Image preview - the first page of the document
>> Download HYT_TC-500U_RDA_Two-way_radio_sm documenatation <<
Text preview - extract from the document
8130050000120
2007-12-25
TC-500 Service Manual
Content
Revision History-----------------------------------------------------------------------------------------------2
General-----------------------------------------------------------------------------------------------------------2
Radio Overview------------------------------------------------------------------------------------------------3
Software Specification--------------------------------------------------------------------------------------5
Circuit Description------------------------------------------------------------------------------------------9
CPU Pins-------------------------------------------------------------------------------------------------------13
Parts List 1-----------------------------------------------------------------------------------------------------15
Adjustment Description-----------------------------------------------------------------------------------59
Disassembly and Assembly for Repair--------------------------------------------------------------63
Exploded View------------------------------------------------------------------------------------------------66
Part List 2------------------------------------------------------------------------------------------------------67
Packing---------------------------------------------------------------------------------------------------------68
PCB View-------------------------------------------------------------------------------------------------------69
Block Diagram------------------------------------------------------------------------------------------------73
Schematic Diagram-----------------------------------------------------------------------------------------74
Specifications------------------------------------------------------------------------------------------------76
1
TC-500 Service Manual
Revision History
Version Date Content of Update
Circuit: 1. Update the parts list 1, schematic diagram, block
02 September,2007 diagram, PCB View and some parameters of specifications.
Structure: update parts list 2, exploded view.
General
Manual Scope
This manual is intended for use by experienced technicians familiar with similar types of communication
equipment. It contains all service information required for the equipment and is current as of the
publication date.
User Safety Information
The following precautions are recommended for personnel safety:
Do not transmit until all RF connectors are verified secure and any open connectors are properly
terminated.
Shut off and do not operate this equipment near electrical blasting caps or in an explosive
atmosphere.
When in vehicles with an airbag, do not place a portable radio in the area over an airbag or in the
airbag deployment area.
Do not expose the radio to direct sunlight for a long time nor place it close to a heating source.
Do not use any portable radio with a damaged antenna. If a damaged antenna comes into contact
with your skin, a minor burn may result.
When transmitting with a portable radio, hold the radio in a vertical position with its microphone
about 5 centimeters away from your mouth.
If you wear a portable radio on your body, be sure to keep the antenna at least 2.5 centimeters away
from your head or body when transmitting.
This equipment should be serviced by qualified technicians only.
2
TC-500 Service Manual
Radio Overview
2 3 4
1
12
8
5 9
11
6
7
10
13
1. Antenna
2. LED Indicator
The light will glow red during transmission. The light will glow green during receiving. During
transmission, the light flashes red when the battery voltage is low.
3. Channel Selector Knob
Turn the Channel Selector Knob to select from channels 1-16 (Channel 16 can be programmed by
your dealer as scan function).
4. Power/Volume Control Knob
Rotate the Power/Volume Control Knob clockwise to turn the radio on and fully counter clockwise to
turn the radio off. When the radio is on, turn the knob to adjust volume.
5. PTT Key
Press and hold down PTT key to talk, release it to receive.
6. Monitor Key
In receive mode, long press (above 2 seconds) Monitor key to monitor activity on the current
channel.
7. Microphone
8. Speaker
3
TC-500 Service Manual
9. External Jack
Remove the jack cover and insert an earphone; or insert programming cable into the jack to program
the radio via programming software.
10. Battery
11. Belt Clip
Used to clip radio on your belt.
12. Battery Latch
Used to fasten and remove the battery.
13. Charging Contact
Connect the charging contacts with that on the charger to begin charging.
4
TC-500 Service Manual
Software Specification
Radio Feature Description
1. Use Channel Selector Knob to choose from 15+1(Scan) channels
2. Monitor
3. CTCSS/CDCSS
Non-standard Model (Other): 38+83 groups
4. Channel Spacing
12.5KHz/25KHz Narrow/Wide Selectable
5. Channel Scan (Priority channel and scan revert channel available)
6. Battery Save Feature (the function can be programmed by dealer as on/off)
7. Time-out Timer (TOT)
8. High/low Power Switch
9. Squelch Level Control (9 levels)
10. Low Battery Alert
11. Model Set Mode
12. PC Programming and Adjusting Mode
13. User Wired Clone Mode
14. Factory Wired Clone Mode
15. Manual Adjust Mode
Radio Modes
User Mode
User mode is conventional communication mode. Turn the power on while disconnecting the two SELF
points, the radio enters user mode. (Refer to "
TC-500 Owner' Manual"for details about operation in this
s
mode.)
Model Set Mode
1. If the radio is in standard model, short out the two MS2 points on PCB and then operate following the
steps (3), (5) and (6). If the radio is in non-standard model, please disconnect the two MS2 points on
PCB and then operate the following steps.
2. To select MS1 (See the initial data table) according to the radio model, if MS1 is 1, short out the two
MS1 points on PCB and continue the following operation. If not, disconnect the two MS1 points and
continue.
3. Short out the two SELF points on PCB and then turn the power on. Two beeps sound.
4. Turn Channel Selector Knob to the corresponding position (1-11) according to the radio model (Refer
to the initial data table).
5. Press PTT key while holding down MONI key to set the model. Channel data and settings are
initialized (Refer to the initial data table).
5
TC-500 Service Manual
6. Turn off the radio and then disconnect the two SELF points on PCB to complete the model setting.
For example, if MS1 of TC-500-U (450.000~469.995MHz) is 0 (See the initial data table) and its
number refers to 7, then it is unnecessary to short out MS1 and MS2. To initialize its model and
channel data, you can operate as following:
(1) Short out the two SELF points on PCB;
(2) Turn on the radio and turn the Channel Selector Knob to the position 7;
(3) Press PTT key while holding down MONI key;
(4) After data reset, turn off the radio, disconnect the two SELF points and restart to use the radio.
