S/M No. : TCM905FEF0
Service Manual
Colour Television
CHASSIS : CM-905F
Model : DTD-29U8ME
29U8MT
29U8MP
29U8MZ
MODEL OIPTION LIST
MODEL TEXT PIP
ME O O
MT O X
MP X O
MZ X X
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr NOVEMBER.2001
TABLE OF CONTENTS
SPECIFICATIONS .............................................................................................................. 2
SAFETY INSTRUCTION .................................................................................................... 3
CIRCUIT BLOCK DIAGRAM ............................................................................................. 4
ALIGNMENT INSTRUCTIONS .......................................................................................... 5
CM-905F TYPICAL SERVICE DATA .................................................................................. 8
SCHEMATIC DIAGRAM ..................................................................................................... 11
PRINTED CIRCUIT BOARD .............................................................................................. 12
MECHANICAL EXPLODED VIEW AND PARTS LIST ...................................................... 18
ELECTRICAL PARTS LIST ............................................................................................... 19
CM-905F EACH MODEL PARTS LIST .............................................................................. 28
APPENDIX ("Appendix is provided only by internet [http://svc.dwe.co.kr]")
IC DESCRIPTION .............................................................................................................. 1
TROUBLE SHOOTING CHARTS ...................................................................................... 14
-1-
SPECIFICATIONS
CAUTION
Items Model DTD- 29U8ME
29U8MT
29U8MP
29U8MZ
TV Standards PAL-SECAM-B/G,D/K,I,NTSC-M,NTSC-4.43(AV)
Mains Voltage AC 110~250V, 50/60Hz
Power Consumption 130Watts
Sound Ouput 7Watts + 7Watts Over (80% MOD.at 1KHz THD.10%)
Speaker 10W 8 Ohm (2 pcs)
Antenna 75 Ohm Unbalanced. (DIN Standard)
Tuning System FS Tuning System
Memory Channel 100 Channels
Remocon Control R-44C07
Reception Channel VHF - BAND1 : CH2 - CH4
BAND2 : CH5 - CH12
CABLE BAND : S1' - S3, S1 - S20
HYPER BAND : S21 - S41
UHF-BAND 4,5 : CH21 - CH69
Remark OSD ( GUI Format )
TELETEXT ( Top & Flop Teletext )
PIP ( AV PIP Swap, Size, Position )
,
Digital Eye
-2-
SAFETY INSTRUCTION
CAUTION
NOTE
BEFORE SERVICING THIS CHASSIS READ THE "X-RAY RADIATION PRECAUTIONS",
"SAFETY PRECAUTIONS" AND "PRODUCT SAFETY NOTICE" BELOW.
X-RAY RADIATION PRECAUTIONS
1. Excessive high voltage can produce potentially hazard- of the high voltage recorded as a part of the service
ous X-RAY RADIATION. To avoid such hazards, the recorded as a part of the service records. It is important
high voltage must not exceed the specified limit. The to use an accurate and reliable high voltage meter.
nominal value of the high voltage of this receiver is 2. The only source of X-RAY RADIATION in this TV
29kV(29") at max beam current. The high voltage must receiver is the picture tube. For continuous RADIATION
not, under any circumstances, exceed 30.5kV(29"). protection, the replacement tube must be exactly the
Each time a receiver requires servicing, the high volt- same type tube as specified in the "PART LIST".
age should be checked. It is recommended the reading
SAFETY PRECAUTIONS
1. Potentials of high voltage are present when this 2. If any FUSE in this TV receiver is blown, replace it will
receiver is operating. Operation of the receiver outside the FUSE specified in the "PART LIST".
the cabinet or with the back cover removed involves a 3. When replacing a high wattage resistor (oxide metal
shock hazard from the receiver. film resistor) in circuit board, keep the resistor 10mm
1) Servicing should not be attempted by anyone who is away from circuit board.
not thoroughly familiar with the precautions necessary 4. Keep wires away from high voltage or high temperature
when working on high voltage equipment. components.
2) Always discharge the picture tube to avoid the shock 5. This receiver must operate between AC 110-250 volts,
harzard before removing the anode cap. 50/60Hz. NEVER connect to DC supply or any other
3) Discharge the high potential of the picture tube before power or frequency.
handling the tube. The picture tube is highly evacuated
and if broken, glass fragments will be violently expelled.
PRODUCT SAFETY
Many electrical and mechanical parts in this chassis have ments, electrical components having such features are
special safety-related characteristics. identified by designated symbol on the "PART LIST".
These characteristics are often passed unnoticed by a Before replacing any of these components, read the "PART
visual inspection and the X-RAY RADIATION protection LIST" in this manual carefully.
afforded by them cannot necessarily be obtained by using The use of substitute replacement part which do not have
replacement components rated for higher voltage, wattage, the same safety characteristics as specified in the "PART
etc. LIST" may created X-RAY RADIATION.
Replacement parts which have these special safety char-
acteristics are identified in this manual and its supple-
-3-
CIRCUIT BLOCK DIAGRAM
-4-
ALIGNMENT INSTRUCTIONS
CAUTION
1. AGC ADJUSTMENT
1) Pattern : PAL B/G 10CH Color BAR (RF Level = 60 dB)
2) Connect the Pattern Generator RF Output to Tuner RF Input.
3) Press the S10 Key of Service Remocon to enter the "AGC MODE".
4) Execute the "AUTO AGC" using the Vol-Up Key.
