                                         Agilent 33330B/C
                                         Coaxial Detectors for OEM and Systems Use
                                         Product Overview




General Information                      ety of input and output connectors in     offers significant advantages over
The Agilent Technologies 33330B/C        the Model 423B, 8470B, and 8472B          other types of detectors. For example,
series of broadband coaxial detectors    series.                                   a typical Schottky requires bias for
are specifically designed for use in                                               proper operation; a tunnel diode
microwave instrumentation and sys-       The Low Barrier Schottky diode detector   detector has a limited power range
tems applications such as the detect-    The 33330B/C detectors consist of a       because of its negative resistance
ing element in leveling loops, power     Low Barrier Schottky (LBS) diode          region; and the point contact diode,
monitoring, and as wideband video        and a miniature thin film circuit that    because of its fragile construction, is
detectors.                               matches the diode to a 50-ohm trans-      unsuitable for many field applications.
                                         mission line. The diode is a specially
These detectors utilize a Low Barrier    fabricated Schottky diode using met-
Schottky (LBS) diode that requires no    alization designed to achieve low ori-
bias, has exceptional broadband flat-    gin resistance, thus eliminating the
ness and low SWR, and is environ-        need for bias. In addition to superior
mentally rugged. For measurement         RF characteristics, the LBS detector
accessory applications, Agilent offers
similar RF performance with a vari-                                                Frequency Range