Remarks: The old data (frequency, CTCSS/CDCSS, channel function settings) will be changed
once the model is set, and part of functions will also be changed. Therefore, do not make this
operation unless it' very necessary, such as changing the EEPROM, etc.
s
PC Programming Mode
The following parameters can be set through programming software:
1. Receive frequency and transmit frequency
2. Receive signaling and transmit signaling
3. Busy channel lockout
4. Time-out timer
5. Squelch level
6. Battery save
7. Audio alarm
8. Monitor mode
9. Scan mode
10. Scan revert channel
11. Priority scan channel
12. N/W model
13. High/low power
14. N/W setting
PC Adjusting Mode
The following parameters can be set via PC programming software:
1. Low battery alert level
2. Squelch level 9
3. Squelch level 3
4. CTCSS deviation (wide)
5. CDCSS deviation (wide)
6. CTCSS deviation (narrow)
7. CDCSS deviation (narrow)
6
TC-500 Service Manual
Manual Adjust Mode
If manual adjust mode is enabled, turn on the radio while holding down PTT and MONI simultaneously,
the radio enters manual adjust mode after 2 seconds. Choose the adjusting items by turning the
Channel Selector Knob to CH1-CH7 position; use PTT (upwards) or MONI (downwards) to adjust
(Note: Microphone jack shouldn' be connected with external cable while adjustment), CH1-CH7
t
positions are defined as follows:
CH1 Low battery alert level
CH2 Squelch level 9
CH3 Squelch level 3
CH4 CTCSS deviation (wide)
CH5 CDCSS deviation (wide)
CH6 CTCSS deviation (narrow)
CH7 CDCSS deviation (narrow)
CH13 to CH16 are used to adjust transmitter and receiver. Press PTT key to transmit; release it to
receive. CH13 to CH16 are defined as follows:
CH13 Center frequency (difference between transmit and receive frequency is 0.1MHz)
CH14 Lowest frequency (difference between transmit and receive frequency is 0.1MHz)
CH15 Highest frequency (difference between transmit and receive frequency is -0.075MHz)
CH16 Center frequency: transmit with 250.3Hz CTCSS signalling (difference between transmit and
receive frequency is 0.1MHz)
Note:
To enable or disable manual adjust mode: short out the two SELF points, turn on the radio to enter model
set mode. And then the manual adjust mode is enabled. Press PTT key, manual adjust mode is disabled.
This mode is suggested to be disabled after the adjustment is completed.
User/Factory Wired Clone Mode
Turn on the radio while holding down MONI, the radio enters wired clone mode.
1. If the two SELF points are disconnected, press MONI key again to begin user wired clone and red
LED blinks; when cloning is completed, red LED goes out.
2. If the two SELF points are short circuit, press MONI again to begin factory wired clone and red LED
blinks; when cloning is completed, red LED goes out.
Note: The difference between user wired clone mode and factory wired clone mode is that the latter is
able to clone tune parameters.
7
TC-500 Service Manual
Initial data table
IF 1CH(Center) 2CH(Low) 3CH(High) 4CH 5CH 6CH 7CH 8CH 9-16CH
MS1 Model Frequency (MHz)
(MHz) Tx (MHz) Rx (MHz) Tx (MHz) Rx (MHz) Tx (MHz) Rx (MHz) (MHz) (MHz) (MHz) (MHz) (MHz) (MHz)
0 1 150.000~173.995 +21.4 162.000 162.100 150.000 150.100 173.975 173.900 162.500 162.550 162.600 162.550 162.650
0 2 136.000~149.995 +21.4 143.000 143.100 136.000 136.100 149.975 149.900 143.500 143.550 143.600 143.550 143.650
0 3 146.000~173.995 +21.4 160.000 160.100 146.000 146.100 173.975 173.900 160.50 0 160.550 160.600 160.550 160.650
0 4 144.000~147.995 +21.4 146.000 146.100 144.000 144.100 147.975 147.900 146.500 146.550 146.600 146.550 146.650
0 5 136.000~147.995 +21.4 142.000 142.100 136.000 136.100 147.975 147.900 142.500 142.550 142.600 142.550 142.650
0 6 136.000~173.995 +21.4 155.000 155.100 136.000 136.100 173.975 173.900 155.500 155.550 155.600 155.550 155.650
0 7 450.000~469.995 -21.4 460.000 460.100 450.000 450.100 469.975 469.900 460.300 460.350 460.400 460.350 460.450
0 8 400.000~419.995 -21.4 410.000 410.100 400.000 400.100 419.975 419.900 410.500 410.550 410.600 410.550 410.650
0 9 470.000~489.995 -21.4 480.000 480.100 470.000 470.100 489.975 489.900 480.500 480.550 480.600 480.550 480.650
0 10 490.000~511.995 -21.4 501.000 501.100 490.000 490.100 511.975 511.900 501.500 501.550 501.600 501.550 501.650
0 11 220.000~239.995 -21.4 230.000 230.100 220.000 220.100 239.975 239.900 230.500 230.550 230.600 230.550 230.650
1 1 240.000~259.995 -21.4 250.000 250.100 240.000 240.100 259.975 259.900 250.500 250.550 250.600 250.550 250.650
1 2 336.000~367.995 -21.4 352.000 352.100 336.000 336.100 367.975 367.900 352.500 352.550 352.600 352.550 352.650
1 3 368.000~395.995 -21.4 382.000 382.100 368.000 368.100 395.975 395.900 382.500 382.550 382.600 382.550 382.650
1 4 370.000~389.995 -21.4 380.000 380.100 370.000 370.100 389.975 389.900 380.500 380.550 380.600 380.550 380.650
1 5 350.000~369.995 -21.4 360.000 360.100 350.000 350.100 369.975 369.900 360.500 360.550 360.600 360.550 360.650
1 6 406.000~429.995 -21.4 418.000 418.100 406.000 406.100 429.975 429.900 418.500 418.550 418.600 418.550 418.650
1 7 400.000~429.995 -21.4 415.000 415.100 400.000 400.100 429.975 429.900 415.500 415.550 415.600 415.550 415.650
1 8 430.000~439.995 -21.4 435.000 435.100 430.000 430.100 439.975 439.900 435.500 435.550 435.600 435.550 435.650
1 9 438.000~449.995 -21.4 444.000 444.100 438.000 438.100 449.975 449.900 444.500 444.550 444.600 444.550 444.650
1 10 480.000~519.995 -21.4 500.000 500.100 480.000 480.100 519.975 519.900 500.500 500.550 500.600 500.550 500.650
1 11 441.000~451.000 -21.4 446.000 446.100 441.000 441.100 450.975 450.900 446.500 446.550 446.600 446.550 446.650
446.00625~
Standard -21.4 446.00625 446.00625 446.01875 446.01875 446.03125 446.03125 446.04375 446.05625 446.06875 446.08125 446.09375
446.09375
CH QT/DQT OFF OFF OFF OFF OFF OFF OFF 023 023 127.3 151.4
Note: For standard model, CTCSS is off in all channels after initialization.
8
TC-500 Service Manual
Circuit Description
Frequency Configuration
The receiver utilizes double conversion superheterodyne. The first IF is 21.4MHz and the second is
455KHz. The first local oscillator signal is supplied from PLL circuit. Frequency needed in the transmitter
is supplied from PLL circuit. Figure 1 shows the frequency configuration.
Frequency Range: 136-150MHz 150-174MHz 350-370MHz
370-390MHz 400-420MHz 450-470MHz
Figure 1 frequency configuration
Receiver
The receiver utilizes double conversion superheterodyne.
1. Front -end RF Amplifier
The input signal from antenna is amplified in RF amplifier (Q27) after passing through the
receive/transmit switch circuit and a 3 -stage LC band pass filter. The amplified signals are
filtered by a band pass filter (a 3-stage LC BPF) to eliminate unwanted signals before they
go to the first frequency mixer.
