Image preview - the first page of the document
>> Download Hitachi Deskstar 120GXP Compatibility Summary v1.1 documenatation <<
Text preview - extract from the document
Compatibility summary
Hitachi Deskstar 120 GXP
Ultra ATA/100 hard disk drive
Models: IC35L020AVVN07 IC35L060AVVA07
IC35L020AVVA07 IC35L080AVVA07
IC35L040AVVN07 IC35L100AVVA07
IC35L040AVVA07 IC35L120AVVA07
Compatibility
The Storage Integration Lab thoroughly tested the Deskstar 120GXP drives for compatibility with a wide vari-
ety of systems, controller cards, and Operating Systems. Testing was to demonstrate compatibility with the
following hardware and software. Other combinations of hardware and software are expected to function
with this product family, but have not been tested.
Systems and System boards
HP KAYAK DRAGSTER K2
Systems:
HP KAYAK XU800
Apple Power Mac G4
HP VECTRA AIRWALK
COMPAQ iPAQ
HP VECTRA VL410
COMPAQ DeskPro EN6600
HP VECTRA VL600
COMPAQ Presario 5005R `Microwave 2'
HP VECTRA VE Cxxx series
COMPAQ Presario 7000 `Quicksilver'
IBM Aptiva 2142-S67
COMPAQ Presario 7001CL `Pipeline'
IBM Eserver `Storm'
COMPAQ Presario 7E13 `Elise'
IBM Intellistation Z Pro `Thor'
COMPAQ Workstation AP550
IBM NetVista A40p-6841
DELL Dimension 4100 `Zuul'
IBM NetVista A40p `Sands'
DELL Dimension 8100 / 8200
IBM NetVista `Razor'
DELL Optiplex GX110 `Jalapeno'
IBM NetVista `Unity'
DELL Optiplex GX150 `Skydive'
IBM PC300GL
DELL Optiplex GX1p/M+ (K2)
MICRON Millennia Max XP
DELL PowerApp 110 (Razor II)
DELL Poweredge 300 (Newt) System Boards:
DELL Precision WS 420 MT (Avalanche) ABIT KA7 / KA7 - RAID
Gateway E-4400 (Valhalla) ABIT KT7-RAID Highpoint
Gateway E-5400 (Hawaii) ABIT SE6
Gateway Essential 466c ABIT TH7 (RAID)
Gateway Performance 533 AOPEN AX34 Pro II
Gateway Profile 3 AOPEN AX37Plus
Gateway Select 1000 (Kodoka) AOPEN AX6C
Gateway Select 475 (Lucas) AOPEN AX63 Pro
Gateway Select 800 (Kodoka) AOPEN MX3W
HP Pavillion XE783 `Tortuga' ASUS A7A266
HP Pavillion XV799 `Alcatraz' ASUS A7V
HP Pavillion `Burmuda' ASUS CUC2
HP Pavillion `Cozumel' ASUS CUSL-2
HP Pavillion `Sonic' ASUS P4T
ASUS P5S-VM
Page 1 version 1.1
Hitachi Global Storage Technologies
BIOSTAR M6SBA
Chaintech 6LTM IDE `add-on' Controllers
DFI P5-BV3+
Adaptec AAA-Ultra (UDMA66 - RAID) (notes 7 & 8)
Elite K7S5A
3ware Escalade 3W-6200
Elite P5SS-Me
AMI Hyper Disk (Ultra ATA100)
EPoX EP-7KXA
Highpoint HPT 370
FIC AD11
IWill Side RAID 100 (note 7)
FIC PA-2013
Promise Ultra66 ATA Accelerator (note 3)
FIC SD11
Promise Ultra100 ATA (note 4)
Gateway GP6-450
Promise FastTrack100 (RAID) (note 7)
Gigabyte GA6W XM-e
Promise SuperTrack SX6000 (RAID) (note 7)
Gigabyte GA7IX / GA7ZX / GA8TX
Intel CA810E
Intel D850GB Operating systems
M-Tech MIG-R557
Microstar MS5169 DOS
Microstar MS6167 LINUX CALDERA 3.1 / REDHAT 7.1 / SUSE 7.0
Microstar MS6321 MAC OS 8.0 / 9.0 / 9.1 / X.1
Microstar MS8156Pro SCO UnixWare7 -- release 7.1.1
QDI LEGEND ADVANCE 5/133E WIN 95 (OSR2)
Soyo SY-6BA+100 Win 98 / SE
Soyo SY-61ZA Millennium
Supermicro PIIISWA Win NT4 (with SP6)
Supermicro P4DC6 WIN 2000 (with SP2) (notes 2, 5, & 6)
Supermicro P4STA
Tekram P5M4-M
Tyan S2380 Trinity K7 Master / Slave operation
Tyan THUNDERBOLT
The Deskstar 120GXP has been tested to the limits of
the ATA/ATAPI-6 Specification Master/Slave timings to
System board chipsets ensure compliance and correct functionality with all other
ATA/ATAPI-6 compliant devices, in both Master and
Ali Aladdin M1543 / Aladdin V Slave configurations.
Ali Magik 1
AMD-750 / 751 / 686A / 760
HPT-370 Drive capacity
Intel 430TX/440BX/440GX/440LX/440ZX
The following utilities available for download from the
Intel 810 / 810e / 815 / 820 / 820e / 840 / 850
Hitachi Global Storage Technologies Website have been
Intel 82801AA / 82801BA
successfully used to allow full access to
VIA KX133 / KT133 / KT133A / Pro133B / KT266 /
Deskstar 120GXP in systems that will not normally
PM266T
support drives of this capacity.
VIA Apollo MVP3 / VT586B / VT686A / VT686B
VIA Apollo MVP4 Disk Manager 2000
SiS 530 / 5513 / 620 / 645S / 730S / 735 DM9.5x - Ontrack
System board BIOS Hard Drive management Utilities
AMI The following third party utilities have been tested with
Apple the Deskstar 120GXP:
Award (note 1)
Compaq Ghost 2001 (Symantec)
HP (AMI) Partition Magic 5 (Power Quest) (note 9)
HP (Phoenix) Partition Magic 6 Pro (Power Quest)
Phoenix SMARTDefender (OnTrack)
Phoenix Plus
IBM Surepath
Page 2 version 1.1
Hitachi Global Storage Technologies
9. The size of partitions is limited to 64 GB using this
Third party certification version.
Microsoft Combined Logo / PC98 / PC99 Compliance
Certification is in progress for the Deskstar 120GXP.