2. SCREEN ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Press the NORMAL Key to set the "NORMAL 1" mode.
3) Press the S2 Key of Service Remocon.
4) Adjust the SCREEN VOLUME on FBT so that the horizontal line reach the cut-off point.
3. FOCUS ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Adjust the FOCUS VOLUME on FBT to obtain clear resolution.
4. WHITE BALANCE ADJUSTMENT
1) Press the NORMAL Key to set the "NORMAL 1" mode.
2) Press the S8 Key of Service Remocon to enter the "WHITE BALANCE" mode.
3) Adjust the each color ( R,G,B ) which appears abnormally on the screen.
5. GEOMETRIC ADJUSTMENT
1) Press the NORMAL Key to set the "NORMAL 1" mode.
2) Press the S6 Key of Service Remocon to enter the "GEOMETRIC" mode.
5-1. VERTICAL CENTER ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Choose the "V-CENTER" using the Pr-Up/Down Keys.
3) Adjust the horizontal line of picture to coincide with the mechanical center marks of the CRT using the
Vol-Up/Down Keys.
* If the pattern is smaller than the screen, adjust the V-size to fit.
5-2. VERTICAL SIZE ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Choose the "V-SIZE" using the Pr-Up/Down Keys.
3) Adjust the vertical size of the picture using the Vol-Up/Down Keys.
-5-
ALIGNMENT INSTRUCTIONS
5-3. HORIZONTAL CENTER ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Choose the "H-CENTER" using the Pr-Up/Down Keys.
3) Adjust the vertical line of picture to coincide with the mechanical center marks of the CRT using the
Vol-Up/Down Keys.
5-4. HORIZONTAL SIZE ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Choose the "H-SIZE" using the Pr-Up/Down Keys.
3) Set each side over scan to be 10% using the Vol-up/Down Keys.
5-5. PINCUSHION ADJUSTMENT
1) Pattern : PAL B/G Crosshatch
2) Choose the "PARABOLA" using the Pr-Up/Down Keys.
Adjust parabola width to fit on screen.
3) Choose the "CORNER" using the Pr-Up/Down Keys.
Adjust coner parabola to fit on screen.
4) Choose the "TRAPEZIUM" using the Pr-Up/Down Keys,
Adjust trapezium to fit on screen.
5-6. S-CORRECTION ADJUSTMENT
1) Pattern : PAL B/G Crosshatch
2) Choose the "S-CORRECTION" using the Pr-Up/Down Keys.
3) Adjust each distance of horizontal line to be the same using the Vol-Up/Down Keys.
5-7. SUB-BRIGHTNESS ADJUSTMENT
1) Pattern : PAL B/G Retma
2) Press the NORMAL Keys to set the "NORMAL 1" mode.
3) Adjust the Brightness so that the second line of top appears, as follow.
-6-
ALIGNMENT INSTRUCTIONS
6. REMOCON
6-1. SERVICE REMOCON 6-2. USER REMOCON
POWER
RECALL MUTE
S1 S2 S3
S4 S5 S6
S7 S8 S9
S10 S12
S11
TV/CATV ADD/ERASE TV/VIDEO
NOISE CLEAR
SOUND MODE SURROUND
CH
MENU
VOL VOL
CH
PIP POSITION M/S
PAUSE/
TV/VIDEO STILL CH VOL
V-
POSITION SIZE SLEEP 1 2
3 4 5 6
7 8 9 0
R-34SVC
6-3. SERVICE REMOCON
1) Enter SERVICE MODE : Press keys of User Remocon, as follows.
Ch91, Sharpness 0, Skip(red), Move(green), Menu.
2) Choice SERVICE MENU : Pr-Up/Down
3) Enter SERVICE SUB MENU : Vol-Up/Down
4) Adjust SERVICE MENU : Vol-Up/Down
-7-
CM-905F TYPICAL SERVICE DATA
CAUTION
CM-905F SVC KEY & FUNCTION DESCRIPTION
EY N NAME RFUNCTION
PRESS THE S1 ONE TINE ----> PRESS THE S1 ANOTHER TIME
S1 HEATRUN MODE ON/OFF
(HEATRUN MODE) (NORMAL OPRATION)
* FBT SCREEN ADJUSTMENT
SCREEN
S2 PRESS THE S2 ON TIME ----> PRESS THE S2 ANOTHER TIME
ADJUSTMENT ON/OFF
(HORIZONTAL KINE) (NORMAL OPRATION)
* SOUND TEST
PRESS THE S3 KEY IS TOGGLE
S3 SOUND TEST
VOLUME 00 ----> VOLUME 32 ----> VOLUME 63---> Line Production
BALANS LEFT ----> BALANS RIGHT ----> BALANS 00 ----> RELEASE
* PICTURE TEST
PRESS THE S4 KEY IS TOGGLE
S4 PICTURE TEST
CONTRAST 00 ----> CONTRASR 32 ----> CONTRAST 63 ----> Line Production
RRIGHT 00 ----> BRIGHT 32 ----> BRIGHT 63 ---->
COLOR 00 ----> COLOR 32 ----> COLOR 63 ----> RELEASE
* ADJUST NORMAL1 DATA INITIAL DATA
CONTRAST 63 63
S5 NORMAL1 RRIGHT 32 32
COLOR 32 32
SHARPNESS 32 32
NAME * ADJUST GEOMETRY DATA
PAL MODE NTSC MODE INITIAL DATA(50Hz)
V-CENTER 05 03 04
V-SIZE 39 39 27
H-CENTER 08 12 14
H-SIZE 36 36 58
S6 PARABORA 32 32 27
TRAPEZIUM 16 16 15
CORNER 06 06 05
H-EHT 03 03 03
S-CORRECTION 09 09 07
V-LINEARITY 08 08 09
V-EHT 03 03 03
PIP * ADJUST PIP DATA INITIAL DATA
S7
R 180 128
G 180 128
B 180 128
-8-
CM-905F TYPICAL SERVICE DATA
CM-905F SVC KEY & FUNCTION DESCRIPTION
WHITE BALANCE * ADJUST WHITE BALANCE DATA
RB R LOW BEAM ADJUSTMENT 128
GB G LOW BEAM ADJUSTMENT 0
S8
BB B LOW BEAM ADJUSTMENT 0
GG G HIGH BEAM ADJUSTMENT 64
BG B HIGH BEAM ADJUSTMENT 32
SUB-BRIGHT ADJUST BRIGHTNESS DATA 15
S9
SUB-CONTRAST ADJUST SUB CONTRAST DATA 15
* MAIN RF AGC ADJUSTMENT KEY
AGC TUNER AGC VOLTAGE 3.5Vdc
S10
AUTO-AGC
DATA 32
* OPTION MODE ADJUSTMENT KEY INITIAL DATA
TEXT ARABIC/CYRILLIC/IRANIAN/EAST-LATIN//WEST-LATIN ARABIC
S11
POWER-ON-START ON/OFF ON
DIGITAL EYE ON/OFF ON
* OUT DATA
PICTURE NORMAL 1
BLUE SCREEN ON
CLOCK
ON TIMER
ON TIMER
OFF
ON/OFF
ON PR 1
OFF TIMER
S12 OFF TIMER
OFF
ON/OFF
LANGUAGE ENGLISH
COLOR SYSTEM PAL
SOUND SYSTEM BG
SOUND MODE MEMORY
NAME(EACH PR) ----
TV/AV1/AV2 TV
TV/TEXT TV
LAST PR 1
VOLUME 20
PICTURE SIZE NORMAL (4:3)
-9-
CM-905S/SF TYPICAL SERVICE DATA
CM-905 SVC KEY & FUNCTION DESCRIPTION
CHILD LOCK OFF
S12
CH LOCK OFF
SUB MENU
NO NAME SERVICE RFUNCTION IITIAL DATA
REMOCON
NAME
1 PIP ON / OFF (PIP) PIP ON/OFF display a sub-picture OFF
2 SWAP (PIP) M/S The main picture and sub-picture are swapped
The sub-picture will be smaller.
PAUSE/
3 SIZE (PIP) To return to be normal size, Press this button
STILL
again.
4 TV / VIDEO (PIP) TV/VIDEO To select the input for the sub pictrue
5 POSITION (PIP) POSITION The display position of the sub-picture will changed
S2 DATA changed
RB 128 128
GB 0 0
6 SCREEN V-POSITION BB 0 0
GG 64 64
BG 64 64
Brightness 32 32
7 DIGITAL EYE V-POSITION DIGITAL EYE funtion ON/OFF