Figure 2 receiver section configuration
2. The First Mixer
The signal from RF amplifier is mixed with the first local oscillator signal from PLL frequency
9
TC-500 Service Manual
synthesizer in the first mixer (Q23) to generate a 21.4MHz first IF signal. The first IF signal is then
fed through two monolithic crystal filters (XF1) to remove spurious signals from adjacent channels.
3. IF Amplifier
The first IF signal is amplified in Q22 and then enters the IF process chip IC1. The signal is mixed
with the second local oscillator signal in IC1 to create a 455KHz second IF signal. The second IF
signal is then fed to a 455KHz ceramics filter (CF1) to eliminate unwanted signals before it is
amplified and FM detected in IC1.
4. Audio Amplifier
The demodulated audio signal obtained from IC1 is amplified in IC7 (1/4), and then filtered by low
pass filter Q19 and high pass filter Q20, and then de-emphasized by R130 and C156. The resulting
audio signal passes through a volume control circuit and then is amplified to a sufficient level to
drive the speaker by audio power amplifier (IC8).
5. Squelch
Part of the audio signal from IC1 enters IC1 again, and the noise component is amplified and
rectified by a filter and an amplifier to produce a DC voltage corresponding to the noise level. The
DC signal from IC1 goes to the analog port of the microprocessor (IC11). IC11 determines whether
to output sounds from the speaker by detecting whether the input voltage is higher or lower than
preset value.
To output sounds from the speaker, IC11 sends a high level signal to the MUTE and AFCO lines and
turns IC8 on through Q12.
FM IF IC1 IC7
IF AMP AF AF/PF AMP
DET LPF HPF SW
IC8
SP
HPF
DET AMP Q12
SW
IC7
LPF
2 39 40 1
BUSY
MUTE
AFCO
TI
IC11
MCU
Figure 3 Audio amplifier and squelch circuit
6. Receive signaling
CTCSS/CDCSS
Audio frequencies over 300Hz of the output signal from IC1 is cut off by a low-pass filter. The
resulting signal enters the microprocessor IC11. IC11 determines whether the CTCSS/CDCSS
10
TC-500 Service Manual
matches the preset value and controls the MUTE and AFCO and the speaker sound output
according to the squelch results.
PLL Frequency Synthesizer
PLL circuit generates the first local oscillator signal for reception and the RF signal for
transmission.
1. PLL Circuit
The step frequency of PLL circuit is 2.5KHz or 6.25KHz. A 12.8MHz reference oscillator
signal is divided at IC2 by a fixed counter to produce a 2.5 KHz or 6.25 KHz reference
frequency. Output signal from voltage control oscillator (VCO) passes through buffer
amplifier Q14 and is divided at IC2 by the dual -module programmable counter. The divided
signal is compared in the phase comparator IC2 with the 2.5 KHz or 6.25 KHz reference
signal. The output signal from phase comparator is filtered through a low -pass filter and
passed to the VCO to control the oscillator frequency. (See figure 4)
Figure 4 PLL circuit
2. VCO
The operating frequency is generated by Q16 in transmit mode and by Q8 in receive mode.
The operation frequency generates a voltage through the phase comparator to control the
varactor, so as to keep the oscillator frequency consistent with the preset frequency in
CPU (D2 and D3 in transmit mode and D7 and D8 in receive mode). T/R pin is set high in
receive mode causing Q6 to turn off Q16 and turn Q7 on. The T/R pin is set low in transmit mode.
The output from Q8 and Q16 is amplified by Q14 and sent to the buffer amplifier.
11
TC-500 Service Manual
Transmitter
1. Transmit audio
The audio signal from microphone is amplified through IC3, and then pre -emphasized , and then
filtered by another low-pass filterseparate filter(Q25 and Q24) to eliminate the frequencies over
3KHz. The resulting signal enters the VCO for direct FM modulation. (See figure 5)
2. CTCSS/CDCSS Encoder
The necessary frequency for CTCSS/CDCSS encoder is generated by IC11 and FM -modulated to
the PLL reference signal. Since the reference OSC does not modulate the loop characteristic
frequency or higher, modulation is performed at the VCO side by splitter. (See figure 5)
Figure 5 transmit CTCSS
3. RF amplifier
The transmit signal obtained from VCO buffer amplifier Q14 is amplified by Q15 and Q17. This
amplified signal is passed to power amplifier Q32 and Q31, and is capable of producing a 4.0W RF
power.
4. Antenna Switch and LPF
The RF amplifier output signal is passed through a low-pass filter network and a transmit/receive
switch circuit before it is passed to the antenna terminal. The transmit/receive switch circuit is
comprised of D11 and D12. D11 and D12 is turned on in transmit mode and off in receive mode.
Power
The 5V reference power supply for the control circuit is derived from an internal battery. The reference
power provides a 5V supply in transmit mode [T_V], a 5V supply in receive mode [R_V], and a 5V supply
shared in both modes based the control signal from the microprocessor.
Control System
The IC11 CPU operates at 7.3728MHz.
