Western Microtechnology
12900 Saratoga Avenue
Saratoga, CA 95070
Phone (408) 725-1660
FAX# (408) 255-6491
Suggested
Retail Price
$13.90
8/16-Bit
Microprocessors
Microcomputers
Peripherals
1987 Data Book
Fujitsu Limited
Fujitsu Microelectronics, Inc.
Fujitsu Mikroelektronik GmbH
Fujitsu Microelectronics Pacific Asia Ltd.
Worldwide Suppliers of Communications
and Electronics Equipment
Copyrlgh1@19S6 by Fujitsu Limited and Fujitsu Microelectronics, Inc.
All Rights Reserved.
Copyright" 1986 Fujitsu Limited, Tokyo, Japan, and Fujitsu Microelectronics, Inc.
All Rights Reserved.
Circuit diagrams utilizing Fujitsu products are Included as a means of illustrating typical semiconductor
applications. Consequently. complete information sufficient for construction purposes Is not necessarily
given.
The Information contained In this document has been carefully checked and Is believed to be entirely
reliable. However, Fujitsu Limited and Its subsidiaries assume no responsibility for inaccuracies.
The information conveyed In this document does not convey any license under the copyrights. patent
rights or trade marks claimed and owned by Fujitsu Limited or Its subsidiaries.
Fujitsu Limited and Its subsidiaries reserve the right to change products or specifications without notice.
This document Is published by the Technical Publications Department, Fujitsu Microelectronics, Inc.,
3320 Scott Blvd., Santa Clara, California, U.S.A. 95054-3197.
Printed In the U.S.A.
Edition 1.0
Fujitsu Limited
Fujitsu Limited, headquartered near Tokyo, Japan, is Japan's largest
supplier of computers and ranks in the top ten companies operating in
Japan. Fujitsu is also one of the world's largest suppliers of telecom-
munications equipment and semiconductor devices.
Established in 1935 as the Communications Division spinoff of Fuji
Electric Company Limited, Fujitsu Limited, in 1985, celebrated 50 years
of service to the world through the development and manufacture of
state-of-the-art products in data processing, telecommunications and
semiconductors. Fujitsu operates subsidiaries worldwide in two dozen
countries and employs over 80,000 people to generate annual sales in
excess of nine billion US dollars. (Year ended March 31, 1986 consoli-
dated base.)
Fujitsu has five plants in key industrial regions in Japan covering all
steps of semiconductor production. Five wholly owned Japanese
subsidiaries provide additional capacity for production of advanced
semiconductor devices. Two additional facilities operate in the U.S. and
Europe to help meet the growing worldwide demand for Fujitsu semicon-
ductor products. In all, Fujitsu operations occupy over 1.6 million
square meters of manufacturing space worldwide.
Semiconductor Products
In 1975, Fujitsu developed 8-bit microcomputers. In 1977, Fujitsu
introduced proprietary 4-bit microcomputers. Today, their 4-bit
microcomputer family is the largest 4-bit product line in the world. With
the development of the high performance 16-bit micropcocessors,
Fujitsu offers a full line of microprocessors, microcomputers, and
peripherals to provide designers with a total of 150 products, including
90 products in CMOS families, 50 products in NMOS families and 10
products in bipolar peripherals.
In 1983, Fujitsu introduced the world's first CMOS single-chip Digital
Signal Processor, the MB8764. Fujitsu's DSP provides telecommunica-
tion designers with high-speed signal processing capabilities and at a
cost-effective solution.
Other Fujitsu industry standard products include GaAs FETs, GaAs FET
amplifiers, Si microwave transistors and light wave semiconductors.
Discrete products include power-switching transistors and Darlington
Array transistors.
Fujitsu's custom product lines include application-specific gate arrays
and standard-cell arrays using high-speed Bipolar and ECl technologies
and advanced CMOS technologies. Gate arrays ranging in size from
350 to 20,000 gates are available in up to 8,000 gate equivalents and
include on-chip memory and program logic array.
Virtually every major type of electronics equipment on the globe .utilizes
Fujitsu technology in integrated circuits. Fujitsu's leadership position in
worldwide integrated circuit development and manufacturing assures
equipment manufacturers that they will always be able to design with the
latest in technology utilizing the highest standards of quality and
reliability.
iii
Fujitsu Microelectronics, Inc.
Established in 1979, Fujitsu Microelectronics, Inc., headquartered in
Santa Clara, California, markets Fujitsu semiconductors through
representatives located throughout the U.S. and North America.
The Component Division, Fujitsu Component of America, Inc., markets
bubble memories, keyboards, plasma displays, relay switches and
hybrid ICs.
FMl's San Diego manufacturing facility provides capacity for manufactur-
ing of many high-technology devices for the U.S. and North American
market.
Customer support for custom designs is available through Fujtsu's
design centers in Santa Clara. Dallas and Boston. Technology Centers
offering on-site customer training. CAE design facilities and design
assistance are planned.
Fujitsu Mikroelektronik GmbH (European Sales Center)
Fujitsu Mikroelektronick GmbH (FMG) was established in June. 1980. in
Frankfurt. West Germany. and is a totally owned subsidiary of Fujitsu
Limited. Tokyo. FMG is the sole representative of the Fujitsu Electronic
Device Group in Western Europe. The wide range of IC products. LSI
memories and. in particular. gate arrays are noted throughout Western
Europe for design excellence and unmatched reliability. Five branch
offices to support Fujitsu's semiconductor operations are located in
Munich. London. Paris. Stockholm. and Milan.
Fujitsu Microelectronics Ireland. Ltd (European Production Center)
Fujitsu Microelectronics Ireland. Ltd. (FME) was established in 1980 in
the suburbs of Dublin as Fujitsu's European Production Center for
integrated circuits. FME supplies 64K/256K DRAMs. 64K CMOS/NMOS
EPROMs. 256K EPROMs. and other LSI memory products.
Fujitsu Microelectronics, Ltd (European Design Center)
