 1W 2.2 OHM J (TAPPING)
R804 RS01Z561J- R M-OXIDE FILM 1W 560 OHM J (TAPPING)
R805 RS02Z560J- R M-OXIDE FILM 2W 56 OHM J (TAPPING)
R806 RS01Z561J- R M-OXIDE FILM 1W 560 OHM J (TAPPING)
R809 RF02Z278J- R FUSIBLE 2W 0.27 OHM J (TAPPING)
R811 RS01Z829J- R M-OXIDE FILM 1W 8.2 OHM J (TAPPING)
R813 RS02Z623J- R M-OXIDE FILM 2W 62K OHM J (TAPPING)
R840 RS01Z393J- R M-OXIDE FILM 1W 39K OHM J (TAPPING)
R841 RF01Z519J- R FUSIBLE 1W 5.1 OHM J (TAPPING)
R842 RF02Z100J- R FUSIBLE 2W 10 OHM J (TAPPING)
R844 RF01Z688J- R FUSIBLE 1W 0.68 OHM J (TAPPING)
R951 RS02Z123J- R M-OXIDE FILM 2W 12K OHM J (TAPPING)
R952 RS02Z123J- R M-OXIDE FILM 2W 12K OHM J (TAPPING)
R953 RS02Z123J- R M-OXIDE FILM 2W 12K OHM J (TAPPING)
C106 CMXM2A683J C MYLAR 100V 0.068MF J (TP)
C109 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C118 CEXF1E330V C ELECTRO 25V RSS 33MF (5X11) TP
C119 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C120 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C122 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C123 CMXM2A153J C MYLAR 100V 0.015MF J (TP)
C131 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C133 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C135 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C202 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C301 CXCH1H100D C CERA 50V CH 10PF D (TAPPING)
25
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
C304 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C306 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C307 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C310 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C401 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C402 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C404 CEXE2C229C C ELECTRO 160V RU 2.2MF (8X11.5) TP
C406 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C407 CMXM2A223J C MYLAR 100V 0.022MF J (TP)
C408 CMXM2A392J C MYLAR 100V 3900PF J (TP)
C412 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C430 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C507 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C508 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C509 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C510 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C513 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C514 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C516 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C525 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C526 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C531 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C532 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C533 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C534 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C543 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C544 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C559 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C574 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C609 CXSL2H470J C CERA 500V SL 47PF J (TAPPING)
C611 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C615 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C704 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C711 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C712 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C713 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C714 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C715 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C716 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C717 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C718 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C720 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C722 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C723 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C809 CMXM2A223J C MYLAR 100V 0.022MF J (TP)
C810 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C813 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C820 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C823 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C844 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C846 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C952 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA02 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
CV01 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CV04 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
L951 5CPX220J-- COIL PEAKING 22UH J (RADIAL)
Q101 TKTC3197-- TR KTC3197 (TP)
Q102 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q103 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q301 TKSC945CY- TR KSC 945C-Y (TAPPING)
26
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
Q401 TKTC3207-- TR KTC3207 (TP)
Q501 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q502 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q504 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q505 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q506 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q561 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q562 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q563 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q601 TKTC1026Y- TR KTC1026Y (TP)
Q703 TKSA733CY- TR KSA733CY (TP)
Q704 TKSA733CY- TR KSA733CY (TP)
Q705 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q706 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q707 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q708 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q709 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q710 TKTC3203Y- TR KTC3203-Y
Q715 TKSA733CY- TR KSA733CY (TP)
Q720 TKSC945CY- TR KSC 945C-Y (TAPPING)
Q804 TKSA733CY- TR KSA733CY (TP)
Q805 TKSC945CY- TR KSC 945C-Y (TAPPING)
QV01 TKSC945CY- TR KSC 945C-Y (TAPPING)
QV02 TKSC945CY- TR KSC 945C-Y (TAPPING)
QV03 TKSA733CY- TR KSA733CY (TP)
QV04 TKSA733CY- TR KSA733CY (TP)
R100 RV5426103P R SEMI FIXED RH0638C 10K OHM B
R300 RV5426472P R SEMI FIXED RH0638C 4.7K OHM B
R350 RV5426473P R SEMI FIXED RH0638C 47K OHM B
R400 RV5426104P R SEMI FIXED EVN-DJA A03 100K OHM B
R500 RV5426103P R SEMI FIXED RH0638C 10K OHM B
X501 5XEX3R579C CRYSTAL QUARTZ HC-49U 3.579545M (TP)
X503 5XEX3R582C CRYSTAL QUARTZ HC-49U 3.582056M 20PPM TA
X701 5XEX4R000C CRYSTAL QUARTZ HC-49U 4.0000MHZ (TP)
A001 4859801596 PCB MAIN 330X246 S1B
C101 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C102 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C103 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C104 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C105 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C107 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C108 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C110 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C111 CZSL1H479K C CERA 50V SL 4.7PF K (AXIAL)
C112 CZCH1H120J C CERA 50V CH 12PF J (AXIAL)
C113 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C114 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C115 CZSL1H240J C CERA 50V SL 24PF J (AXIAL)
C116 CZSL1H300J C CERA 50V SL 30PF J (AXIAL)
C117 CZSL1H300J C CERA 50V SL 30PF J (AXIAL)
C124 CZSL1H300J C CERA 50V SL 30PF J (AXIAL)
C405 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C502 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C511 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C512 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C515 CZSL1H470J C CERA 50V SL 47PF J (AXIAL)
C524 CZSL1H390J C CERA 50V SL 39PF J (AXIAL)
