Image preview - the first page of the document
![Hitachi_32PD5100_32PD5200_32PD5300_42PD5100_42PD5200_42PD5300_37PD5200_42PMA500E_55PMA550E_55PD5200_CMP4214E_[SM]](/pics/5c1c10638a5b8.gif)
>> Download Hitachi_32PD5100_32PD5200_32PD5300_42PD5100_42PD5200_42PD5300_37PD5200_42PMA500E_55PMA550E_55PD5200_CMP4214E_[SM] documenatation <<
Text preview - extract from the document
SM005
32PD5000/5100/5200/5300
42PD5000/5100/5200/5300
SERVICE MANUAL 37PD5200 42PMA500E
55PMA550E 55PD5200
CMP4214E
Caution
Be sure to read this manual before servicing. To assure safety from fire, electric shock, injury, harmful radiation
and materials, various measures are provided in this HITACHI Plasma display.
Be sure to read cautionary items described in the manual to maintain safety before servicing.
Service Warning
1. Since Panel Module and Front Filter are made of glass, handling the broken Module and Filter shall be
taken care sufficiently in order not to be injured.
2. Replacing work shall be started after the Panel Module and the AC/DC Power Supply become sufficiently
cool.
3. Special care shall be taken to the display area in order not to damage its surface.
4. The Panel Module shall not be touched with bare hand to protect its surface from stains.
5. It is recommended to use clean soft gloves during the replacing work in order to protect not only the
display area of the Panel Module but also a serviceman himself.
6. The Chip Tube of Panel Module (located upper left of the back and surrounded by frame) and flexible
cables connecting Panel glasses to drive circuit PWBs are very weak, so shall be taken care sufficiently
not to break. If you break Chip Tube, the Panel doesn't display anything forever.
Contents
1. Features --------------------------------------------------3 9. Basic circuit diagram--------------------------------- 48
2. Specifications--------------------------------------------5 10.Printed wiring board diagram ---------------------- 47
3. Service point ---------------------------------------------9 11.Block diagram ----------------------------------------- 53
4. Difference table ----------------------------------------10 12.Connection diagram --------------------------------- 55
5. New adoption technology----------------------------12 13.Wiring diagram ---------------------------------------- 56
6. Adjustment --------------------------------------------- 15 14.Disassembly diagram-------------------------------- 60
7. Troubleshooting --------------------------------------- 37 15.Mechanical Measurements-------------------------60
8. Self diagnosis function ------------------------------ 46
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Plasma Display
October 2003 Digital Media Division
32PD5000/42PD5000/42PMA500E/CMP4214E (PW1)
CAUTION FOR SAFETY
Please read this page before repair the monitor.
This page explains to following items for keep the safety of set and prevent to accident during
repair work.
We explain by symbol at happen the damage or injury when took wrong repair.
Warning This symbol means "possible to die or heavy damage"
Caution This symbol means "possible to damage or something will break"
We made the symbol as below, which are kind of following items.
This symbol means "CAUTION" This symbol means "MUST"
This symbol means "POSSIBLE to
This symbol means "DO NOT"
ELECTRIC SHOCK"
WARNING
Should be follows to instructions. Should be kept same style of wiring or component.
We indicates to cabinet, chassis and parts Monitor uses tubes or tapes, which made
by label, which are special attention part. by insulator, and some components are
Please follow to note and [Safety Instructions] keep distance from surface of PWB for
of User's Manual. safety.
Prevent the electric shock. Internal leads kept from hot part or high voltage
Please take care during working because part by clamper or styling, so please return to
monitor has high voltage part and power original condition for prevent to electric shock
supply part. or fire.
Possible to die if you tough to these place Should be done safety check after finished.
by miss take. Every part (removed screws, component
Please disconnect power plug during and wiring) should be returned to previous
overhaul, reassemble or change parts. condition.
You will die or take damage by electric Check around repair position for make
shock if you touch to live part. damage by miss take and measure the
Use recommended components. insulated impedance by meg-ohm meter.
Please use to same characteristic compo- Confirm the value of impedance, that
nent, which is same as previous for your value is more than 4M ohm.
safety and keep reliability especially marked It is reason for electric shock or fire if that
by in parts list and circuit diagram. value is less than 4M ohm.
It is reason of electric shock or fire if you Nobody can check and repair to the code
use non-recommended component. and combination circuit of HDCP.
Never remove the shield case, which is
assembled to the code and combination
circuit of HDCP.
2
32PD5000/42PD5000/42PMA500E/CMP4214E (PW1)
PRECAUTIONS
How to clean the plasma screen panel of the monitor
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the plasma screen face, do not knock or rub the surface with sharp or hard
objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not
enough, then use a cloth with mild detergent. Do not use harsh or abrasive cleaners.
How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral
detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax,
glass cleaner, etc. especially because they would cause discoloration, scratches or cracks.
