Image preview - the first page of the document
>> Download CN-207A documenatation <<
Text preview - extract from the document
S/G No. : TCN207MEF0G1
Service Guide
Color Television
CHASSIS : CN-207a
Model : DTQ-25G4FS
DTQ-29G4FS
SPECIFICATIONS
MODEL
DTH-25G4FS DTH-29G4FS
ITEM
TV STANDARD NTST-M
POWER INPUT 120V / 220V 50/60HZ
POWER CONSUMPTION 120W 135W
TUNING SYSTEM F.S.REMOCON
VHF VHF(L) : CH 2 ~ 6
(H) : CH 7 ~ 13
TUNING RANGES UHF CH 14 ~ CH 69
CATV CH 1 ~ CH 125
SOUND OUTPUT 6.5W + 6.5W (R+L)
SPEAKER 8 10W + 8 10W (R+L)
ANTENNA INPUT IMPEDANCE 75 ohm
Font : Video, Audio, R/L, 1EA
AUXILIARY INPUT TERMINAL Rear : Video, Audio, R/L, 1EA
PIF : 45.75 MHZ
INTERMEDIATE FREQUENCIES SIF : 41.25 MHZ
COLOR SUB : 3.579545 MHZ
REMOTE CONTROL R-35H13
1) ICON MENU TYPE
2) 3-Language OSD
SPECIAL FUNCTIONS
3) WITH CAPTION
4) CH LABEL
5) WITH CAPTION
6) CH LABEL, AUTO DEMO
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr Oct. 2000
DTQ-25G4FS
DTQ-29G4FS
The Different Part List
Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
DTQ- DTQ-
part_cd part_nm part_desc loc
25G4FS 29G4FS
DTQ- DTQ- HRFT104JCA R CHIP 1/10 100K OHM J 2012 RC304 1 0
part_cd part_nm part_desc loc
25G4FS 29G4FS HRFT913JCA R CHIP 1/10 91K OHM J 2012 RC304 0 1
CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP C306 1 0 HRFT183JCA R CHIP 1/10 18K OHM J 2012 RC305 1 0
CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP C306 0 1 HRFT273JCA R CHIP 1/10 27K OHM J 2012 RC305 0 1
CMYH3C822J C MYLAR 1.6KV BUP 8200PF J C404 0 1 HRFT123JCA R CHIP 1/10 12K OHM J 2012 RC307 0 1
CMYH3D752J C MYLAR 2KV BUP 7500PF J C404 1 0 HRFT163JCA R CHIP 1/10 16K OHM J 2012 RC307 1 0
CMYH3C692J C MYLAR 1.6KV BUP 6900PF J C405 1 0 HRFT183JCA R CHIP 1/10 18K OHM J 2012 RC308 0 1
CMYH3C912J C MYLAR 1.6KV BUP 9100PF J C405 0 1 HRFT203JCA R CHIP 1/10 20K OHM J 2012 RC308 1 0
CMXE2J273J C MYLAR 630V PU 0.027MF J (TP) C406 1 0 HRFT513JCA R CHIP 1/10 51K OHM J 2012 RC309 1 0
CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C406 0 1 HRFT623JCA R CHIP 1/10 62K OHM J 2012 RC309 0 1
CMXE2D683J C MYLAR 200V PU 0.068MF J (TP) C419 0 1 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012 RC420 1 0
CMYE2D394J C MYLAR 200V PU 0.39MF J C420 1 0 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012 RC420 0 1
CMYE2D514J C MYLAR 200V PU 0.51MF J C420 0 1 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC426 1 0
CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP C826 1 0 HRFT479JCA R CHIP 1/10 4.7 OHM J 2012 RC426 0 1
HCBH224KCA C CHIP CERA 25V X7R 0.22MF K 2012 CC723 0 1 HRFT273JCA R CHIP 1/10 27K OHM J 2012 RC428 1 0
HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012 CC723 1 0 HRFT393JCA R CHIP 1/10 39K OHM J 2012 RC428 0 1
DRGP15J--- DIODE RGP15J D824 1 0 HRFT561JCA R CHIP 1/10 560 OHM J 2012 RC570 1 0
4856310600 EYE LET BSR T0.2 (R2.3) E034 0 1 HRFT911JCA R CHIP 1/10 910 OHM J 2012 RC570 0 1
4856310600 EYE LET BSR T0.2 (R2.3) E035 0 1 HRFT112JCA R CHIP 1/10 1.1K OHM J 2012 RC571 0 1
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J019 1 0 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012 RC571 1 0
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J020 1 0 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC725 0 1
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J200 0 1 HRFT103JCA R CHIP 1/10 10K OHM J 2012 RC725 1 0
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J212 0 1 HRFT334JCA R CHIP 1/10 330K OHM J 2012 RC820 1 0
58H0000025 COIL H-LINEARITY TRL-330 L401 1 0 HRFT434JCA R CHIP 1/10 430K OHM J 2012 RC820 0 1
58H1600022 COIL H-LINEARITY TRL-2093 L401 0 1 HRFT184JCA R CHIP 1/10 180K OHM J 2012 RC822 1 0
58W0000018 COIL WIDTH TLN-2092 L402 0 1 HRFT684JCA R CHIP 1/10 680K OHM J 2012 RC822 0 1
4852066501 MASK FRONT HIPS BK M201 0 1 HRFT161JCA R CHIP 1/10 160 OHM J 2012 RC905 1 0
4852073303 MASK FRONT HIPS BK M201 1 0 HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC905 0 1
4856015800 SCREW CRT FIX L=27 M201A 4 0 HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC911 0 1
4856015820 SCREW CRT FIX SWRM+SK5 L=35 M201A 0 4 HRFT201JCA R CHIP 1/10 200 OHM J 2012 RC911 1 0
4856215402 WASHER RUBBER CR T2.0 M201B 4 0 HRFT161JCA R CHIP 1/10 160 OHM J 2012 RC917 1 0
4856215404 WASHER RUBBER CR T4.0 M201B 0 4 HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC917 0 1
4852150741 COVER BACK HIPS BK M211 0 1 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK SP01A 0 4
4852155321 COVER BACK HIPS BK M211 1 0 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK SP01A 4 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M211A 8 0 4859629060 CRT A59KPR84X01(D) P38 V901 1 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M211A 0 10 4859629160 CRT A68KTB259X001 P38 V901 0 1
4852821201 DOOR ABS BK M281 0 1 48B3235H13 TRANSMITTER REMOCON R-35H13 ZZ100 1 0
4852821900 DOOR ABS BK M281 1 0 48B3235H13 TRANSMITTER REMOCON R-35H13 ZZ100 0 1
4853526600 HOLDER CORD NYLON6(DACB-183) M351 1 0 PTACPWJ663 ACCESSORY AS DTQ-29G3FS ZZ110 1 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M351A 1 0 PTACPWJ663 ACCESSORY AS DTQ-29G3FS ZZ110 0 1
7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK M381A 2 0 PTBCSHJ752 COVER BACK AS DTQ-29G4FS ZZ120 0 1
4854852501 BUTTON POWER ABS BK M481 0 1 PTBCSHJ793 COVER BACK AS DTQ-25G4FS ZZ120 1 0
4854856100 BUTTON POWER ABS BK M481 1 0 PTPKCPJ752 PACKING AS DTQ-29G4FS ZZ130 0 1
4855535401 DECO SENSOR PMMA CL M551 0 1 PTPKCPJ793 PACKING AS DTQ-25G4FS ZZ130 1 0
4855540800 DECO SENSOR PMMA M551 1 0 48519A4010 CRT GROUND NET 2501H-1015-2P ZZ131 1 0
4855616100 MARK BRAND A1050P-H24 M561 1 0 48519A4210 CRT GROUND NET 2901H-1015-2P ZZ131 0 1
48556174SD MARK BRAND SILVER DIA-CUTTING M561 0 1 58G0000148 COIL DEGAUSSING DC-25SF ZZ132 1 0
4856812400 BAND 18MM X 3M M681 1 0 58G0000149 COIL DEGAUSSING DC-29SF ZZ132 0 1
4856812400 BAND 18MM X 3M M681 0 1 PTCACAJ752 CABINET AS DTQ-29G4FS ZZ140 0 1
4857820001 CLOTH BLACK CLOTH 320X12X0.5 M781 0 2 PTCACAJ793 CABINET AS DTQ-25G4FS ZZ140 1 0
4857821103 CLOTH BLACK FELT 180X10X1.5 M781 2 0 PTFMSJJ752 MASK FRONT AS DTQ-29G4FS ZZ200 0 1
4858053400 BOX CARTON DW-4 A TYPE M801 0 1 PTFMSJJ793 MASK FRONT AS DTQ-25G4FS ZZ200 1 0
4858055500 BOX CARTON DW-2 M801 1 0 PTMPJ0J752 PCB MAIN (RHU) AS DTQ-29G4FS ZZ200 0 1
4858185900 PAD EPS 29G4 M811 0 1 PTMPJ0J793 PCB MAIN (RHU) AS DTQ-25G4FS ZZ200 1 0
4858192500 PAD EPS 25G4 M811 1 0 PTMPJ2J752 PCB CHIP MOUNT B AS DTQ-29G4FS ZZ200 0 1
4858215100 BAG P.E PE FOAM t0.5x1430x1270 M821 1 0 PTMPJ2J793 PCB CHIP MOUNT B AS DTQ-25G4FS ZZ200 1 0
4858215600 BAG P.E PE FOAM t0.5x1600x1270 M821 0 1 PTMPJAJ752 PCB MAIN AXIAL AS DTQ-29G4FS ZZ200 0 1
RS02Z220JS R M-OXIDE FILM 2W 22 0HM J SMALL R314 1 0 PTMPJAJ793 PCB MAIN AXIAL AS DTQ-25G4FS ZZ200 1 0
RS02Z620JS R M-OXIDE FILM 2W 62 OHM J SMALL R314 0 1 PTMPJBJ752 PCB MAIN M-10 AS DTQ-29G4FS ZZ200 0 1
RF01Z159J- R FUSIBLE 1W 1.5 OHM J (TAPPING) R409 1 0 PTMPJBJ793 PCB MAIN M-10 AS DTQ-25G4FS ZZ200 1 0
RF01Z399J- R FUSIBLE 1W 3.9 OHM J (TAPPING) R409 0 1 PTMPJRJ752 PCB MAIN RADIAL AS DTQ-29G4FS ZZ200 0 1
RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING) R817 0 1 PTMPJRJ793 PCB MAIN RADIAL AS DTQ-25G4FS ZZ200 1 0
RF01Z688K- R FUSIBLE 1W 0.68 OHM K (TAPPING) R817 1 0 PTMPMSJ752 PCB MAIN MANUAL AS DTQ-29G4FS ZZ290 0 1
RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING) R818 0 1 PTMPMSJ793 PCB MAIN MANUAL AS DTQ-25G4FS ZZ290 1 0
RF01Z688K- R FUSIBLE 1W 0.68 OHM K (TAPPING) R818 1 0
HRFT512JCA R CHIP 1/10 5.1K OHM J 2012 RC301 1 0
HRFT682JCA R CHIP 1/10 6.8K OHM J 2012 RC301 0 1
Electrical Parts List
LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION
CC535 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC12 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC601 T2SC2412KB TR CHIP 2SC2412K-T146-BR
CC538 HCQK561JCA C CHIP CERA 50V CH 560PF J 2012 JC14 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC602 T2SC2412KB TR CHIP 2SC2412K-T146-BR
CC548 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC15 HRF8000-EA R CHIP 1/8 0 OHM 3216 QC603 T2SC2412KB TR CHIP 2SC2412K-T146-BR
CC549 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC16 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC701 T2SA1037KB TR CHIP 2SA1037AKT146-R
LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION
CC550 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC17 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC702 T2SC2412KB TR CHIP 2SC2412K-T146-BR
LOC PART CODE PART NAME PART DESCRIPTION R202 RD-4Z300J- R CARBON FILM 1/4 30 OHM J JP03 4859109250 JACK PIN BOARD PH-JB-9614A
CC553 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC18 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC703 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R203 RD-4Z474J- R CARBON FILM 1/4 470K OHM J JP04 4859109250 JACK PIN BOARD PH-JB-9614A
ZZ100 48B3235H13 TRANSMITTER REMOCON R-35H13 CC602 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216 JC19 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC704 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R204 RD-4Z474J- R CARBON FILM 1/4 470K OHM J L101 58C5580019 COIL CHOKE TRF-9225 (0.55UH)
ZZ110 PTACPWJ663 ACCESSORY AS DTQ-29G3FS CC603 HCBK822KCA C CHIP CERA 50V X7R 8200PF K 2012 JC20 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC705 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R206 RD-4Z181J- R CARBON FILM 1/4 180 OHM J L401 58H1600022 COIL H-LINEARITY TRL-2093
30 4850Q00810 BATTERY R6P/LN CC604 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528 JC22 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC805 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R207 RD-2Z221J- R CARBON FILM 1/2 220 OHM J L402 58W0000018 COIL WIDTH TLN-2092
40 4.86E+09 MANUAL INSTRUCTION DTQ-29G4FS CC606 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216 JC23 HRF8000-EA R CHIP 1/8 0 OHM 3216 QC809 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R208 RD-2Z221J- R CARBON FILM 1/2 220 OHM J L403 58C7070085 COIL CHOKE TLN-3062A
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400 CC607 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528 JC24 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC901 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R209 RD-4Z302J- R CARBON FILM 1/4 3K OHM J L502 58N0000037 COIL VCO TRF-V004
ZZ120 PTBCSHJ752 COVER BACK AS DTQ-29G4FS CC608 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528 JC25 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC902 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R211 RD-4Z242J- R CARBON FILM 1/4 2.4K OHM J L503 58S0000045 COIL SIF TRF-S001
M211 4852150741 COVER BACK HIPS BK CC609 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216 JC26 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC904 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R212 RD-4Z152J- R CARBON FILM 1/4 1.5K OHM J L801 5PTLF3024- FILTER LINE TLF-3024
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV) CC610 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216 JC27 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC906 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R213 RD-4Z821J- R CARBON FILM 1/4 820 OHM J L807 58C0000107 COIL CHOKE L-680
M782 4857817630 CLOTH BLACK FELT 400X20X0.7 CC612 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528 JC28 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC907 T2SA1037KB TR CHIP 2SA1037AKT146-R
R214 RD-4Z681J- R CARBON FILM 1/4 680 OHM J M682 4856812001 TIE CABLE NYLON66 DA100
ZZ130 PTPKCPJ752 PACKING AS DTQ-29G4FS CC614 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528 JC29 HRFT000-CA R CHIP 1/10 0 OHM 2012 QCP01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R215 RD-4Z681J- R CARBON FILM 1/4 680 OHM J P901 4850703S20 CONNECTOR YH025-
M641 6520010100 STAPLE PIN 18M/M J D O 03+YST025+ULW=400 CC617 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216 JC30 HRFT000-CA R CHIP 1/10 0 OHM 2012 QCP02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R216 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
M681 4856812400 BAND 18MM X 3M P902 4850705S04 CONNECTOR YH025- CC618 HCBK822KCA C CHIP CERA 50V X7R 8200PF K 2012 JC31 HRFT000-CA R CHIP 1/10 0 OHM 2012 QCP03 T2SC2412KB TR CHIP 2SC2412K-T146-BR
R217 RD-4Z750J- R CARBON FILM 1/4 75 OHM J
M801 4858053400 BOX CARTON DW-4 A TYPE 05+YST025+ULW=400 CC622 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216 JC32 HRFT000-CA R CHIP 1/10 0 OHM 2012 QCP04 T2SC2412KB TR CHIP 2SC2412K-T146-BR