C528 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C529 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C530 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C535 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C536 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
27
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
C537 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C538 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C539 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C540 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C541 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C542 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C545 CZSL1H300J C CERA 50V SL 30PF J (AXIAL)
C546 CZSL1H300J C CERA 50V SL 30PF J (AXIAL)
C561 CZSL1H470J C CERA 50V SL 47PF J (AXIAL)
C562 CZSL1H470J C CERA 50V SL 47PF J (AXIAL)
C563 CZSL1H470J C CERA 50V SL 47PF J (AXIAL)
C564 CZSL1H360J C CERA 50V SL 36PF J (AXIAL)
C565 CZSL1H360J C CERA 50V SL 36PF J (AXIAL)
C567 CZSL1H360J C CERA 50V SL 36PF J (AXIAL)
C568 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C571 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C572 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C573 CCZF1E103Z C CERA 25V F 0.01MF Z (AXIAL)
C616 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C705 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C706 CZSL1H390J C CERA 50V SL 39PF J (AXIAL)
C707 CZSL1H220J C CERA 50V SL 22PF J (AXIAL)
C708 CZSL1H220J C CERA 50V SL 22PF J (AXIAL)
C709 CZSL1H220J C CERA 50V SL 22PF J (AXIAL)
C719 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C721 CCZB1H271K C CERA 50V B 270PF K (AXIAL)
C761 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
C762 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
C763 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
C770 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
C953 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C954 CCZB1H271K C CERA 50V B 270PF K (AXIAL)
C955 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C956 CCZB1H271K C CERA 50V B 270PF K (AXIAL)
C957 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C958 CCZB1H271K C CERA 50V B 270PF K (AXIAL)
CA01 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
CV02 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
CV03 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
D101 DUZ5R1BM-- DIODE ZENER UZ-5.1BM
D201 DBYV95C--- DIODE BYV95C (TAPPING)
D301 DBYV95C--- DIODE BYV95C (TAPPING)
D302 D1N4003--- DIODE 1N4003 (TAPPING)
D401 DBYV95C--- DIODE BYV95C (TAPPING)
D402 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D404 D1N4148--- DIODE 1N4148 (TAPPING)
D503 D1N4148--- DIODE 1N4148 (TAPPING)
D504 D1N4148--- DIODE 1N4148 (TAPPING)
D505 D1N4148--- DIODE 1N4148 (TAPPING)
D506 D1N4148--- DIODE 1N4148 (TAPPING)
D507 D1N4148--- DIODE 1N4148 (TAPPING)
D508 D1N4148--- DIODE 1N4148 (TAPPING)
D511 D1N4148--- DIODE 1N4148 (TAPPING)
D512 D1N4148--- DIODE 1N4148 (TAPPING)
D513 D1N4148--- DIODE 1N4148 (TAPPING)
D601 D1N4148--- DIODE 1N4148 (TAPPING)
D702 DUZ12BM--- DIODE ZENER UZ-12BM
D703 DUZ3R9B--- DIODE ZENER UZ-3.9B
D704 D1N4148--- DIODE 1N4148 (TAPPING)
D705 D1N4148--- DIODE 1N4148 (TAPPING)
D706 D1N4148--- DIODE 1N4148 (TAPPING)
D707 D1N4148--- DIODE 1N4148 (TAPPING)
28
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
D713 D1N4148--- DIODE 1N4148 (TAPPING)
D714 D1N4148--- DIODE 1N4148 (TAPPING)
D715 D1N4148--- DIODE 1N4148 (TAPPING)
D717 D1N4148--- DIODE 1N4148 (TAPPING)
D719 D1N4148--- DIODE 1N4148 (TAPPING)
D720 D1N4148--- DIODE 1N4148 (TAPPING)
D802 DBYV95C--- DIODE BYV95C (TAPPING)
D803 DBYV95C--- DIODE BYV95C (TAPPING)
D804 DBYV95C--- DIODE BYV95C (TAPPING)
D805 DBYV95C--- DIODE BYV95C (TAPPING)
D806 DBYV95C--- DIODE BYV95C (TAPPING)
D807 DBYV95C--- DIODE BYV95C (TAPPING)
D808 DBYV95C--- DIODE BYV95C (TAPPING)
D809 DBYV95C--- DIODE BYV95C (TAPPING)
D812 D1N4148--- DIODE 1N4148 (TAPPING)
D813 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D814 D1N4148--- DIODE 1N4148 (TAPPING)
D815 DUZ22BM--- DIODE ZENER UZ-22BM
D825 D1N4148--- DIODE 1N4148 (TAPPING)
D960 D1N4148--- DIODE 1N4148 (TAPPING)
DV01 D1N4148--- DIODE 1N4148 (TAPPING)
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J010 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J011 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J030 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J031 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J032 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J033 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J034 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J035 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J037 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J038 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J039 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J040 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J041 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J042 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J043 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J044 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J045 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J046 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J048 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
29
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
J049 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J050 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J051 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J053 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J054 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J055 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J056 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J057 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J059 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J060 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J061 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J062 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J063 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J064 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J065 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J068 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J070 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J071 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J074 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J076 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J077 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J078 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J080 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J082 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J083 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J084 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J085 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J089 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J090 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J092 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J093 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J094 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J096 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J098 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J099 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J100 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J101 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J104 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J105 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J106 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J107 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J108 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J109 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J110 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J111 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J112 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J113 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J114 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J117 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J118 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J119 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J120 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J125 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J129 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J130 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J131 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
