Image preview - the first page of the document



>> Download SI-1997GB documenatation <<

Text preview - extract from the document

Service
Information
Bulletins




1997
                                                            Table of Contents
Audio / Hifi
RR 3500 CD, RR 650 CD
  Serial no. 1/97 ................................................................................................................................. 4

UMS1, UMS2
  Serial no. 2/97 ................................................................................................................................. 5

R14 DPL5
  Serial no. 3/97 ................................................................................................................................. 6

CD 436, CD 437, CD 11, CD 12, CD-IR, M30 CD
  Serial no. 4/97 ................................................................................................................................. 7

RCD400, UMS2
  Serial no. 5/97 ................................................................................................................................. 8

TV / Sat
Chassis Digi Basic, e.g. ST 70-255 IDTV/LOG, M 70-280 IDTV/LOG, SE 7089 IDTV/LOG
  Serial no. 1/97 ................................................................................................................................. 9

Chassis Digi Basic (CUC 1825, 1826), Digi Basic+ (CUC 1827) and Digi 6 (CUC 1952, 1983, 1984)
  Serial no. 1/97 ................................................................................................................................. 9

TVR 3701 SV
  Serial no. 2/97 ............................................................................................................................... 10

Chassis CUC 7301 text, e.g. P 37-730 text
  Serial no. 3/97 ............................................................................................................................... 11

Chassis CUC 7303 and 7305, e.g. P 37-071, T 51-720 text, T 55-731 text
  Serial no. 5/97 ............................................................................................................................... 12

Chassis CUC 7350, e.g. ST 55-750 text
  Serial no. 6/97 ............................................................................................................................... 13

Chassis CUC 7300, e.g. P 37-740 SAT, and all sets retrofitted with
  the built-in Satellite Receiver SER 7300
  Serial no. 7/97 ............................................................................................................................... 14

Chassis Digi Basic CUC 1825, 1826 and 1827 - e.g. ST 63-255 IDTV/LOG,
  M 70-281 IDTV/LOG, SE 7089 IDTV/LOG
  Serial no. 8/97 ............................................................................................................................... 15

Chassis Digi 6 - CUC 1952, 1983, 1984 and built-in Satellite Receiver
  SER 150/SER 150 ET - e.g. Denver SE 8216/9 Ref./PIP, M 82-269/9 Reference
  Serial no. 9/97 ............................................................................................................................... 16

Mono-TV-Recorders TVR 3710, 5100 and 5500
  Serial no. 10/97 ............................................................................................................................. 17

Chassis Digi IV - CUC 1821/1851/1881/1892 and 1981
  e.g. M 70-781 IDTV, M 70-791 IDTV, M 82-102 IDTV, M 95-102 IDTV, M 82-169 PALplus
  Serial no. 11/97 ............................................................................................................................. 18

Colour television receivers with 82/70 cm Toshiba picture tube and chassis Digi 6 -
   e.g. M 82-269/9 Ref, SE 8216/9 Ref/PIP, M 70-269/9 Ref, SE 7016/9 Ref/PIP Trento
Colour television receivers with chassis Digi Basic CUC 1805/1825/1826 and 1827
   e.g. ST 63-255 IDTV/LOG, ST 72-261 IDTV/LOG, Boston SE 7090 IDTV/LOG
   Serial no. 12/97 ............................................................................................................................. 19




2
Chassis CUC 7301/7301F, e.g. P 37-070, T 51-730 text, T 55-730/5 text
Chassis Digi 6 - CUC 1952, 1983, 1984 and built-in Satellite Receiver SER 150/SER 150 ET
  e.g. Denver SE 8216/9 Ref./PIP, M 82-269/9 Reference
  Serial no. 13/97 ............................................................................................................................. 20

Chassis CUC 7303 e.g. P 37-731 text, P 45-731 text, T 55-731 text
Chassis CUC 7303/7305/7350 and CRT panels 29305-022.16/-022.17, e.g. P 37-731 text,
  P 45-731 text, T 55-731 text, P 37-731/12 text, ST 55-750 text, XS 55/1, Lissabon SE 5576 text
  Serial no. 14/97 ............................................................................................................................. 21

Chassis Digi 6 - CUC 1842, 1894, 1952, 1962 and 1983
  e.g. M 72-410 Ref., Denver SE 8216/9 PAL Plus, M 70-269/9 Ref.
  Serial no. 15/97 ............................................................................................................................. 22

Chassis Digi Basic and Digi 6 - CUC 1805, 1825, 1826, 1827, 1828, 1842,
  1894, 1952, 1962 and 1983, e.g. M 72-410 Ref., Denver SE 8216/9 PAL Plus, M 70-269/9 Ref
  Serial no. 16/97 ............................................................................................................................. 23

Chassis Digi Basic - CUC 1806, 1825, 1826, 1827, 1829, 1830 with CRT panels
  29305-122.04/10/12/17 z.B. ST 70-255 IDTV/LOG, ST 72-261 IDTV/LOG,
  Atlanta SE 7220 IDTV/LOG, ST 72-261 IDTV/LOG
  Serial no. 17/97 ............................................................................................................................. 24

CTV sets ST 72-261 IDTV/LOG and ST 72-261/8 IDTV/LOG with Toshiba picture tube
  Serial no. 18/97 ............................................................................................................................. 25

Satellite Receivers STR 631/632/641/642
   Serial no. 19/97 ............................................................................................................................. 26

Colour television receivers MW 70-100/8, M 72-100 and M 72-100/8
   Serial no. 20/97 ............................................................................................................................. 27




Video
Series GV 4xx video recorders with " World Deck "
   Serial no. 1/97 ............................................................................................................................... 28

GV 560HIFI
  Serial no. 2/97 ............................................................................................................................... 29

GV 6096 SV
  Serial no. 3/97 ............................................................................................................................... 30

Series GV 4xx video recorders with " World Deck "
   Serial no. 4/97 ............................................................................................................................... 31

GV 6096 SV
  Serial no. 5/97 ............................................................................................................................... 32

GV 660 / GV 690
  Serial no. 6/97 ............................................................................................................................... 33

GV 5xx and GV 6xx range of video recorders
  Serial no. 7/97 ............................................................................................................................... 34

GV 403, 407, 411/1, 411/2, 417, 437, 4001, 4002VPS, 4003VPS.
  Serial no. 8/97 ............................................................................................................................... 35

GV 7400 HIFI and variants, SE 7105 HIFI
  Serial no. 9/97 ............................................................................................................................... 36

                                                                                                                                                        3
                                             SERVICE INFORMATION

Product:       RR 3500 CD, RR 650 CD                                            Audio No 1/97



 RR 3500 CD, RR 650 CD

 Possible complaint:
 The working distance of the remote control handset is too short (<2m).

 Reason:
 Reverse connection of the collector and emitter of the transistor Q 901 ( remote
 control RC CD).

 Cure:
 Exchange the remote control or connect the transistor terminals correctly.

 Workshop:
 Check all available remote control handsets for a working range of about 4.5m
 and exchange or repair them where necessary.

 Stores:
 Remote control handset for RR 3500 CD / RR 650 CD, part no. 75954-046.34.




 Technical Services / Information




 8002 / 8012                                                                          5407700000
                                             SERVICE INFORMATION

Product:    UMS1, UMS2                                                          Audio No.   2/97




 UMS1, UMS2

 Possible complaint:
 No playback at all or distorted playback of a CD.

 Reason:
 Reversed polarity of capacitors C222 and C223 (1
