Image preview - the first page of the document



>> Download HYUNDAI L17T_SVC_Manual documenatation <<

Text preview - extract from the document

L17T
TFT LCD COLOR MONITOR



TECHNICAL SERVICE MANUAL
L17T Technical Service Manual


1    FORWORD
      This document defines design and performance requirements for Hyundai 17.0" On Screen Display
      Color TFT LCD monitor L17T. It is capable of displaying maximum 1,280 horizontal dots and 1024
      vertical lines resolution image.
      It also offers Power Management and DDC2B features according to VESA proposal.


2    GENERAL DESCRIPTION
     The monitor described in the followings is based on a multi- scanning, digital control display, 17.0
     inches diagonal. The monitor is intended to be a finished product, basically a display device mounted
     inside a plastic enclosure which will provide the aesthetic, ergonomic and safety requirements.


     2.1     LCD Descriptions
