Image preview - the first page of the document
>> Download Repairing-Screen-2921 documenatation <<
Text preview - extract from the document
Repairing IBM ThinkPad T41 Screen
Repairing IBM ThinkPad T41 Screen
Tools used in this guide
Small Phillips Screw Driver
Spudger
Step 1 - Keyboard
Close the screen and turn the closed laptop over.
Remove all 17 screws on the bottom of the computer.
The multiple colors (turquoise, red, blue,
orange, yellow, and purple) are for
organizational purposes, indicating different
screws.
Your computer may have more if it still has its optical
device, HDD, or battery. The yellow markers are the
location of at least two extra screws that we don't have.
Step 2
Remove the extra RAM cover, by lifting where the
screw was and pulling out.