ZZ290 PTMPMSJ752 PCB MAIN MANUAL AS DTQ-29G4FS
M811 4858185900 PAD EPS 29G4 P903 4859238620 CONN WAFER YPW500-02 CC623 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528 JC33 HRFT000-CA R CHIP 1/10 0 OHM 2012 QCV01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
C307 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
M821 4858215600 BAG P.E PE FOAM t0.5x1600x1270 PWC1 PTWASW0910 CORD POWER ASS`Y 4859901111+ 4857417700 CC624 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528 JC34 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC102 HRFT102JCA R CHIP 1/10 1K OHM J 2012
C404 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
ZZ131 48519A4210 CRT GROUND NET 2901H-1015-2P PW000 4859901111 CORD POWER KKP-419C KLCE-2F (2.1ME) CC625 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528 JC35 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC103 HRFT102JCA R CHIP 1/10 1K OHM J 2012
C405 CMYH3C912J C MYLAR 1.6KV BUP 9100PF J
ZZ132 58G0000149 COIL DEGAUSSING DC-29SF PW001 4857417700 TERM CLAMP PT-01-T3 CC628 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528 JC36 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC104 HRFT102JCA R CHIP 1/10 1K OHM J 2012
C406 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP)
ZZ140 PTCACAJ752 CABINET AS DTQ-29G4FS Q401 PTK2SW7602 HEAT SINK ASS`Y T2SD1880-- + 7174300811 CC632 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC37 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC301 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
C420 CMYE2D514J C MYLAR 200V PU 0.51MF J
40 2TF01612CL TAPE FILAMENT 12MMX55ME CLEAR 1 T2SD1880-- TR 2SD1880 CC637 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC39 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC303 HRFT153JCA R CHIP 1/10 15K OHM J 2012
C422 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
AD001 4859000240 ADAPTER 2P15A 300V(D=4.0) 0000A 4857027602 HEAT SINK AL EX CC701 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012 JC40 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC304 HRFT913JCA R CHIP 1/10 91K OHM J 2012
C636 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
M201A 4856015820 SCREW CRT FIX SWRM+SK5 L=35 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN CC702 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012 JC41 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC305 HRFT273JCA R CHIP 1/10 27K OHM J 2012
C801 CL1JB3104M C LINE ACROSS AC250V 0.1MF M ECQ-UV
M201B 4856215404 WASHER RUBBER CR T4.0 Q406 PTB2SW7602 HEAT SINK ASS`Y TKTD2058Y- + 7174301011 CC703 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC42 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC307 HRFT123JCA R CHIP 1/10 12K OHM J 2012
WRL
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 1 TKTD2058Y- TR KTD 2058-Y CC705 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC44 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC308 HRFT183JCA R CHIP 1/10 18K OHM J 2012
C802 CEYD2G331D C ELECTRO 400V FHS 330MF (35X35)
M211B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 0000A 4857027602 HEAT SINK AL EX CC707 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216 JC45 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC309 HRFT623JCA R CHIP 1/10 62K OHM J 2012
C809 CEYN2D221T C ELECTRO 200V FWS 220MF (22X30)
M281 4852821201 DOOR ABS BK 0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN CC708 HCBK332KCA C CHIP CERA 50V X7R 3300PF K 2012 JC46 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC404 HRFT331JCA R CHIP 1/10 330 OHM J 2012
C814 CBYB3D152K C CERA SEMI 2KV BL(N) 1500PF K
M481 4854852501 BUTTON POWER ABS BK 0000D 4856215200 WASHER SPCC CC709 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216 JC47 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC405 HRFT511JCA R CHIP 1/10 510 OHM J 2012
C815 CEYF1V222V C ELECTRO 35V RSS 2200MF (16X31.5)
M481A 4856716000 SPRING SWPA PIE0.5 Q901 TKTC3229-- TR KTC 3229 CC710 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216 JC48 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC412 HRFT363JCA R CHIP 1/10 36K OHM J 2012
C825 CH1AFE472M C CERA AC 4KV 4700PF M KX DE1610
