Image preview - the first page of the document
![er0286_brera__led_ita-eng_(sup037rg)_rev.00[1]](/pics/5c182d9d6ffd6.gif)
>> Download er0286_brera__led_ita-eng_(sup037rg)_rev.00[1] documenatation <<
Text preview - extract from the document
Esp. ER0286 Rev.00
25 17 40
4 47 50 5
1 2
15
26
30 51
53 39
30
49 30
14
41 37
18 30
30 42
36
16
54
30 43
27 30 34
19 35 38
52
8
9
30
29 33
28
30
7 44
21
22 30
10
11 31
6 32
12 20
6
13 45
48 3
46
23 24
SUP037RG Cod.10003083-10003230
POS CODICE DESCRIZIONE NOTE POS CODE DESCRIPTION NOTE
01 11022867 TUBET.GAGGIA KLUBER TRIBOSTAR SIL 2 5GR 01 11022867 GAGGIA KLUBER TRIBOSTAR SIL 2 TUBE 5GR.
02 15001876 LIBR.ISTR.GAG SUP037RG GXSM GB/I/D/F/E 02 15001876 MANUAL GAG SUP037RG GXSM GB/I/D/F/E
15001877 LIBR.ISTR.GAG SUP037RG GXSM P/NL/PL/RUS 15001877 MANUAL GAG SUP037RG GXSM P/NL/PL/RUS
03 147622800 PIEDINO PIANETA CAFFE' SILIC.TRASPAR. 03 147622800 TRANSPARENT SILICONE FOOT
04 183911050 CAVO AL.SCHUKO 3X1 H05VV-F NERO L=1200MM 04 183911050 BLACK POWER CABLE SCHUKO L=1200MM
05 11013206 POMEL.REGOL.MACINAT.CAF.XSM NER. 05 11013206 BLACK GRIND.ADJUSTMENT KNOB XSM
06 11021742 AS.COPERTURA CONTENITORI GXSM INOX/NERO 06 11021742 BLACK/SS CONTAINERS COVER GXSM ASSY.
07 11013093 AS.CONTENIT.ACQUA XSM GRI/NAT. 07 11013093 NATUR/GREY WATER CONTAINER XSM ASSY.
08 224640200 AS.FILTRO ESTERNO X CONTENITORI ACQUA 08 224640200 EXTERNAL FILTER FOR WATER CONTAINER ASSY
09 140328461 OR METRICO 0190-10 IN EPDM 09 140328461 EPDM OR METRIC 0190-10
10 11003672 MOLLA CILINDRICA X VALV.CONT.ACQUA P0049 10 11003672 SPRING FOR WATER CONTAINER VALVE P0049
11 11003673 INSERTO X VALV.CONTEN.ACQUA P0049 GRIGIO 11 11003673 GREY WATER CONTAINER VALVE INSERT P0049
12 11003671 VALVOLA X CONTENIT.ACQUA P0049 TRASPAR. 12 11003671 TRANSP.VALVE FOR WATER CONTAINER P0049
13 11001298 COPERCHIO X VALVOLA DUCKBILL P0049 NERO 13 11001298 BLACK LID FOR DUCKBILL VALVE P0049
14 11022932 COPERTURA SUP.CARC.GXSM VERN.GRIGIO 14 11022932 GREY UPPER CASING COVER GXSM
11013882 COPERTURA SUP.CARC.GXSM NERO 11013882 BLACK UPPER CASING COVER GXSM
15 129912504 VITE TCBR 3,5X14 PLAST.ZN-N 15 129912504 SCREW TCBR TORX 10 3,5X14 PLAST.ZN-N
16 11021337 TAPPO PANNELLO FRONT.GXSM CROM. 16 11021337 CHROMED FRONTAL PANEL CAP GXSM