12
TC-500 Service Manual
CPU Pins
PIN No. PIN NAME I/O DESCRIPTION
1 TI I CTCSS/CDCSS input
2 BUSY I Input busy signal
3 BATT I Detect battery voltage
4 TIBI I CTCSS/CDCSS exterior circuit central point input
5 NC
6 SAVE O Power saving control H: OFF L: ON
7 TXLow O Transmitter power control H: Low power L: High power
8 NC
9 DAT O data output
10 CLK O clock output
11 LE O PLL IC enable
12 BEEP O Beep output
13 SCL O E2PROM clock cable
14 SDA I/O E2PROM data cable
Microphone mute control H: Microphone mute
15 MUTE O
L: Microphone enable
16 MS1 I Model set
17 GREEN O Green light control H: light
18 RED O Red light control H: light
19 TXD O RS-232C output
20 RXD I RS-233C input
21 PTTK I PTT key input
22 MS2 I Standard model select H: Non-standard L: Standard
23 RXC O Receiver power control L: power on
24 NC
25 RESET I Reset input
26 SELF I Self-program L: on
27 TXC O Transmitter power control H:on
28 XIN I Oscillator input
29 XOUT O Oscillator output
30 Vss I Grounding
31 R/T O TX/RX control HRX L TX
32 UL I PLL unlock detector H: Lock L: unlock
33 IF-SELECT I IF select H: 21.4MHz L: 45.05MHz
13
TC-500 Service Manual
34 MONIK I MONI key input
35 ENC0 I
36 ENC1 I Channel Selector Knob encode input
37 ENC2 I
38 ENC3 I
39 AFMUTE O Audio muting control
40 AFP O Audio power control
41 TONE5 O CTCSS code output
42 TONE4 O CTCSS code output
43 TONE3 O CTCSS code output
44 TONE2 O CTCSS code output
45 TONE1 O CTCSS code output
46 TONE0 O CTCSS code output
47 WNTC O W/N L: Wide H: Narrow
47-70 NC
71 Vcc I Power input: 5V
72 VREF I A-D converse reference voltage
73 Avss I A-D GND
74-77 NC
78 NC
79 NC
80 NC
14
TC-500 Service Manual
Parts List 1
TC-500 VHF (136-150MHz)
No. Material No. Description Qty. Ref.No. Address
1 3001051030000 Chip resistor 0402 10K 1 R86 B5J
2 3001060000000 Chip resistor 0603 0 1 D20 T1D
3 3001060000000 Chip resistor 0603 0 1 D25 T2C
4 3001060000000 Chip resistor 0603 0 1 L29 B3C
5 3001060000000 Chip resistor 0603 0 1 Q41 T3F
6 3001060000000 Chip resistor 0603 0 1 R107 B3I
7 3001060000000 Chip resistor 0603 0 1 R108 B3F
8 3001060000000 Chip resistor 0603 0 1 R110 T4G
9 3001060000000 Chip resistor 0603 0 1 R128 B4I
10 3001060000000 Chip resistor 0603 0 1 R151 B2F
11 3001060000000 Chip resistor 0603 0 1 R193 B3E
12 3001060000000 Chip resistor 0603 0 1 R194 B3E
13 3001060000000 Chip resistor 0603 0 1 R508 B1I
14 3001060000000 Chip resistor 0603 0 1 R701 T2F
15 3001060000000 Chip resistor 0603 0 1 R702 T4G
16 3001060000000 Chip resistor 0603 0 1 R94 T3F
17 3001061000000 Chip resistor 0603 10 1 R106 T3F
18 3001061000000 Chip resistor 0603 10 1 R113 T5J
19 3001061000000 Chip resistor 0603 10 1 R164 B4H
20 3001061000000 Chip resistor 0603 10 1 R171 B5G
21 3001061000000 Chip resistor 0603 10 1 R80 B4G
22 3001061000000 Chip resistor 0603 10 1 R82 B2E
23 3001061010000 Chip resistor 0603 100 1 R127 B1E
24 3001061010000 Chip resistor 0603 100 1 R147 B2F
25 3001061010000 Chip resistor 0603 100 1 R74 B4G
26 3001061010000 Chip resistor 0603 100 1 R75 B2A
27 3001061010000 Chip resistor 0603 100 1 R76 B1F
28 3001061010000 Chip resistor 0603 100 1 R90 T5H
29 3001061020010 Chip resistor 0603 1K 1 R203 T2E
30 3001061020010 Chip resistor 0603 1K 1 R39 B3I
31 3001061020010 Chip resistor 0603 1K 1 R51 B5E
32 3001061020010 Chip resistor 0603 1K 1 R52 T3F
33 3001061020010 Chip resistor 0603 1K 1 R53 B4G
34 3001061020010 Chip resistor 0603 1K 1 R56 B4I
35 3001061020010 Chip resistor 0603 1K 1 R57 B1I
36 3001061020010 Chip resistor 0603 1K 1 R58 T4B
37 3001061020010 Chip resistor 0603 1K 1 R59 T3B
38 3001061020010 Chip resistor 0603 1K 1 R60 T2D
39 3001061020010 Chip resistor 0603 1K 1 R61 T2D
40 3001061020010 Chip resistor 0603 1K 1 R89 T4I
41 3001061030010 Chip resistor 0603 10K 1 R100 T4B
42 3001061030010 Chip resistor 0603 10K 1 R119 B4J
43 3001061030010 Chip resistor 0603 10K 1 R169 T2H
44 3001061030010 Chip resistor 0603 10K 1 R36 B2I
45 3001061030010 Chip resistor 0603 10K 1 R37 T2E
46 3001061030010 Chip resistor 0603 10K 1 R38 B4J
47 3001061030010 Chip resistor 0603 10K 1 R40 B3F
48 3001061030010 Chip resistor 0603 10K 1 R41 T5F
49 3001061030010 Chip resistor 0603 10K 1 R42 T5E
15
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
50 3001061030010 Chip resistor 0603 10K 1 R44 B4B
51 3001061030010 Chip resistor 0603 10K 1 R45 B4B
52 3001061030010 Chip resistor 0603 10K 1 R46 T2G
53 3001061040010 Chip resistor 0603 100K 1 R10 B2H
54 3001061040010 Chip resistor 0603 100K 1 R12 B2I
55 3001061040010 Chip resistor 0603 100K 1 R13 B3G
56 3001061040010 Chip resistor 0603 100K 1 R15 B3G
57 3001061040010 Chip resistor 0603 100K 1 R168 B1E
58 3001061040010 Chip resistor 0603 100K 1 R17 B2F
59 3001061040010 Chip resistor 0603 100K 1 R173 B3F
60 3001061040010 Chip resistor 0603 100K 1 R175 T2B
61 3001061040010 Chip resistor 0603 100K 1 R176 T2B
62 3001061040010 Chip resistor 0603 100K 1 R178 B3F
63 3001061040010 Chip resistor 0603 100K 1 R18 T4B
64 3001061040010 Chip resistor 0603 100K 1 R202 B4I