M491 4854937711 BUTTON ABS BK Q903 TKTC3229-- TR KTC 3229 CC711 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC49 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC413 HRFT223JCA R CHIP 1/10 22K OHM J 2012
C827 CH1BFB471K C CERA AC AC400V 470PF K SD
M491A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK Q905 TKTC3229-- TR KTC 3229 CC712 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012 JC50 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC415 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
C831 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
M501 4855058702 DECO CTRL PVC T0.25 R400 RX10T402J- R CEMENT 10W 4K OHM J TRIPOD CC723 HCBH224KCA C CHIP CERA 25V X7R 0.22MF K 2012 JC51 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC416 HRFT203JCA R CHIP 1/10 20K OHM J 2012
C832 CCYR3D681K C CERA 2KV R 680PF K 125 DE1007
M551 4855535401 DECO SENSOR PMMA CL R414 RF01Y478K- R FUSIBLE 1W 0.47 OHM K CC816 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC52 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC417 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
C910 4SG0D00103 SPARK GAP S-23 900V-1.5KV
M551A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK R802 RX10T109KS R CEMENT 10W 1 OHM K TRIPOD CC817 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC53 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC420 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
C911 4SG0D00103 SPARK GAP S-23 900V-1.5KV
SMALL
M561 48556174SD MARK BRAND SILVER DIA-CUTTING C912 4SG0D00103 SPARK GAP S-23 900V-1.5KV CC901 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012 JC54 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC422 HRFT103JCA R CHIP 1/10 10K OHM J 2012
R803 RM02Y108K- R METAL FLAT 2W 0.1 OHM K
M681 4856812001 TIE CABLE NYLON66 DA100 COMB1 5PUGL349KN FILTER COMB UGL-349KNT CC902 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012 JC55 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC423 HRFT244JCA R CHIP 1/10 240K OHM J 2012
RP801 DDC7R0M290 POSISTOR ECPCD7R0M290
M685 4856816300 CLAMP WIRE NYLON 6 (V0) D401 DDG3------ DIODE DG3 CC903 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012 JC56 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC424 HRFT823JCA R CHIP 1/10 82K OHM J 2012
RS801 DSVC471D14 VARISTOR SVC471D14A
M781 4857820001 CLOTH BLACK CLOTH 320X12X0.5 D402 DRGP30J--- DIODE RGP30J CCP01 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC57 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC425 HRFT752JCA R CHIP 1/10 7.5K OHM J 2012
RTH01 DR320K---- THERMISTOR R-320K
M791 4857923300 DOOR LOCK LA701(KIFCO) D406 DRGP30J--- DIODE RGP30J CCP02 HCQK120JCA C CHIP CERA 50V CH 12PF J 2012 JC58 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC426 HRFT479JCA R CHIP 1/10 4.7 OHM J 2012
SAW1 5PM1859M-- FILTER SAW M1859M
SP01 48A8304800 SPEAKER SYSTEM SS-78128F04 10W 8 OHM D801 PTC1SW8902 HEAT SINK ASS`Y DPBS606GU- + 7174300811 CCP03 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012 JC60 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC428 HRFT393JCA R CHIP 1/10 39K OHM J 2012
SCT1 4859302830 SOCKET CRT ISH-02S
SP01A 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK D801 DPBS606GU- DIODE BRIDGE PBS606G CCP04 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC61 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC429 HRFT102JCA R CHIP 1/10 1K OHM J 2012
T401 50H0000189 FBT FFA94048L
V901 4859629160 CRT A68KTB259X001 P38 D801A 4857018902 HEAT SINK A1050P-H24 CCP06 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC62 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC432 HRFT362JCA R CHIP 1/10 3.6K OHM J 2012
T401A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
ZZ200 PTFMSJJ752 MASK FRONT AS DTQ-29G4FS D801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN CCP08 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC63 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC433 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
T402 5TD0000018 TRANS DRIVE THD-120
M201 4852066501 MASK FRONT HIPS BK D804 PTZ2SW5200 HEAT SINK ASS`Y DFMLG16S-- + 7174300811 CCP13 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC65 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC434 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