30
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
J133 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J134 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J135 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J136 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J137 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J138 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J139 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J141 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J142 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J144 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J145 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J146 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J147 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J148 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J149 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J151 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J152 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J153 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J159 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J161 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J163 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J164 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J165 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J166 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J167 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J168 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J169 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J170 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J171 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J172 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J174 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J175 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J178 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J179 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J183 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J185 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L101 5CPZ568M02 COIL PEAKING 0.56UH M (AXIAL 3.5MM)
L108 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
L109 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
L501 5CPZ330K02 COIL PEAKING 33UH K (AXIAL 3.5MM)
L502 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L503 5CPZ829K02 COIL PEAKING 8.2UH K (AXIAL 3.5MM)
L504 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
L505 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
L506 5CPZ120K02 COIL PEAKING 12UH K (AXIAL 3.5MM)
L701 5CPZ330K02 COIL PEAKING 33UH K (AXIAL 3.5MM)
L702 5CPZ560K02 COIL PEAKING 56UH K (AXIAL 3.5MM)
L705 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
L706 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
L707 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
L708 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
R101 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R102 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R103 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R104 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R105 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R106 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R107 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R108 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
R110 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R111 RD-AZ124J- R CARBON FILM 1/6 120K OHM J
R112 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
31
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
R113 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R114 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R115 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R116 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R117 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R118 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R120 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R121 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R122 RD-AZ911J- R CARBON FILM 1/6 910 OHM J
R123 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R124 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
R125 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R301 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R302 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R303 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R304 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R305 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R306 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R308 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R310 RD-2Z391J- R CARBON FILM 1/2 390 OHM J
R311 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R312 RD-AZ363J- R CARBON FILM 1/6 36K OHM J
R313 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R314 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R316 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R317 RD-AZ822J- R CARBON FILM 1/6 8.2K OHM J
R401 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R402 RD-AZ201J- R CARBON FILM 1/6 200 OHM J
R403 RD-4Z432J- R CARBON FILM 1/4 4.3K OHM J
R407 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R408 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R409 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R411 RD-2Z562J- R CARBON FILM 1/2 5.6K OHM J
R412 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R413 RD-4Z304J- R CARBON FILM L 1/4 300K OHM J 14"
R413 RD-4Z244J- R CARBON FILM 1/4 240K OHM J 20"
R414 RD-4Z304J- R CARBON FILM L 1/4 300K OHM J 14"
R414 RD-4Z244J- R CARBON FILM 1/4 240K OHM J 20"
R415 RD-2Z752J- R CARBON FILM 1/2 7.5K OHM J
R416 RD-4Z512J- R CARBON FILM 1/4 5.1K OHM J
R417 RD-AZ204J- R CARBON FILM 1/6 200K OHM J
R501 RD-AZ564J- R CARBON FILM 1/6 560K OHM J
R503 RD-AZ753J- R CARBON FILM 1/6 75K OHM J
R504 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R505 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R506 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R508 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R509 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R510 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R511 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R512 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R513 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R514 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R515 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R516 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R517 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R518 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R519 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R526 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R527 RD-AZ622J- R CARBON FILM 1/6 6.2K OHM J
R528 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