65 3001061040010 Chip resistor 0603 100K 1 R35 T2C
66 3001061040010 Chip resistor 0603 100K 1 R7 B2I
67 3001061040010 Chip resistor 0603 100K 1 R8 B4F
68 3001061040010 Chip resistor 0603 100K 1 R9 B5G
69 3001061050010 Chip resistor 0603 1M 1 R109 T2B
70 3001061050010 Chip resistor 0603 1M 1 R116 T3B
71 3001061050010 Chip resistor 0603 1M 1 R197 T2G
72 3001061240010 Chip resistor 0603 120K 1 R11 B4I
73 3001061240010 Chip resistor 0603 120K 1 R150 B2F
74 3001061240010 Chip resistor 0603 120K 1 R154 T4F
75 3001061240010 Chip resistor 0603 120K 1 R72 B4G
76 3001061510000 Chip resistor 0603 150 1 R5 B2F
77 3001061510000 Chip resistor 0603 150 1 R68 B4F
78 3001061510000 Chip resistor 0603 150 1 R92 T3E
79 3001061520000 Chip resistor 0603 1.5K 1 R146 B2G
80 3001061520000 Chip resistor 0603 1.5K 1 R48 B3F
81 3001061520000 Chip resistor 0603 1.5K 1 R50 T5F
82 3001061520000 Chip resistor 0603 1.5K 1 R55 T2E
83 3001061530010 Chip resistor 0603 15K 1 R161 T4F
84 3001061530010 Chip resistor 0603 15K 1 R162 T4G
85 3001061530010 Chip resistor 0603 15K 1 R163 T4F
86 3001061540000 Chip resistor 0603 150K 1 R139 B2I
87 3001061540000 Chip resistor 0603 150K 1 R14 B3G
88 3001061540000 Chip resistor 0603 150K 1 R140 B2J
89 3001061540000 Chip resistor 0603 150K 1 R141 B2J
90 3001061540000 Chip resistor 0603 150K 1 R142 B2J
91 3001061540010 Chip resistor 0603 150K 1 R190 T1H
92 3001061540010 Chip resistor 0603 150K 1 R195 T2G
93 3001061540010 Chip resistor 0603 150K 1 R199 T1G
94 3001061540010 Chip resistor 0603 150K 1 R201 T1H
95 3001061540010 Chip resistor 0603 150K 1 R204 T2G
96 3001061540010 Chip resistor 0603 150K 1 R208 T1G
97 3001061800000 Chip resistor 0603 18 1 R196 B2D
98 3001061820000 Chip resistor 0603 1.8K 1 R131 T4E
99 3001061820000 Chip resistor 0603 1.8K 1 R144 B3H
100 3001061830010 Chip resistor 0603 18K 1 R102 B3C
101 3001061840000 Chip resistor 0603 180K 1 R124 T3F
102 3001061840000 Chip resistor 0603 180K 1 R83 T1E
16
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
103 3001061840000 Chip resistor 0603 180K 1 R97 B3H
104 3001061850000 Chip resistor 0603 1.8M 1 R155 T5G
105 3001061850000 Chip resistor 0603 1.8M 1 R156 T5F
106 3001062030000 Chip resistor 0603 20K 1 R98 B3G
107 3001062220000 Chip resistor 0603 2.2K 1 R114 B5I
108 3001062220000 Chip resistor 0603 2.2K 1 R165 B2E
109 3001062220000 Chip resistor 0603 2.2K 1 R174 T4H
110 3001062220000 Chip resistor 0603 2.2K 1 R207 T2G
111 3001062220000 Chip resistor 0603 2.2K 1 R3 B2I
112 3001062220000 Chip resistor 0603 2.2K 1 R6 T2B
113 3001062230000 Chip resistor 0603 22K 1 R104 B2D
114 3001062230000 Chip resistor 0603 22K 1 R120 T4G
115 3001062240010 Chip resistor 0603 220K 1 R167 T1D
116 3001062430010 Chip resistor 0603 24K 1 R206 T2G
117 3001062710000 Chip resistor 0603 270 1 R67 B4G
118 3001062710000 Chip resistor 0603 270 1 R69 B4H
119 3001062720000 Chip resistor 0603 2.7K 1 R49 B2G
120 3001062720000 Chip resistor 0603 2.7K 1 R64 B4D
121 3001062720000 Chip resistor 0603 2.7K 1 R65 B4D
122 3001062730010 Chip resistor 0603 27K 1 R132 B3H
123 3001062730010 Chip resistor 0603 27K 1 R602 B3H
124 3001062740010 Chip resistor 0603 270K 1 R16 B3G
125 3001062740010 Chip resistor 0603 270K 1 R2 B3H
126 3001063310010 Chip resistor 0603 330 1 R115 B5J
127 3001063310010 Chip resistor 0603 330 1 R118 B4B
128 3001063310010 Chip resistor 0603 330 1 R122 B3D
129 3001063310010 Chip resistor 0603 330 1 R62 B4B
130 3001063320000 Chip resistor 0603 3.3K 1 R130 B2I
131 3001063320000 Chip resistor 0603 3.3K 1 R25 B2I
132 3001063320000 Chip resistor 0603 3.3K 1 R26 B2G
133 3001063320000 Chip resistor 0603 3.3K 1 R27 B4E
134 3001063320000 Chip resistor 0603 3.3K 1 R28 B5E
135 3001063320000 Chip resistor 0603 3.3K 1 R29 B4G
136 3001063320000 Chip resistor 0603 3.3K 1 R30 B4F
137 3001063320000 Chip resistor 0603 3.3K 1 R31 B3D
138 3001063320000 Chip resistor 0603 3.3K 1 R32 B1F
139 3001063320000 Chip resistor 0603 3.3K 1 R33 T5F
140 3001063320000 Chip resistor 0603 3.3K 1 R34 B4G
141 3001063320000 Chip resistor 0603 3.3K 1 R601 B5F
142 3001063330010 Chip resistor 0603 33K 1 R129 T3B
143 3001063330010 Chip resistor 0603 33K 1 R172 B3E
144 3001063340000 Chip resistor 0603 330K 1 R43 T2A
145 3001063920000 Chip resistor 0603 3.9K 1 R135 B2I
146 3001063920000 Chip resistor 0603 3.9K 1 R136 B2J
147 3001063920000 Chip resistor 0603 3.9K 1 R137 B2I
148 3001063920000 Chip resistor 0603 3.9K 1 R138 B1I
149 3001063920000 Chip resistor 0603 3.9K 1 R81 B3E
150 3001063930010 Chip resistor 0603 39K 1 R152 T5F
151 3001063930010 Chip resistor 0603 39K 1 R153 T5F
152 3001063930010 Chip resistor 0603 39K 1 R158 T5F
153 3001063930010 Chip resistor 0603 39K 1 R159 T5E
154 3001063930010 Chip resistor 0603 39K 1 R192 B2F
155 3001064700000 Chip resistor 0603 47 1 R123 B3D
17
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
156 3001064700000 Chip resistor 0603 47 1 R125 B3C
157 3001064700000 Chip resistor 0603 47 1 R191 B4J
158 3001064710000 Chip resistor 0603 470 1 L1 B2I
