Image preview - the first page of the document
>> Download SBC2410diff documenatation <<Text preview - extract from the documentFeatures SBC2410-I SBC2410-II SBC2410-III
CPU Samsung S3C2410A
SDRAM 128Mbyte 64Mbyte 32Mbyte
Nand flash No 64Mbyte 64Mbyte
Nor flash 32Mbyte 1Mbyte No
Serial flash 8Mbit (1M x 8) No No
Serial EEPROM (I2C) 256Kbyte No No
10M Ethernet interface No Yes Yes
Serial port UART1 for GPS 3 3
UART2 for PC communication
USB Host 2-channel 1 1
USB Slave 1 1 1
SD/MMC card socket Yes Yes Yes
Audio In/Out Yes Yes Yes
RTC Yes Yes Yes
IDE interface No No Yes
Keypad interface Yes No (Can be extended) No (Can be extended)
LCD interface Yes Yes Yes
TouchScreen interface Yes Yes Yes
Jtag interface 20pin 20pin 20pin
Bluetooth port UART0 No No
System bus interface No Yes No
User buttons No Yes Yes
User LED Yes Yes Yes
GPIO connector 96pin 36pin No
Power +5V +5V +12V
Size 120 x 107 mm 120 x 90 mm 135x169mm (carrier board)
58x36mm (kernel board)
May, 2007