T801 50M5345B4- TRANS SMPS TSM-5345B4
ZZ203 PTCTMSJ752 PCB CONTROL MANUAL A DTQ-29G4FS 1 DFMLG16S-- DIODE FML-G16S CCP14 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC66 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC502 HRFT303JCA R CHIP 1/10 30K OHM J 2012
TU01 4859715630 TUNER VARACTOR TELH9-039A
DF01 DKLR114L-- LED KLR114L 0000A 4857025200 HEAT SINK SPCC T1.0 DG CCP15 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC67 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC503 HRFT124JCA R CHIP 1/10 120K OHM J 2012
TU03 4850M02910 MODULE RF PH-RF-9505B
IL01 1TS0P1238W IC PREAMP TS0P1238WI1 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN CCP16 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC68 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC504 HRFT393JCA R CHIP 1/10 39K OHM J 2012
UT01 4859003750 PLUG PHONE AS PLUG+CABLE
JP01 4859102130 JACK EARPHONE YSC-1537 D808 DEGP50D--- DIODE EGP50D (TAPPING) 1365AWG26=150B CCP18 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC70 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC505 HRFT823JCA R CHIP 1/10 82K OHM J 2012
JP02 4859108450 JACK PIN BOARD YSC03P-4120-14A F801 5FKGB6323L FUSE GLASS TUBE KS MF51 6.3A 125/250V TL X502 4850L03110 RESONATOR CERA CSB503F44 CCP19 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC71 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC506 HRFT622JCA R CHIP 1/10 6.2K OHM J 2012
M351 4853530901 HOLDER LED P.P I301 PTE2SW8200 HEAT SINK ASS`Y 1LA7845N-- + 7174301011 X601 4850L03810 RESONATOR CERA CSB503F58 CCP20 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC72 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC507 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
M381 4853816400 FRAME SUB PCB FR HIPS BK I301 1LA7845N-- IC LA7845N X701 5XYR03276C CRYSTAL QUARTZ C-001R 32.768000KHZ CCP23 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC73 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC508 HRFT824JCA R CHIP 1/10 820K OHM J 2012
M683 4856812001 TIE CABLE NYLON66 DA100 20PPM CCP25 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC74 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC510 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
I301A 4857028200 HEAT SINK AL EX BK
PA907 4850706S01 CONNECTOR YH025- XP01 5XJ14R31DE CRYSTAL QUARTZ HC49S 14.318MHZ 30PPM CCP28 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC75 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC512 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
06+YST025+ULW=200 16P
I501 1LA76070A- IC VIDEO PROCESSOR LA76070A CCP29 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC76 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC513 HRFT750JCA R CHIP 1/10 75 OHM J 2012
PA908 4850709S01 CONNECTOR YH025- Y801 5SC0101325 SW RELAY HR-CR7 DC12V
I502 1LA7956--- IC LA7956 CCP30 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC77 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC514 HRFT183JCA R CHIP 1/10 18K OHM J 2012
09+YST025+ULW=200 Z502 5PYXT4R5MB FILTER CERA XT 4.5MB
I503 1LA7956--- IC LA7956 CCP32 HCQK510JCA C CHIP CERA 50V CH 51PF J 2012 JC78 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC515 HRFT333JCA R CHIP 1/10 33K OHM J 2012
SW12 5S50101035 SW TACT KPT-1112 1C-1P ZZ200 PTMPJ2J752 PCB CHIP MOUNT B AS DTQ-29G4FS
I504 1TC4053BP- IC TC4053BP CCP33 HCQK750JCA C CHIP CERA 50V CH 75PF J 2012 JC79 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC516 HRFT363JCA R CHIP 1/10 36K OHM J 2012
ZZ200 PTCTJRJ752 PCB CONTROL RADIAL A DTQ-29G4FS CC102 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I601 1TDA9852-- IC AUDIO PROCESSOR TDA9852 CCP34 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC80 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC517 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
C201 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP CC103 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I602 PTA2SW3332 HEAT SINK ASS`Y 1LA4282--- + 7174301011 CCP36 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012 JC81 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC519 HRFT151JCA R CHIP 1/10 150 OHM J 2012