8 ZOOM SIZE Picture size changed ( 4:3 -> 16:9 -> ZOOM -> 4:3 ->)
9 TEXT SLEEP TEXT funtion ON/OFF
10 CH UP CH
USING the SERVICE MODE to Channel UP/DOWN
11 CH DOWN CH
12 RESISTER VOL
USING the FACTIRY KEY
13 RELEASE VOL
- 10 -
SCHEMATIC DIAGRAM
11
PRINTED CIRCUIT BOARD
PCB MAIN
- 12 -
PRINTED CIRCUIT BOARD
- 13 -
PRINTED CIRCUIT BOARD
- 14 -
SCHEMATIC DIAGRAM
DAEWOO ELEC. CO., LTD.
CM-905/CM-905F PIP BOARD
2000,11,13
REVISION; PIP 1
S/N;4859811724
- 15 -
PRINTED CIRCUIT BOARD
- 16 -
PRINTED CIRCUIT BOARD
- 17 -
ELECTRICAL PARTS LIST
i CAUTION : In this Service Manual, some parts can be changed for improving their
performance without notice in the parts list. So, if you need the latest parts
information, please refer to PPL(Parts Price List)in Service information
Center(http://svc.dwe.co.kr)
10 6520010100 STAPLE PIN AUTO W65 C308 CEYF1E332V C ELECTRO 25V RSS 3300MF (16X31.5)
10 2193102005 SOLDER BAR SN:PB=63:47 S63S-1320 C310 CEYD1H689V C ELECTRO 50V RUB 6.8MF (16*35.5)
10 2TM18006BE TAPE MASKING 6.2X500 C312 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M C401 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M C402 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M C403 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M C404 CMYH3C752J C MYLAR 1.6KV BUP 7500PF J
30 2291050616 FLUX SOLDER JS-64T3 C405 CMYH3C912J C MYLAR 1.6KV BUP 9100PF J
40 2291050301 FLUX SOLVENT IM-1000 C406 CMYE2J273J C MYLAR 630V PU 0.027MF J
00001 DPBS606GU- DIODE BRIDGE PBS606G C407 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
00001 DFMLG16S-- DIODE FML-G16S C408 CMYE2G394J C MYLAR 400V PU 0.39MF J
00001 1TDA7297-- IC AUDIO AMP TDA7297 C409 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
00001 1STRF6656- IC POWER STR-F6656 C411 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
00001 1KA7805--- IC REGULATOR KA7805 C412 CCXB2H221K C CERA 500V B 220PF K (TAPPING)
00001 1K1A7809P1 IC REGULATOR K1A7809API C413 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
00001 TKTC2026Y- TR KTC2026Y C414 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
00001 T2SD2578-- TR 2SD2578 C415 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
00001 TKTA1659AY TR KTA1659AY C416 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
00001 TKTC4370AY TR KTC4370AY C417 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
0000A 4857018900 HEAT SINK A1050P-H24 T1.6 C419 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
0000A 4857026900 HEAT SINK AL EX C420 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
0000A 4857028218 HEAT SINK AL EX BK C500 CZCH1H160J C CERA 50V CH 16PF J (AXIAL)
0000A 4857027920 HEAT SINK AL EX BK C501 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
0000A 4857026900 HEAT SINK AL EX C502 CCZF1H103Z C CERA 50V F 0.01MF Z
0000A 4857026902 HEAT SINK AL EX BK C503 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
0000A 4857027609 HEAT SINK AL EX C504 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
0000A 4857027609 HEAT SINK AL EX C505 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
0000A 4857026900 HEAT SINK AL EX C506 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
0000A 4857026900 HEAT SINK AL EX C507 CMXM2A222J C MYLAR 100V 2200PF J (TP)
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C508 CXCH1H100D C CERA 50V CH 10PF D (TAPPING)
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C509 CCZF1H103Z C CERA 50V F 0.01MF Z
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C510 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN C511 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C512 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C513 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C514 CMXL1J474J C MYLAR 63V MEU 0.47MF J
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C515 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
0000B 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN C517 CMXM2A222J C MYLAR 100V 2200PF J (TP)
0000B 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN C519 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
00100 4850Q00810 BATTERY R6P/LN C520 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
10000 48586054K1 MANUAL INSTRUCTION DTM-2082CW C522 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
A001 4859804096 PCB MAIN 330X246 S1B C523 CMXM2A822J C MYLAR 100V 8200PF J (TP)
A001 4859806960 PCB UNION 246X246/1X2 C524 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
A001 4859811724 PCB PIP 88X60(246X246/6) SIB C525 CCZF1H103Z C CERA 50V F 0.01MF Z
C101 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING) C526 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP C527 CCZF1H103Z C CERA 50V F 0.01MF Z
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) C528 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C104 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C529 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C105 CCXB1H102K C CERA 50V B 1000PF K (TAPPING) C530 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C106 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP C531 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C107 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) C532 CCZF1H103Z C CERA 50V F 0.01MF Z
C108 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C533 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C301 CMXM2A224J C MYLAR 100V 0.22MF J C534 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C302 CMXM2A102J C MYLAR 100V 1000PF J (TP) C535 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
C303 CEXF1H221V C ELECTRO 50V RSS 220MF (10X16) TP C537 CCZF1H103Z C CERA 50V F 0.01MF Z
