Image preview - the first page of the document
>> Download SL-S00T & 10T documenatation <<
Text preview - extract from the document
Service Manual
Chassis : SL-S00T/10T
2
Contents
Model line-up using SL-S00T/10T chassis. ................................................................................... 4
1) Mechanical design of DAEWOO models. ............................................................................................................................. 4
2) Mechanical design of hanseatic models. .............................................................................................................................. 4
3) Buyer and Factory Model Names. ............................................................................................................................................ 4
1. Safety Precaution. .......................................................................................................................... 5
2. Preliminary Troubleshooting ....................................................................................................... 6
2-1) LCD TV does not response or remote controller does not work. ...................................................................... 6
2-2) Sound is discontinuous or broken sometimes. ............................................................................................................ 6
2-3) Picture of digital program is sometimes broken and sound is discontinuous. ........................................... 6
2-4) Picture of analog program is noisy. ................................................................................................................................... 6
2-5) Sound is not generated in HDMI mode. .......................................................................................................................... 6
2-6) In spite of 'Auto Adjust', picture size in the PC mode is not completely adapted to the screen. .... 6
2-7) In spite of 'Auto Adjust' in the PC mode, picture is not clear. ............................................................................ 6
3. Product Specifications. ................................................................................................................. 7
3-1) Standard. ........................................................................................................................................................................................... 7
3-2) Available Input Signal. ............................................................................................................................................................... 8
3-3) Available user remote controller. ......................................................................................................................................... 9
4. Block Diagram. ............................................................................................................................. 10
5. Software Update. ......................................................................................................................... 11
5-1) Update using RS-232C cable. .............................................................................................................................................. 11
5-1-1) Preparation. .................................................................................................................................................................... 11
5-1-2) System Configuration. ............................................................................................................................................... 11
5-1-3) Introduction. ................................................................................................................................................................... 11
5-1-4) Tool installation. ........................................................................................................................................................... 12
5-1-5) Procedure. ........................................................................................................................................................................ 12
5-2) Upgrade using USB Memory. ............................................................................................................................................. 14
6. Service mode................................................................................................................................. 14
6-1) Using the Service Remote controller. ............................................................................................................................. 14
6-2) Using the User Remote controller (S/N : 48B6360B01). ....................................................................................... 14
7. Hardware Trouble Shooting ...................................................................................................... 16
7-1) No picture or picture with poor quality. ...................................................................................................................... 16
7-1-1) Back-light does not turn on and no LVDS signal. ...................................................................................... 16
7-1-2) No Analog TV is displayed. .................................................................................................................................... 17
7-1-3) No picture in CVBS of AV1 mode. ...................................................................................................................... 18
7-1-4) No picture in RGB of AV1 mode. ........................................................................................................................ 19
7-1-5) No picture in CVBS of AV2 mode. ...................................................................................................................... 20
7-1-6) No picture in CVBS of AV3 mode. ...................................................................................................................... 21
7-1-7) No picture in PC Mode. ............................................................................................................................................ 21
3
7-1-8) No picture in component mode. ......................................................................................................................... 23
