Image preview - the first page of the document



>> Download HAIER_HNS1260TVE_HNS1260TVEME documenatation <<

Text preview - extract from the document

                                               Front Load Washing Machine        Model:HNS1260TVE/ME




FRONT LOAD WASHING MACHINE



                                          Service Manual


                                                          Suited model:

                                                               HNS1260TVE
                                                               HNS1260TVEME




Features

        300mm diameter porthole, door may be open at a 180 degrees.
       Class-A energy-saving; Homocentric tubs with higher energy efficiency
       Multi-gear speed controller
       Unique gasket design featuring no residual water hidden inside
       Delay time adjustive
       Large wash load capacity 6kg,Europe standard AAB




Serial Number: S M - H N S 1 2 6 0 T V E 0 1   Version: 1.00        Edition: 2008-04
                                   Front Load Washing Machine                Model:HNS1260TVE/ME




1. Contents----------------------------------------------------------------------------------------1

2. Product code illumination and series introduction-----------------------------------2

3. Features ---------------------------------------------------------------------------------------3

4. Specification ----------------------------------------------------------------------------------4

5. Safety --------------------- ---------------------------------------------------------------------6

6. Installation ------------------------------------------------------------------------------------9

7. Net dimension -------------------------------------------------------------------------------11

8. Names of the parts-------------------------------------------------------------------------12

9. Operational functions----------------------------------------------------------------------13

10. Program description table -------------------------------------------------------------15

11. Error display and troubleshooting ----------------------------------------------------16

12. Wiring circuit ------------------------------------------------------------------------------24




                                                   Page 1
                            Front Load Washing Machine            Model:HNS1260TVE/ME


 PRODUCT INTRODUCTION




 It represents HNS series appearance with big window 180 opening window 1200rpm
spin speed.Spin speed is adjustive from 400 to 1200 rpm,and alse exclude spin(indicate"0")
temprature is also adjustive,you can alse choose cold water. it's controlled by computer.




                                          Page 2
                                     Front Load Washing Machine                  Model:HNS1260TVE/ME

FEATURES

   300mm diameter porthole, door may be open at a 180 degrees.
Facilitate view of wash process, facilitate unloading and easy to use with large porthole.

  Multi-gear speed controller
According to different costuming you can slect corresponding spin speed     from 400 to 1400 rpm.


  Unique gasket design featuring no residual water hidden inside.
By the unique gasket   washing machine can left no residual water hidden between outer drum and
board.




                                                       Page 3
                                       Front Load Washing Machine                       Model:HNS1260TVE/ME


SPECIFICATION
         Proposal                                                                 2007          New Sensor
         Front load       washing machines
         Brand position center upper frame of door / chromed sticker
         Model number serigraphy right top corner control panel
         On white: silver / On silver : black or dark grey
1.       Product identification
         Description of appliance                                                            Washing machine
         Type of appliance         (FS = standing, BI = built-in)                                  FS
         Supplier own brand                                                                       Haier
         Supplier bar code                                                        EAN
         Mares computer code
         Commercial         Brand / Model
         Commercial bar code                                                      EAN
 2.      Key-Features
         Energy efficiency class                                                                     A
         Washing performance class                                                                   A
         Spin efficiency class                                                                       B
         Programs                                                                   n
