Image preview - the first page of the document
Hitachi_55PMA550_55HDM71_[SM]


>> Download Hitachi_55PMA550_55HDM71_[SM] documenatation <<

Text preview - extract from the document
                                                                                  YK                  No.006E-1
                                                                                            55PMA550
     SERVICE MANUAL                                                                         55HDM71
                                                                                                     (PW1)




                                                            Caution
Be sure to read this manual before servicing. To assure safety from fire, electric shock, injury, harmful radiation
and materials, various measures have been provided for in this HITACHI Plasma display service manual.
Be sure to read all cautionary items described in the manual to maintain safety before servicing.


                                                     Service Warning
1. Since the Panel Module and front Filter are made of glass, handle a broken Module and/or Filter with
   sufficient care, in order not to be injured.
2. Repair work should not be started until after the Panel Module and the AC/DC Power supply have cooled
   sufficiently.
3. Special care should be exercised in the proximity of the display area in order not to damage its surface.
4. The Panel Module should not be touched with bare hands, as this will protect its surface from stains.
5. It is recommended to use clean soft gloves during the repair work in order to protect not only the display
   area of the Panel Module but also the technician.
6. The Chip Tube of the Panel Module (located in the upper left corner of the back of the glass panel)
   is very fragile; as well, the flat cables connecting the Panel to the drive circuit PWBs are very weak. Take
   care not to damage these, otherwise, the panel will never light again..


                                                           Contents
1.   Features --------------------------------------------------3   8. Basic circuit diagram--------------------------------- 35
2.   Specifications--------------------------------------------4    9. Printed wiring board diagram ---------------------- 42
3.   Service point s -------------------------------------------5   10.Block diagram ----------------------------------------- 47
4.   Component names -------------------------------------6         11.Connection diagram --------------------------------- 49
5.   New Technology ----------------------------------------7       12.Wiring diagram -----------------------------------------50
6.   Service Modes ---------------------------------------- 10      13.Disassembly diagram-------------------------------- 52
7.   Troubleshooting --------------------------------------- 29     14.Replacement parts list------------------------------- 55
                                                                    15.DC Voltage Tables --------------------------------- 66



     SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.

                                          Plasma Display
                                   July 2004 Digital Media Division
                                        55PMA550/55HDM71 (PW1)


                                CAUTION FOR SAFETY
Please read this page before making repairs to the monitor.
This page explains certain safety items found in this manual which are intended to ensure the
safety of the technician and to prevent accidents during any repair work.



       Warning          This symbol means "Personnel Electrical Safety Hazard"


       Caution          This symbol means "Equipment Operational Hazard"




          This symbol means "CAUTION"                                     This symbol means "DO IT!"

          This symbol means "POSSIBILITY OF
                                                                          This symbol means "DON'T DO IT!"
          ELECTRIC SHOCK"




                                                   WARNING
  Special Instructions                                          Keep the same wiring dress for boards.
          This indicates cabinet, chassis or parts                       This monitor uses insulated spacers
          which require special attention.                               which are intended to isolate metal
          Please follow any notes as well as all safety                  parts from electrical components.
          precautions.
  Prevent electrical shock                                               Internal wiring is isolated from components by
          Please use care and caution when                               using clamps, retainers, etc., so please return
          servicing this product. High voltages                          to original condition for prevention of electrical
          exist in the set which can cause injury                        shock or fire.
          or death.                                             Safety check should be done after finished.
                                                                         Every part (removed screws, component
          Please disconnect the AC power                                 and wiring) should be returned to previous
          during repair to prevent serious shock                         condition.
          or death.                                                      Check around the repaired area for
                                                                         any damage by mistake. Measure the
  Use only recommended components.                                       insulated impedance of AC by ohm meter.
          Please use the same characteristic compo-                      Confirm that the value of impedance
          nents, which is same as previous for your                      is greater than 4M ohm.
          safety. To ensure reliability, specially marked                It is possible for electric shock or fire to
          parts ( ) should be OEM when replaced.                         occur if the value is less than 4M ohm.
          These parts are also safety related, so               Repair to the HDCP circuit is limited.
          electrical shock and/or fire could result
          from using generic parts.                                      Never remove the shield case, which is
                                                                         assembled to code with the HDCP circuit




                                                            2
                                           55PMA550/55HDM71 (PW1)


PRECAUTIONS
 How to clean the plasma panel screen (front glass) of the monitor -
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the plasma screen face, do not wipe the surface with sharp or hard
objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not
clean enough, then use a cloth with glass cleaner. Do not use any harsh or abrasive chemicals.
 How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral
detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax,
etc. because they could cause discoloration, scratches or cracks.