7-1-9) No picture in S-video mode. ................................................................................................................................. 24
7-1-10) No picture at external TV connected with AV1(RF-Output). ............................................................. 25
7-1-11) No picture/Sound in HDMI mode. ................................................................................................................... 26
7-2) When no sound output from internal speaker. ........................................................................................................ 27
7-2-1) No sound of analog TV mode. ............................................................................................................................. 27
7-2-2) No sound of AV1 mode. .......................................................................................................................................... 28
7-2-3) No sound of AV2 mode. .......................................................................................................................................... 29
7-2-4) No sound of PC/DVI Sound mode. .................................................................................................................... 30
7-2-5) No sound of Component Sound mode. .......................................................................................................... 31
7-2-6) No sound of AV3/S-Video Sound mode. ........................................................................................................ 32
7-2-7) No sound of Digital TV/HDMI mode. ............................................................................................................... 33
7-2-8) No sound at external TV connected with AV1(RF-Output). .................................................................. 33
7-2-9) No Picture or No Sound In the Media(USB) Mode. .................................................................................. 34
7-2-10) Sound In/Output of AMP. .................................................................................................................................... 34
7-3. When supply voltage of SMPS is not good. ............................................................................................................... 35
7-3-1) 32, 37 inch Model (FEL-3237VN). ........................................................................................................................ 35
7-3-2) 42 inch Models (FEL-4247VN)............................................................................................................................... 36
8. Parts List. ....................................................................................................................................... 37
8-1. Main Board Part List. ............................................................................................................................................................... 37
8-2. Differential Part List. ................................................................................................................................................................ 48
8-2-1. Differential Part of Main Chassis depending on Panel Maker.............................................................. 48
8-2-2. Differential Part of Main Chassis depending on Panel type. ................................................................ 48
8-3. Union Part List. ........................................................................................................................................................................... 48
8-4. Cable Lists. .................................................................................................................................................................................... 48
8-5. SMPS Part list. ............................................................................................................................................................................. 49
8-5-1) FEL-3237VN. ................................................................................................................................................................... 49
8-5-2) FEL-4247VN. ................................................................................................................................................................... 52
9. Mechanical Assembly Drawing. ................................................................................................ 55
9-1. Model : 32L1. ............................................................................................................................................................................... 55
9-2. Model : 32L2. ............................................................................................................................................................................... 56
9-3. Model : 37L1. ............................................................................................................................................................................... 57
9-4. Model : 37L2. ............................................................................................................................................................................... 58
9-5. Model : 42L1. ............................................................................................................................................................................... 59
9-6. Model : 42L2. ............................................................................................................................................................................... 60
10. Schematics. .................................................................................................................................. 61
4
Model line-up using SL-S00T/10T chassis.
1) Mechanical design of DAEWOO models.
32 Inch 37 Inch 42 Inch 42 Inch FHD
Brand L2 Cabinet
(SL-S00T) (SL-S00T) (SL-S00T) (SL-S10T)
Black / Silver LT32L2 LT37L2 LT42L2 LT42L2FH
Black / Gold LT32L2K LT37L2K LT42L2K LT42L2KFH
DAEWOO
Black / Red LT32L2R LT37L2R LT42L2R LT42L2RFH
Black / Blue LT32L2Z LT37L2Z LT42L2Z LT42L2ZFH
2) Mechanical design of hanseatic models.
32 Inch 37 Inch 42 Inch
Brand L1 Cabinet
(SL-S00T) (SL-S00T) (SL-S00T)
hanseatic Black 1 Tone LC32-260T LC37-260T LC42-260T
3) Buyer and Factory Model Names.