159 3001064710000 Chip resistor 0603 470 1 R166 B2E
160 3001064720000 Chip resistor 0603 4.7K 1 R121 T1B
161 3001064720000 Chip resistor 0603 4.7K 1 R177 T2A
162 3001064720000 Chip resistor 0603 4.7K 1 R84 B4H
163 3001064720000 Chip resistor 0603 4.7K 1 R87 T2A
164 3001064720000 Chip resistor 0603 4.7K 1 R88 T1C
165 3001064720000 Chip resistor 0603 4.7K 1 R99 T1B
166 3001064730000 Chip resistor 0603 47K 1 R103 B2D
167 3001064730000 Chip resistor 0603 47K 1 R105 B5F
168 3001064730000 Chip resistor 0603 47K 1 R145 T5F
169 3001064730000 Chip resistor 0603 47K 1 R198 T4E
170 3001064730000 Chip resistor 0603 47K 1 R23 B3H
171 3001064730000 Chip resistor 0603 47K 1 R4 T2B
172 3001064730000 Chip resistor 0603 47K 1 R54 T3G
173 3001064730000 Chip resistor 0603 47K 1 R606 T3I
174 3001064730000 Chip resistor 0603 47K 1 R607 T3I
175 3001064730000 Chip resistor 0603 47K 1 R608 T3I
176 3001064730000 Chip resistor 0603 47K 1 R609 T3I
177 3001064730000 Chip resistor 0603 47K 1 R610 T2C
178 3001064730000 Chip resistor 0603 47K 1 R91 T2F
179 3001064740010 Chip resistor 0603 470K 1 R22 T1D
180 3001065620010 Chip resistor 0603 5.6K 1 R79 B4G
181 3001065630000 Chip resistor 0603 56K 1 R101 B2C
182 3001065630000 Chip resistor 0603 56K 1 R149 B3F
183 3001065640000 Chip resistor 0603 560K 1 R148 B2G
184 3001066810010 Chip resistor 0603 680 1 R126 B2G
185 3001066810010 Chip resistor 0603 680 1 R47 B2G
186 3001066820000 Chip resistor 0603 6.8K 1 R117 B5I
187 3001066820000 Chip resistor 0603 6.8K 1 R85 T4F
188 3001066830000 Chip resistor 0603 68K 1 R157 T4F
189 3001066830000 Chip resistor 0603 68K 1 R200 B4I
190 3001066830000 Chip resistor 0603 68K 1 R95 B4I
191 3001066840000 Chip resistor 0603 680K 1 R1 B2I
192 3001066840000 Chip resistor 0603 680K 1 R134 B3H
193 3001067540000 Chip resistor 0603 750K 1 R160 T4G
194 3001068210010 Chip resistor 0603 820 1 R66 B5E
195 3001068210010 Chip resistor 0603 820 1 R70 B3E
196 3001068220000 Chip resistor 0603 8.2K 1 R628 T2E
197 3001068230010 Chip resistor 0603 82K 1 R133 T2C
198 3001070000000 Chip resistor 0805 0 1 C202 B4I
199 3001070000000 Chip resistor 0805 0 1 L9 B3I
200 3001080000000 Chip resistor 1206 0 1 F1 T4G
201 3002994730000 Trimmer resistor 2.7*2.0*1.6 47K 1 VR2 T5E
202 3002996830000 Trimmer resistor(2*2) 68K(+25%) 1 VR7 T1E
203 3002996830000 Trimmer resistor(2*2) 68K(+25%) 1 VR3 T4E
204 3002996830000 Trimmer resistor(2*2) 68K(+25%) 1 VR4 T1B
205 3002996830000 Trimmer resistor(2*2) 68K(+25%) 1 VR6 T2G
206 3005061030040 Resistor array 0603 10K*2 1 CP5 T1B
207 3005064720000 Resistor array 0603 4.7K*2 1 CP4 T1B
208 3005064720010 Resistor array 0603 4.7K*4 1 CP3 T1B
18
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
209 3005991030070 Resistor array 0603 10K*4 1 CP6 T4A
210 3005991030070 Resistor array 0603 10K*4 1 CP1 T1B
211 3099080398000 Chip resistor 1206 0.39 1 R188 T2H
212 3099080398000 Chip resistor 1206 0.39 1 R189 T2I
213 3099080398000 Chip resistor 1206 0.39 1 R77 T2H
214 3101050100030 Chip capacitor 0402 1PF 1 C143 B2A
215 3101050100030 Chip capacitor 0402 1PF 1 C95 B5F
216 3101050200010 Chip capacitor 0402 2PF 1 C163 B2D
217 3101050400010 Chip capacitor 0402 4PF 1 C103 B4I
218 3101050400010 Chip capacitor 0402 4PF 1 C164 B2D
219 3101050500010 Chip capacitor 0402 5PF 1 C116 B2F
220 3101050500010 Chip capacitor 0402 5PF 1 C140 B2B
221 3101050590020 Chip capacitor 0402 0.5PF 1 C91 B4G
222 3101050700010 Chip capacitor 0402 7PF 1 C130 B3J
223 3101050700010 Chip capacitor 0402 7PF 1 C146 B2A
224 3101050800000 Chip capacitor 0402 8PF 1 C196 B3F
225 3101051000020 Chip capacitor 0402 10PF 1 C106 B2F
226 3101051000020 Chip capacitor 0402 10PF 1 C144 T4F
227 3101051010030 Chip capacitor 0402 100PF 1 C132 B4G
228 3101051010030 Chip capacitor 0402 100PF 1 C15 B4J
229 3101051010030 Chip capacitor 0402 100PF 1 C16 B4J
230 3101051010030 Chip capacitor 0402 100PF 1 C17 B4J
231 3101051010030 Chip capacitor 0402 100PF 1 C179 B3G
232 3101051010030 Chip capacitor 0402 100PF 1 C180 B4J
233 3101051010030 Chip capacitor 0402 100PF 1 C213 T3E
234 3101051010030 Chip capacitor 0402 100PF 1 C237 T1H
235 3101051020010 Chip capacitor 0402 1000PF 1 C109 B4H
236 3101051020010 Chip capacitor 0402 1000PF 1 C110 B4H
237 3101051020010 Chip capacitor 0402 1000PF 1 C111 B2D
238 3101051020010 Chip capacitor 0402 1000PF 1 C113 B4I
239 3101051020010 Chip capacitor 0402 1000PF 1 C114 B3D
240 3101051020010 Chip capacitor 0402 1000PF 1 C121 B4F
241 3101051020010 Chip capacitor 0402 1000PF 1 C205 B5J
242 3101051020010 Chip capacitor 0402 1000PF 1 C207 B3E
243 3101051020010 Chip capacitor 0402 1000PF 1 C24 B2E
244 3101051020010 Chip capacitor 0402 1000PF 1 C30 B2B
245 3101051020010 Chip capacitor 0402 1000PF 1 C32 B1F
246 3101051020010 Chip capacitor 0402 1000PF 1 C33 B1E
247 3101051020010 Chip capacitor 0402 1000PF 1 C42 B2D
248 3101051020010 Chip capacitor 0402 1000PF 1 C59 B5D
249 3101051020010 Chip capacitor 0402 1000PF 1 C60 B5D
250 3101051020010 Chip capacitor 0402 1000PF 1 C61 B4D