C202 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP CC106 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
1 1LA4282--- IC LA4282 CCP38 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC83 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC520 HRFT681JCA R CHIP 1/10 680 OHM J 2012
C203 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP CC302 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
0000A 4857023332 HEAT SINK AL EX CCP39 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012 JC84 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC521 HRFT331JCA R CHIP 1/10 330 OHM J 2012
C204 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP CC401 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN CCP41 HCQK470JCA C CHIP CERA 50V CH 47PF J 2012 JC85 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC522 HRFT102JCA R CHIP 1/10 1K OHM J 2012
C205 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP CC501 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I701 1DW8647DM1 IC MICOM DW864732V-DM1(5N74) CCV07 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012 JC86 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC523 HRFT102JCA R CHIP 1/10 1K OHM J 2012
SW07 5S50101090 SW TACT THVH472GCA CC502 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I702 1AT24C08PC IC AT24C08-10PC JC01 HRFT000-CA R CHIP 1/10 0 OHM 2012 JC87 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC524 HRFT102JCA R CHIP 1/10 1K OHM J 2012
SW08 5S50101090 SW TACT THVH472GCA CC504 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I801 PTB2SW7900 HEAT SINK ASS`Y 1STRF6656- + 7174300811 JC02 HRFT000-CA R CHIP 1/10 0 OHM 2012 JC88 HRFT000-CA R CHIP 1/10 0 OHM 2012 RC525 HRFT102JCA R CHIP 1/10 1K OHM J 2012
SW09 5S50101090 SW TACT THVH472GCA CC510 HCBK333KCA C CHIP CERA 50V X7R 0.033MF K 2012
I801 1STRF6656- IC POWER STR-F6656 JC03 HRFT000-CA R CHIP 1/10 0 OHM 2012 JC89 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC526 HRFT102JCA R CHIP 1/10 1K OHM J 2012
SW10 5S50101090 SW TACT THVH472GCA CC512 HCQK130JCA C CHIP CERA 50V CH 13PF J 2012
I801A 4857027900 HEAT SINK AL EX BK JC04 HRFT000-CA R CHIP 1/10 0 OHM 2012 JC90 HRF8000-EA R CHIP 1/8 0 OHM 3216 RC528 HRFT102JCA R CHIP 1/10 1K OHM J 2012
SW11 5S50101090 SW TACT THVH472GCA CC515 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I801B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN JC05 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC501 T2SA1037KB TR CHIP 2SA1037AKT146-R RC529 HRFT684JCA R CHIP 1/10 680K OHM J 2012
ZZ200 PTCTJAJ752 PCB CONTROL AXIAL AS DTQ-29G4FS CC516 HCBK333KCA C CHIP CERA 50V X7R 0.033MF K 2012
I802 1KA78R08-- IC REGULATOR KA78R08 JC06 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC503 T2SC2412KB TR CHIP 2SC2412K-T146-BR RC530 HRFT394JCA R CHIP 1/10 390K OHM J 2012
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M CC517 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
I803 1PQ3RF23-- IC REGULATOR PQ3RF23 JC07 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC504 T2SA1037KB TR CHIP 2SA1037AKT146-R RC532 HRFT561JCA R CHIP 1/10 560 OHM J 2012
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M CC518 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I804 TX0202DA-- THYRISTOR X0202DA1BA2 JC08 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC505 T2SC2412KB TR CHIP 2SC2412K-T146-BR RC533 HRFT564JCA R CHIP 1/10 560K OHM J 2012
A001 4859833014 PCB CONTROL 56X246(246X246/1X4) CC524 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I805 1K1A7806P1 IC REGULATOR KIA7806API JC09 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC506 T2SC2412KB TR CHIP 2SC2412K-T146-BR RC535 HRFT304JCA R CHIP 1/10 300K OHM J 2012
J298 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING CC526 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
I807 4850M04810 MODULE POWER DPM011 TI JC10 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC507 T2SC2412KB TR CHIP 2SC2412K-T146-BR RC537 HRFT000-CA R CHIP 1/10 0 OHM 2012