Brand Chassis BYR Model FCT Model
DAEWOO SL-S00T LT32L1 LT32L1B1LM
DAEWOO SL-S00T LT32L1 LT32L1B1SM
hanseatic SL-S00T LC32-260T LT32L1B1LM
hanseatic SL-S00T LC32-260T LT32L1B1SM
DAEWOO SL-S00T LT37L1 LT37L1B1LM
hanseatic SL-S00T LC37-260T LT37L1B1LM
DAEWOO SL-S00T LT42L1 LT42L1B1LM
hanseatic SL-S00T LC42-260T LT42L1B1LM
DAEWOO SL-S10T LT42L1FH LT42L1B1LF
hanseatic SL-S10T LC42-300FT LT42L1B1LF
DAEWOO SL-S00T LT32L2 LT32L2BSLM
DAEWOO SL-S00T LT32L2 LT32L2BSSM
DAEWOO SL-S00T LT32L2K LT32L2BKLM
DAEWOO SL-S00T LT32L2K LT32L2BKSM
DAEWOO SL-S00T LT32L2R LT32L2BRLM
DAEWOO SL-S00T LT32L2R LT32L2BRSM
DAEWOO SL-S00T LT32L2Z LT32L2BZLM
DAEWOO SL-S00T LT32L2Z LT32L2BZSM
DAEWOO SL-S00T LT37L2 LT37L2BSLM
DAEWOO SL-S00T LT37L2K LT37L2BKLM
DAEWOO SL-S00T LT37L2R LT37L2BRLM
DAEWOO SL-S00T LT37L2Z LT37L2BZLM
DAEWOO SL-S00T LT42L2 LT42L2BSLM
DAEWOO SL-S00T LT42L2K LT42L2BKLM
DAEWOO SL-S00T LT42L2R LT42L2BRLM
DAEWOO SL-S00T LT42L2Z LT42L2BZLM
DAEWOO SL-S10T LT42L2FH LT42L2BSLF
DAEWOO SL-S10T LT42L2KFH LT42L2BKLF
DAEWOO SL-S10T LT42L2RFH LT42L2BRLF
DAEWOO SL-S10T LT42L2ZFH LT42L2BZLF
5
1. Safety Precaution.
(1) When moving or laying down a LCD Set, please deal with care. Avoid any impact towards the LCD Set.
(2) Do not leave a broken LCD Set on for a long time. To prevent some damages, after check it, make sure to
turn the power (AC) off.
(3) When opening the BACK COVER, you must turn off power (AC) to prevent any electric shock.
(4) When loosening screws, check the connecting position and type of the screw.
Sort out the screws and store them separately, because screws holding PCBs are working as a ground level,
make sure to check if any screw is missing when assembling.
(5) A LCD Set contains different kinds of connector cables.
Before connecting or disconnecting connector cables, check the direction and position of the cable beforehand.
(6) When disconnecting connectors unplug the connectors slowly with care.
(7) Connectors are designed so that if the number of pins or the direction does not match, connectors will not
fit. When having problem in plugging the connectors, make sure to check their kind, position, and direction.
6
2. Preliminary Troubleshooting
2-1) LCD TV does not response or remote controller does not work.
Check the power cord to be plugged.
Check the battery of the remote controller.
2-2) Sound is discontinuous or broken sometimes.
Check [SOUND] -> [AVC] is [ON].
Set the sound into 'Mono'.
Ask for the broadcasting station if the RF cable connection has no problem.
Ask for the broadcasting station to check signal strength of RF cable.
2-3) Picture of digital program is sometimes broken and sound is discontinuous.
Digital program has a little problem because of signal receiving status.
Check the RF cable connection.
Ask for the broadcasting station if the RF cable connection has no problem.
Ask for the broadcasting station to check signal strength of RF cable.
2-4) Picture of analog program is noisy.
Check the RF cable connection.
Check [Picture] -> [Noise Reduction] is ON.
Change the [Install] -> [Analog or Digital Manual Tuning] -> [Fine] value.
Ask for the broadcasting station to check signal strength of RF cable.
2-5) Sound is not generated in HDMI mode.
Reconnect HDMI jack.
DVI cable has no sound. Check the output signal of device to be connected to LCD TV.
If you want to use DVI-HDMI cable, to listen sound, stereo cable should be connected to PC audio jack.
2-6) In spite of 'Auto Adjust', picture size in the PC mode is not completely adapted to the screen.
Check if the input signal is available.
Ensure that the desktop has no black area.
Some errors (picture position problem) will be occurred according to certain video card.
In this case, you should adjust 'Frequency' control.
2-7) In spite of 'Auto Adjust' in the PC mode, picture is not clear.
Adjust 'Phase' control.
7
3. Product Specifications.
3-1) Standard.
32 Inch HD Model 37 Inch HD Model 42 inch HD Model 42 inch Full HD Model
Screen Size 32" 37" 42" 42"
Aspect Ratio 16 : 9 16 : 9 16 : 9 16 : 9
LCD Panel Resolution 1366 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
