Image preview - the first page of the document
>> Download SB-10 documenatation <<
Text preview - extract from the document
harman/kardon SB 10 / 230V Service Manual
Harman/kardon Service Manual
SB 10/230
Passive Soundbar with active subwoofer
CONTENTS
INCLUDED ITEMS 2 SOUNDBAR PACKAGE LIST AND PARTS 10
SUBWOOFER REAR PANEL 3 SOUNDBAR EXPLODED VIEW / PARTS 11
CONNECTIONS 5 SUBWOOFER PACKAGE LIST AND PARTS 12
OPERATION 7 SUBWOOFER EXPLODED VIEW / PARTS 13
TROUBLESHOOTING 8 SUBWOOFER SCHEMATIC DIAGRAMS 14
SPECIFICATIONS 9
Released EU2010 Harman Consumer Group, Inc. Rev 0, 12/2010
8500 Balboa Boulevard
Northridge, California 91329
Page 1 of 16
harman/kardon SB 10 / 230V Service Manual
SB 10 Included Items
Included Items
One SB 10 three-channel soundbar speaker One combination LFE/trigger cable
One 8" (203mm) 200-watt subwoofer
Important: If anything is missing, or if any part of your SB 10 system fails to operate
properly, contact your dealer immediately.
Two wall-mount brackets for the SB 10 soundbar
Three speaker cables
5
Page 2 of 16
harman/kardon SB 10 / 230V Service Manual
SB 10 Subwoofer Rear-Panel Controls
Subwoofer Rear-Panel Connections
Subwoofer
Level Control
Bass Boost
Switch
Phase Switch
Power On Mode
Switch
External Trigger
Input Connector
Line-Level In
LFE Connector
Line-Level In
L/R Connectors
Power Switch
Power Cord
PL0004-01001
Phase Switch: This switch determines whether the subwoofer driver's piston-like action Line-Level In LFE Connector: This input bypasses the subwoofer's internal crossover
moves in and out in phase with the satellite speakers. If the subwoofer were to play out circuitry, so use it only with a receiver or processor subwoofer output that has been
of phase with the satellite speakers, the sound waves from the satellites could cancel out low-pass filtered. If your receiver or processor does not have a dedicated subwoofer
some of the sound waves from the subwoofers, reducing bass performance and sonic output that is low-pass filtered, you should use the subwoofer's Line-Level In L/R
impact. This phenomenon depends in part on the placement of all the speakers relative Connectors instead (see below).
to each other in the room.
Use the supplied LFE cable (the one with purple connectors) to connect the Line-Level In
Bass Boost Switch: Set this switch to "On" to enhance the subwoofer's low-frequency LFE Connector to the dedicated subwoofer output of a receiver or preamp/processor.
performance. Set this switch to "Off" for normal low-frequency performance.
Line-Level In L/R Connectors: These inputs pass through the subwoofer's built-in
Power-On Mode Switch: When this switch is set in the "Auto" position and when the crossover. Use them if your receiver or preamp/processor does not have a dedicated
Power Switch is set to "On," the subwoofer will automatically turn itself on when it subwoofer output that is low-pass filtered.
receives an audio signal and will enter the Standby mode when it has gone without