1. Features
 Large-screen, high-definition plasma display panel
The 55-inch color plasma display panel, with a resolution of 1366 (H) x 768(V) pixels, creates a high-definition, large-
screen (aspect ratio : 16:9) and low-profile flat display. Free from electromagnetic interferences from geomagnetic
sources and ambient power lines, the panel produces high-quality images free from any color misconvergence
or corner focus distortion.
 High Performance Digital Processor
A wide range of personal computer signals can be handled, from 640 x 400, 640 x 480 VGA to 1600 x 1200 UXGA.
                                                                                            (RGB analog input)
 Easy-to-use remote control and on-screen-display system (OSD)
The remote control included eases the setting of display controls. Furthermore, the on-screen-display (OSD),
displays the input status control settings in an easy-to-view fashion.
 Power saving system
The International ENERGY STAR power saver feature saves power consumption automatically when input sig-
nals are not available.
When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle.
 TruBass
TruBass, SRS and ( ) symbol are trademarks of SRS Labs,Inc.
TruBass technology is incorporated under license from SRS Labs, Inc.
 One mini D-sub terminal and one DVI-D terminal for RGB input.
 The D-sub terminal can also receive the RGB-component by On-Screen Display control.
 One composite/S.video input terminal and two component video input terminals added with VIDEO board.
 One component input is possible to switch to RGB signal input from the Menu screen.
 One SCART terminal for the signal of the European standard added with VIDEO board.
 It operates as composite/S.video input and RGB input terminal, or composite video output terminal.
 One composite video output terminal as a monitoring output added with VIDEO board.




                                                           3
                                                              55PMA550/55HDM71 (PW1)


2. Specifications
                                                                 55PMA550                                                             55HDM71
                Display
                                                                         Approx. 55 inches (1229 (H) x 691 (V) mm, diagonal 1410mm)
Panel           dimensions
                Resolution                                                                      1366 (H) x 768 (V) pixels
Net dimensions
                                                                                             1394 (W) x 857 (H) x 105 (D) mm
(excluding Speakers/Stand)
Net weight
                                                                    63.5kg                                                                 64.2kg
(excluding Speakers/Stand)
                Temperature                                                                       o        o               o     o
Ambient                                                                         Operating : 5 C to 35 C, Storage : 0 C to 40 C
conditions       Relative humidity                                     Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply                                                                                     AC100 - 240V, 50/60Hz
Power consumption/at standby                                                                          530W / <3W
Audio output                                                                      12W + 12W (6 ohm load), sub woofer terminal (RCA)
(RGB input)
                                                                                      RGB1 DVI input terminal (DVI-D)
                                                                              RGB1 audio input terminal (3.5mm Stereo Mini Jack)
                Input terminals
                                                                               RGB2 analog RGB input terminal (D-sub 15-pin)
                                                                              RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Input signals                                                                 0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
                Video signals
                                                                              480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
                                                                                             H/V composite, TTL level (2K )
                Sync signals                                                                 H/V separate, TTL level (2K )
                                                                                             Sync on green, 0.3 Vp-p (75 )

Recommended signal                                                                                     47 modes

(Video input)
                                                                                AV1: composite video input terminal (RCA)
                                                                                 AV1: Y PB PR video input terminal (RCA)
                                                                                    AV1: L/R audio input terminal (RCA)
                                                                                AV2: composite video input terminal (RCA)
                                                                             AV2: Y/G PB/B PR/R video input terminal (RCA)
                Input terminals
                                                                                    AV2: L/R audio input terminal (RCA)
                                                                                AV3: composite video input terminal (RCA)
                                                                                     AV3: S video input terminal (RCA)
Input signals                                                                       AV3: L/R audio input terminal (RCA)
                                                                    AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
                                                 AV1: PAL, SECAM, NTSC3.58, NTSC4.43                                AV1: NTSC-M, PAL-M, PAL-N
                                                                      AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
                                                 AV2: PAL, SECAM, NTSC3.58, NTSC4.43                                AV2: NTSC-M, PAL-M, PAL-N
                Video signals                                      AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
                                                 AV3: PAL, SECAM, NTSC3.58, NTSC4.43                                AV3: NTSC-M, PAL-M, PAL-N
                                                 AV4: PAL, SECAM, NTSC3.58, NTSC4.43                                AV4: NTSC-M, PAL-M, PAL-N
                                                                                             AV4: RGB
                                                                OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
Video output Signal                                                OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
                                                                  AV4: composite video / L/R audio monitor-output terminal (SCART)

Recommended signal                                                15 modes                                                                13 modes

The monitor takes at least 30 minutes to attain the status of optimal picture quality.




Applicable video signals for each input terminal
                         Terminal                           RCA/SCART                                          DVI                   D-sub
                           Signal         CVBS       S-video      Component          RGB              PC             STB       RGB    Component
                             AV1

                             AV2

                             AV3

                             AV4

                           RGB1

                           RGB2

                                                                                                                                      (    :Available)




                                                                                         4
                                         55PMA550/55HDM71 (PW1)


3. Service points
  Lead free solder
This product uses lead free solder (unleaded) to help preserve the environment. Please read these instructions
before attempting any soldering work.

 Caution: Always wear safety glasses to prevent fumes or molten solder from getting into the eyes. Lead free
          solder can splatter at high temperatures (600