17 11013876 COP.TRAMOGGIA CAF.MACIN.GXSM GRI/NAT. 17 11013876 NATUR/GREY GROUND COFFEE HOPPER LID GXSM
18 11022930 CARC.LATO SX GXSM VERN.GRIGIO 18 11022930 GREY CASING LEFT SIDE GXSM
11013880 CARC.LATO SX GXSM NERO 11013880 BLACK CASING LEFT SIDE GXSM
19 11012708 INSER.FONDO CARC.XSM NER. 19 11012708 BLACK INSERT FOR CASING BOTTOM XSM
20 11022419 COPERTURA FONDO CARC.XSM VERN.GRIGIO 20 11022419 GREY CASING BOTTOM COVER XSM
11012681 COPERTURA FONDO CARC.XSM NERO 11012681 BLACK CASING BOTTOM COVER XSM
21 11012601 FONDO CARC.XSM NERO 21 11012601 BLACK CASING BOTTOM XSM
22 11013857 GRIGLIA VASCA REC.ACQUA GXSM INOX 22 11013857 STAINL.STEEL GRATE FOR DRIP TRAY GXSM
23 11013184 GALLEG.VASCA REC.ACQUA XSM ROSSO 23 11013184 RED FLOAT FOR DRIP TRAY XSM
24 11022931 VASCA REC.ACQUA GXSM VERN.GRIGIO 24 11022931 GREY DRIP TRAY GXSM
11013883 VASCA REC.ACQUA GXSM NERO 11013883 BLACK DRIP TRAY GXSM
25 11022854 COP.CONT.CAF.GRANI C/GUARN.GXSM GRI/NAT. 25 11022854 NATUR/GREY BEAN COFF.CONTAINER LID GXSM
26 11012724 CONTENIT.CAFFE' GRANI XSM GRI/NAT. 26 11012724 NATUR/GREY BEAN CONTAINER XSM
27 11012642 PIASTRA SUPPORTO MACINACAFFE' XSM NERO 27 11012642 BLACK COFFEE GRINDER PLATE XSM
28 11013709 AS.CONN.3POLI LIVELLO ACQUA XSM UL 28 11013709 3POLES CONNECTOR WATER LEVEL XSM UL
29 11000651 SCHEDA SENSORE CAPACITIVO LIVEL.ACQ.P124 29 11000651 WATER LEVEL SENSOR BOARD P124
30 12000450 VITE TCBR 3,5X12 PLAST.ZN-N 30 12000450 SCREW TCBR TORX 10 3,5X12 PLAST.ZN-N
31 11012709 CASSET.RACCOGLI FONDI XSM NERO 31 11012709 BLACK DUMP BOX XSM
32 11022978 AS.SPORT.LATO DX VERN.GRIGIO 32 11022978 GREY DOOR RIGHT SIDE GXSM ASSY.
11021743 AS.SPORT.LATO DX GXSM NERO 11021743 BLACK DOOR RIGHT SIDE GXSM ASSY.
33 11012713 CERNIERA SPORT.PLAST.LATO DX XSM NERO 33 11012713 BLACK HINGE FOR DOOR RIGHT SIDE XSM
34 11012714 CERNIERA CARC.POST.XSM NERO 34 11012714 BLACK HINGE FOR REAR CASING XSM
35 NE03.038 INTERRUTTORE BIPOLARE FUSIT C1250AR 35 NE03.038 BIPOLAR SWITCH FUSIT C1250AR
36 NE05.013 MICROINTERRUTTORE 36 NE05.013 MICROSWITCH
37 11012719 COPERTURA INSONORIZZAZIONE MC XSM NERO 37 11012719 SOUNDPROOFING COVER FOR COFGRINDER XSM
Rev. 00 - 14/10/09 TAVOLA 1a/5
BRERA LED
Esp. ER0286 Rev.00
25 17 40
4 47 50 5
1 2
15
26
30 51
53 39
30
49 30
14
41 37
18 30
30 42
36
16
54
30 43
27 30 34
19 35 38
52
8
9
30
29 33
28
