Image preview - the first page of the document
>> Download HS-300 & 500 documenatation <<
Text preview - extract from the document
harman/kardon service manual
HS 300/500 Home Cinema System
SERVICE MANUAL
CONTENTS
SERVICE INFO, MECHAS 2 UNIT EXPLODED VIEW AND PARTS 11
SERVICING PRECAUTIONS 3 PARTS LIST 12
ESD PRECAUTIONS 5 PINOUTS 69
BASIC SPECIFICATIONS 300 6 PCB DRAWINGS 85
BASIC SPECIFICATIONS 500 7 BLOCK DIAGRAM 93
TROUBLESHOOTING GUIDE 8 WIRING DIAGRAM 94
PACKING LIST AND VIEW 10 SCHEMATIC DIAGRAMS 95
Page 1 of 109
harman/kardon service manual
harman/kardon Service Info
HS 300/500 23 Aug 2007
To: All harman/kardon Service Centers
Models: HS 300/500
Subject: Hardware changes (2 changes, mecha and main board).
Please note that a change in hardware from Sanyo optics and mecha to Hitachi optics and
mecha has been carried out from the serial numbers stated below.
Model Start serial number End serial number Optic / mecha Part number
WA0020-01001 WA0020-03501 HD62 - DV342 (Sanyo) 01.15.JX.DV342
HOP1200W- DM3403-C
HS 300/230 WA0020-03502 - (Hitachi) 01.15.JX.EDM3403
WA0023-01001 WA0023-03500 HD62 - DV342 (Sanyo) 01.15.JX.DV342
HOP1200W- DM3403-C
HS 500/230 WA0023-03501 - (Hitachi) 01.15.JX.EDM3403
Due to the change of mecha, the main boards are also different. It is important to use the correct
main board for the loader, as the servo circuit has changed on the main board.
Model Start serial number End serial number Main board version Part number
WA0020-01001 WA0020-03501 Up to version 1.6 HAV06M1802C02*
HS 300/230 WA0020-03502 - From version 1.7 0211HAV06M3625C023
WA0023-01001 WA0023-03500 Up to version 1.6 HAV06M1802C02*
HS 500/230 WA0023-03501 - From version 1.7 0211HAV06M3625C025
* Please note that correct software according to model must be installed after change of main
board
Please note that there is no difference in playability or functionality between the Sanyo and Hitachi loaders.
Page 2 of 109
harman/kardon service manual
SERVICING PRECAUTIONS
NOTES REGARDING HANDLING OF THE PICK-UP
1. Notes for transport and storage
1) The pick-up should always be left in its conductive bag until immediately prior to use.
2) The pick-up should never be subjected to external pressure or impact.
Drop impact
Storage in conductive bag
2. Repair notes
1) The pick-up incorporates a strong magnet, and so should never be brought close to magnetic materials.
2) The pick-up should always be handled correctly and carefully, taking care to avoid external pressure and
impact. If it is subjected to strong pressure or impact, the result may be an operational malfunction
and/or damage to the printed-circuit board.
3) Each and every pick-up is already individually adjusted to a high degree of precision, and for that reason
the adjustment point and installation
screws should absolutely never be touched.
4) Laser beams may damage the eyes!
Absolutely never permit laser beams to enter the eyes!
Also NEVER switch ON the power to the laser output part (lens, etc.) of the pick-up if it is damaged.
NEVER look directly at the laser beam, and don't let contact
fingers or other exposed skin.
5) Cleaning the lens surface
If there is dust on the lens surface, the dust should be cleaned away by using an air bush (such as used
for camera lens). The lens is held by a delicate spring. When cleaning the lens surface, therefore, a cot-
ton swab should be used, taking care not to distort this.
Pressure
Magnet
Pressure
How to hold the pick-up
Cotton swab
Conductive Sheet
6) Never attempt to disassemble the pick-up.
Spring by excess pressure. If the lens is extremely dirty, apply isopropyl alcohol to the cotton swab. (Do
not use any other liquid cleaners, because they will damage the lens.) Take care not to use too much of
this alcohol on the swab, and do not allow the alcohol to get inside the pick-up.
Page 3 of 109
harman/kardon service manual
NOTES REGARDING COMPACT DISC PLAYER REPAIRS
1. Preparations
1) Compact disc players incorporate a great many ICs as well as the pick-up (laser diode). These compo-
nents are sensitive to, and easily affected by, static electricity. If such static electricity is high voltage,
components can be damaged, and for that reason components should be handled with care.