C304 CXCH1H360J C CERA 50V CH 36PF J (TAPPING) C538 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C305 CMXM2A103J C MYLAR 100V 0.01MF J (TP) C539 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C306 CMXM2A473J C MYLAR 100V 0.047MF J (TP) C540 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C307 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP C541 CCZF1H103Z C CERA 50V F 0.01MF Z
ELECTRICAL PARTS LIST
C546 CCZF1H103Z C CERA 50V F 0.01MF Z C723 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C547 CCZF1H103Z C CERA 50V F 0.01MF Z C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C548 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C802 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C549 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING) C803 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C550 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C804 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C551 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C805 CEYN2G331P C ELECTRO 400V LHS 330MF (30X45)
C552 CCZF1H103Z C CERA 50V F 0.01MF Z C806 CBYB3D152K C CERA SEMI 2KV BL(N) 1500PF K
C555 CXCH1H470J C CERA 50V CH 47PF J (TAPPING) C807 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C556 CXCH1H470J C CERA 50V CH 47PF J (TAPPING) C808 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C571 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C809 CH1HFE102M C CERA AC 4.0KV 1000PF E DG
C572 CCZF1H103Z C CERA 50V F 0.01MF Z C810 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
C573 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C812 CEYF2C221V C ELECTRO 160V RSS 220MF (18X35.5)
C574 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C813 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C575 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C814 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C581 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C815 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C583 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C816 CCXB2H101K C CERA 500V B 100PF K (TAPPING)
C584 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C817 CBXB3D471K C CERA SEMI 2KV BL(N) 470PF K (T)
C585 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C818 CEXF2A470V C ELECTRO 100V RSS 47MF (10X16) TP
C586 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C819 CCXB3A471K C CERA 1KV B 470PF K (T)
C587 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C820 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C601 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C821 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C602 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C822 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C603 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C824 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C604 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C825 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C606 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C826 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C608 CMXM2A333J C MYLAR 100V 0.033MF J (TP) C827 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C609 CMXM2A562J C MYLAR 100V 5600PF J (TP) C828 CEYF1E332V C ELECTRO 25V RSS 3300MF (16X31.5)
C611 CMXM2A682J C MYLAR 100V 6800PF J (TP) C830 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C613 CMXM2A682J C MYLAR 100V 6800PF J (TP) C831 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C614 CMXM2A562J C MYLAR 100V 5600PF J (TP) C832 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C615 CMXM2A333J C MYLAR 100V 0.033MF J (TP) C834 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C617 CMXM2A153J C MYLAR 100V 0.015MF J (TP) C836 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C618 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C839 CCXB3D271K C CERA 2KV B 270PF K (T)
C619 CMXM2A153J C MYLAR 100V 0.015MF J (TP) C841 CH1HFE102M C CERA AC 4.0KV 1000PF E DG
C620 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C901 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C621 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C902 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C622 CMXM2A224J C MYLAR 100V 0.22MF J C903 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C623 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C904 CEYF2E100V C ELECTRO 250V RSS 10MF (10X20)
C624 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP C905 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C626 CMXM2A224J C MYLAR 100V 0.22MF J C906 CEYF2E100V C ELECTRO 250V RSS 10MF (10X20)
C628 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C907 CCYB3D472K C CERA 2KV B 4700PF K
C629 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP C908 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV)
C630 CCZF1H103Z C CERA 50V F 0.01MF Z C909 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV)
C701 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) C910 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV)
C702 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP C911 CMXM2A822J C MYLAR 100V 8200PF J (TP)
C703 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C912 CCZF1H103Z C CERA 50V F 0.01MF Z
C704 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C913 CCZB1H561K C CERA 50V B 560PF K
C705 CEXF1H338V C ELECTRO 50V RSS 0.33MF (5X11) TP C914 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C706 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP C915 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C707 CMXM2A104J C MYLAR 100V 0.1MF J (TP) C916 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C708 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C917 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C711 CCZF1H103Z C CERA 50V F 0.01MF Z C918 CCXB2H472K C CERA 500V B 4700PF K (TAPPING)
