Image preview - the first page of the document



>> Download TV-CIWP4206 A documenatation <<

Text preview - extract from the document

                                                       SUPPLEMENT




SERVICE MANUAL
This service manual shows only the differences between
the model CIWP4206 A and the original model CIWP4206.
All other information is described in the service manual
of the model CIWP4206.



          42 DIGITAL/ANALOG
          PLASMA DISPLAY TV
               CIWP4206 A




                                                               INPUT SELECT /                  POWER
                                    SETUP   VOLUME   CHANNEL       ENTER        STANDBY   ON
                                   MAIN SECTION
                                42 DIGITAL/ANALOG
                                PLASMA DISPLAY TV
                                                CIWP4206 A


                                                       TABLE OF CONTENTS
Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .    1-1-1
Schematic Diagrams / CBA's and Test Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .                       1-2-1
Mechanical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .       1-3-1
Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   1-4-1
                                                                                                                                                                                              NOTE:
               CAUTION !                                                                                                                                                                      The voltage for parts in hot circuit is measured using
               Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.                       CAUTION ! : For continued protection against risk of fire,         hot GND as a common terminal.
               If Main Fuse (F601, F2000) is blown , check to see that all components in the power                                     replace only with same type 4A, 250V fuse.
               supply circuit are not defective before you connect the AC plug to the AC power supply.         4A 250V     ATTENTION : Utiliser un fusible de rechange de m
