Image preview - the first page of the document



>> Download AVR-134 documenatation <<

Text preview - extract from the document

                                    SAFETY PRECAUTIONS


WARNING
Before servicing this unit, familiarize yourself with the following precautions:

1. Many electrical and mechanical parts in this             exposed metal parts of the cabinet, such as
   chassis have special safety characteristics that         terminals, screw heads, and metal overlays, to
   often pass unnoticed and the protection                  be sure the set is safe to operate danger of
   afforded by them cannot necessarily be                   electrical shock. Plug the AC line cord directly
   obtained by using replacement components                 into a 120 V AC outlet(USA Version) or 230 V
   rated for higher voltage, wattage, etc.                  AC outlet(EU Version). (Do not use a line
   Replacement parts that have these special                isolation transformer during this check.) Be
   safety characteristics are identified in this            sure your AC voltmeter has a sensitivity of
   manual and its supplements: electrical                   5000  per volt or greater. Then connect a
   components having such features are identified           1500  10 watt resistor, paralleled by a 0.15
   by     in the schematic diagram and the parts
