Image preview - the first page of the document
>> Download HS-350 & 650 Rev 0 documenatation <<Text preview - extract from the document harman/kardon HS 350/650DL Service Manual
harman/kardon Service Manual
HS 350/230
Digital Lounge HS 650/230
Integrated Home Theater System controllers
CONTENTS
HS 350 TECHNICAL SPECIFICATIONS 2 HS 350 PACKAGE LIST AND PARTS 15
HS 350 TROUBLESHOOTING GUIDE 3 HS 650 PACKAGE LIST AND PARTS 16
HS 350 FRONT PANEL CONTROLS 5 EXPLODED VIEW AND PARTS 17
HS 350 FRONT PANEL DISPLAY 6 ELECTRICAL PARTS LIST 18
HS 350 REAR PANEL CONNECTIONS 7 SEMICONDUCTOR PINOUTS 33
HS 650 TECHNICAL SPECIFICATIONS 9 PCB DRAWINGS 47
HS 650 TROUBLESHOOTING GUIDE 10 BLOCK DIAGRAM 59
HS 650 FRONT PANEL CONTROLS 12 WIRING DIAGRAM 60
HS 650 FRONT PANEL DISPLAY 13 REVISION HISTORY 61
HS 650 REAR PANEL CONNECTIONS 14 SCHEMATIC DIAGRAMS 62-89
Released EU2008 harman/kardon, Inc. Rev 0, 10/2008
250 Crossways Park Dr.
Downloaded from www.Manualslib.com manuals search engine
Woodbury, New York, 11797 Page 1 of 89
harman/kardon HS 350/650DL Service Manual
HS 350 Controller Specifications
ENGLISH
DVD player
Pickup: Semiconductor laser, wavelength 650nm
Signal system: NTSC / PAL
Video signal horizontal resolution: More than 480 lines (DVD)
Video signal-to-noise ratio: More than 60 dB (DVD)
Audio frequency response: DVD (PCM): 20Hz ~ 22kHz (+/- 1.0dB)
(Stereo) CD (PCM): 20Hz ~ 20kHz (+/- 1.0dB)
Audio signal-to-noise ratio: More than 80 dB (PCM)
Total harmonic distortion:: Less than 0.01% (PCM)
Dynamic range: DVD (PCM): More than 85 dB (EIAJ, 2kHz)
CD: More than 85 dB (EIAJ)
FM Tuner
System: PLL quartz-locked digital synthesizer system
Tuning range: 87.50 ~ 108.00 MHz
Antenna terminals: 75 Ohms, unbalanced
Intermediate frequency: 10.7 MHz
Video Outputs HDMI:
Component Video Output: Y: 1 Vp-p/75 Ohms, sync negative polarity
Cr: 0.7 Vp-p/75 Ohms
Cb: 0.7 Vp-p/75 Ohms
CVBS Video: 1 Vp-p 75 Ohms
S-video: Y: 1 Vp-p 75 Ohms
C: PAL 0.3 Vp-p 75 Ohms / NTSC 0.286 Vp-p 75 Ohms
Audio line Outputs
Audio L/R: 2 Vrms, 1 kilohms
General
Power requirements: AC 100-240 V, 50/60 Hz
Max power consumption: 230W
Idle power consumption: Less than 2 W
Dimensions (WxHxD): 357mm x 105mm x 293mm
Weight: 7.5 kg
* Designs and specifications are subject to change without notice.
Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis.
All features and specifications are subject to change without notice.
Harman Kardon, The Bridge and Logic 7 are registered trademarks of Harman International Industries, Incorporated.
Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories, registered in the United States and/or other countries. All rights reserved.
DTS is a trademark of Digital Theater Systems, Inc.