1. Features
PW1 chassis
This chassis basically constitutes just a MONITOR to use with AVC (Audio Visual Control center). But it can con-
stitute AV MONITOR when applied the VIDEO board, and also a TV when applied the VIDEO board and the
TUNER board.
[Common Features]
Large-screen, high-definition plasma display panel
The 42-inch color plasma display panel, with a resolution of 1024 (H) x 1024(V) pixels, and the 32-inch color plasma
display panel with a resolution of 852(H) X 1024(V) pixels, creates a high-definition, large-screen (aspect ratio : 16:9)
and low-profile flat display. Free from electromagnetic interferences from geomagnetic sources and ambient power
lines, the panel produces high-quality display images free from color misconvergence and display distortion.
High Performance Digital Processor
A wide range of personal computer signals can be handled, from 640 x 400, 640 x 480 VGA to 1600 x 1200 UXGA.
Easy-to-use remote control and on screen display system
The remote control included eases the work of setting display controls. Further, the on-screen display system,
displays the status of signal reception and display control settings in an easy-to-view fashion.
Power saving system
The International ENERGY STAR power saver feature saves power consumption automatically when input sig-
nals are not available.
When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle.
TruBass
TruBass, SRS and ( ) symbol are trademarks of SRS Labs,Inc.
TruBass technology is incorporated under license from SRS Labs, Inc.
[AVC MONITOR model] 42/32PD5000
DVI-D terminal and 8pin-DIN terminal for AVC input
(Other terminals, buttons and remote control for use are all with the AVC unit.)
[AV MONITOR model] 42PD5100
One mini D-sub terminal and one DVI-D terminal for RGB input
The D-sub terminal can also receive the RGB-component by On-Screen Display control.
One composite/S.video input terminal and two component video input terminals added with VIDEO board
One component input is possible to switch to RGB signal input from the Menu screen.
One SCART terminal for the signal of the European standard added with VIDEO board
It operates as composite/S.video input and RGB input terminal, or composite video output terminal.
One composite video output terminal as a monitoring output added with VIDEO board
Simple type of the remote control
[TV model] 42/37/32PD5200
Various input/output terminals added with VIDEO board - same to above-mentioned feature of the AV MONI-
TOR model
Tuner and TELETEXT receiver added with TUNER board
High performance type of the remote control
3
37PD5200 (EU) (PW1)
PRECAUTIONS
How to clean the plasma screen panel of the monitor
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the plasma screen face, do not knock or rub the surface with sharp or hard
objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not
enough, then use a cloth with mild detergent. Do not use harsh or abrasive cleaners.
How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral
detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax,
glass cleaner, etc. especially because they would cause discoloration, scratches or cracks.
1. Features
PW1 chassis
This chassis basically constitutes just a MONITOR to use with AVC (Audio Visual Control center). But it can con-
stitute AV MONITOR when applied the VIDEO board, and also a TV when applied the VIDEO board and the
TUNER board.
[Common Features]
Large-screen, high-definition plasma display panel
The 37-inch color plasma display panel, with a resolution of 1024 (H) x 1024(V) pixels, creates a high-definition, large-
screen (aspect ratio : 16:9) and low-profile flat display. Free from electromagnetic interferences from geomagnetic
sources and ambient power lines, the panel produces high-quality display images free from color misconvergence
and display distortion.
High Performance Digital Processor
A wide range of personal computer signals can be handled, from 640 x 400, 640 x 480 VGA to 1600 x 1200 UXGA.
(RGB analog input)
Easy-to-use remote control and on screen display system
The remote control included eases the work of setting display controls. Further, the on-screen display system,
displays the status of signal reception and display control settings in an easy-to-view fashion.
Power saving system
The International ENERGY STAR power saver feature saves power consumption automatically when input sig-
nals are not available.
When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle.
TruBass
TruBass, SRS and ( ) symbol are trademarks of SRS Labs,Inc.
TruBass technology is incorporated under license from SRS Labs, Inc.
[AVC MONITOR model] 37PD5000
DVI-D terminal and 8pin-DIN terminal for AVC input
(Other terminals, buttons and remote control for use are all with the AVC unit.)
[TV model] 37PD5200
One mini D-sub terminal and one DVI-D terminal for RGB input.
The D-sub terminal can also receive the RGB-component by On-Screen Display control.
One composite/S.video input terminal and two component video input terminals added with VIDEO board.
One component input is possible to switch to RGB signal input from the Menu screen.
One SCART terminal for the signal of the European standard added with VIDEO board.
It operates as composite/S.video input and RGB input terminal, or composite video output terminal.
One composite video output terminal as a monitoring output added with VIDEO board.
Tuner and TELETEXT receiver added with TUNER board.