J299 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING CC529 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
IP01 1M65617SP- IC PIP M65617SP JC11 HRFT000-CA R CHIP 1/10 0 OHM 2012 QC508 T2SC2412KB TR CHIP 2SC2412K-T146-BR RC538 HRFT331JCA R CHIP 1/10 330 OHM J 2012
R201 RD-4Z300J- R CARBON FILM 1/4 30 OHM J CC530 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION LOC PART CODE PART NAME PART DESCRIPTION
RC539 HRFT331JCA R CHIP 1/10 330 OHM J 2012 RC738 HRFT131JCA R CHIP 1/10 130 OHM J 2012 C614 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP P907 485923192S CONN WAFER YW025-06 (STICK) C620 CMXB1H153J C MYLAR 50V EU 0.015MF J (TP) C556 CCZF1H103Z C CERA 50V F 0.01MF Z
RC540 HRFT331JCA R CHIP 1/10 330 OHM J 2012 RC745 HRFT102JCA R CHIP 1/10 1K OHM J 2012 C615 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP P908 485923522S CONN WAFER YW025-09 (STICK) C621 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP) D101 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
RC543 HRFT824JCA R CHIP 1/10 820K OHM J 2012 RC746 HRFT102JCA R CHIP 1/10 1K OHM J 2012 C803 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP PA901 485923162S CONN WAFER YW025-03 (STICK) C622 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP D102 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
RC546 HRFT824JCA R CHIP 1/10 820K OHM J 2012 RC747 HRFT103JCA R CHIP 1/10 10K OHM J 2012 C804 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP PA902 485923182S CONN WAFER YW025-05 (STICK) C623 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP D301 D1N4004S-- DIODE 1N4004S
RC547 HRFT131JCA R CHIP 1/10 130 OHM J 2012 RC819 HRFT102JCA R CHIP 1/10 1K OHM J 2012 C811 CBXB3D471K C CERA SEMI 2KV BL(N) 470PF K (T) R302 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL C624 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP D302 D1N4937G-- DIODE 1N4937G (TAPPING)
RC548 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC820 HRFT434JCA R CHIP 1/10 430K OHM J 2012 C823 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP R306 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL C625 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP) D403 D1N4148--- DIODE 1N4148 (TAPPING)
RC549 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC822 HRFT684JCA R CHIP 1/10 680K OHM J 2012 C828 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP R314 RS02Z620JS R M-OXIDE FILM 2W 62 OHM J SMALL C626 CMXL1J474J C MYLAR 63V MEU 0.47MF J D404 D1N4937G-- DIODE 1N4937G (TAPPING)
RC553 HRFT561JCA R CHIP 1/10 560 OHM J 2012 RC830 HRFT303JCA R CHIP 1/10 30K OHM J 2012 C908 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING) R315 RS02Z561JS R M-OXIDE FILM 2W 560 OHM J SMALL C627 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP) D405 D1N4937G-- DIODE 1N4937G (TAPPING)
RC554 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC832 HRFT101JCA R CHIP 1/10 100 OHM J 2012 ZZ200 PTMPJBJ752 PCB MAIN M-10 AS DTQ-29G4FS R316 RF01Z229J- R FUSIBLE 1W 2.2 OHM J (TAPPING) C628 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP D407 DRGP15J--- DIODE RGP15J
RC555 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC833 HRFT431JCA R CHIP 1/10 430 OHM J 2012 10 2TM18006BE TAPE MASKING 6.2X500 R407 RF01Z100J- R FUSIBLE 1W 10 OHM J (TAPPING) C629 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP D501 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
RC556 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC834 HRFT103JCA R CHIP 1/10 10K OHM J 2012 E001 4856310600 EYE LET BSR T0.2 (R2.3) R408 RF01Z241J- R FUSIBLE 1W 240 OHM J (TAPPING) C630 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP D504 D1N4148--- DIODE 1N4148 (TAPPING)
RC557 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012 RC842 HRFT102JCA R CHIP 1/10 1K OHM J 2012 E002 4856310300 EYE LET BSR T0.2 (R1.6) R409 RF01Z399J- R FUSIBLE 1W 3.9 OHM J (TAPPING) C633 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP D505 D1N4148--- DIODE 1N4148 (TAPPING)
RC558 HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC901 HRFT103JCA R CHIP 1/10 10K OHM J 2012 E003 4856310600 EYE LET BSR T0.2 (R2.3) R415 RS02Z103JS ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
