   Electrical Calibration
   Workload Matrix

                                                                                                         Electrical
                                      Multi-Product              Multifunction      Oscilloscope                             Power and Energy                      Precision Process
                                                                                                          Tester
                                       Calibrators               Calibrators         Calibrators                         Calibrators and Standards                    Calibrators
                                                                                                         Calibrator




Workload                    5080A        5502A       5522A          5730A               9500B              5320A         6003A        6100B        6105A          525B             7526A
Analog/panel meters
High burden meters
Low burden meters                                                                                          V dc & V ac                                         V dc, I dc & R    V dc, I dc & R
DMMs
Basic dc V accuracy         100 ppm      50 ppm       11 ppm        3.5 ppm                n/a              0.10 %       375 ppm      112 ppm      42 ppm         40 ppm           40 ppm
3.5 digits                                                                                                 V dc & V ac                                         V dc, I dc & R     V dc & V ac
(typ.