C712 CCZB1H101K C CERA 50V B 100PF K (AXIAL) C919 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C713 CCZB1H101K C CERA 50V B 100PF K (AXIAL) C920 CCXB2H472K C CERA 500V B 4700PF K (TAPPING)
C715 CXCH1H270J C CERA 50V CH 27PF J (TAPPING) C921 CEXF2C100V C ELECTRO 160V RSS 10MF (10X16) TP
C716 CXCH1H270J C CERA 50V CH 27PF J (TAPPING) C922 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C718 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C923 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C720 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C924 CEXF2C100V C ELECTRO 160V RSS 10MF (10X16) TP
C722 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z C925 CCXB2H101K C CERA 500V B 100PF K (TAPPING)
- 20 -
ELECTRICAL PARTS LIST
C926 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) D801 PTA1SW8900 HEAT SINK ASS`Y DPBS606GU- + 7174300811
CD01 CCZF1H103Z C CERA 50V F 0.01MF Z D802 PTS2SW6900 HEAT SINK ASS`Y DFMLG16S-- + 7128301011
CP01 CXCH1H100D C CERA 50V CH 10PF D (TAPPING) D803 DLT2A05G-- DIODE LT2A05G (TP)
CP02 CXCH1H100D C CERA 50V CH 10PF D (TAPPING) D804 D1N4937G-- DIODE 1N4937G (TAPPING)
CP05 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP D812 D1N4937G-- DIODE 1N4937G (TAPPING)
CP06 CBZP1C103M C CERA SEMI 16V Y5S 0.01MF M (AXIAL) D813 D1N4937G-- DIODE 1N4937G (TAPPING)
CP08 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP D814 DFMLG12S-- DIODE FML-G12S
CP09 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z D815 D1N4937G-- DIODE 1N4937G (TAPPING)
CP10 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP D816 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
CP11 CMXM2A103J C MYLAR 100V 0.01MF J (TP) D817 DRGP30J--- DIODE RGP30J
CP12 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP D820 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
CP13 CCZF1H103Z C CERA 50V F 0.01MF Z D901 D1N4148--- DIODE 1N4148 (TAPPING)
CP14 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP D903 D1N4148--- DIODE 1N4148 (TAPPING)
CP15 CCZF1H103Z C CERA 50V F 0.01MF Z D904 D1N4148--- DIODE 1N4148 (TAPPING)
CP16 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP D905 D1N4148--- DIODE 1N4148 (TAPPING)
CP17 CCZF1H103Z C CERA 50V F 0.01MF Z D906 D1N4148--- DIODE 1N4148 (TAPPING)
CP18 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP D907 D1N4148--- DIODE 1N4148 (TAPPING)
CP19 CCZF1H103Z C CERA 50V F 0.01MF Z D908 D1N4148--- DIODE 1N4148 (TAPPING)
CP20 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP D909 D1N4148--- DIODE 1N4148 (TAPPING)
CP21 CMXL1J104J C MYLAR 63V MEU 0.1MF J D910 DLT2A05G-- DIODE LT2A05G (TP)
CP22 CMXL1J104J C MYLAR 63V MEU 0.1MF J D911 D1N4004S-- DIODE 1N4004S
CP23 CMXL1J104J C MYLAR 63V MEU 0.1MF J D912 D1N4004S-- DIODE 1N4004S
CP24 CCZB1H820K C CERA 50V B 82PF K (AXIAL) D913 D1N4004S-- DIODE 1N4004S
CS01 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP D914 D1N4148--- DIODE 1N4148 (TAPPING)
CS02 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP D915 D1N4148--- DIODE 1N4148 (TAPPING)
D101 D1N4148--- DIODE 1N4148 (TAPPING) D916 D1N4148--- DIODE 1N4148 (TAPPING)
D102 DUZ33B---- DIODE ZENER UZ-33B D917 D1N4148--- DIODE 1N4148 (TAPPING)
D103 D1N4148--- DIODE 1N4148 (TAPPING) D918 D1N4148--- DIODE 1N4148 (TAPPING)
D201 D1N4148--- DIODE 1N4148 (TAPPING) D919 D1N4004S-- DIODE 1N4004S
D202 D1N4148--- DIODE 1N4148 (TAPPING) D920 D1N4004S-- DIODE 1N4004S
D302 D1N4004S-- DIODE 1N4004S DF01 4858900002 HOLDER LED ASSY LH-3P
D304 D1N4937G-- DIODE 1N4937G (TAPPING) DP02 D1N4148--- DIODE 1N4148 (TAPPING)
D401 D1N4937G-- DIODE 1N4937G (TAPPING) DP03 D1N4148--- DIODE 1N4148 (TAPPING)
D402 DRGP30J--- DIODE RGP30J DP04 D1N4148--- DIODE 1N4148 (TAPPING)
D403 DDG3------ DIODE DG3 E001 4856310300 EYE LET BSR T0.2 (R1.6)
D405 D1N4937G-- DIODE 1N4937G (TAPPING) E002 4856310300 EYE LET BSR T0.2 (R1.6)
D406 DFMLG12S-- DIODE FML-G12S E004 4856310300 EYE LET BSR T0.2 (R1.6)
D407 D1N4937G-- DIODE 1N4937G (TAPPING) E005 4856310300 EYE LET BSR T0.2 (R1.6)
D409 DRH1B----- DIODE RH1B E006 4856310300 EYE LET BSR T0.2 (R1.6)
D410 DUZ9R1BM-- DIODE ZENER UZ-9.1BM E008 4856310300 EYE LET BSR T0.2 (R1.6)
D413 DUZ9R1BM-- DIODE ZENER UZ-9.1BM E009 4856310300 EYE LET BSR T0.2 (R1.6)
D502 D1N4148--- DIODE 1N4148 (TAPPING) E010 4856310300 EYE LET BSR T0.2 (R1.6)
D503 D1N4148--- DIODE 1N4148 (TAPPING) E011 4856310300 EYE LET BSR T0.2 (R1.6)
D507 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING E012 4856310300 EYE LET BSR T0.2 (R1.6)
D508 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING E013 4856310300 EYE LET BSR T0.2 (R1.6)
D509 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING E014 4856310300 EYE LET BSR T0.2 (R1.6)
D581 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E015 4856310300 EYE LET BSR T0.2 (R1.6)
D582 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E016 4856310300 EYE LET BSR T0.2 (R1.6)
D583 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E017 4856310300 EYE LET BSR T0.2 (R1.6)
D584 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E018 4856310300 EYE LET BSR T0.2 (R1.6)
D585 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E019 4856310300 EYE LET BSR T0.2 (R1.6)
D586 DUZ5R1B--- DIODE ZENER UZ-5.1B E020 4856310300 EYE LET BSR T0.2 (R1.6)
D587 DUZ7R5BM-- DIODE ZENER UZ-7.5BM E021 4856310300 EYE LET BSR T0.2 (R1.6)
D588 DUZ5R1B--- DIODE ZENER UZ-5.1B E022 4856310300 EYE LET BSR T0.2 (R1.6)
D589 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E023 4856310300 EYE LET BSR T0.2 (R1.6)