30
7 44
21
22 30
10
11 31
6 32
12 20
6
13 45
48 3
46
23 24
SUP037RG Cod.10003083-10003230
POS CODICE DESCRIZIONE NOTE POS CODE DESCRIPTION NOTE
38 11014196 CARC.POST.GXSM NERO 38 11014196 BLACK REAR CASING GXSM
39 11022934 COP.ACCESSO INFRAROSSI GXSM VERN.GRIGIO 39 11022934 GREY COVER INFRAREDS ACCESS GXSM
11014031 COP.ACCESSO INFRAROSSI GXSM NERO 11014031 BLACK COVER INFRAREDS ACCESS GXSM
40 149213000 TAPPO X POMELLI CONT.CAF.GRANI TRASP. 40 149213000 TRANSP.CAP FOR KNOBS BEAN CONTAINER
41 120350604 ANELLO 6 UNI 7434 BRUNITO 41 120350604 SHAFT 6 UNI 7434
42 11012301 PROTEZIONE SCHEDA PWR/CPU P0057 NERO 42 11012301 BLACK PWR/CPU BOARD PROTECTION P0057
43 11012593 AS.CPU+SW XSM V2 230V 43 11012593 CPU+SW AS.XSM V2 230V
44 13000994 INSER.SUP.SCATOLA GXSM PS-E 44 13000994 PS-E UPPER INSERT FOR BOX GXSM
45 13000995 INSER.INF.SCATOLA GXSM PS-E 45 13000995 PS-E LOWER INSERT FOR BOX GXSM
46 13000999 SCATOLA LITOGRAF.GAGGIA BRERA LED 46 13000999 DISPLAY BOX GAGGIA BRERA LED
47 146680850 MISURINO X CAFFE' SMART NER. 47 146680850 BLACK COFFEE MEASURE SMART
48 11022933 SUPP .GRIGL.VASCA REC.ACQ.GXSM VERN.GRIGIO 48 11022933 GREY DRIP TRAY GRATE SUPPORT GXSM
11013858 SUPP.GRIGL.VASCA REC.ACQ.GXSM NERO 11013858 BLACK DRIP TRAY GRATE SUPPORT GXSM
49 11021744 AS.PANNELLO FRONT.GXSM INOX/NERO SER. 49 11021744 BLACK/SS FRONTAL PANEL S/SCR.GXSM ASSY.
50 21000961 ACC SAE BRITA WATER FILTER 1 UNIT EUR 50 21000961 ACC SAE BRITA WATER FILTER 1 UNIT EUR
51 129912521 VITE TCBR 3,5X14 PLAST.INOX 51 129912521 SCREW TCBR TORX 10 3,5X14 PLAST.SS
52 12000280 PRESA A VASCHETTA C/SMUSSI EN 60320 C 13 52 12000280 CUP SOCKET EN 60320 C 13
53 11023102 GUARNIZ.CONTEN.CAFFE' GRANI GXSM NERO 53 11023102 BLACK BEAN COFFEE CONTAIN.SEAL GXSM
54 11023103 PROTEZ.ISOLANTE ADES.COP.SUP.CARC.GXSM 54 11023103 UPPER COVER CASING INSUL.PROTECTION GXSM
Rev. 00 - 14/10/09 TAVOLA 1b/5
BRERA LED
Esp. ER0286 Rev.00
12 1
30 2 30
24
11 25
21 3
28 26
22
31 27 23 30
20 4 30
29
5
6 10
9
7 17
30 8 16
18
19
14 15
30
30
13
SUP037RG Cod.10003083-10003230
POS CODICE DESCRIZIONE NOTE POS CODE DESCRIPTION NOTE
01 11013856 SUPP.SCHEDA CPU GXSM NERO 01 11013856 BLACK CPU BOARD SUPPORT GXSM
02 11013859 GUARNIZ.TASTIERA GXSM NEU. 02 11013859 NEUTER TOUCH PANEL SEAL GXSM