High performance type of the remote control
4
32PD5000/42PD5000/42PMA500E/CMP4214E (PW1)
2. Specifications
Display
Approx. 32 inches (716 (H) x 399 (V) mm, diagonal 820mm) Approx. 42 inches (922 (H) x 522 (V) mm, diagonal 1059mm)
Panel dimensions
Resolution 852 (H) x 1024 (V) pixels 1024 (H) x 1024 (V) pixels
Net dimensions
830 (W) x 506 (H) x 92 (D) mm 1030 (W) x 636 (H) x 91 (D) mm
(excluding Speakers/Stand)
Net weight
24.6kg 34.9kg
(excluding Speakers/Stand)
Ambient Temperature Operating : 5 C to 35 C, Storage : 0 C to 40 C
conditions Relative humidity Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply AC100 - 240V, 50/60Hz
Power consumption/at standby 255W / <3W 365W / <3W
Audio output 12W + 12W (6 )
(RGB input)
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
Input terminals
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Input signals 0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
Video signals
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
H/V separate, TTL level [2K ]
Sync signals H/V composite, TTL level [2K ]
Sync on green, 0.3 Vp-p [75 ]
(Video input)
AV1: composite video input terminal (RCA)
AV1: Y PB PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/G PB/B PR/R video input terminal (RCA)
Input terminals
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal (RCA)
Input signals AV3: L/R audio input terminal (RCA)
AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
AV1: PAL, SECAM, NTSC3.58, NTSC4.43
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: PAL, SECAM, NTSC3.58, NTSC4.43
Video signals AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
AV3: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: RGB
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
Video output Signal OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
AV4: composite video / L/R audio output terminal (SCART)
(RF input)
Input terminals ANT : 75 Unbalanced
Input signals PAL B, G, H / I / D, K
RF Video System SECAM B, G / D, K / K1
NTSC-M
Applicable video signals for each input terminal
Terminal RCA/SCART DVI D-sub
Signal CVBS S-video Component RGB PC STB RGB Component
AV1
AV2
AV3
AV4
RGB1
RGB2
( :Available)
5
37PD5200 (EU) (PW1)
2. Specifications
Display
Approx. 37 inches (814 (H) x 445 (V) mm, diagonal 930mm)
Panel dimensions
Resolution 1024 (H) x 1024 (V) pixels
Net dimensions
939 (W) x 573 (H) x 98 (D) mm
(excluding Speakers/Stand)
Net weight
29.0kg
(excluding Speakers/Stand)
Ambient Temperature Operating : 5 C to 35 C, Storage : 0 C to 40 C
conditions Relative humidity Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply AC100 - 240V, 50/60Hz
Power consumption/at standby 320W / <3W
Audio output 12W + 12W (6 )
(RGB input) - 37PD5000TE(*
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
Input terminals
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Input signals 0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
Video signals
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
H/V separate, TTL level [2K ]
Sync signals H/V composite, TTL level [2K ]
Sync on green, 0.3 Vp-p [75 ]
(Video input) - 37PD5000TE(*
AV1: composite video input terminal (RCA)
AV1: Y PB PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/G PB/B PR/R video input terminal (RCA)
Input terminals
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal (RCA)
Input signals AV3: L/R audio input terminal (RCA)
AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
AV1: PAL, SECAM, NTSC3.58, NTSC4.43
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: PAL, SECAM, NTSC3.58, NTSC4.43
Video signals AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
AV3: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: RGB
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
Video output Signal OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
AV4: composite video / L/R audio output terminal (SCART)
(RF input) - 37PD5000TE(*
Input terminals ANT : 75 Unbalanced
Input signals
PAL B, G, H / I / D, K
RF Video System
SECAM B, G / D, K / K1 / L, L'
*) 37PD5000TE:Refer to the Service Manual for 32/42PD3000(AV3000E).
Applicable video signals for each input terminal (37PD5000TE)
Terminal RCA/SCART DVI D-sub
Signal CVBS S-video Component RGB PC STB RGB Component
AV1
AV2
AV3
AV4
RGB1
RGB2
( :Available)
6
55PMA550/55HDM71
2. Specifications
00E 55HDM71
Applicable video signals for each input terminal
Terminal RCA/SCART DVI D-sub
Signal CVBS S-video Component RGB PC STB RGB Component
AV1
AV2
AV3
AV4
RGB1
RGB2
( :Available)
7
37PD5200 (EU) (PW1)
Component names
[Main unit]
Remote-control
receiver
Indicating lamp
MENU button
Main power switch
INPUT SELECT button
VOLUME (OK button)
UP/DOWN RECALL button
buttons ( SELECT button)
( ADJUST SIZE button
buttons) ( SELECT button)
SUB-POWER button
( ) indicates the function while the MENU is displayed on the screen.
[Remote control]
CLE-958 CLE-952A
(for 37PD5000TE) (for 37PD5000VE)
----- packed with
AV3000E
8
32PD5000/42PD5000/42PMA500E/CMP4214E (PW1)
3. Service points
Lead free solder
This product uses lead free solder (unleaded) to help preserve the environment. Please read these instructions
before attempting any soldering work.
Caution: Always wear safety glasses to prevent fumes or molten solder from getting into the eyes. Lead free
solder can splatter at high temperatures (600◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
