Image preview - the first page of the document
HD-980 & 230 Rev 0


>> Download HD-980 & 230 Rev 0 documenatation <<

Text preview - extract from the document
harman/kardon                                                      HD 980/230 Service Manual




  harman/kardon                                         Service Manual

HD 980/230
CD Player




                                 CONTENTS

    BASIC SPECIFICATIONS              2       SEMICONDUCTOR PINOUTS                 16
    TROUBLESHOOTING GUIDE             3       PCB DRAWINGS                          30
    PACKAGE LIST AND PARTS            4       BLOCK DIAGRAM                         35
    EXPLODED VIEW                     5       VERSION HISTORY                       36
    PARTS LIST                        6       SCHEMATIC DIAGRAMS                    37




Released EU2009              Harman International              Rev 0, 09/2009
                             8500 Balboa Boulevard
                             Northridge, California 91329
                                                                                Page 1 of 46
harman/kardon                                                                                                             HD 980/230 Service Manual




   Technical Specifications

   Signal Format
   Sampling Frequency                                        32 kHz to 96 kHz
   D/A Conversion                                            Multibit Sigma-Delta modulator
   Oversampling                                              24-bit/176.4 kHz Sample Rate Convertor or
                                                             24-bit/96 kHz with HRS-Link, internal DAC.

   Discrete Analog Output Section
   Error Correction                                          CIRC System
   Frequency Response                                        20 Hz