D592 DUZ5R6BM-- DIODE ZENER UZ-5.6BM E024 4856310300 EYE LET BSR T0.2 (R1.6)
D701 D1N4004S-- DIODE 1N4004S E025 4856310300 EYE LET BSR T0.2 (R1.6)
D704 D1N4148--- DIODE 1N4148 (TAPPING) E026 4856310300 EYE LET BSR T0.2 (R1.6)
D705 DUZ2R4B--- DIODE ZENER UZ-2.4B E027 4856310300 EYE LET BSR T0.2 (R1.6)
- 21 -
ELECTRICAL PARTS LIST
E028 4856310300 EYE LET BSR T0.2 (R1.6) I809 1K1A7809P1 IC REGULATOR K1A7809API
E029 4856310300 EYE LET BSR T0.2 (R1.6) I901 PT12SW5401 HEAT SINK ASS`Y 1TDA6107Q- + 7174301011
E030 4856310600 EYE LET BSR T0.2 (R2.3) I901 1TDA6107Q- IC VIDEO TDA6107Q
E031 4856310600 EYE LET BSR T0.2 (R2.3) I901A 4857025401 HEAT SINK A1050P-H24 T2
E032 4856310300 EYE LET BSR T0.2 (R1.6) I901B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
E033 4856310300 EYE LET BSR T0.2 (R1.6) ID01 1PNA4603H- IC PHOTO SENSOR PNA4603H
E034 4856310300 EYE LET BSR T0.2 (R1.6) IF01 1TS0P1238W IC PREAMP TS0P1238WI1
E035 4856310300 EYE LET BSR T0.2 (R1.6) IP01 1SDA9488XE IC CHIP PIP SDA9488X
E036 4856310600 EYE LET BSR T0.2 (R2.3) IP02 1LP295033- IC REGULATOR LP2950 3.3V
E037 4856310600 EYE LET BSR T0.2 (R2.3) J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E038 4856310600 EYE LET BSR T0.2 (R2.3) J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E039 4856310600 EYE LET BSR T0.2 (R2.3) J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E040 4856310600 EYE LET BSR T0.2 (R2.3) J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E041 4856310600 EYE LET BSR T0.2 (R2.3) J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E042 4856310600 EYE LET BSR T0.2 (R2.3) J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E046 4856310600 EYE LET BSR T0.2 (R2.3) J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E047 4856310600 EYE LET BSR T0.2 (R2.3) J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E049 4856310600 EYE LET BSR T0.2 (R2.3) J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E050 4856310600 EYE LET BSR T0.2 (R2.3) J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E051 4856310600 EYE LET BSR T0.2 (R2.3) J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E058 4856310600 EYE LET BSR T0.2 (R2.3) J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E059 4856310600 EYE LET BSR T0.2 (R2.3) J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E060 4856310600 EYE LET BSR T0.2 (R2.3) J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E061 4856310600 EYE LET BSR T0.2 (R2.3) J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E062 4856310300 EYE LET BSR T0.2 (R1.6) J010 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
E063 4856310300 EYE LET BSR T0.2 (R1.6) J011 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
E064 4856310300 EYE LET BSR T0.2 (R1.6) J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E065 4856310300 EYE LET BSR T0.2 (R1.6) J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E101 4856310600 EYE LET BSR T0.2 (R2.3) J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E102 4856310600 EYE LET BSR T0.2 (R2.3) J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E103 4856310600 EYE LET BSR T0.2 (R2.3) J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E104 4856310600 EYE LET BSR T0.2 (R2.3) J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E105 4856310600 EYE LET BSR T0.2 (R2.3) J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E106 4856310600 EYE LET BSR T0.2 (R2.3) J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E107 4856310600 EYE LET BSR T0.2 (R2.3) J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E108 4856310600 EYE LET BSR T0.2 (R2.3) J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E109 4856310600 EYE LET BSR T0.2 (R2.3) J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
E110 4856310600 EYE LET BSR T0.2 (R2.3) J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
F801 5F3GB6322L FUSE GLASS TUBE V/S TL 6.3A 250V MF51 J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
F801A 4857415001 CLIP FUSE PFC5000-0702 J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
F801B 4857415001 CLIP FUSE PFC5000-0702 J029 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
HP01 4859102130 JACK EARPHONE YSC-1537 J030 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I301 PTD2SW7903 HEAT SINK ASS`Y 1TA8427K-- + 7174301011 J031 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I303 1TA8427K-- IC TA8427K J032 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I303A 4857027903 HEAT SINK AL EX BK J035 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I303B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN J036 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I501 1TB1251N-- IC TB1251CN J037 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I571 1MM1118--- IC A/V SWITCH MM1118 J038 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I601 PTA2SW8218 HEAT SINK ASS`Y 1TDA7297-- + 7174301011 J039 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I602 1TDA9859-- IC AUDIO PROCESSOR TDA9859 J040 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I701 1SDA555XFL IC MICOM OTP SDA555XFL J041 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I702 124LC16B1B IC MEMORY 24LC16B1B J042 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I801 PTA2SW7920 HEAT SINK ASS`Y 1STRF6656- + 7174301011 J051 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I802 4850M04810 MODULE POWER DPM011 TI J052 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I803 TX0202DA-- THYRISTOR X0202DA1BA2 J053 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I804 1LP295033- IC REGULATOR LP2950 3.3V J054 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I805 PTH2SW6900 HEAT SINK ASS`Y 1KA7805--- + 7174301011 J055 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I806 PTH2SW6902 HEAT SINK ASS`Y 1K1A7809P1 + 7174301011 J056 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