R529 RD-AZ132J- R CARBON FILM 1/6 1.3K OHM J
32
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
R530 RD-AZ132J- R CARBON FILM 1/6 1.3K OHM J
R531 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R532 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R533 RD-AZ203J- R CARBON FILM 1/6 20K OHM J
R534 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R535 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R536 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R541 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R546 RD-AZ242J- R CARBON FILM 1/6 2.4K OHM J
R547 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R548 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R549 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R550 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R551 RD-AZ203J- R CARBON FILM 1/6 20K OHM J
R552 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R553 RD-AZ623J- R CARBON FILM P 1/6 62K OHM J 14"
R553 RD-AZ753J- R CARBON FILM 1/6 75K OHM J 20"
R554 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R556 RD-AZ105J- R CARBON FILM 1/6 1M OHM J
R561 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R562 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R563 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R564 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R565 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R566 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R567 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R568 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R570 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R573 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R580 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
R605 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R606 RD-AZ244J- R CARBON FILM 1/6 240K OHM J
R607 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
R608 RD-4Z430J- R CARBON FILM 1/4 43 OHM J
R609 RD-2Z223J- R CARBON FILM 1/2 22K OHM J
R610 RD-4Z430J- R CARBON FILM 1/4 43 OHM J
R701 RD-4Z222J- R CARBON FILM 1/4 2.2K OHM J
R704 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R705 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R706 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R707 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R708 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R709 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R710 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R711 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R712 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R713 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R716 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R717 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R718 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R719 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R720 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R721 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R722 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R723 RD-AZ753J- R CARBON FILM 1/6 75K OHM J
R724 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R725 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R726 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R727 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R728 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R731 RD-AZ433J- R CARBON FILM 1/6 43K OHM J
R732 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
33
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
R733 RD-AZ512J- R CARBON FILM 1/6 5.1K OHM J
R734 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R735 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R736 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R738 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R739 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R740 RD-AZ302J- R CARBON FILM 1/6 3K OHM J
R741 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R742 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R743 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R744 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R745 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R746 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R747 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R748 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R749 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R750 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R751 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R752 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R753 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R754 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R755 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R756 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R757 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R758 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R761 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R762 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R802 RD-4Z274J- R CARBON FILM 1/4 270K OHM J
R803 RD-4Z304J- R CARBON FILM 1/4 300K OHM J
R808 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R810 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J
R812 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J
R814 RC-2Z275J- R CARBON COMP 1/2 2.7M OHM J
R815 RC-2Z275J- R CARBON COMP 1/2 2.7M OHM J
R820 RD-4Z824J- R CARBON FILM 1/4 820K OHM J
R821 RD-4Z824J- R CARBON FILM 1/4 820K OHM J
R822 RD-4Z303J- R CARBON FILM 1/4 30K OHM J
R823 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R824 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R826 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R827 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R828 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R845 RD-2Z153J- R CARBON FILM 1/2 15K OHM J
R846 RD-4Z223J- R CARBON FILM 1/4 22K OHM J
R847 RD-4Z223J- R CARBON FILM 1/4 22K OHM J
R954 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R955 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R956 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R957 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R958 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R959 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R961 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R962 RD-AZ241J- R CARBON FILM 1/6 240 OHM J
R963 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
R964 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R965 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R966 RD-AZ241J- R CARBON FILM 1/6 240 OHM J
R967 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
R968 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R969 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R970 RD-AZ241J- R CARBON FILM 1/6 240 OHM J
R971 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
34
LOC. PART-CODE PART-NAME PART-DESCRIPTION REMARK
R972 RD-AZ201J- R CARBON FILM 1/6 200 OHM J
RA01 RD-AZ622J- R CARBON FILM 1/6 6.2K OHM J
RA02 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
RV01 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RV02 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
RV03 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
RV04 RD-AZ622J- R CARBON FILM 1/6 6.2K OHM J
RV05 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
RV06 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RV07 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
RV08 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
RV10 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
35
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