251 3101051020010 Chip capacitor 0402 1000PF 1 C62 B4D
252 3101051020010 Chip capacitor 0402 1000PF 1 C65 B5H
253 3101051020010 Chip capacitor 0402 1000PF 1 C66 T1E
254 3101051020010 Chip capacitor 0402 1000PF 1 C67 B3C
255 3101051020010 Chip capacitor 0402 1000PF 1 C68 B3C
256 3101051020010 Chip capacitor 0402 1000PF 1 C69 B3H
257 3101051020010 Chip capacitor 0402 1000PF 1 C70 B2J
258 3101051020010 Chip capacitor 0402 1000PF 1 C71 B1I
259 3101051020010 Chip capacitor 0402 1000PF 1 C73 B3F
260 3101051020010 Chip capacitor 0402 1000PF 1 C74 B2F
261 3101051020010 Chip capacitor 0402 1000PF 1 C75 T4F
19
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
262 3101051020010 Chip capacitor 0402 1000PF 1 C76 T4G
263 3101051020010 Chip capacitor 0402 1000PF 1 C77 T4G
264 3101051020010 Chip capacitor 0402 1000PF 1 C78 T2D
265 3101051020010 Chip capacitor 0402 1000PF 1 C79 T1E
266 3101051020010 Chip capacitor 0402 1000PF 1 C80 T1D
267 3101051020010 Chip capacitor 0402 1000PF 1 C81 T1C
268 3101051020010 Chip capacitor 0402 1000PF 1 C82 B4B
269 3101051020010 Chip capacitor 0402 1000PF 1 C83 B4B
270 3101051030020 Chip capacitor 0402 0.01UF 1 C10 T5G
271 3101051030020 Chip capacitor 0402 0.01UF 1 C11 T1B
272 3101051030020 Chip capacitor 0402 0.01UF 1 C12 B3B
273 3101051030020 Chip capacitor 0402 0.01UF 1 C137 T2I
274 3101051030020 Chip capacitor 0402 0.01UF 1 C2 B2I
275 3101051030020 Chip capacitor 0402 0.01UF 1 C240 T4J
276 3101051030020 Chip capacitor 0402 0.01UF 1 C241 T3J
277 3101051030020 Chip capacitor 0402 0.01UF 1 C242 T3J
278 3101051030020 Chip capacitor 0402 0.01UF 1 C243 T4J
279 3101051030020 Chip capacitor 0402 0.01UF 1 C3 B2I
280 3101051030020 Chip capacitor 0402 0.01UF 1 C4 B2H
281 3101051030020 Chip capacitor 0402 0.01UF 1 C5 B5E
282 3101051030020 Chip capacitor 0402 0.01UF 1 C7 B4H
283 3101051030020 Chip capacitor 0402 0.01UF 1 C8 B2J
284 3101051040060 Chip capacitor 0402 0.1UF 1 C178 T2B
285 3101051040060 Chip capacitor 0402 0.1UF 1 C209 T2E
286 3101051040060 Chip capacitor 0402 0.1UF 1 C210 T2E
287 3101051040060 Chip capacitor 0402 0.1UF 1 C233 B2F
288 3101051040060 Chip capacitor 0402 0.1UF 1 C245 B2I
289 3101051040060 Chip capacitor 0402 0.1UF 1 C37 B2I
290 3101051040060 Chip capacitor 0402 0.1UF 1 C38 B2H
291 3101051040060 Chip capacitor 0402 0.1UF 1 C39 B2G
292 3101051040060 Chip capacitor 0402 0.1UF 1 C40 T2F
293 3101051040060 Chip capacitor 0402 0.1UF 1 C43 B3H
294 3101051040060 Chip capacitor 0402 0.1UF 1 C44 B2I
295 3101051040060 Chip capacitor 0402 0.1UF 1 C45 B1I
296 3101051040060 Chip capacitor 0402 0.1UF 1 C46 B3H
297 3101051040060 Chip capacitor 0402 0.1UF 1 C50 T4G
298 3101051040060 Chip capacitor 0402 0.1UF 1 C51 B3B
299 3101051040060 Chip capacitor 0402 0.1UF 1 C64 T2F
300 3101051200020 Chip capacitor 0402 12PF 1 C186 B4H
301 3101051500020 Chip capacitor 0402 15PF 1 C100 B4G
302 3101051500020 Chip capacitor 0402 15PF 1 C107 B2F
303 3101051500020 Chip capacitor 0402 15PF 1 C98 B3D
304 3101051800010 Chip capacitor 0402 18PF 1 C104 B2D
305 3101051800010 Chip capacitor 0402 18PF 1 C119 B1F
306 3101051800010 Chip capacitor 0402 18PF 1 C182 B5G
307 3101051800010 Chip capacitor 0402 18PF 1 C187 B4H
308 3101051820000 Chip capacitor 0402 1800PF 1 C172 T5F
309 3101051830000 Chip capacitor 0402 0.018UF 1 C9 T5F
310 3101052000020 Chip capacitor 0402 20PF 1 C105 B2D
311 3101052000020 Chip capacitor 0402 20PF 1 C139 B2B
312 3101052200010 Chip capacitor 0402 22PF 1 C97 B4F
313 3101052210010 Chip capacitor 0402 220PF 1 C13 B2I
314 3101052210010 Chip capacitor 0402 220PF 1 C14 B2I
20
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
315 3101052210010 Chip capacitor 0402 220PF 1 C239 T5I
316 3101052230000 Chip capacitor 0402 0.022UF 1 C151 B2J
317 3101052230000 Chip capacitor 0402 0.022UF 1 C167 T5F
318 3101052230000 Chip capacitor 0402 0.022UF 1 C168 T4G
319 3101052230000 Chip capacitor 0402 0.022UF 1 C169 T4G
320 3101052230000 Chip capacitor 0402 0.022UF 1 C170 T1B
321 3101052230000 Chip capacitor 0402 0.022UF 1 C57 B2G
322 3101052700000 Chip capacitor 0402 27PF 1 C128 B4J
323 3101052700000 Chip capacitor 0402 27PF 1 C141 B2B
324 3101052700000 Chip capacitor 0402 27PF 1 C142 B2B
325 3101052700000 Chip capacitor 0402 27PF 1 C18 B1I
326 3101052700000 Chip capacitor 0402 27PF 1 C193 B5G
327 3101053300000 Chip capacitor 0402 33PF 1 C134 B1C
328 3101053300000 Chip capacitor 0402 33PF 1 C135 B3F
329 3101053300000 Chip capacitor 0402 33PF 1 C175 T2B
330 3101053300000 Chip capacitor 0402 33PF 1 C176 T3B
331 3101053300000 Chip capacitor 0402 33PF 1 C211 B3F
332 3101053300000 Chip capacitor 0402 33PF 1 C52 B2I
333 3101053300000 Chip capacitor 0402 33PF 1 C53 B2I
334 3101053300000 Chip capacitor 0402 33PF 1 C54 B2H
335 3101053300000 Chip capacitor 0402 33PF 1 C96 B4G
336 3101053310020 Chip capacitor 0402 330PF 1 C171 T5F
337 3101053320010 Chip capacitor 0402 3300PF 1 C166 T5F
338 3101053330000 Chip capacitor 0402 0.033UF 1 C150 B2I
339 3101053330000 Chip capacitor 0402 0.033UF 1 C152 B2I