03 11014002 SCHEDA KYB-LED INTERF.GXSM 03 11014002 KEYBOARD LED INTERFACE GXSM
04 11013888 SUPP.GUIDA LUCE GXSM NERO 04 11013888 BLACK GUIDE LIGHT SUPPORT GXSM
05 11013893 VETRINO LED GXSM TRASP. 05 11013893 TRANSPARENT GLASS FOR LED GXSM
06 11021887 TASTO GXSM SER.NERO+TAZZA CAFFE' CORTO 06 11021887 BLACK SHORT COFFEE CUP BUTTON GXSM
07 11021886 TASTO GXSM SER. NERO +TAZZA CAFFE' LUNGO 07 11021886 BLACK LONG COFFEE CUP BUTTON GXSM
08 11021888 TASTO GXSM SER. NERO + AROMA 08 11021888 BLACK AROMA COFFEE BUTTON GXSM
09 11021889 TASTO GXSM SER.NERO + ON/OFF 09 11021889 BLACK ON/OFF BUTTON GXSM
10 11013889 INSER.BLOCCAGGIO SCHEDA CPU GXSM NERO 10 11013889 BLACK CPU BOARD RETAINING INSERT GXSM
11 11021362 FRONTALINO EROGAT.CAFF.GXSM CROM. 11 11021362 CHROM.COFFEE DISPENSER FRONT PLATE GXSM
12 11021339 SUPP.FISSO EROGAT.CAFF.GXSM CROM. 12 11021339 CHROMED COFFEE DISPENSER SUPPORT GXSM
13 11021338 COPERT.POMEL.COMANDI GXSM CROM. 13 11021338 CHROMED CONTROL KNOB COVER GXSM
14 11013886 POMEL.COMANDI GXSM NEU. 14 11013886 NATURAL CONTROL KNOB GXSM
15 11014090 COP.SUPP.POMEL.COMANDI GXSM NERO 15 11014090 BLACK CONTROL KNOB SUPPORT COVER GXSM
16 11013117 AS.SUPP.POMEL.COMANDI C/CALAM.XSM NERO 16 11013117 BLACK CONTROL KNOB SUPPORT XSM ASSY.
17 11014029 SCHEDA RUBINETTO GXSM 17 11014029 KEYBOARD TAP SENSOR GXSM
18 11012704 SUPP.SCHEDA POMELLO XSM NERO 18 11012704 BLACK KNOB ELECTR.BOARD SUPPORT XSM
19 11004120 INGRANAGGIO Z=26 VAPORE/ACQUA P0057 NERO 19 11004120 BLACK STEAM/WATER GEAR Z=26 P0057
20 11012707 SUPP.FRONTALINO XSM NERO 20 11012707 BLACK FRONT PANEL SUPPORT XSM
21 11013829 SUPP.PARTE MOBILE EROGAT.CAFF.GXSM NERO 21 11013829 BLACK COF.DISPENSER MOBILEPART SUPP.GXSM
22 11005101 BOCCOLA X TUBO TEFLON 4X2 P124 22 11005101 BUSH FOR 4X2 TEFLON TUBE P124
23 11005100 PIASTRINA X BOCCOLA TUBO TEFLON 4X2 P124 23 11005100 PLATE FOR 4X2 TEFLON TUBE P124
24 149361200 TUBO SILICONE NERO 7,5X9,3 IN MATASSA 24 149361200 BLACK SILICONE TUBE 7,5X9,3 IN ROLL
25 140328059 OR 2015 IN SILICONE PTFE/FDA 25 140328059 OR 2015 IN SILICONE PTFE/FDA
26 11004132 AS.TUBO TEFLON 2X4 L=250MM+1BOC.DIST13MM 26 11004132 TEFLON TUBE 2X4 L=250 MM ASSY
27 9011.144 FORCELLA X TUBO D.4 27 9011.144 FORK FOR TUBE D.4
28 11013070 AS.EROGATORE CAFFE' SALD.XSM NERO 28 11013070 BLACK COFFEE DISPENSER XSM ASSY.