I808 1KA7805--- IC REGULATOR KA7805 J057 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
- 22 -
ELECTRICAL PARTS LIST
J058 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J126 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J059 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J127 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J061 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J128 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J062 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J129 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J063 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J130 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J064 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J131 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J065 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J132 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J066 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J133 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J067 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J134 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J068 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J135 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J069 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J136 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J070 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J150 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J071 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J151 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J186 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J302 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J074 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J303 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J400 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J076 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J401 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J077 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J403 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J404 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J081 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J407 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J082 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J413 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J083 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J500 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J084 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J501 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J085 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J502 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J086 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J503 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J087 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J504 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J088 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J505 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J089 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J506 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J090 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J507 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J092 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J508 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J093 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J600 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J094 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J603 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J095 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J606 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J096 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J607 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J097 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J610 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J099 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J700 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J100 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J701 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J101 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J800 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J804 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP01 4859110950 JACK PIN BOARD YS01-0001
J104 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J105 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP02 4859108450 JACK PIN BOARD YSC03P-4120-14A
J106 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP02 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J107 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP03 4859110950 JACK PIN BOARD YS01-0001
J108 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP03 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J109 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J110 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP05 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J111 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP06 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J112 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING JP07 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J113 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L102 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
J114 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L201 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
J119 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L202 5CPZ829K02 COIL PEAKING 8.2UH K (AXIAL 3.5MM)
J120 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L301 58C7070085 COIL CHOKE TLN-3062A
J121 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L401 58H0000064 COIL H-LINEARITY TRL-350B
J122 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L402 5MC0000100 COIL BEAD HC-3550
J123 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L403 58C0000096 COIL CHOKE 610G0233(470K)
J124 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L500 5CPZ120K02 COIL PEAKING 12UH K (AXIAL 3.5MM)
J125 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING L501 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
- 23 -
ELECTRICAL PARTS LIST
L502 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) M811 4858198100 PAD EPS 29U8
L504 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
L505 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING M821 4858215600 BAG P.E PE FOAM T0.5X1600X1270
L506 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L507 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L508 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L555 58N0000045 COIL VCO TRF-V011 N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L571 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) N005 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L601 58C0000096 COIL CHOKE 610G0233(470K) N006 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L701 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) N007 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L702 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) N008 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L703 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) ND01 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
L704 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) P601 485923172S CONN WAFER YW025-04 (STICK)
L705 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING P601A 4850704S32 CONNECTOR YH025-04+35098+ULW=900
L706 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) P603A 4850705N07 CONNECTOR BIC-05T-25T+ULW=200
L710 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) P901 485923202S CONN WAFER YW025-07 (STICK)
L711 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) P901A 4850707S02 CONNECTOR YH025-07+YST025+ULW=400
L712 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) P902 485923182S CONN WAFER YW025-05 (STICK)
L801 5MC0000100 COIL BEAD HC-3550 P902A 4850705S04 CONNECTOR YH025-05+YST025+ULW=400
L811 5MC0000100 COIL BEAD HC-3550 P904 4859281320 CONN WAFER TAC-L18X-A3
L813 5MC0000100 COIL BEAD HC-3550 P906 4859205620 CONN WAFER LW-0640-03
L901 5MC0000100 COIL BEAD HC-3550 P907 4859238620 CONN WAFER YPW500-02
L902 5MC0000100 COIL BEAD HC-3550 PD01 485923162S CONN WAFER YW025-03 (STICK)
L903 5MC0000100 COIL BEAD HC-3550 PD01A 4850703S18 CONNECTOR YH025-03+YST025+ULW=200
LF801 5PLF30A1-- FILTER LINE LF-30A1 PP01 4859279820 CONN WAFER TAC-L18P-A3 (ANGLE)
LP02 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) PW801 4859908110 CORD POWER AS 1-L0+H03VVH2-F+HOU=2200
LP03 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) Q101 TKTC3198Y- TR KTC3198Y
LP04 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) Q102 TKTC3198Y- TR KTC3198Y
LP05 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM) Q201 TKTC3198Y- TR KTC3198Y
M191 4851944701 DOOR AS 2823101+5544901 29U8 Q202 TKTC3198Y- TR KTC3198Y
M201 4852078801 MASK FRONT HIPS GY 29U8 Q203 TKTC3198Y- TR KTC3198Y
M201A 4856015820 SCREW CRT FIX SWRM+SK5 L=35 Q204 TKTC3198Y- TR KTC3198Y
M201B 4856215404 WASHER RUBBER CR T4.0 Q205 TKTA1266Y- TR KTA1266Y (TP)
M201C 4856013600 SCREW SPKR FIX SWRM+SECC Q301 TKTA1266Y- TR KTA1266Y (TP)
M201D 4856816300 CLAMP WIRE NYLON 6 (V0) Q302 TKTC3198Y- TR KTC3198Y
M201E 4856013600 SCREW SPKR FIX SWRM+SECC Q303 TKTA1266Y- TR KTA1266Y (TP)
M211 4852160401 COVER BACK HIPS GY 29U8 Q304 PTF2SW7609 HEAT SINK ASS`Y TKTC2026Y- + 7174300811
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK Q401 PTB2SW7609 HEAT SINK ASS`Y T2SD2578-- + 7174300811
M211B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK Q402 TKTC3229-- TR KTC3229
M371A 4853747800 RETA PCB NYLON 66 Q403 TKTC3198Y- TR KTC3198Y
M371B 4853747800 RETA PCB NYLON 66 Q501 TKTC3198Y- TR KTC3198Y
M481 4854860901 BUTTON POWER ABS GY 29U8 Q502 TKTC3198Y- TR KTC3198Y
M481A 4856716000 SPRING SWPA PIE0.5 Q503 TKTC3198Y- TR KTC3198Y
M491 4854950401 BUTTON CH ABS GY 29U8 Q504 TKTC3198Y- TR KTC3198Y
M491A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN Q581 TKTC3198Y- TR KTC3198Y
M501 4855060301 DECO CTRL PVC T0.25 Q582 TKTC3198Y- TR KTC3198Y
M541 4855419800 SPEC PLATE ART 150 Q583 TKTC3198Y- TR KTC3198Y
M561 48556174SD MARK BRAND SILVER DIA-CUTTING Q601 TKTC3198Y- TR KTC3198Y
M591 4855934900 DECO TERM PVC T0.3 Q603 TKTC3198Y- TR KTC3198Y
M592 4855936301 DECO EYE ABS BLUE Q701 TH2N7000-- FET H2N7000
M592A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN Q702 TH2N7000-- FET H2N7000
M681 4856812400 BAND PP AUTO 0.95X17MMX1000M Q704 TKTA1266Y- TR KTA1266Y (TP)
M681 4856812001 TIE CABLE NYLON66 DA100 Q801 TKSA1013Y- TR KSA1013Y (TP)
M683 2TF15025CL TAPE FILAMENT T0.15XW25X50M CLEAR Q803 TKTC3198Y- TR KTC3198Y
M683 4856812001 TIE CABLE NYLON66 DA100 Q901 TKTA1266Y- TR KTA1266Y (TP)
M781 4857817630 CLOTH BLACK FELT 400X20X0.7 Q902 TKTC3198Y- TR KTC3198Y
M782 4857817612 CLOTH BLACK FELT 250X20X0.7 Q903 TKTC3198Y- TR KTC3198Y
M791 4857923300 DOOR LOCK LA701(KIFCO) Q904 TKTC3198Y- TR ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
