Image preview - the first page of the document
>> Download Hitachi Deskstar 7K80 II documenatation <<
Text preview - extract from the document
Verkrijgbaar bij: Grafi-Call Computers BV. Leiden
hitachi.com
Search by Google
| home | products | services | support | partners | about us | how to buy
Technical Library
General specifications Overview
Downloads
Warranty/RMA
Rebates & Promotions
Contact Support
80GB and 40GB | 7200 RPM | ATA 133 and Serial ATA 3.0Gb/s
High performance. Low cost-per-megabyte. 3.5-inch drives for the desktop and beyond.
Highlights:
q SATA 3.0 Gb/s and Native Command Queuing for maximum data speeds
q 80 GB and 40 GB capacities with either Serial ATA or Parallel ATA interface
q ECC and CRC protection within drive circuitry
q Low-power design reduces system costs and drives high reliability
q Quiet operating modes for easy integration into noise sensitive environments
Why Serial ATA 3.0Gb/s?
The newly approved SATA specification has standardized three important features:
> 3.0 Gb/s (300 MB/s) interface data rate
> NCQ (native command queuing)
> Staggered (delayed) spin-up
The 7K80 provides all of these enhancements to enable faster data access and better power management to the system.
The drive is also backward compatible for those wishing to upgrade their storage of SATA 1.0 systems.
A/V Streaming Feature Set
http://www.hitachigst.com/hdd/support/7k80/7k80_ov.htm (1 van 2)14-3-2006 15:47:04
Support | Deskstar 7K80 datasheet
Verkrijgbaar bij: Grafi-Call Computers BV. Leiden
The Deskstar 7K80 is the second generation Deskstar drive to enable the host system to optimize storage of data. This
is achieved by Hitachi's "Smooth Stream" technology which gives the host control over the drive's error recovery process.
This important ATA-7 Standards feature fine tunes the Deskstar to capture long audio or video data streams.
Applications Hitachi quality and service
> Traditional PCs The Hitachi Deskstar 7K80 extends the company's long-standing tradition of
> ATA servers performance leadership. Hitachi's standardized features in desktop solutions
> PC gaming enable fast transfer rates, low power utilization and quiet acoustics. These
> Video surveillance features combine to make the Deskstar 7K80 ideal not only for standard PC
> Disk to disk backup and systems but also for personal video recorders and other non-PC computing
recovery requirements.
> Media storage (DVR)
> Industrial automation Hitachi is dedicated to provide a breadth of hard disk drive solutions to satisfy
all of today's demanding computing needs.