2) The pick-up is composed of many optical components and other high-precision components. Care must
be taken, therefore, to avoid repair or storage where the temperature of humidity is high, where strong
magnetism is present, or where there is excessive dust.
2. Notes for repair
1) Before replacing a component part, first disconnect the power supply lead wire from the unit
2) All equipment, measuring instruments and tools must be grounded.
3) The workbench should be covered with a conductive sheet and grounded.
When removing the laser pick-up from its conductive bag, do not place the pick-up on the bag. (This is
because there is the possibility of damage by static electricity.)
4) To prevent AC leakage, the metal part of the soldering iron should be grounded.
5) Workers should be grounded by an armband (1M)
6) Care should be taken not to permit the laser pick-up to come in contact with clothing, in order to prevent
static electricity changes in the clothing to escape from the armband.
7) The laser beam from the pick-up should NEVER be directly facing the eyes or bare skin.
Armband
Resistor
(1 Mohm)
Resistor
(1 Mohm) Conductive
Sheet
Page 4 of 109
harman/kardon service manual
ESD PRECAUTIONS
Electrostatically Sensitive Devices (ESD)
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components com-
monly are called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated cir-
cuits and some field-effect transistors and semiconductor chip components. The following techniques should
be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off
any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a
commercially available discharging wrist strap device, which should be removed for potential shock reasons
prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ESD devices, place the assembly on a conductive sur-
face such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ESD devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static"
can generate electrical charges sufficient to damage ESD devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESD
devices.
6. Do not remove a replacement ESD device from its protective package until immediately before you are
ready to install it. (Most replacement ESD devices are packaged with leads electrically shorted together by
conductive foam, aluminum foil or comparable conductive materials).
7. Immediately before removing the protective material from the leads of a replacement ESD device, touch the
protective material to the chassis or circuit assembly into which the device will by installed.
CAUTION : BE SURE NO POWER IS APPLIED TO THE CHASSIS OR CIRCUIT, AND OBSERVE ALL
OTHER SAFETY PRECAUTIONS.
8. Minimize bodily motions when handing unpackaged replacement ESD devices. (Otherwise harmless motion
such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can gen-
erate static electricity sufficient to damage an ESD device).
Page 5 of 109
harman/kardon service manual
HS 300 Controller Specifications
ENGLISH
DVD player
Pickup: Semiconductor laser, wavelength 650nm
Signal system: NTSC / PAL
Video signal horizontal resolution: More than 480 lines (DVD)
Video signal-to-noise ratio: More than 60 dB (DVD)
Audio frequency response: DVD (PCM): 20Hz ~ 22kHz (+/- 1.0dB)
(Stereo) CD (PCM): 20Hz ~ 20kHz (+/- 1.0dB)
Audio signal-to-noise ratio: More than 80 dB (PCM)
Total harmonic distortion:: Less than 0.01% (PCM)
Dynamic range: DVD (PCM): More than 85 dB (EIAJ, 2kHz)
CD: More than 85 dB (EIAJ)
FM Tuner
System: PLL quartz-locked digital synthesizer system
Tuning range: 87.50 ~ 108.00 MHz
Antenna terminals: 75 Ohms, unbalanced
Intermediate frequency: 10.7 MHz
Video Outputs HDMI:
Component Video Output: Y: 1 Vp-p/75 Ohms, sync negative polarity
Cr: 0.7 Vp-p/75 Ohms
Cb: 0.7 Vp-p/75 Ohms
CVBS Video: 1 Vp-p 75 Ohms
S-video: Y: 1 Vp-p 75 Ohms
C: PAL 0.3 Vp-p 75 Ohms / NTSC 0.286 Vp-p 75 Ohms
Audio line Outputs
Audio L/R: 2 Vrms, 1 kilohms
General
Power requirements: AC 230 V, 50 Hz
Max power consumption: 400 W
Idle power consumption: Less than 2 W
Dimensions (WxHxD): 440mm x 68mm x 380mm
Weight: 7.5 kg
* Designs and specifications are subject to change without notice.
Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon is a registered trademark of Harman International Industries, Incorporated.
Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories, registered in the United States and/or other countries. All rights reserved.
DTS is a trademark of Digital Theater Systems, Inc.
