Image preview - the first page of the document
>> Download Deskstar 14GXP & 16GP Datasheet documenatation <<
Text preview - extract from the document
IBM DeskstarTM
Hard Disk Drive Family
Extending Leadership in Storage
Capacity and Performance
deskstar16GP deskstar14GXP deskstar16GP deskstar14GXP
Advanced Desktop Solutions for
Performance
Desktop Needs
Whether you use your desktop computer for audio and video editing,
computer-aided design and manufacturing (CAD/CAM), 3D graphics,
animation and photo manipulation, web page design, or data mining
and data warehousing--advanced desktop applications such as
these demand an advanced data storage solution. And, whether you
work at the office or at home, you need solutions and innovations
for desktop storage that provide the power, flexibility, and capacity
to perform a wide range of applications. Enter the IBM Deskstar
deskstar
16GP and 14GXP family of high performance, high capacity Ultra
ATA hard disk drives.
With our comprehensive Deskstar 16GP The Deskstar 16GP family, which offers
and 14GXP family of hard disk drives, capacities of 3.2 GB to 16.8 GB, provides
you can take advantage of our powerful one of the industry's highest storage capacities
performance and massive capacity-- for desktop systems. The Deskstar 14GXP
ranging from 3.2 gigabytes (GB) of storage family, with a capacity range from 10.1 GB
to more than 16 GB. With that kind of to 14.4 GB, represents one of the industry's
power and capacity, you can download first implementations of desktop disk drive
a web movie, or even two, install full technology running at a rotational speed
versions of storage-hungry application of 7200 RPM. The bottom line? These fast
programs, save those high-resolution speeds and high capacities translate directly
digital images, or store an entire data into higher quality video pictures, superior
warehouse. If you've got power performance CAD/CAM performance, extensive data
needs, the new IBM Deskstar 16GP or mining analysis, and significantly faster
14GXP hard disk drive is the drive for you. turnaround for the emerging wave of data-
intensive multimedia applications that are
quickly finding their way to the desktop.
The Capacity
to Really Perform
The Deskstar 16GP and 14GXP family technology to help meet the evolving increased areal density resulting in an
of hard disk drives from IBM gives you requirements of high-performance unprecedented 3.38 GB per disk.
a reliable data storage solution with the desktop users.
capacity and performance that your most No-IDTM sector formatting increases capacity
demanding desktop applications require. by helping to eliminate the overhead caused
We can help you maximize your produc- GMR Dramatically Increases by the duplicate storage of data sector ID
tivity and efficiency. We give you higher Capacity fields. For superior system performance,
capacity, faster performance, and greater These Deskstar products leverage IBM's we provide an Ultra ATA interface. In
reliability than has ever been available years of disk drive experience by building addition, Partial Response Maximum
before in one family of performance on our proven track record of providing Likelihood (PRML) digital data channel
desktop disk drives. the most reliable, highest performing, and delivers increased media-to-buffer and
r
highest quality in one family of performance buffer transfer rates. Perhaps, just as impor-
As the company that pioneered disk drive hard disk drives on the market today. Setting tant with our advanced technology, these
technology, IBM has long been acknowledged new standards once again, the Deskstar 16GP hard disk drives rank among the quietest
as one of the world's leading technology and 14GXP family represents IBM's first available and have low power consumption--
providers of data storage solutions. The implementation of Giant Magnetoresistive a key advantage for many of today's users.
latest example of this leadership is the (GMR) head technology that lets IBM pack
Deskstar 16GP and 14GXP family, which the most data into every square inch of the
sets new standards for today's data storage Deskstar's platters. GMR technology offers
Continuing Our High Capacity Data Protection
Leadership in areal density is what gives To help ensure data availability and help
Technology our Deskstar family its superior perfor- alert the system to potential drive failures,
Leadership mance and capacity. The Deskstar 16GP
family offers capacities of 3.2, 4.3, 6.4, and
8.4 GB, and the industry's first offering of
we provide S.M.A.R.T. (Self-Monitoring
Analysis and Reporting Technology) protocol
support across the Deskstar family.
in Data Storage 16.8 GB running at 5400 RPM. With a
maximum capacity of 3.38 GB per platter,
the Deskstar 16GP family packs significant Advanced Interface
amounts of data into a one-inch high disk The Deskstar 16GP and 14GXP family
drive. The Deskstar 14GXP offers capacities has an Ultra ATA interface and supports
of 10.1, 12.9, and 14.4 GB running at 7200 transfer rates of 33.3 MB/sec in Ultra DMA
RPM--giving users access to information Mode, and 16.6 MB/sec in Multi-word DMA
more quickly than ever before. Mode-2 and in PIO Mode-4. The family
also supports Logical Block Address (LBA)
and extended Cylinder Head Sector (CHS)
Superior Performance addressing modes.
The Deskstar 16GP and Deskstar 14GXP
family of disk drives offers average seek
times of 9.5 milliseconds, while the 16GP
family offers sustained data rates of up to
12 MB per second and the 14GXP offers
sustained data rates of up to 13 MB per
second. These high sustained data rates
can easily handle the large and complex
multimedia images used in today's video
applications.
IBM: A Partner You Can Count On
The Deskstar family of hard disk drives
offers you the capacity, performance, and
reliability you need to help satisfy your
Model Name Deskstar 14GXP Deskstar 16GP most advanced desktop computing needs.
DTTA-371440/ DTTA-351680/351290/ Our solutions provide you with a set of
371290/371010 351010/350840/350640/
Configuration 350430/ 350320
offerings with a proven track record and a
Interface ATA-4 ATA-4 migration path that can grow with you as
Device Capacity1 14.4/12.9/10. GB
1 16.8/12.9/10. /8.4/6.4/4.3/3.2 GB
1 your needs evolve. We also offer one of the
Sector Size 512 Bytes 512 Bytes
Recording Zones 8 8
industry's best customer service and support
User Cylinders 13,085 13,085 programs--all in keeping with our commit-
Data Heads 10/8/7 10/8/6/5/4/3/2 ment to excellence and innovation in the
Disks 5/5/4 5/4/3/3/2/2/1
Areal Density (Maximum) 2440 Mbits/sq.in 2687 Mbits/sq.in world of advanced data storage solutions.
Recording Density (Maximum) 178. KBPI
1 196.1 KBPI
Track Density 13,700 TPI 13,700 TPI
If you would like more information on
Performance
what an advanced hard disk drive storage
Data Buffer2 512 KB 512 KB
Rotational Speed 7200 RPM 5400 RPM solution from IBM can do for you, call us
Latency (Average) 4.17 ms 5.56 ms today at 1 800 IBM-7777 (1 416 383-5161)
Media Transfer Rate (Maximum) 175.6 Mbits/sec 163.7 Mbits/sec
Interface Transfer Rate (Maximum AT) 33.3 MB/sec 33.3 MB/sec
or fax us at 1 905 316-4733 outside of
Ultra DMA Mode-2 Ultra DMA Mode-2 North America and ask for Dept. Star 30.
16.6 MB/sec PIO Mode-4, 16.6 MB/sec PIO Mode-4, Or check out our Website at
MW DMA Mode-2 MW DMA Mode-2
Sustained Data Transfer Rate 13(Max)-8(Min) MB/sec 12(Max)-6(Min) MB/sec www.ibm.com/storage
Seek Time (Typical Read)
Average 9.5 ms 9.5 ms
Track-to-Track 2.2 ms 2.2 ms
Full Track 15.5 ms 15.5 ms
Reliability
Error Rates (Non-recoverable) < 1 per 10E13 bits < 1 per 10E13 bits
Contact Start Stop (below 40◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
