Image preview - the first page of the document
DVD-2550S


>> Download DVD-2550S documenatation <<

Text preview - extract from the document
 harman/kardon                                                                 Service Sheet
DVD2550S                                                                                                                July 03



Model: DVD2550S
The DVD2550S is nearly identically with DVD25 the below part list and exploded view show the part there is difference.
For service manual see DVD25 SN> WA0001-23264
The main board for DVD2550 is not available, use the DVD25 V2 main board and then download the DVD2550S software
from the HCI-SERVICES.COM. or change U8 and U9 see part number below.




                                                                                               1

                                                                D
             2                  B             C

                          A


                                C
                 10
                                                                           E               4
                                                                                                   5
                                        3

                                              G
                                                                                   6
                                                                           9
                                                   F                           8                             H

                                                                                       7
      Pos             Part name                   Part Number        Pos           Part name             Part Number
       A    Power supply PCB 714C           WLD6.672.223              1    Top cover                   WLD8.404.014-4
       B    Output board 736C scart         WLD6.672.228              2    Rear Panel HB028-1          WLD8.610.030-4
       C    Main board 737C-1               WLD6.672.227-1            3    Foot SD005-1                WLD8.085.005-4
       D     Mechanism DVD-kit710           WLD5.018.024              4    Front Panel MB028-1         WLD6.116.033-4
       E     Front board 787C               WLD6.672.229              5    window Lens                 WLD7.370.004
       F     Front St-by board 787C-1       WLD6.672.229-1            6    Door SC010                  WLD8.082.021-4
       G     Front SW board 787C-2          WLD6.672.229-2            7    Button set                  WLD       .
       H     Remote control                 WLD2.018.059              8    Power button SA009          WLD8.337.024-4
      U8    HY29F800TG-90 U8                WLD5.HY29F8.2550.U8.V1    9    Harman / kardon badge       WLD8.809.002-4
      U9    HY29F800TG-90 U9                WLD5.HY29F8.2550.U9.V1   10    Chassis DZ025-1             WLD8.031.027-1


            Carton Box                      WLD8.865.066-4                 Owners Manual               WLD8.810.2550S



Harman International SNC - Harman Consumer International 2, route de Tours 72500 Ch