340 3101053330000 Chip capacitor 0402 0.033UF 1 C153 B2I
341 3101053330000 Chip capacitor 0402 0.033UF 1 C156 B1I
342 3101053330000 Chip capacitor 0402 0.033UF 1 C160 B3G
343 3101053330000 Chip capacitor 0402 0.033UF 1 C161 T2C
344 3101053340000 Chip capacitor 0402 0.33UF 1 C126 B5J
345 3101053900000 Chip capacitor 0402 39PF 1 C56 B3F
346 3101053920000 Chip capacitor 0402 3900PF 1 C181 T2C
347 3101053930000 Chip capacitor 0402 0.039UF 1 C122 T2E
348 3101054700010 Chip capacitor 0402 47PF 1 C129 B4J
349 3101054700010 Chip capacitor 0402 47PF 1 C136 B2C
350 3101054710010 Chip capacitor 0402 470PF 1 C154 T2G
351 3101054710010 Chip capacitor 0402 470PF 1 C131 B4I
352 3101054710010 Chip capacitor 0402 470PF 1 C149 B4D
353 3101054710010 Chip capacitor 0402 470PF 1 C197 B3I
354 3101054710010 Chip capacitor 0402 470PF 1 C20 B2I
355 3101054710010 Chip capacitor 0402 470PF 1 C204 B3E
356 3101054710010 Chip capacitor 0402 470PF 1 C208 B2A
357 3101054710010 Chip capacitor 0402 470PF 1 C21 B4F
358 3101054710010 Chip capacitor 0402 470PF 1 C217 T2H
359 3101054710010 Chip capacitor 0402 470PF 1 C218 T1G
360 3101054710010 Chip capacitor 0402 470PF 1 C22 B4G
361 3101054710010 Chip capacitor 0402 470PF 1 C231 B5H
362 3101054710010 Chip capacitor 0402 470PF 1 C25 B4I
363 3101054710010 Chip capacitor 0402 470PF 1 C26 B4I
364 3101054710010 Chip capacitor 0402 470PF 1 C27 B3D
365 3101054710010 Chip capacitor 0402 470PF 1 C28 B2C
366 3101054710010 Chip capacitor 0402 470PF 1 C29 B3B
367 3101054710010 Chip capacitor 0402 470PF 1 C31 B4G
21
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
368 3101054710010 Chip capacitor 0402 470PF 1 C34 T5G
369 3101054710010 Chip capacitor 0402 470PF 1 C35 B2E
370 3101054710010 Chip capacitor 0402 470PF 1 C36 B2F
371 3101054710010 Chip capacitor 0402 470PF 1 C84 T2G
372 3101054730000 Chip capacitor 0402 0.047UF 1 C157 T5F
373 3101054730000 Chip capacitor 0402 0.047UF 1 C158 T4E
374 3101054730000 Chip capacitor 0402 0.047UF 1 C162 B3H
375 3101054730000 Chip capacitor 0402 0.047UF 1 C212 T3F
376 3101054740020 Chip capacitor 0402 470NF 1 C244 T3C
377 3101055600000 Chip capacitor 0402 56PF 1 C138 B3C
378 3101055610000 Chip capacitor 0402 560PF 1 C147 B2B
379 3101055610000 Chip capacitor 0402 560PF 1 C201 B5J
380 3101055620010 Chip capacitor 0402 5600PF 1 C47 B3G
381 3101056800000 Chip capacitor 0402 68PF 1 C88 B5F
382 3101058200000 Chip capacitor 0402 82PF 1 C58 B2H
383 3101058200000 Chip capacitor 0402 82PF 1 C89 B2B
384 3101058210010 Chip capacitor 0402 820PF 1 C232 T4F
385 3101060390000 Chip capacitor 0603 0.3PF 1 C92 B4H
386 3101060500010 Chip capacitor 0603 5PF 1 C94 B2F
387 3101061010010 Chip capacitor 0603 100PF 1 C19 B5H
388 3101061020000 Chip capacitor 0603 1000PF 1 C198 T4G
389 3101061020000 Chip capacitor 0603 1000PF 1 C235 B2A
390 3101061020000 Chip capacitor 0603 1000PF 1 C63 B5G
391 3101061020000 Chip capacitor 0603 1000PF 1 C72 B3G
392 3101061020000 Chip capacitor 0603 1000PF 1 R111 B2F
393 3101061030010 Chip capacitor 0603 0.01UF 1 C123 B5I
394 3101061030010 Chip capacitor 0603 0.01UF 1 C90 B5G
395 3101061040010 Chip capacitor 0603 0.1UF 1 C48 T4G
396 3101061040010 Chip capacitor 0603 0.1UF 1 C49 T4G
397 3101061500010 Chip capacitor 0603 15PF 1 C145 B1A
398 3101063330030 Chip capacitor 0603 0.033UF 1 R112 B3I
399 3101071020010 Chip capacitor 0805 1000PF 1 L36 B1E
400 3101071040000 Chip capacitor 0805 0.1UF 1 C194 T4H
401 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC1 B5G
402 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC2 B5H
403 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC3 B2D
404 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC4 B1E
405 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC5 B2F
406 3102992000040 Trimmer capacitor 3.2*2.5*1.25mm 1 TC6 B3I
407 3104071050010 Tantalum capacitor 0805 1UF 1 C200 T4E
408 3104071050010 Tantalum capacitor 0805 1UF 1 C85 B5D
409 3104071050010 Tantalum capacitor 0805 1UF 1 C86 B5F
410 3104071050010 Tantalum capacitor 0805 1UF 1 C87 B4D
411 3104081050000 Tantalum capacitor 1206 1UF 1 C174 T3F
412 3104081060080 Tantalum capacitor 1206 10UF 1 C1 B2I
413 3104081060080 Tantalum capacitor 1206 10UF 1 C118 T2E
414 3104081060080 Tantalum capacitor 1206 10UF 1 C125 B2E
415 3104081060080 Tantalum capacitor 1206 10UF 1 C155 B2J
416 3104081060080 Tantalum capacitor 1206 10UF 1 C159 B2I
417 3104081060080 Tantalum capacitor 1206 10UF 1 C234 T3E
418 3104081550020 Tantalum capacitor 1206 1.5UF 1 C124 B5I
419 3104081560020 Tantalum capacitor 1206 15UF 1 C115 B4H
420 3104081560020 Tantalum capacitor 1206 15UF 1 C177 T1D
22
TC-500 Service Manual
No. Material No. Description Qty. Ref.No. Address
421 3104082250030 Tantalum capacitor 1206 2.2UF 1 C165 T5F
422 3104084750030 Tantalum capacitor 1206 4.7UF 1 C117 B5I
423 3104084750030 Tantalum capacitor 1206 4.7UF 1 C120 B4D
424 3104084750030 Tantalum capacitor 1206 4.7UF 1 C173 T4F
425 3104086850000 Tantalum capacitor 1206 6.8UF◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