29 11013828 PARTE MOBILE EROG.CAFF.GXSM NERO 29 11013828 BLACK COF.DISPENSER MOBILE PART GXSM
30 12000450 VITE TCBR 3,5X12 PLAST.ZN-N 30 12000450 SCREW TCBR TORX 10 3,5X12 PLAST.ZN-N
31 129912902 VITE TCB 2,9X6,5 LAMIERA ZN-B 31 129912902 SCREW TCB TORX 10 2,9X6,5 SHEET ZN-B
Rev. 00 - 14/10/09 TAVOLA 2/5
BRERA LED
Esp. ER0286 Rev.00
17
12
13
26
21 24
4
24 12 27
31 25
14 34 28
18 15 29
16 12
17 19
12 30
20 12
4 12
1
28
21
2 5 7 22
8 4 35
3 6 9 23 27 32
10
11
33
27
SUP037RG Cod.10003083-10003230
POS CODICE DESCRIZIONE NOTE POS CODE DESCRIPTION NOTE
01 11007194 IMPUGNATURA TUBO VAPORE G0053 NERO 01 11007194 BLACK STEAM TUBE HANDGRIP G0053
02 11001620 CANOTTO INT.PANNARELLO P0049 NERO 02 11001620 BLACK PANNARELLO INTERNAL TUBE P0049
03 11011504 COPERTURA PANNARELLO P0049 OT/CROM.TF 03 11011504 TF/CHROM.PANNARELLO COVER P0049
04 12000450 VITE TCBR 3,5X12 PLAST.ZN-N 04 12000450 SCREW TCBR TORX 10 3,5X12 PLAST.ZN-N
05 128210600 RONDELLA ELASTICA X ALBERI D=6 MM 05 128210600 ELASTIC WASHER FOR SHAFT D=6MM
06 11012381 RUB.REGOLATORE FLUSSO ACQ/VAP.V2 P0057 06 11012381 FLOW SELECTOR FAUCET V2 P0057
07 12000893 OR METRICO 0120-20 IN EPDM 07 12000893 OR METRIC 0120-20 IN EPDM
08 11008104 VALVOLA A FUNGO REGOLAT.DI FLUSSO P0057 08 11008104 MUSHROOM VALVE FOR FLOW SELECTOR P0057
09 11008105 SUPP.VALV.A FUNGO REGOL.DI FLUSSO P0057 09 11008105 SUPPORT VALVE FOR FLOW SELECTOR P0057
10 11008077 MOLLA VALVOLA REGOLAT.DI FLUSSO P0057 10 11008077 SPRING FOR VALVE FLOW SELECTOR P0057
11 11008106 TAPPO VALV.A FUNGO REGOL.DI FLUSSO P0057 11 11008106 VALVE CAP FOR FLOW SELECTOR P0057
12 12000892 FASCETTA OETIKER D=9,5 16700004 12 12000892 OETIKER CLAMP D=9,5 16700004
13 11005757 SUPPORTO TUBO VAPORE P0057 NEU. 13 11005757 STEAM TUBE SUPPORT P0057
14 11014042 AS.TUBO VAPORE+DADO GXSM OT/CROM.TF 14 11014042 TF/CHROMED STEAM TUBE GXSM ASSY.
15 140324461 OR ORM 0060-20 IN TERMOIL 15 140324461 OR ORM 0060-20 IN TERMOIL
16 11011127 BOCCOLA TUBO VAPORE P0057 PA6 NERO 16 11011127 BLACK PA6 BUSH FOR STEAM TUBE P0057
17 16000380 TUBO SIL.RETIN.5X8,9 IN MATASSA 17 16000380 5X8,9 SILICONE TUBE IN ROLL
18 11012923 PROTEZIONE TUBO VAPORE XSM CROM. 18 11012923 CHROMED STEAM TUBE PROTECTION XSM
19 12001368 VITE TSP 5X35 PLAST.ZN-B 19 12001368 SCREW TSP TORX 10 5X35 PLAST.ZN-B
20 11013735 AS.CALD.TUB.SLIM 230V - 1300W 20 11013735 SLIM TUB.BOILER ASSY. 230V - 1300W
21 129573202 VITE TCB M4X8 AUTOFORMANTE ZN-B 21 129573202 SCREW TCB TORX 20 M4X8 AUTOFORMING ZN-B
22 190800100 SENSORE TEMPERATURA NTC UL L=280MM 22 190800100 TEMPERATURE SENSOR NTC UL L=280MM
23 11022791 SUPPORTO CALDAIA TUB.SLIM/EXSL NERO 23 11022791 BLACK SLIM/EXSL BOILER SUPPORT
24 12001034 TERMOSTATO 175◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
