Image preview - the first page of the document
>> Download IBM Deskstar 75GXP and 40GV documenatation <<
Text preview - extract from the document
Redefining state-of-the-art for desktop storage
IBM Deskstar 75GXP and Deskstar 40GV
hard disk drives
Leading drive technology IBM Deskstar drives utilize proven IBM
The IBM Deskstar 75GXP and Deskstar technologies such as TrueTrack* servo
Highlights 40GV disk drives combine the perfor- and No-ID* sector formatting. IBM
mance and capacity to handle a wide Drive Fitness Technologies, a set of
The IBM Deskstar* 75GXP com- range of advanced desktop and audio/ diagnostic tools, include award-
bines industry-leading perfor- video applications. The IBM Deskstar winning Drive Fitness Test* (DFT),
mance at 7200 RPM with internal 75GXP incorporates innovative new tech- S.M.A.R.T Self Test, and error logging.
.
transfer rates of 444 Mbits/sec nologies to greatly enhance system per-
and average seek times of 8.5 ms formance--delivering an internal transfer
to enable a sustained data rate that tops the industry average by Advanced desktop systems
transfer rate of up to 37 MB/sec. 27 percent. Glass media, differential With these new drives, IBM has
Capacities range from 75 to 15 GB. preamplifier, and fifth-generation GMR redefined state-of-the-art for storage.
heads enable this level of performance The fast speeds and high capacities of
The IBM Deskstar 40GV balances by increasing track capacity an average IBM Deskstar drives translate into
capacity, performance, and price of 41 percent. A thermal monitor helps higher quality digital audio and video,
with one and two disks, 5400 RPM, ensure data reliability at this high rate. superior digital content creation
and an average seek time of 9.5 capabilities, and significantly faster
ms in capacities of 40 to 20 GB. The industry's greatest areal densities processing for data-intensive multime-
provide popular capacity points while dia and Internet applications.
A safety ramp feature virtually reducing the number of components
eliminates damage to the data and increasing reliability. The first desktop
area caused by drive mishandling drive with the IBM safety ramp feature IBM quality and service
before installation. (head load/unload capability) helps IBM drives are backed by an array of
protect data by moving the heads off the technical support and services, which
A thermal monitor protects data media surface when powering down. In may include customer and integration
writes/reads over the full system addition, a laminated top cover and assistance.1
temperature range. ceramic spindle bearings reduce drive
acoustics by up to 7 dB.
Tagged command queuing and
hardware caching boost sus-
tained data rates to reduce wait
times.
An ATA-compatible drive inter-
face enables data transfers to
100 MB/sec.
IBM Deskstar 75GXP 3.5-inch 7200 RPM IBM Deskstar 40GV 3.5-inch 5400 RPM
75, 60, 45, 30, 20, and 15 GB ATA disk drive 40, 30, and 20 GB ATA disk drive
IBM Deskstar 75GXP and Deskstar 40GV at a glance For more information
Model Deskstar 75GXP Deskstar 40GV Internet and e-mail:
